Samsung Dc68 02347b 05 manual
Dryers · 20 Q&As

Samsung Dc68 02347b 05

Ask about this product

Ask AI

— answers from the official manual

Answers from the official manual.

Common questions

Common Questions

20 total
1

What should I do if my dryer displays a heater temperature control problem code?

If your dryer displays a heater temperature control problem code, you should call for service at 1-800-726-7864 (1-800-SAMSUNG). This code indicates an issue that cannot be resolved by the user and requires a qualified technician. For any codes not listed in the manual, Samsung customer service should also be contacted at the same number. (Page E-2)

2

How often should I clean the lint filter?

You should clean the lint filter after each load. Cleaning it regularly shortens drying time and helps the dryer operate more energy efficiently. The manual also warns that you should never operate your dryer without the lint filter in place. (Page B-6)

3

What are the electrical requirements for installing this dryer?

The dryer requires a 120/240 volt, 60 Hz AC approved electrical service fused through a 30-ampere fuse or circuit breaker on both sides of the line. The power cord should be plugged into a 30-ampere receptacle, and the use of an extension cord is not permitted. The dryer must also be properly grounded in accordance with local codes. (Page A-5)

4

What should I do if I detect a gas smell near my dryer?

Immediately clear the room or area and evacuate all occupants. Do not operate electrical switches, light matches, or attempt to ignite pilot lights. Contact your utility company from a neighbor's phone using their landline.

5

How do I safely clean foam rubber items in the dryer?

Do not use heat settings on the dryer when drying foam rubber, plastic, or rubber items. Instead, use only the Air Fluff cycle to minimize fire hazards (page B-6).

6

How often should I clean my dryer's exhaust system?

The interior of the exhaust system and ductwork should be inspected and cleaned annually as clogged or crushed venting can seriously restrict airflow, increasing drying times and creating fire hazards (page A-3).

Show 14 more questions

How do I set up door reversal on my dryer?

What are some common items I should not dry in my dryer?

How do I know if my dryer is properly grounded?

What should I do if my laundry doesn't dry properly?

What type of exhaust duct should I use for installation?

How do I activate the Child Lock feature?

What are the dryer's dimensions and weight?

How do I set Child Lock on my dryer control panel?

What materials can I use for my exhaust duct?

How do I clean the lint filter?

What should I do if my dryer shuts off before the load is dry?

Can I dry items that have been soaked in cooking oil or vegetable oil?

What is the Wrinkle Prevent feature and how does it work?

What is covered under the Samsung dryer's limited warranty?

Full Manual

27 pages
Page 1
Samsung Dc68 02347b 05 manual — page 1

Electric Dryer Owner’s Manual Register your product at www.samsung.com/global/register Code No.: DC68-02347B-EN

Page 2
Samsung Dc68 02347b 05 manual — page 2

2 SAMSUNG Dryer Owner’s Instructions Safety Precautions Congratulations on your new Samsung Dryer. This manual contains valuable information on the installation, use, and care of your appliance. Please take the time to read this manual to take full advantage of your dryer’s many benefits and features. What you need to know about Safety Instructions Warnings and Important Safety Instructions in this manual do not cover all possible conditions and situations that may occur. It is your responsibility to use common sense, caution, and care when installing, maintaining, or operating your dryer. Always contact your manufacturer about problems or conditions you do not understand.

Recognize Safety Symbols, Words, Labels

WARNING – Hazards or unsafe practices that COULD result in severe personal injury or death.

Caution –

Hazards or unsafe practices that COULD result in minor personal injury or property damage. WARNING – Follow the information in this manual to minimize the risk of fire or explosion or to prevent property damage, personal injury, or death. Do not store or use gasoline or other flammable vapors and liquids near this or any other appliance.

What To Do If You Smell Gas:

• Do not try to light any appliance. • Do not turn on the appliance. • Do not touch any electrical switch. • Do not use any phone in your building. • Clear the room, building or area of all occupants. • Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions. • If you cannot reach your gas supplier, call the fire department. Installation and service must be performed by a qualified installer, service agency, or the gas supplier. WARNING – To reduce the risk of fire, explosion, electric shock, or personal injury when using your dryer, follow the basic safety precautions below:
  • Read all instructions before using your appliance.
  • To avoid the possibility of fire or explosion:
    • a. Do not dry items that have been previously cleaned, washed, soaked, or spotted with gasoline, dry cleaning solvents, or other flammable or explosive substances. They emit vapors that could ignite or explode. Any material that has been in contact with a cleaning solvent or flammable liquids or solids should not be placed in the dryer until all traces of these flammable liquids or solids and their fumes have been removed. There are many highly flammable items used in homes, such as acetone, denatured alcohol, gasoline, kerosene, some liquid household cleaners, some spot removers, turpentine, waxes, and wax removers. b. Items containing foam rubber (may be labeled latex foam) or similarly textured rubber-like materials must not be dried on a heat setting. Heated foam rubber materials can, under certain circumstances, produce fire by spontaneous combustion.

    Save These Instructions

    Page 3
    Samsung Dc68 02347b 05 manual — page 3

    SAMSUNG Dryer Owner’s Instructions 1 Safety Precautions

  • Do not allow children or pets to play on, in, or in front of the appliance. Close supervision is
    • necessary when the appliance is used near children and pets.
  • Before discarding or removing your dryer from service, remove the door to the drying
    • compartment to prevent children or animals from becoming trapped inside.
  • Do not reach into the appliance when the drum is moving.
  • Do not install or store this appliance where it will be exposed to the weather.
  • Do not tamper with controls.
  • Do not repair, replace, or attempt to service any part of the appliance unless specifically
    • recommended in the user-repair instructions and you understand and have the skills to carry those out.
  • Do not use fabric softeners or products to eliminate static unless recommended for dryer use by
    • the manufacturer of the fabric softener or product.
  • Clean the lint screen before or after each load.
  • Keep the area around the exhaust opening and surrounding areas free from lint, dust, and dirt.
  • The interior of the dryer and exhaust duct should be cleaned periodically by qualified service
    • personnel.
  • This appliance must be properly grounded. Never plug the power cord into a receptacle that is not
    • grounded adequately and in accordance with local and national codes. See installation instructions for grounding this appliance.
  • Do not sit on top of the dryer.
    • NOTE: Because of continuing product improvements, Samsung reserves the right to change specifications without notice. For complete details, see the Installation Instructions packed with your product before selecting cabinetry, making cutouts, or beginning installation.
  • Ensure pockets are free from small irregularly shaped hard objects, foreign material, etc. ie. coins,
    • knives, pins, etc. These objects could damage your dryer.
  • Do not wash clothing with large buckles, buttons, or other heavy metal or solid things.
    • WARNING – Gas leaks may occur in your system, resulting in a dangerous situation. Gas leaks may not be detected by smell alone. Gas suppliers recommend you purchase and install a UL-approved gas detector. Install and use in accordance with the manufacturer’s instructions. WARNING – Do not place items in your dryer that have been spotted or soaked with vegetable oil or cooking oil. Even after being washed, these items may contain significant amounts of these oils. The residual oil can ignite spontaneously. The potential for spontaneous combustion increases when the items containing vegetable oil or cooking oil are exposed to heat. Heat sources such as your dryer can warm these items, allowing an oxidation reaction in the oil to occur. Oxidation creates heat. If this heat cannot escape, the items can become hot enough to catch fire. Piling, stacking, or storing these kinds of items may prevent heat from escaping and can create a fire hazard. All washed and unwashed fabrics that contain vegetable oil or cooking oil can be dangerous. Washing these items in hot water with extra detergent will reduce, but not eliminate, the hazard. Always use the Cool Down cycle for these items to reduce their temperature. Never remove these items from the dryer hot or interrupt the drying cycle until the items have run through the Cool Down cycle. Never pile or stack these items when they are hot.

    Save These Instructions

    Page 4
    Samsung Dc68 02347b 05 manual — page 4

    Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . inside cover Table of Contents 28 Installation Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1 Tools needed for installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1 See Exhaust Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1 DUCTING REQUIREMENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-2 IMPORTANT TO INSTALLER. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-3 LOCATION CONSIDERATIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-3 ALCOVE OR CLOSET INSTALLATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-3 MOBILE HOME INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-4 EXHAUSTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-4 ELECTRICAL REQUIREMENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-4 GROUNDING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-4 ELECTRICAL CONNE CTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-5 REPLACEMENT PARTS AND ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-5 INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-5 FINAL INSTALLATION CHECKLIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-5 Dryer Exhaust Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-6 Door Reversal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-7 Operating Instructions, Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B-1 OVERVIEW OF THE CONTROL PANEL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B-1 CHILD LOCK. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B-4 MY CYCLE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B-4 Rack Dry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B-5 CLEAN THE LINT FILTER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B-6 LOAD THE DRYER PROPERLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B-6 GETTING STARTED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B-6 Care and Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .C-1 Control Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .C-1 Tumbler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .C-1 Stainless Steel Tumbler (select models) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .C-1 Dryer Exterior. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .C-1 Dryer Exhaust System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .C-1 Special Laundry Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . D-1 THINGS TO AVOID : . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . D-1 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .E-1 CHECK THESE POINTS IF YOUR DRYER... . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .E-1 INFORMATION CODES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .E-2 Appendix. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .F-1 FABRIC CARE CHART . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .F-1 PROTECTING THE ENVIRONMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .F-2 DECLARATION OF CONFORMITY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .F-2 SPECIFICATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .F-2 CYCLE CHART . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .F-3

    Page 5
    Samsung Dc68 02347b 05 manual — page 5

    SAMSUNG Dryer Owner’s Manual A-1 Tools needed for installation Proper installation is the owner’s responsibility.

    However, Service Calls Performed As A Result Of Poor Set-Up, Adjustment, And

    Connection Are The Responsibility Of The Installer.

    Make sure you have everything necessary for proper installation.
  • GROUNDED ELECTRICAL OUTLET is required. See Electrical Requirements.
  • EXHAUST SYSTEM – must be rigid metal or flexible stiff-walled metal exhaust ducting.
    • See Exhaust Requirements. Installation Instructions Door Control panel Adjustable leg Pliers Cutting knife Pipe wrench (gas only) Nut drivers Level Screwdriver (standard) Duct tape Crescent spanner

    Page 6
    Samsung Dc68 02347b 05 manual — page 6

    A-2 SAMSUNG Dryer Owner’s Instructions

    Ducting Requirements

    • Use a 4-inch (10.2 cm) diameter rigid aluminum or rigid galvanized steel duct. • Do not use a smaller duct. • Ducts larger than 4 inches (10.2 cm) in diameter can result in increased lint accumulation. Lint accumulation should be cleaned regularly. • If a flexible metal duct must be used, use the type with a stiff sheet metal wall. Do not use a flexible duct with a thin foil wall. Serious blockage can result if the flexible metal duct is bent too sharply. • Never install any type of flexible duct in walls, ceilings, or other concealed spaces. • Keep exhaust duct as straight and short as possible. • Secure joints with duct tape. Do not use screws. • DO NOT EXHAUST DRYER INTO ANY WALL, CEILING, CRAWL SPACE, OR CONCEALED SPACE OF A

    Building, Gas Vent, Or Any Other Common Duct Or Chimney.

    This Could Create A Fire Hazard From Lint Expelled By The Dryer.

    • Plastic flexible duct can kink, sag, be punctured, reduce airflow, extend drying times, and affect dryer operation. • Exhaust systems longer than recommended can extend drying times, affect machine operation, and may collect lint. • The exhaust duct should end with an exhaust hood with a swing-out damper to prevent back drafts and entry of wildlife. Never use an exhaust hood with a magnetic damper. • The hood should have at least 12 inches (30.5 cm) of clearance between the bottom of the hood and the ground or other obstruction. The hood opening should point down. • Never install a screen over the exhaust outlet. • To avoid lint buildup, do not exhaust the dryer directly into a window well. Do not exhaust under a house or porch. • If exhaust ductwork must run through an unheated area, the duct should be insulated and slope slightly down towards the exhaust hood to reduce condensation and lint buildup. • Inspect and clean the interior of the exhaust system at least once a year. Unplug the power cord before cleaning. • Check frequently to be sure the exhaust hood damper opens and closes freely. • Check once per month, and clean at least one time per year. Note: If clothes are not getting dry, then check ducting for obstructions.

    Electric And Gas Dryer

    Weather Hood Type Recommended Use only for short-run installation 4” (10 .16 cm) 2.5” (6.35 cm) No. of 90° elbows Rigid Metallic Flexible* Rigid Metallic Flexible* 0 24.4 m (80 ft.) 12.4 m (41 ft.) 22.6 m (74 ft.) 10.1 m (33 ft.) 1 20.7 m (68 ft.) 11.2 m (37 ft.) 18.9 m(62 ft.) 8.8 m (29 ft.) 2 17.4 m (57 ft.) 10.1 m (33 ft.) 15.5 m(51 ft.) 7.6 m (25 ft.) 3 14.3m (47 ft.) 9.0 m (29 ft.) 12.5 m(41 ft.) 6.5 m (21 ft.)
  • Do not use non-metallic flexible duct.
    • Installation Instructions

    Page 7
    Samsung Dc68 02347b 05 manual — page 7

    SAMSUNG Dryer Owner’s Instructions A-3 If new dryer is installed into an existing exhaust system you must make sure: • The exhaust system meets all local, state, and national codes. • That flexible plastic duct is not used. • Inspect and clean all lint buildup from inside the existing duct. • The duct is not kinked or crushed. • The exhaust hood damper opens and closes freely. The static pressure in any exhaust system must not exceed 0.83 inches of water column, or be less than 0. This can be measured with the dryer running with a manometer at the point where the exhaust duct connects to the dryer. A no-heat setting should be used. The dryer tumbler should be empty and the lint filter clean.

    Important To Installer

    Please read the following instructions carefully before installing the dryer. These instructions should be kept for future reference.

    Remove The Door From All Discarded Appliances To Avoid The Danger Of A

    Child Suffocating.

    Location Considerations

    The dryer should be located where there is enough space in front for loading the dryer, and enough space behind for the exhaust system. This dryer is factory-ready for rear exhaust. To exhaust out the bottom or the left, use the accessory exhaust kit. Instructions are included with the kit. It’s important to make sure the room has enough fresh air. The dryer must be located where there is no air-flow obstruction. THE DRYER MUST NOT BE INSTALLED OR STORED IN AN AREA WHERE IT WILL BE EXPOSED TO WATER AND/OR WEATHER. THE DRYER AREA IS TO BE KEPT CLEAR OF COMBUSTIBLE MATERIALS, GASOLINE, AND OTHER FLAMMABLE VAPORS AND LIQUIDS. A DRYER PRODUCES COMBUSTIBLE LINT. THE AREA

    Around The Dryer Should Be Kept Lint-Free.

    Alcove Or Closet Installation

    WARNING – The dryer must be exhausted to the outside to reduce the risk of fire when installed in an alcove or closet. • No other fuel-burning appliance should be installed in the same closet as the dryer. • WARNING: To reduce the risk of fire, this dryer MUST BE EXHAUSTED TO THE OUTDOORS. See EXHAUST INFORMATION section. • Minimum clearances between the dryer and adjacent walls or other surfaces are: 2” in front, 17” on top, 1” on either side, and 2.375” in the back. • Closet front must have two unobstructed air openings for a combined minimum total area of 72 in² with 3” minimum clearance on the top and bottom. A louvered door with equivalent space clearance is acceptable. Installation Instructions

    Page 8
    Samsung Dc68 02347b 05 manual — page 8

    A-4 SAMSUNG Dryer Owner’s Instructions

    Mobile Home Installation

    The installation of the dryer in mobile homes must conform to CSA Standards Z240 (for Canada). When installing a dryer in a mobile home, provisions for anchoring the dryer to the floor must be made. Locate in an area that has adequate fresh air. A minimum of 72 in² (183 cm² ) of unobstructed space is required. Call 1-800-SAMSUNG for information on purchasing the Floor Anchoring Kit as an accessory. All mobile home installations must be exhausted to the outside with the exhaust duct termination securely fastened to the mobile home structure, using materials that will not support combustion. The exhaust duct may not terminate underneath the mobile home. See Exhausting section for more information.

    Exhausting

    Exhausting the dryer to the outside will prevent large amounts of lint and moisture from being blown into the room. • All dryers must be exhausted to the outside. WARNING – The dryer must be exhausted to the outside to reduce the risk of fire when installed in an alcove or closet.

    Never Use Plastic Or Non-Metal Flexible Duct.

    If your existing ductwork is plastic, non-metal, or combustible, replace it with metal. Use only metal exhaust duct that is non-flammable to ensure containment of exhaust air, heat, and lint.

    Electrical Requirements

    NOTE: Wiring diagram is located on plate below the control panel.

    Warning –

    • Improper connection of the equipment grounding conductor can result in a risk of electric shock. Check with a qualified electrician or serviceman if you are in doubt as to whether your dryer is properly grounded. Do not modify the plug provided with your dryer – if it doesn’t fit the outlet, have a proper outlet installed by a qualified electrician. • To prevent unnecessary risk of fire, electrical shock, or personal injury, all wiring and grounding must be done in accordance with local codes, or in the absence of local codes, with the Canadian Electrical Code CSA C22.1 – Latest Revisions and local codes and ordinances. It is your responsibility to provide adequate electrical services for your dryer.

    Grounding

    This dryer must be grounded. In the event of malfunction or breakdown, the ground will reduce the risk of electrical shock by providing a path of least resistance for electrical current. The plug must be plugged into an appropriate outlet that is properly installed and grounded in accordance with all local codes and ordinances. If a power cord is not used and the electric dryer is to be permanently wired, the dryer must be connected to a permanent grounded metal wiring system, or an equipment grounding conductor must be run with the circuit conductors and connected to the equipment grounding terminal. Installation Instructions

    Page 9
    Samsung Dc68 02347b 05 manual — page 9

    SAMSUNG Dryer Owner’s Instructions A-5

    Electrical Conne Ctions

    Before operating or testing, follow all grounding instructions in the Grounding section. An individual branch (or separate) circuit serving only your dryer is recommended. DO NOT USE AN

    Extension Cord.

    • A 120/240 volt, 60 Hz AC approved electrical service fused through a 30-ampere fuse or circuit breaker on both sides of the line is required. • The power cord should be plugged into a 30-ampere receptacle. NOTE: It is not permissible to convert a dryer in Canada to 208 volts.

    Replacement Parts And Accessories

    If your dryer requires replacement parts or accessories, contact the dealer from whom you purchased your dryer or the SAMSUNG customer care center at 1-800-SAMSUNG (726-7864).

    Installation

    Parts and literature are packaged inside your dryer drum. To install:
  • Move your dryer to an appropriate location for installation. Consider installing the dryer and
    • washer side-by-side, to allow access to electrical, and exhaust connections. Lay two of the carton cushion-tops on the floor. Tip your dryer on its side so it will lay across both cushion-tops.
  • Set your dryer back in an upright position.
  • Review the Exhausting section before installing the exhaust system. Install the ductwork from your
    • dryer to the exhaust hood. The crimped end of the duct sections must point away from your dryer. DO NOT use sheet metal screws when assembling ducting. These joints should be taped. Never use plastic flexible exhaust material. Tip for tight installations: install a section of exhaust system to your dryer before putting it in place. Use duct tape to secure this section to your dryer, but do not cover louvers in dryer cabinet.
  • Review Electrical Requirements section.
    • BEFORE OPERATING OR TESTING, follow the grounding instructions in the Grounding section.
  • With a level, check your dryer and make necessary adjustments to the leveling legs.
  • At this time, make sure all exhaust and electrical connections are complete. Plug in your dryer, and
    • check operation by using the checklist below.

    Final Installation Checklist

     Dryer is plugged into electrical outlet and properly grounded.  Exhaust ductwork is hooked up and joints taped.  Plastic flexible duct is NOT used.  Use rigid or stiff-walled flexible metal vent material.  Dryer is level with all legs firmly on the floor.  Start your dryer to confirm that it runs, heats, and shuts off. Installation Instructions

    Page 10
    Samsung Dc68 02347b 05 manual — page 10

    A-6 SAMSUNG Dryer Owner’s Instructions Dryer Exhaust Tips

    Warning:

    Plastic or non-metal flexible duct presents a potential fire hazard. 1 2 3 4
  • Let your dryer exhaust the air easily.
  • Use 4” diameter rigid metal duct.Tape all joints, including at the dryer.
    • Never use lint-trapping screws.
  • Keep ducts as straight as possible.
  • Clean all old ducts before installing your new dryer.
    • Be sure vent flap opens and closes freely. Inspect and clean the exhaust system annually. Don’t let a poor exhaust system slow drying by: 1 2 3 4
  • Restricting your dryer with a poor exhaust system.
  • Using a plastic, thin foil, or non-metal flexible duct.
  • Using unnecessarily long duct runs with many elbows.
  • Allowing crushed or clogged ducts and vent.
    • Installation Instructions

    Page 11
    Samsung Dc68 02347b 05 manual — page 11

    SAMSUNG Dryer Owner’s Instructions A-7 Door Reversal

  • Unplug power cord.
  • Remove two door hinge screws.
  • Lift the door and remove from
    • dryer.
  • Place the door on the other side
    • and reattach it to dryer.
  • Remove two screws on the
    • opposite side of door hinge.
  • Reassemble holder lever.
  • Remove two screws on holder
    • lever.
  • Reassemble the screws in the
    • remaining holes. Installation Instructions

    Page 12
    Samsung Dc68 02347b 05 manual — page 12

    B-1 SAMSUNG Dryer Owner’s Instructions  Control Features vary by model.

    Overview Of The Control Panel

    Operating Instructions, Tips

    Page 13
    Samsung Dc68 02347b 05 manual — page 13

    SAMSUNG Dryer Owner’s Instructions B-2

  • Digital Graphic Display
    • The display window shows the estimated time remaining in the cycle after the Cycle Selector dial is pressed. The estimated time remaining may fluctuate as the cycle progresses. The Drying light will illuminate and remain lit until the cycle is complete. When your dryer is in the cool-down phase, the Cooling light will illuminate. When your dryer is in the wrinkle prevent phase, the Wrinkle Prevent light will illuminate. When the cycle is complete, “END” will appear in the display panel until the dryer door is opened or Power key is pushed. If your dryer is paused during a cycle, the indicator lights will blink until the Cycle Selector dial is pressed.
  • Dry Level Selection Button
    • To select the dry level in the Normal, Heavy Duty, or other Sensor Dry cycles, press the Dry Level button. An indicator light will illuminate next to the desired dryness level. Press the button repeatedly to scroll through the settings. Larger or bulkier loads may require the Very Dry (select models) or More Dry setting for complete dryness. The Less Dry setting is best suited for lightweight fabrics or for leaving some moisture in the clothing at the end of the cycle. Damp Dry (select models) is designed to partially dry items. Use for items that lay flat or hang to dry.
  • Temp Selection Button
    • To select the correct temperature for the load, press the Temp button. An indicator light will illuminate next to the desired temperature. Press the button repeatedly to scroll through the settings. High – For sturdy cottons or those labeled Tumble Dry. Medium – For permanent press, synthetics, lightweight cottons, or items labeled Tumble Dry Medium. Medium Low – For lower heat than Medium to dry synthetic or washable knit fabrics. Low – For heat sensitive items labeled Tumble Dry Low or Tumble Dry Warm. Extra Low – Provides the lowest heated dry temperature possible.
  • Time Selection Button
    • When using Manual Dry cycles, time can be adjusted by pressing time selection button. During the Sensory Dry cycle, the time light indicator is off because exact drying times are determined by fluctuating humidity levels.
  • Signal Selection Button
    • When the cycle is complete, a chime will sound. When the Wrinkle Prevent option is selected, the chime will sound intermittently. Adjust the volume of the chime or turn it off by pressing the Signal button. Press the button repeatedly to scroll through the choices.
  • Wrinkle Prevent Selection Button
    • Wrinkle Prevent provides approximately 90 minutes of intermittent tumbling in unheated air at the end of the cycle to reduce wrinkling. Press the Wrinkle Prevent button to activate this feature. The indicator light above the pad will illuminate when Wrinkle Prevent is selected. Chasing lights appear in the display when the Wrinkle Prevent option is selected. The load is dry, and can be removed at any time during the Wrinkle Prevent cycle. Operating Instructions, Tips

    Page 14
    Samsung Dc68 02347b 05 manual — page 14

    B-3 SAMSUNG Dryer Owner’s Instructions

  • Select Cycle Option
    • Adjust Time – Time can be added or subtracted from the automatically set times in the Manual Dry cycles (Time Dry, Freshen Up, Delicates, Wrinkle Release, or Air Fluff cycles). To add or subtract time from the cycle, press the Adjust Time arrow pad up or down until the desired time is displayed. My Cycle – Choose your favorite cycle including cycle, temp, dry level option, etc. (See page B4 for detail.) Rack Dry – Rack Dry is available at Time Dry cycle. Temperature will be set only to Extra Low. (See page B5 for detail.)
  • Cycle Selector
    • To select a cycle, rotate the Cycle Selector dial to the desired cycle. The indicator light by the cycle name will illuminate. The Normal, Heavy Duty, Towels, Perm Press and Delicates cycles are Sensor Dry cycles. Sensor Dry automatically senses the moisture in the load and shuts the dryer off when the selected dryness level (very dry to damp dry) is reached. Normal – Dry loads such as cotton, underwear, and linens use this cycle to get various levels of heat for drying. Heavy Duty – Use this cycle to get high heat for heavy fabrics such as jeans, corduroys, or work clothes. Towels – Dry loads such as bath towels. Perm Press – Dry wrinkle-free cottons, synthetic fabrics, knits, and permanent press fabrics automatically. The cycle minimizes wrinkling by providing a longer unheated cool-down period at the end of the cycle. Delicates – The Delicates cycle is designed to dry heat-sensitive items at a low drying temperature. Freshen Up – This cycle removes odors and freshens garments. Time Dry – Time Dry allows you to select the desired cycle time in minutes. Turn the Cycle Selector dial to Time Dry, then press the Adjust Time up arrow to set the drying time. Press the arrow repeatedly to scroll through the time settings. Wrinkle Release – The Wrinkle Release cycle will release wrinkles from items that are clean, dry, and only slightly wrinkled, such as clothes from a crowded closet, suitcase or items that have been in the dryer too long after the cycle has ended. Wrinkle Release can be used with any temperature selection. Air Fluff – The Air Fluff cycle tumbles the load in room temperature air.
  • Start/Pause Selection Button
    • Press to pause and restart programs.
  • Power Button
    • Press once to turn your dryer on, press again to turn it off. If your dryer is left on for more than 10 minutes without any buttons being touched, the power automatically turns off. Operating Instructions, Tips

    Page 15
    Samsung Dc68 02347b 05 manual — page 15

    SAMSUNG Dryer Owner’s Instructions B-4

    Child Lock

    A function to prevent children from playing with your dryer.

    Setting/Releasing

    If you want to set or release Child Lock, press both the Time and Signal buttons at the same time for 3 seconds. How to Set:
  • It can be set while your dryer is running.
  • Once you set the Child Lock function, no button, except for the Power button, can be
    • controlled until you release the Child Lock function.
  • The Child Lock indicator will be lit.
    • Notice:
  • If the power is on again, the Child Lock function remains unchanged.
  • To release that function, follow the instructions above.
    • Notice: When other buttons, except for the Power button, do not respond, check the Child Lock indicator.

    My Cycle

    Lets you activate your customized cycle that includes Dry Level, Temp, Time option, etc. By pushing the My Cycle button, you activate the settings used during the previous My Cycle mode. (Default : Normal Cycle) If My Cycle mode is activated, My Cycle lamp will be lit. You can select all options in My Cycle mode as follows.
  • Select cycle using Cycle Selector dial.
  • After cycle selection, set each option.
    • Note: At this time, the option will follow as per each cycle’s default option selection.
  • Then, you can start My Cycle by pushing the Start/Pause button in My Cycle mode. The cycle
    • and options you select will be displayed next time you choose My Cycle. Note : You can change My Cycle setting by repeating same process above. The last used setting will be displayed at next time you choose My Cycle. Operating Instructions, Tips

    Page 16
    Samsung Dc68 02347b 05 manual — page 16

    B-5 SAMSUNG Dryer Owner’s Instructions Rack Dry

    Installing The Drying Rack

  • Open dryer door.
  • Position drying rack in tumbler, placing the rear legs in the two recessed areas of the dryer’s back
    • wall.
  • Place the front lip of the drying rack on top of the lint filter.
  • Place items to be dried on the rack, leaving space between them so air can reach all surfaces.
  • Close dryer door.
  • Use the Time Dry cycle. Select time according to moisture and weight of the items. Start dryer.
    • It may be necessary to reset the timer if a longer drying time is needed.

    Suggested Items

    Suggested Temp. Settings

    Washable sweaters (block to shape and lay flat on rack) Heat (Low/Extra Low) Stuffed toys (cotton or polyester fiberfilled) Heat (Low/Extra Low) Stuffed toys (foam or rubber-filled) Air Fluff Foam rubber pillows Air Fluff Sneakers Fluff or Heat WARNING – Drying foam rubber, plastic, or rubber on a heat setting may cause damage to the item and lead to a fire hazard. Operating Instructions, Tips

    Page 17
    Samsung Dc68 02347b 05 manual — page 17

    SAMSUNG Dryer Owner’s Instructions B-6

    Clean The Lint Filter

    • After each load. • To shorten drying time. • To operate more energy efficiently. NOTE: Do not operate your dryer without the lint filter in place.

    Load The Dryer Properly

    • Place only one washload in your dryer at a time. • Mixed loads of heavy and lightweight fabrics will dry differently, which may result in lightweight fabrics being dry while heavy fabrics remaining damp at the end of a drying cycle. • Add one or more similar items to your dryer when only one or two articles need drying. This improves the tumbling action and drying efficiency. • Overloading restricts tumbling action, resulting in uneven drying as well as excessive wrinkling of some fabrics.

    Getting Started

  • Load your dryer loosely – DO NOT overload.
  • Close the door.
  • Select the appropriate cycle and options for the load (see pages B-2, B-3).
  • Press the Cycle Selector dial.
  • The dryer indicator light will illuminate.
  • The estimated cycle time will appear in the display.
    • The time may fluctuate to better indicate drying time remaining in the cycle.

    Notes:

    • When the cycle is complete, the Door Lock light will go out and “End” will appear in the display. • Pressing Power cancels the cycle and stops your dryer. • The Drying, Cooling, and Wrinkle Prevent indicator lights will illuminate during those portions of the cycle. Operating Instructions, Tips

    Page 18
    Samsung Dc68 02347b 05 manual — page 18

    C-1 SAMSUNG Dryer Owner’s Instructions Care and Cleaning Control Panel Clean with a soft, damp cloth. Do not use abrasive substances. Do not spray cleaners directly on the panel. The control panel finish could be damaged by some laundry pre-treatment soil and stain remover products. Apply such products away from your dryer and wipe up any spills or overspray immediately. Tumbler Remove any stains such as crayon, ink, or fabric dye (from new items such as towels or jeans) with an all-purpose cleaner. Then tumble old towels or rags to remove any excess stain or cleaning substance. Once these steps are done, stains may still be visible, but should not transfer to subsequent loads. Stainless Steel Tumbler (select models) To clean the stainless steel tumbler, use a damp cloth with a mild, non-abrasive cleaner suitable for stainless steel surfaces. Remove the cleaner residue and dry with a clean cloth. Dryer Exterior Clean with a soft, damp cloth. Do not use abrasive substances. Protect the surface from sharp objects. Dryer Exhaust System Should be inspected and cleaned yearly to maintain optimum performance. The outside exhaust hood should be cleaned more frequently to ensure proper operation.

    Page 19
    Samsung Dc68 02347b 05 manual — page 19

    SAMSUNG Dryer Owner’s Instructions D-1 Special Laundry Tips Please follow the care label or manufacturer’s instructions for drying special items. If care label instructions are not available, use the following information as a guide. Bedspreads & Comforters • Follow the care label instructions or dry on the Normal cycle and High temperature. • Make sure the item is thoroughly dry before using or storing. • May require repositioning to ensure even drying. Blankets • Use Normal and dry only one blanket at a time for best tumbling action. • Make sure the item is thoroughly dry before using or storing. Curtains & Draperies • Use the Perm Press cycle and Low or Extra Low temperature to help minimize wrinkling. • Dry these in small loads for best results and remove as soon as possible. Cloth Diapers • Use the Normal cycle and the High temperature setting for soft, fluffy diapers. Down–filled Items (jackets, sleeping bags, comforters, etc.) • Use the Normal cycle and the Low or Extra Low temperature setting. • Place a clean pair of sneakers in your dryer with the item to fluff the down comforters, etc. Adding a couple of dry towels shortens drying time and absorbs moisture. Foam Rubber (rug backs, stuffed toys, shoulder pads, etc.) • DO NOT dry on a heat setting. Use the Air Fluff cycle (no heat). • WARNING – Drying a rubber item with heat may damage it or be a fire hazard. Pillows • Use the Normal cycle. • Add a couple of dry towels and a pair of clean sneakers to help the tumbling action and to fluff the item. • DO NOT dry kapok or foam pillows in dryer. Plastics (shower curtains, outdoor furniture covers, etc.) • Use the Air Fluff cycle or the Time Dry cycle and the Low or Extra Low temperature setting depending on the care label instructions.

    Things To Avoid :

    • Fiberglass items (curtains, draperies, etc.). • Woolens, unless recommended on the label. • Vegetable or cooking oil-soaked items.

    Page 20
    Samsung Dc68 02347b 05 manual — page 20

    E-1 SAMSUNG Dryer Owner’s Instructions Troubleshooting

    Check These Points If Your Dryer...

    doesn’t run. • Be sure the door is latched shut. • Be sure the power cord is plugged into a live electrical outlet. • Check the home’s circuit breaker and fuses. • Press the Cycle Selector dial again if the door is opened during the cycle. doesn’t heat. • Check the home’s circuit breaker and fuses. • Select a heat setting other than Air Fluff. • Clean the lint filter and exhaust duct. • Dryer may have moved into the cool-down phase of the cycle. doesn’t dry. • Check all of the above, plus... • Be sure the exhaust hood outside the home can open and close freely. • Check exhaust system for lint buildup. Ducting should be inspected and cleaned annually. • Use 4” rigid metal exhaust duct. • Do not overload. 1 wash load = 1 dryer load. • Sort heavy items from lightweight items. • Large, bulky items like blankets or comforters may require repositioning to ensure even drying. • Check that the washer is draining properly to extract adequate water from the load. • Load may be too small to tumble properly. Add a few towels. is noisy. • Check the load for objects such as coins, loose buttons, nails, etc. Remove promptly. • It is normal to hear the dryer gas valve or heating element cycle on and off during the drying cycle. • Be sure the dryer is leveled properly as outlined in the installation instruction. • It is normal for the dryer to hum from the high velocity of air moving through the dryer drum and exhaust system. dries unevenly. • Seams, pockets, and other similarly heavy areas may not be completely dry when the rest of the load has reached the selected dryness level. This is normal. Select the Very Dry setting if desired. • If one heavy item is dried with a lightweight load, such as one towel with sheets, it is possible that the heavy item will not be completely dry when the rest of the load has reached the selected dryness level. Sort heavy items from lightweight items for best drying results. has an odor. • Household odors from painting, varnishing, strong cleaners, etc. may enter the dryer with the surrounding room air. This is normal as the dryer draws the air from the room, heats it, pulls it through the tumbler, and exhausts it outside. • When these odors linger in the air, ventilate the room completely before using the dryer. shuts off before load is dry • Dryer load is too small. Add more items or a few towels and restart the cycle. • Dryer load is too large. Remove some items and restart the dryer.

    Page 21
    Samsung Dc68 02347b 05 manual — page 21

    SAMSUNG Dryer Owner’s Instructions E-2 Troubleshooting

    Information Codes

    Information codes may be displayed to help you better understand what is occurring with the dryer. Code Symbol Meaning Solution Heater temperature control problem. Call for service. See below. Door open sensing problem. Call for service. See below. Door open error When the door is open, the dryer will not operate. Be sure the door is latched shut. If problem continues, call for service. See below. For any codes not listed above, call 1-800-726-7864 (1-800-SAMSUNG).

    Page 22
    Samsung Dc68 02347b 05 manual — page 22

    F-1 SAMSUNG Dryer Owner’s Instructions Appendix

    Fabric Care Chart

    The following symbols provide garment care directions without words. The care label will include, in order, four symbols: washing, bleaching, drying, and ironing (or dry cleaning when necessary). The use of symbols ensures consistency among garment manufacturers of domestic and imported items. Follow care label directions to maximize garment life and reduce laundering problems. Wash Cycle Special Instructions Warning Symbols for Laundering Normal Line Dry/ Hang to Dry Do Not Wash Permanent Press/ Wrinkle Resistant/ Wrinkle Control Drip Dry Do Not Wring Gentle/Delicates Dry Flat Do Not Bleach Hand Wash Heat Setting Do Not Tumble Dry Water Temperature** High No Steam (added to iron) Hot Medium Do Not Iron Warm Low Cold Any Heat Bleach No Heat/Air Any Bleach (when needed) Iron-Dry or Steam Temperatures Line Dry/ Hang to Dry Only Non-Chlorine (color-safe) Bleach (when needed) High Drip Dry Tumble Dry Cycle Medium Dry Flat Normal Low Permanent Press/ Wrinkle Resistant/ Wrinkle Control Dryclean Gentle/ Delicates Dry Clean Do Not Dry Clean ** The dot symbols represent appropriate wash water temperatures for various items. The temperature range for Hot is 105° –125° F/ 41° – 52° C, for Warm 85° – 105° F/29° – 41° C and for Cold 60° – 85° F/16° – 29° C. (Wash water temperature must be a minimum of 60° F/16° C for detergent activation and effective cleaning.)

    Page 23
    Samsung Dc68 02347b 05 manual — page 23

    SAMSUNG Dryer Owner’s Instructions F-2 Appendix

    Protecting The Environment

    This appliance is manufactured from recyclable materials. If you decide to dispose of this appliance, please observe local waste disposal regulations. Cut off the power cord so that the appliance cannot be connected to a power source. Remove the door so that animals and small children cannot get trapped inside the appliance.

    Declaration Of Conformity

    This appliance complies with UL2158.

    Specification

    Type

    Front Loading Dryer

    Dimension

    Div Inches (cm) Div Inches (cm) A. Height 38” (96.5) C. Depth with door open 90° 49” (124.5) B. Width 27” (68.6) D. Depth 30.25” (77.0)

    Weight

    56.8 kg

    Heater Rating

    5300 W

    Power

    Consumption

    No Heat

    268 W

    Heating

    5445 W

    Page 24
    Samsung Dc68 02347b 05 manual — page 24

    F-3 SAMSUNG Dryer Owner’s Instructions Appendix

    Cycle Chart

    Cycle Default Drying Cooling Wrinkle prevent Temp control Sensor dry level Time Time Time Time Sensor Dry Normal High (Medium) Normal dry 44 min 39 min 5 min 90 min Heavy Duty High (No change) Normal dry 60 min 55 min 5 min 90 min Towels High (Medium) Normal dry 52 min 47 min 5 min 90 min Perm Press Medium Low (No change) Normal dry 34 min 24 min 10 min 90 min Delicates Low (No change) Normal dry 29 min 24 min 5 min 90 min Extra Delicates Extra Low (No change) Normal dry 29 min 24 min 5 min 90 min Manual Dry Freshen Up High (No change)
  • 30 min
    • 25 min 5 min
  • Time Dry
    • High
  • 40 min
    • 35 min 5 min
  • Wrinkle
    • Release Medium
  • 25 min
    • 20 min 5 min
  • Air Fluff
  • (No change)
  • 20 min
    • 20 min Quick Dry High
  • 30 min
    • 25 min 5 min -

    Page 25
    Samsung Dc68 02347b 05 manual — page 25

    SAMSUNG Dryer Owner’s Instructions F-4 Appendix

    Samsung Dryer

    Limited Warranty To Original Purchaser

    This SAMSUNG brand product, as supplied and distributed by SAMSUNG ELECTRONICS CANADA, INC. (SAMSUNG) and delivered new, in the original carton to the original consumer purchaser, is warranted by SAMSUNG against manufacturing defects in materials and workmanship for a limited warranty period of: One (1) Year All Parts and Labor, Two (2) Years Control Board Parts This limited warranty begins on the original date of purchase, and is valid only on products purchased and used in Canada. To receive warranty service, the purchaser must contact SAMSUNG for problem determination and service procedures. Warranty service can only be performed by a SAMSUNG authorized service center. The original dated bill of sale must be presented upon request as proof of purchase to SAMSUNG or SAMSUNG’s authorized service center. SAMSUNG will provide in-home service during the warranty period at no charge, subject to availability within Canada. In-home service is not available in all areas. To receive in-home service, product must be unobstructed and accessible to the service agent. If service is not available, SAMSUNG may elect to provide transportation of the product to and from an authorized service center. SAMSUNG will repair, replace, or refund this product at our option and at no charge as stipulated herein, with new or reconditioned parts or products if found to be defective during the limited warranty period specified above. All replaced parts and products become the property of SAMSUNG and must be returned to SAMSUNG. Replacement parts and products assume the remaining original warranty, or ninety (90) days, whichever is longer. This limited warranty covers manufacturing defects in materials and workmanship encountered in normal, noncommercial use of this product and shall not apply to the following: damage that occurs in shipment; delivery and installation; applications and uses for which this product was not intended; altered product or serial numbers; cosmetic damage or exterior finish; accidents, abuse, neglect, fire, water, lightning, or other acts of nature or God; use of products, equipment, systems, utilities, services, parts, supplies, accessories, applications, installations, repairs, external wiring or connectors not supplied or authorized by SAMSUNG that damage this product or result in service problems; incorrect electrical line voltage, fluctuations and surges; customer adjustments and failure to follow operating instructions, maintenance and environmental instructions that are covered and prescribed in the instruction book; product removal and reinstallation; problems caused by pest infestations. This limited warranty does not cover problems resulting from incorrect electric current, voltage or supply, light bulbs, house fuses, house wiring, cost of a service call for instructions, or fixing installation errors. SAMSUNG does not warrant uninterrupted or error-free operation of the product.

    Page 26
    Samsung Dc68 02347b 05 manual — page 26

    F-5 SAMSUNG Dryer Owner’s Manual Appendix EXCEPT AS SET FORTH HEREIN, THERE ARE NO WARRANTIES ON THIS PRODUCT EITHER EXPRESS OR IMPLIED, AND SAMSUNG DISCLAIMS ALL WARRANTIES INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTIES OF MERCHANTABILITY, INFRINGEMENT OR FITNESS FOR A PARTICULAR PURPOSE. NO WARRANTY OR GUARANTEE GIVEN BY ANY PERSON, FIRM, OR CORPORATION WITH RESPECT TO

    This Product Shall Be Binding On Samsung.

    SAMSUNG SHALL NOT BE LIABLE FOR LOSS OF REVENUE OR PROFITS, FAILURE TO REALIZE SAVINGS OR OTHER BENEFITS, OR ANY OTHER SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES CAUSED BY THE USE, MISUSE, OR INABILITY TO USE THIS PRODUCT, REGARDLESS OF THE LEGAL THEORY ON WHICH THE CLAIM IS BASED, AND EVEN IF SAMSUNG HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

    Nor Shall Recovery Of Any Kind Against Samsung Be Greater In Amount Than The

    Purchase Price Of The Product Sold By Samsung And Causing The Alleged Damage.

    WITHOUT LIMITING THE FOREGOING, PURCHASER ASSUMES ALL RISK AND LIABILITY FOR LOSS,

    Damage, Or Injury To Purchaser And Purchaser’S Property And To Others And Their

    Property Arising Out Of The Use, Misuse, Or Inability To Use This Product.

    THIS LIMITED WARRANTY SHALL NOT EXTEND TO ANYONE OTHER THAN THE ORIGINAL PURCHASER OF

    This Product, Is Nontransferable And States Your Exclusive Remedy.

    Some states do not allow limitations on how long an implied warranty lasts, or the exclusion or limitation of incidental or consequential damages, so the above limitations or exclusions may not apply to you. This warranty gives you specific rights, and you may also have other rights, which vary from state to state. To obtain warranty service, please contact SAMSUNG at:

    Samsung Electronics Canada, Inc. – Consumer Electronics Customer Service

    55 Standish Court, Mississauga, On L5R 4B2

    1-800-Samsung (1-800-726-7864)

    www.samsung.ca

    Page 28
    Samsung Dc68 02347b 05 manual — page 28

    Contact SAMSUNG WORLD WIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. Samsung Electronics Canada, Inc.

    1-800-Samsung (726-7864)

    www.samsung.ca

    More from Samsung

    Washing Machines

    Active Waterjet Washer

    27 Q&As

     Refrigerators

    Bespoke Fridge

    14 Q&As

     TVs

    Bn68 Series Smart TV

    12 Q&As

     TVs

    Bn68 Smart TV

    23 Q&As

    Similar Dryers

    Maytag

    # Centennial Series Dryer

    29 Q&As

     Chicco

    00007392100070 Advanced Steam Sterilizer With Dryer

    9 Q&As

     Kenmore

    110.60942990 Dryer

    28 Q&As

     Bosch

    300 Series Dryer

    10 Q&As
