HP Smart Tank 500 All-in-One

Datasheet HP Smart Tank 500 All-in-One The ultimate in printing freedom This high-capacity ink tank printer delivers uncompromising quality and helps reduce interruptions. Get high- volume printing at a low cost – up to 8,000 color pages or up to 6,000 black pages. Entrepreneurs and families looking for a hassle-free, low-cost, low-intervention printing solution with the freedom to print whatever, whenever.

Latest technology delivers outstanding quality Count on dark, crisp text, and get vibrant color graphics for all your prints. Print fade-resistant photos that last. Create borderless brochures, flyers, photos, and other documents that look great

right in your office.

Easy productivity Print documents quickly – get up to 38% faster speeds compared to previous HP Smart Tank. Get the features you need for work and other tasks with copy and scan functions. High-volume, low-cost printing – innovative design Easily monitor and maintain ink levels with an integrated tank design and an automatic ink sensor. Easily refill your ink tank system with spill-free, resealable bottles. Get up to 8,000 color pages or up to 6,000 black pages. For more information, see hp.com/go/printpermanence. Compared with HP Smart Tank/Ink Tank All-in-One Printer series. Excludes first set of ISO test pages. For details, see hp.com/go/printerclaims. When used in accordance with set up instructions. Black and composite color average per bottle (cyan/magenta/yellow) Results based on HP methodology and continuous printing of ISO/IEC 24712 test pages. Not based on ISO/IEC 24711 test process. An additional black ink bottle is required to print 8000 color test pages. Actual yield varies based on content of printed pages and other factors. Some ink from included bottles is used to start up the printer. For more information about fill and yield, see: www.hp.com/go/learnaboutsupplies. 4 1 2 3 4 1 2 3 4

Data sheet | HP Smart Tank 500 All-in-One HP Smart Tank 500 All-in-One Technical specifications Functions Print, copy, scan Multitasking supported No Print speed Black (ISO): Up to 11 ppm; Color (ISO): Up to 5 ppm; First page out black: As fast as 14 sec; First Page Out Color: As fast as 21 sec; Draft black (A4): Up to 22 ppm; Draft color (A4): Up to 16 ppm Print resolution Black (best): Up to 1200 x 1200 rendered dpi; Color (best): Up to 4800 x 1200 optimized dpi color when printing from a computer and 1200 input dpi Print technology HP Thermal Inkjet Print cartridges number 4 (1 each black bottle, set of 3 color bottles) Borderless printing Yes (up to 8.5 x 11 in, 210 x 297 mm) Standard print languages

Hp Pcl 3 Gui

Scan type / Scan technology Flatbed / Contact Image Sensor (CIS) Scan resolution Hardware: Up to 1200 x 1200 dpi; Optical: Up to 1200 dpi Scan file format

Jpg, Bmp, Tiff, Pdf, Rtf, Txt, Png

Scan input modes Front Panel Scan; Copy; HP Software Scan size maximum Flatbed: 216 x 297 mm Bit depth / Grayscale levels 24-bit/256 Copy speed Black (ISO): Up to 10 cpm; Color (ISO): Up to 2 cpm Copy resolution Black (text and graphics): Up to 300 dpi; Up to 300 dpi; Color (text and graphics): Up to 300 dpi Maximum number of copies Up to 99 copies Copier settings Number of Copies, Resize, Quality, Lighter/Darker, Papersize, Papertype, ID Copy, Enhancement Fax Features Fax phone TAM interface supported: No; Remote retrieval capability supported: No Standard connectivity Hi-Speed USB 2.0 Wireless capability No Mobile printing capability USB Only Memory Standard: 256 MB; Integrated memory; Maximum: 256 MB Processor speed 800 MHz Duty cycle Monthly, A4: Up to 1000 pages Recommended monthly page volume 400 to 800 Media types supported Plain Paper, HP Photo Papers, HP Matte Brochure or Professional Paper, HP Matte Presentation Paper, HP Glossy Brochure or Professional Paper, Other Photo Inkjet Papers, Other Matte Inkjet Papers, Other Glossy Inkjet Papers, Inkjet Hagaki, Plain Paper, Thick, HP Tri-fold Brochure Paper, Glossy, Plain Paper, Light/Recycled Media weight supported Plain paper: 60 to 90 g/m²; Envelopes: 75 to 90 g/m²; Cards: up to 200 g/m²; Photo paper: up to 300 g/m² Media sizes supported A4; B5; A6; DL envelope, legal Media Sizes Custom 76.2 x 127 mm to 215.9 x 355.6 mm Paper handling Input Capacities: Up to 100 sheets Standard; Up to 10 envelopes; Up to 30 cards; Up to 10 sheets Labels; Up to 100 sheets Legal Output Capacities: Up to 30 sheets Standard; Up to 10 envelopes; Up to 30 cards; Up to 10 sheets Labels; Up to 30 sheets Legal Duplex Options: Manual (driver support provided) Envelope feeder: No Standard paper trays: 1 What's in the box 4SR29A HP Smart Tank 500 All-in-One; HP GT53XL Black Original Ink Bottle; HP GT52 Cyan Original Ink Bottle; HP GT52 Magenta Original Ink Bottle; HP GT52 Yellow Original Ink Bottle; Ink caution flyer; Setup guide; Reference guide; Regulatory flyer; Warranty card, Power cord; USB Cable [For more information about fill and yield, see http://www.hp.com/go/learnaboutsupplies] Replacement cartridges HP GT53 90-ml Black Original Ink Bottle 1VV22AL; HP GT52 Cyan Original Ink Bottle M0H54AL; HP GT52 Magenta Original Ink Bottle M0H55AL; HP GT52 Yellow Original Ink Bottle M0H56AL; HP GT52 3-pack Cyan/Magenta/Yellow Original Ink Bottles X4E44AL; HP GT51 Black Original Ink Bottle M0H57AL Product dimensions W x d x h: 447 x 373 x 158 mm; Maximum: 449 x 605.65 x 258.7 mm Product weight 5.14kg Warranty features One year of 24/7 world-class technical support services through http://www.hp.com/support; One-year or 30,000 pages limited hardware warranty, whichever is earlier from the date of purchase; user replaceable parts have separate warranty periods Energy star certified Yes Control panel 3 LEDs and 6 buttons (cancel, resume, color copy, black copy, info, power button), one ICON LCD for display Display description 7 segment + 2-inch icon display Software included HP Printer Software, available online Compatible operating systems Windows 11; Windows 10; Windows 7; macOS 10.11 El Capitan; macOS 10.12 Sierra; macOS 10.13 High Sierra; macOS 10.14 Mojave Compatible network operating systems Windows 11 Minimum system requirements PC: Windows 10, 7: 1 GHz 32-bit (x86) or 64-bit (x64) processor, 2 GB available hard disk space, Internet connection, USB port, Internet Explorer 8.; Mac: macOS Sierra v10.12 (previously OS X), macOS High Sierra v10.13, macOS Mojave v10.14, 1 GB HD; Internet; USB Power Power supply type: Internal built in; Power requirements: Input voltage 100 to 240 VAC (+/- 10%), 50/60 Hz (+/- 3 Hz). High voltage: Input voltage 200 to 240 VAC (+/- 10%), 50/60 Hz (+/- 3Hz). Not dual voltage, power supply varies by part number with # Option code identifier.; Power consumption: 0.11 watts (manual- off), 3.17 watts (ready), 0.75 watts (sleep) Acoustics Acoustic power emissions: 6.5 B(A); Acoustic pressure emissions: 51 dBA Operating environment Operating temperature range: 5 to 40°C; Recommended operating temperature: 15 to 30°C; Storage temperature range: -40 to 60°C; Non-operating humidity range: 5 to 90% RH (non-condensing); Operating humidity range: 15 to 80% RH (non- condensing); Recommended humidity operating range: 20 to 80% RH HP Service and Support options With services, software, solutions and support from HP Total Care, you can use, protect and enjoy your HP technology; one-year technical support; one-year or 30,000 pages limited hardware warranty, whichever is earlier from the date of purchase; user replaceable parts have separate warranty periods; access to 24/7 world-class support services through http://www.hp.com/support; to improve your product experience, please take the time to register at http://www.register.hp.com. CHINA ONLY WARRANTY STATEMENT: With services, software, solutions and support from HP Total Care, you can use, protect and enjoy your HP technology; one-year technical support; one-year limited hardware warranty; user replaceable parts have separate warranty periods; access to 24/7 world-class support services through http://www.hp.com/support; to improve your product experience, please take the time to register at http://www.register.hp.com Learn more at hp.com Dimensions vary as per configuration Power requirements are based on the country/region where the printer is sold. Do not convert operating voltages. This will damage the printer and void the product warranty. Wireless performance is dependent upon physical environment and distance from the access point. Wireless operations are compatible with 2.4 GHz routers only; excludes wireless direct. Wireless direct may require driver or apps be installed and connected on wireless-enabled mobile device or PC. Wireless functionality may vary by computer and mobile operating systems, see http://hpconnected.com. Print times and connection speeds may vary. AirPrint™ supports macOS Mojave, iOS 4.2 or later and requires the printer be connected to the same network as your macOS or iOS device. AirPrint, the AirPrint Logo and macOS are trademarks of Apple Inc. Windows is a trademark of the Microsoft group of companies. Speed specifications have been updated to reflect current industry testing methods. ISO speeds measured using ISO/IEC 24734, ISO/IEC 17629 or ISO/IEC 29183. In simplex mode. Excludes first page or first set of ISO test pages for PPM measurements. For details see: http://www.hp.com/go/printerclaims. Exact speed varies depending on the system configuration, software application, driver, and document complexity. Average based on ISO/IEC 24711 or HP testing methodology and continuous printing. Actual yield varies considerably based on content of printed pages and other factors. For details see http://hp.com/go/learnaboutsupplies For details see: http://www.hp.com/go/printerclaims © Copyright 2022 HP Development Company, L.P. The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
