Nordictrack c950i user manual

Nordictrack 950i manual. Nordictrack c950i specs. Nordictrack c950i manual. Nordictrack c950i disassembly. Nordictrack c 950 pro treadmill manual. Nordictrack c950 pro manual.

Page 1 of manual for NORDICTRACK C 950I treadmill, Model No. 831.25044.0. User is advised to register their product on www.nordictrackservice.com/registration to activate warranty and seek customer care at www.nordictrackservice.com. Treadmill's Bluetooth SIG and IOS features are used under license. Treadmill has model number and serial number, which should be noted for reference and service purposes. 9. Place the console assembly near the Pulse Crossbar and connect the pulse wires to it, as shown in the inset drawing on page 14. 10. Insert the Upright Wire into the looped ties on the console assembly, then connect it to the console wire; the connectors should fit together smoothly and snap into place, as described on page 15. 12. Identify the Right and Left Trays and attach them to the Console Base with eight #8 x 1/2" Screws; be sure not to overtighten the screws, as mentioned on page 16. 13. Carefully position the Upright Crossbar between the Left and Right Uprights, then secure it with four 5/16" screws, following the instructions on page 17. 14. Place the Right Handrail Cover onto the right Handrail, starting two #8 x 3/4" Truss Head Screws into the bottom of the cover; do not fully tighten the screws yet, as instructed on page 18. 15. Remove the 5/16" Nut and Bolt from the bracket on the Base, then orient the Storage Latch and attach its lower end to the bracket with a 5/16" x 1 3/4" bolt; this should be done according to the diagram on page 19. 17. Firmly tighten the specified screws – four 3/8" x 2 1/4", two 3/8" x 1 3/4", and two 3/8" x 1 1/4" – and attach the Left Inner Base Cover to the lower end of the Left Upright, as detailed on page 20. 1. To turn on the power, refer to page 21. 2. For a custom-focus weight loss workout, follow step 6 on page 22. 3. Connect your smart device via Bluetooth to the console, as shown on page 25. 4. Adjust the cushioning system by plugging in an audio cable and placing the treadmill in storage position, as described on page 27. 5. To fold and move the treadmill, adjust the incline to zero and then follow the instructions on page 28. 6. Perform regular maintenance by checking the power switch and tightening all parts each time the treadmill is used, as mentioned on page 29. 7. If the walking belt slips or the tablet holder does not stay in place, refer to page 30 for troubleshooting instructions. 8. To burn fat effectively, exercise at a low intensity level for a sustained period, as advised before starting any exercise program on page 32. 9. For suggested stretches, follow the correct form shown on page 33. Component list: * Unused #8 x 1/2" screw * Unused #8 x 3/4" screw * 5/16" x 2 1/4" bolt storage latch * 5/16" x 3/4" screw drive motor assembly Page 35 key components: * Controller clamp fan screw * Incline leg bushing * Tablet holder * Incline leg washer * Left speaker grill * Left inner base cover * Right speaker grill * Right inner base cover * Speaker unit * #8 x 1" tek screw * Left speaker cover * Base pad * Right speaker cover Explosions drawing references: * Model No. 831.25044.0 R0915A, page 35-39 * Pages 37-39 contain exploded drawings A-D for the same model. Replacement parts ordering process: To order replacement parts, refer to the front cover of this manual. When contacting us, be prepared to provide: Model number and serial number of the product (located on the front cover) Other required information (to be specified).
