WorkForce® WF-7010 User's Guide

Contents WorkForce WF-7010 User's Guide............................................................................................................. 9 Product Basics .......................................................................................................................................... 10 Printer Parts Locations....................................................................................................................... 10 Printer Parts - Top ......................................................................................................................... 10 Printer Parts - Back........................................................................................................................ 11 Printer Parts - Inside...................................................................................................................... 12 Printer Parts - Control Panel Buttons and Lights ........................................................................... 13 The Power Off Timer .......................................................................................................................... 13 Changing the Power Off Timer Setting - Windows......................................................................... 14 Changing the Power Off Timer Setting - Mac OS X....................................................................... 15 Loading Paper ........................................................................................................................................... 17 Loading Paper for Documents............................................................................................................ 17 Loading Paper for Photos................................................................................................................... 22 Loading Envelopes............................................................................................................................. 27 Paper Loading Capacity..................................................................................................................... 32 Available EPSON Papers................................................................................................................... 33 Borderless Paper Type Compatibility ................................................................................................. 36 Paper or Media Type Settings............................................................................................................ 37 Setting the Paper Size for Each Source ............................................................................................. 38 Setting the Paper Size for Each Source - Windows....................................................................... 38 Setting the Paper Size for Each Source - Mac OS X ..................................................................... 40 Printing From a Computer ........................................................................................................................ 43 Printing with Windows ........................................................................................................................ 43 Selecting Basic Print Settings - Windows ...................................................................................... 43 Paper Source Options - Windows............................................................................................. 46 Print Quality Options - Windows ............................................................................................... 46 Multi-Page Printing Options - Windows..................................................................................... 46 Selecting Double-sided Printing Settings - Windows..................................................................... 47 Double-sided Printing Options - Windows................................................................................. 49 Print Density Adjustments - Windows ....................................................................................... 50 3

Selecting Additional Layout and Print Options - Windows ............................................................. 50 Custom Color Correction Options - Windows............................................................................ 51 Additional Settings Options - Windows ..................................................................................... 53 Selecting a Printing Preset - Windows........................................................................................... 53 Printing Your Document or Photo - Windows ................................................................................ 54 Selecting Default Print Settings - Windows.................................................................................... 55 Changing the Language of the Printer Software Screens ......................................................... 56 Changing Automatic Update Options ............................................................................................ 57 Printing with Mac OS X 10.5, 10.6, or 10.7......................................................................................... 58 Selecting Basic Print Settings - Mac OS X 10.5/10.6/10.7............................................................. 59 Paper Source Options - Mac OS X 10.5/10.6/10.7.................................................................... 63 Print Quality Options - Mac OS X 10.5/10.6/10.7...................................................................... 63 Print Options - Mac OS X 10.5/10.6/10.7.................................................................................. 64 Selecting Page Setup Settings - Mac OS X 10.5/10.6/10.7 ........................................................... 64 Selecting Print Layout Options - Mac OS X 10.5/10.6/10.7 ........................................................... 65 Sizing Printed Images - Mac OS X 10.5/10.6/10.7......................................................................... 66 Selecting Double-sided Printing Settings - Mac OS X 10.5/10.6/10.7 ........................................... 66 Double-sided Printing Options and Adjustments - Mac OS X ................................................... 68 Managing Color - Mac OS X 10.5/10.6/10.7.................................................................................. 69 Color Matching and Color Options - Mac OS X 10.5/10.6/10.7................................................. 70 Printing Your Document or Photo - Mac OS X 10.5/10.6/10.7....................................................... 71 Checking Print Status - Mac OS X 10.5/10.6/10.7 .................................................................... 72 Selecting Printing Preferences - Mac OS X 10.5/10.6/10.7 ........................................................... 73 Printing Preferences - Mac OS X 10.5/10.6/10.7 ...................................................................... 74 Printing with Mac OS X 10.4............................................................................................................... 74 Selecting Page Setup Settings - Mac OS X 10.4........................................................................... 75 Selecting Basic Print Settings - Mac OS X 10.4............................................................................. 76 Paper Source Options - Mac OS X 10.4.................................................................................... 79 Print Quality Options - Mac OS X 10.4...................................................................................... 79 Print Options - Mac OS X 10.4.................................................................................................. 80 Selecting Print Layout Options - Mac OS X 10.4 ........................................................................... 80 Sizing Printed Images - Mac OS X 10.4......................................................................................... 81 Selecting Double-sided Printing Settings - Mac OS X 10.4 ........................................................... 81 4

Managing Color - Mac OS X 10.4.................................................................................................. 83 Color Options - Mac OS X 10.4................................................................................................. 83 Selecting Printing Preferences - Mac OS X 10.4 ........................................................................... 84 Printing Preferences - Mac OS X 10.4 ...................................................................................... 84 Printing Your Document or Photo - Mac OS X 10.4....................................................................... 85 Checking Print Status - Mac OS X 10.4 .................................................................................... 85 Cancelling Printing Using a Product Button........................................................................................ 86 Replacing Ink Cartridges .......................................................................................................................... 87 Check Cartridge Status ...................................................................................................................... 87 Checking Cartridge Status Lights .................................................................................................. 87 Checking Cartridge Status with Windows...................................................................................... 88 Checking Cartridge Status with Mac OS X .................................................................................... 91 Purchase EPSON Ink Cartridges ....................................................................................................... 92 Ink Cartridge Part Numbers........................................................................................................... 92 Removing and Installing Ink Cartridges.............................................................................................. 93 Printing With Black Ink and Expended Color Cartridges .................................................................... 96 Printing With Expended Color Cartridges - Windows .................................................................... 97 Printing With Expended Color Cartridges - Mac OS X 10.5/10.6/10.7........................................... 97 Conserving Low Black Ink with Windows ........................................................................................... 98 Adjusting Print Quality............................................................................................................................ 100 Print Head Maintenance................................................................................................................... 100 Print Head Nozzle Check............................................................................................................. 100 Checking the Nozzles Using the Product Buttons................................................................... 100 Checking the Nozzles Using a Computer Utility...................................................................... 102 Print Head Cleaning .................................................................................................................... 105 Cleaning the Print Head Using the Product Buttons................................................................ 105 Cleaning the Print Head Using a Computer Utility................................................................... 106 Print Head Alignment................................................................................................................... 109 Aligning the Print Head Using a Computer Utility.................................................................... 109 Cleaning the Paper Path .................................................................................................................. 112 Cleaning and Transporting the Product................................................................................................ 113 Cleaning the Product........................................................................................................................ 113 Transporting the Product.................................................................................................................. 113 5

Solving Problems.................................................................................................................................... 115 Checking for Software Updates........................................................................................................ 115 Printer Light Status........................................................................................................................... 115 Running a Printer Check .................................................................................................................. 117 Solving Setup Problems................................................................................................................... 119 Noise After Ink Installation........................................................................................................... 119 Software Installation Problems.................................................................................................... 119 Solving Network Problems ............................................................................................................... 120 Network Software Cannot Find Product on a Network................................................................. 120 Cannot Print Over a Network....................................................................................................... 120 Printing a Network Status Sheet.................................................................................................. 121 Solving Paper Problems................................................................................................................... 121 Paper Feeding Problems............................................................................................................. 122 Paper Jam Problems Inside the Product ..................................................................................... 122 Paper Jam Problems in the Cassette .......................................................................................... 124 Paper Jam Problems in the Duplexer .......................................................................................... 127 Paper Ejection Problems............................................................................................................. 129 Solving Problems Printing from a Computer .................................................................................... 129 Nothing Prints.............................................................................................................................. 129 Noise Occurs, But Nothing Prints ................................................................................................ 130 Noise When Product Sits for a While........................................................................................... 130 Product Icon Does Not Appear in Windows Taskbar................................................................... 131 Error After Cartridge Replacement .............................................................................................. 131 Printing is Slow............................................................................................................................ 132 Solving Page Layout and Content Problems.................................................................................... 133 Inverted Image ............................................................................................................................ 133 Too Many Copies Print ................................................................................................................ 133 Blank Pages Print........................................................................................................................ 134 Incorrect Margins on Printout....................................................................................................... 134 Incorrect Characters Print............................................................................................................ 135 Incorrect Image Size or Position.................................................................................................. 135 Solving Print Quality Problems......................................................................................................... 136 White or Dark Lines in Printout .................................................................................................... 136 6

Blurry or Smeared Printout .......................................................................................................... 137 Faint Printout or Printout Has Gaps............................................................................................. 138 Grainy Printout............................................................................................................................. 139 Incorrect Colors ........................................................................................................................... 140 Slanted Printout........................................................................................................................... 140 When to Uninstall Your Product Software ........................................................................................ 141 Uninstalling Printing Software - Windows .................................................................................... 141 Uninstalling Product Software - Mac OS X .................................................................................. 142 Where to Get Help............................................................................................................................ 142 Technical Specifications ........................................................................................................................ 144 Windows System Requirements ...................................................................................................... 144 Mac System Requirements .............................................................................................................. 145 Printing Specifications...................................................................................................................... 145 Paper Specifications ........................................................................................................................ 145 Printable Area Specifications ........................................................................................................... 147 Ink Cartridge Specifications.............................................................................................................. 148 Dimension Specifications................................................................................................................. 149 Electrical Specifications ................................................................................................................... 149 Environmental Specifications........................................................................................................... 150 Interface Specifications.................................................................................................................... 150 Network Interface Specifications...................................................................................................... 150 Safety and Approvals Specifications................................................................................................ 150 Notices ..................................................................................................................................................... 151 FCC Compliance Statement............................................................................................................. 151 Software Notices.............................................................................................................................. 152 Trademarks...................................................................................................................................... 155 Copyright Notice............................................................................................................................... 156 A Note Concerning Responsible Use of Copyrighted Materials................................................... 156 Default Delay Times for Power Management for EPSON Products ............................................ 156 Copyright Attribution.................................................................................................................... 157 7

WorkForce WF-7010 User's Guide Welcome to the WorkForce WF-7010 User's Guide. 9

Product Basics See these sections to learn about the basic features of your product. Printer Parts Locations The Power Off Timer Printer Parts Locations See these sections to identify the parts on your printer. Printer Parts - Top Printer Parts - Back Printer Parts - Inside Printer Parts - Control Panel Buttons and Lights Parent topic: Product Basics Printer Parts - Top 1 Control panel 2 Output tray 3 Output tray extension 4 Paper stopper 5 Feeder guard 10

6 Edge guides on paper cassette 7 Tray release button Parent topic: Printer Parts Locations Printer Parts - Back 1 USB port 2 Ethernet LAN port 3 AC inlet 4 Duplexer Parent topic: Printer Parts Locations 11

Printer Parts - Inside 1 Cover 2 Paper cassette 1 3 Paper cassette 2 4 Print head (do not remove) 5 Cartridge holder 6 Cartridge cover Parent topic: Printer Parts Locations 12

Printer Parts - Control Panel Buttons and Lights 1 The power light 2 The power button 3 The network status button 4 The paper feed button 5 The ink button 6 The cancel button 7 The Ethernet light 8 The paper light 9 The ink out lights Parent topic: Printer Parts Locations Related references Printer Light Status The Power Off Timer The product turns off automatically if it is not used for a period of time after it enters sleep mode. You can adjust the time period before power off, but increasing the time reduces the product's energy efficiency. Changing the Power Off Timer Setting - Windows 13

Changing the Power Off Timer Setting - Mac OS X Parent topic: Product Basics Changing the Power Off Timer Setting - Windows You can use the printer software to change the time period before the printer turns off automatically.

Loading Paper Before you print, load paper for the type of printing you will do. Loading Paper for Documents Loading Paper for Photos Loading Envelopes Paper Loading Capacity Available EPSON Papers Borderless Paper Type Compatibility Paper or Media Type Settings Setting the Paper Size for Each Source Loading Paper for Documents You can print documents on a variety of paper types and sizes. You can load custom paper sizes in Cassette 1 only.

Note: The paper may slide forward slightly as you insert the cassette. This is normal.

Note: Make sure the envelopes fit beneath the top edges of the guide. Caution: To prevent paper feeding problems, make sure you do not load too many envelopes in the cassette.

Paper type Loading capacity EPSON Bright White Paper 200 sheets** EPSON Presentation Paper Matte 80 sheets EPSON Photo Paper Glossy 20 sheets EPSON Premium Photo Paper Glossy EPSON Ultra Premium Photo Paper Glossy EPSON Premium Photo Paper Semi-gloss EPSON Premium Presentation Paper Matte EPSON Premium Presentation Paper Matte Double-sided EPSON Ultra Premium Presentation Paper Matte EPSON Brochure & Flyer Paper Matte Double- sided EPSON Photo Quality Self-adhesive Sheets 1 sheet EPSON Iron-on Cool Peel Transfer paper Envelopes 10 envelopes

Paper Type Size Part number Sheet count EPSON Bright White Paper Letter (8.5 × 11 inches

S041586

S042384

S041341

S041343

S041339

S041568

S041467

S041257

S042180

S041468

S041260

S041263

S041067

S041062

S041070

S041069

Paper Type Size Part number Sheet count EPSON Photo Paper Glossy 4 × 6 inches (102 × 152 mm)

S041809

S042038

S041141

S041649

S041271

S041156

S044143

S041808

S041727

S041464

S041465

S042183

S041667

S041466

S041290

S041288

S041289

Paper Type Size Part number Sheet count EPSON Ultra Premium Photo 4 × 6 inches (102 × 152 mm)

S042181

S042174

S041945

S041946

S042182

S042175

S041982

S041331

S041327

S041106

S041153

Borderless Paper Sizes

For this paper Select this paper Type or Media Type setting Cardstock up to 68 lb Thick-Paper Parent topic: Loading Paper Setting the Paper Size for Each Source You can set the paper size for each paper source using your printer software. The settings apply to all print jobs sent to the product. Setting the Paper Size for Each Source - Windows Setting the Paper Size for Each Source - Mac OS X Parent topic: Loading Paper Setting the Paper Size for Each Source - Windows You can change the default paper size for each source in Windows.

product will print even if the image size exceeds the printable area, and your printout may be smudged.

product will print even if the image size exceeds the printable area, and your printout may be smudged.

Printing From a Computer Before printing documents or photos from your computer, make sure you have set up your product and installed its software as described on the Start Here sheet. Note: If you have an internet connection, it is a good idea to check for updates to your product software on Epson's support website. Printing with Windows Printing with Mac OS X 10.5, 10.6, or 10.7 Printing with Mac OS X 10.4 Cancelling Printing Using a Product Button Printing with Windows You can print with your product using any Windows printing program, as described in these sections. Selecting Basic Print Settings - Windows Selecting Double-sided Printing Settings - Windows Selecting Additional Layout and Print Options - Windows Selecting a Printing Preset - Windows Printing Your Document or Photo - Windows Selecting Default Print Settings - Windows Changing Automatic Update Options Parent topic: Printing From a Computer Selecting Basic Print Settings - Windows Select the basic settings for the document or photo you want to print.

Paper Source Options - Windows You can select any of the available options in the Paper Source menu to print from paper loaded in that source. Auto Select Automatically selects the paper source based on the selected paper size. Paper Cassette 1 Selects the paper in cassette 1 as the paper source. Paper Cassette 2 Selects the paper in cassette 2 as the paper source. Parent topic: Selecting Basic Print Settings - Windows Print Quality Options - Windows You can select any of the available Quality options to fine-tune the quality of your print. Some settings may be unavailable, depending on the paper type and border setting you have chosen. Fast Economy For the fastest printing with draft quality. Economy For fast printing with reduced quality. Normal For everyday text and image printing. Fine For text and graphics with good quality and print speed. Quality For photos and graphics with good quality and print speed. High Quality For photos and graphics with high print quality. Best Quality For the best print quality, but the slowest print speed. Parent topic: Selecting Basic Print Settings - Windows Multi-Page Printing Options - Windows You can select any of the available options in the Multi-Page menu to set up your multi-page print job. 46

2-Up and 4-Up Prints 2 or 4 pages on one sheet of paper. Click the Page Order button to select page layout and border options. 2×1 Poster, 2×2 Poster, 3×3 Poster, 4×4 Poster Prints one image on multiple sheets of paper to create a larger poster. Click the Settings button to select image layout and guideline options. Parent topic: Selecting Basic Print Settings - Windows Selecting Double-sided Printing Settings - Windows You can print on both sides of the paper by selecting the 2-Sided Printing checkbox on the Main tab. Note: Some options may be pre-selected or unavailable, depending on other settings you have chosen or if you are accessing the product over a network.

Print Density Adjustments - Windows When you select the User-Defined setting, you can select any of the available options on the Print Density Adjustment window to adjust the print quality of your double-sided print job. Print Density Sets the level of ink coverage for double-sided printing. Increase Ink Drying Time Sets the amount of time required for drying ink after printing on one side of the paper before printing the other side in double-sided printing to prevent ink smearing. Parent topic: Selecting Double-sided Printing Settings - Windows Selecting Additional Layout and Print Options - Windows You can select a variety of additional layout and printing options for your document or photo on the More Options tab. 50

Color Controls Lets you select a Color Mode setting, individual settings for Brightness, Contrast, Saturation, and Density, and individual color tones. If you select the Adobe RGB color mode, you can also adjust the midtone density using the Gamma setting. Fix Photo Improves the color, contrast, and sharpness of flawed photos. Note: Fix Photo uses a sophisticated face recognition technology to optimize photos that include faces. For this to work, both eyes and the nose must be visible in the subject's face. If your photo includes a face with an intentional color cast, such as a statue, you may want to turn off Fix Photo to retain the special color effects.

Icm

Parent topic: Selecting Additional Layout and Print Options - Windows Additional Settings Options - Windows You can select any of the Additional Settings options to customize your print. Some options may be pre- selected or unavailable, depending on other settings you have chosen. Rotate 180º Prints the image rotated 180º from its original orientation. High Speed Speeds up printing, but may reduce print quality. Mirror Image Flips the printed image left to right. Edge Smoothing Smooths jagged edges in low-resolution images such as screen captures or images from the Web. Fix Red-Eye Reduces or removes red-eye in photos. Parent topic: Selecting Additional Layout and Print Options - Windows Selecting a Printing Preset - Windows For quick access to common groups of print settings, you can select a printing preset on the Main or More Options tab. Note: You can create your own preset by clicking the Add/Remove Presets button.

Note: Printing presets may vary depending on model.

You see your application's Print window, such as this one:

You see the maintenance options:

Selecting Page Setup Settings - Mac OS X 10.5/10.6/10.7 Selecting Print Layout Options - Mac OS X 10.5/10.6/10.7 Sizing Printed Images - Mac OS X 10.5/10.6/10.7 Selecting Double-sided Printing Settings - Mac OS X 10.5/10.6/10.7 Managing Color - Mac OS X 10.5/10.6/10.7 Printing Your Document or Photo - Mac OS X 10.5/10.6/10.7 Selecting Printing Preferences - Mac OS X 10.5/10.6/10.7 Parent topic: Printing From a Computer Selecting Basic Print Settings - Mac OS X 10.5/10.6/10.7 Select the basic settings for the document or photo you want to print.

Note: The print window may look different, depending on the version of Mac OS X and the application you are using.

Related references Paper or Media Type Settings Related tasks Setting the Paper Size for Each Source - Mac OS X Selecting Page Setup Settings - Mac OS X 10.5/10.6/10.7 Printing Your Document or Photo - Mac OS X 10.5/10.6/10.7 Paper Source Options - Mac OS X 10.5/10.6/10.7 You can select any of the available options in the Paper Source menu to print from paper loaded in that source. Auto Select Automatically selects the paper source based on the selected paper size. Paper Cassette 1 Selects the paper in cassette 1 as the paper source. Paper Cassette 2 Selects the paper in cassette 2 as the paper source. Parent topic: Selecting Basic Print Settings - Mac OS X 10.5/10.6/10.7 Print Quality Options - Mac OS X 10.5/10.6/10.7 You can select any of the available Print Quality options to fine-tune the quality of your print. Some settings may be unavailable, depending on the paper type and border setting you have chosen. Fast Economy For the fastest printing with draft quality. Economy For fast printing with reduced quality. Normal For everyday text and image printing. Fine For text and graphics with good quality and print speed. Quality For photos and graphics with good quality and print speed. High Quality For photos and graphics with high print quality. 63

Best Quality For the best print quality, but the slowest print speed. Parent topic: Selecting Basic Print Settings - Mac OS X 10.5/10.6/10.7 Print Options - Mac OS X 10.5/10.6/10.7 You can select any of the print options to customize your print. Some options may be unavailable, depending on other settings you have chosen. Expansion If you selected a borderless paper size setting, adjusts the image expansion settings to control printing at the edges of borderless prints. Grayscale Prints text and graphics in black or shades of gray. Mirror Image Flips the printed image left to right. Note: If you select the Min option for the Expansion setting, you may see white borders on your printed photo. Parent topic: Selecting Basic Print Settings - Mac OS X 10.5/10.6/10.7 Selecting Page Setup Settings - Mac OS X 10.5/10.6/10.7 Depending on your application, you may be able to select the paper size and orientation settings from the print window. Note: If you do not see these settings in the print window, check for them in your application before printing. They may be accessible by selecting Page Setup from the File menu. 64

Note: Some options may be pre-selected or unavailable, depending on other settings you have chosen or if you are accessing the product over a network. This screen may be different, depending on the version of Mac OS X you are using.

Short-Edge binding Orients double-sided printed pages to be bound on the short edge of the paper. Adjustments Print Density Sets the level of ink coverage for double-sided printing. Increased Ink Drying Time Sets the amount of time required for drying ink after printing on one side of the paper before printing the other side in double-sided printing. Parent topic: Selecting Double-sided Printing Settings - Mac OS X 10.5/10.6/10.7 Managing Color - Mac OS X 10.5/10.6/10.7 You can adjust the Color Matching and Color Options settings to fine-tune the colors in your printout, or turn off color management in your printer software.

Color Options Settings Manual Settings Lets you select manual color adjustments. Click the arrow next to Advanced Settings and select settings for Brightness, Contrast, Saturation, and individual color tones. You can also select a color Mode setting for printing photos and graphics. If you select the Adobe RGB color mode, you can also adjust the midtone density using the Gamma setting. Fix Photo Improves the color, contrast, and sharpness of flawed photos. Note: Fix Photo uses a sophisticated face recognition technology to optimize photos that include faces. For this to work, both eyes and the nose must be visible in the subject's face. If your photo includes a face with an intentional color cast, such as a statue, you may want to turn off Fix Photo to retain the special color effects. Fix Red-Eye Reduces or removes red-eye in photos. Off (No Color Adjustment) Turns off color management in your printer software so you can manage color using only your application software. Parent topic: Managing Color - Mac OS X 10.5/10.6/10.7 Printing Your Document or Photo - Mac OS X 10.5/10.6/10.7 Once you have selected your print settings, you are ready to print. Click Print at the bottom of the print window. 71

Checking Print Status - Mac OS X 10.5/10.6/10.7 Parent topic: Printing with Mac OS X 10.5, 10.6, or 10.7 Checking Print Status - Mac OS X 10.5/10.6/10.7 During printing, you can view the progress of your print job, control printing, and check ink cartridge status.

Selecting Page Setup Settings - Mac OS X 10.4 Selecting Basic Print Settings - Mac OS X 10.4 Selecting Print Layout Options - Mac OS X 10.4 Sizing Printed Images - Mac OS X 10.4 Selecting Double-sided Printing Settings - Mac OS X 10.4 Managing Color - Mac OS X 10.4 Selecting Printing Preferences - Mac OS X 10.4 Printing Your Document or Photo - Mac OS X 10.4 Parent topic: Printing From a Computer Selecting Page Setup Settings - Mac OS X 10.4 Select the page setup settings for the document or photo you want to print.

Print Options - Mac OS X 10.4 Parent topic: Printing with Mac OS X 10.4 Related references Paper or Media Type Settings Related tasks Setting the Paper Size for Each Source - Mac OS X Printing Your Document or Photo - Mac OS X 10.4 Paper Source Options - Mac OS X 10.4 You can select any of the available options in the Paper Source menu to print from paper loaded in that source. Auto Select Automatically selects the paper source based on the selected paper size. Paper Cassette 1 Selects the paper in cassette 1 as the paper source. Paper Cassette 2 Selects the paper in cassette 2 as the paper source. Parent topic: Selecting Basic Print Settings - Mac OS X 10.4 Print Quality Options - Mac OS X 10.4 You can select any of the available Print Quality options to fine-tune the quality of your print. Some settings may be unavailable, depending on the paper type and border setting you have chosen. Fast Economy For the fastest printing with draft quality. Economy For fast printing with reduced quality. Normal For everyday text and image printing. Fine For text and graphics with good quality and print speed. Quality For photos and graphics with good quality and print speed. High Quality For photos and graphics with high print quality. 79

Best Quality For the best print quality, but the slowest print speed. Parent topic: Selecting Basic Print Settings - Mac OS X 10.4 Print Options - Mac OS X 10.4 You can select any of the print options to customize your print. Some options may be unavailable, depending on other settings you have chosen. Expansion If you selected a borderless paper size setting, adjusts the image expansion settings to control printing at the edges of borderless prints. Grayscale Prints text and graphics in black or shades of gray. Mirror Image Lets you flip the printed image horizontally. Note: If you select the Min option for the Expansion setting, you may see white borders on your printed photo. Parent topic: Selecting Basic Print Settings - Mac OS X 10.4 Selecting Print Layout Options - Mac OS X 10.4 You can select layout options for multi-page documents by selecting Layout from the pop-up menu on the print window. 80

Note: Some options may be pre-selected or unavailable, depending on other settings you have chosen or if you are accessing the product over a network.

ColorSync Prints using standard color profiles for your product and paper to help match image colors. You can customize the conversion method and filter settings on the ColorSync pop-up menu in the print window. Off (No Color Adjustment) Turns off color management in your printer software so you can manage color using only your application software. Parent topic: Managing Color - Mac OS X 10.4 Selecting Printing Preferences - Mac OS X 10.4 You can select various printing preferences from the Extension Settings menu.

Parent topic: Selecting Printing Preferences - Mac OS X 10.4 Printing Your Document or Photo - Mac OS X 10.4 Once you have selected your print settings, you are ready to print. Click Print at the bottom of the print window. Checking Print Status - Mac OS X 10.4 Parent topic: Printing with Mac OS X 10.4 Checking Print Status - Mac OS X 10.4 During printing, you can view the progress of your print job, control printing, and check ink cartridge status.

Replacing Ink Cartridges When an ink cartridge is expended, you need to replace it. You may also need to replace a cartridge that is more than six months old, if your printouts do not look their best, even after cleaning and aligning the print head. Note: Please dispose of your used EPSON branded ink cartridges responsibly and in accordance with local requirements. If you would like to return your used ink cartridges to Epson for proper disposal, please go to www.epson.com/recycle for more information. Check Cartridge Status Purchase EPSON Ink Cartridges Removing and Installing Ink Cartridges Printing With Black Ink and Expended Color Cartridges Conserving Low Black Ink with Windows Check Cartridge Status Your product and its printing software will let you know when an ink cartridge is low or expended. Checking Cartridge Status Lights Checking Cartridge Status with Windows Checking Cartridge Status with Mac OS X Parent topic: Replacing Ink Cartridges Checking Cartridge Status Lights You can check the status of your ink cartridges by checking the lights on your product. 87

1 The ink out lights

Checking Cartridge Status with Mac OS X You can check the status of your ink cartridges using a utility on your Mac.

Ink color Part number High-capacity Extra High-capacity Magenta 126 127 Yellow 126 127 Parent topic: Purchase EPSON Ink Cartridges Removing and Installing Ink Cartridges Make sure you have your replacement cartridges handy before you begin. You must install new cartridges immediately after removing the old ones. Caution: Leave your old cartridges in the printer until you are ready to replace them to prevent the print head nozzles from drying out. Do not open ink cartridge packages until you are ready to install the ink. Cartridges are vacuum packed to maintain reliability.

Printing With Expended Color Cartridges - Windows Printing With Expended Color Cartridges - Mac OS X 10.5/10.6/10.7 Parent topic: Replacing Ink Cartridges Printing With Expended Color Cartridges - Windows If you see a message during printing telling you that you can temporarily print in black ink with an expended color cartridge, you can cancel your print job and select settings to print on plain paper or on an envelope.

Note: The window appears only when you have selected Plain Paper/Bright White Paper as the paper type setting, and depends on other selected print settings.

Adjusting Print Quality If your print quality declines, you may need to run a utility to clean or align the print head. If running these utilities does not solve the problem, you may need to replace the ink cartridges. Print Head Maintenance Cleaning the Paper Path Print Head Maintenance If your printouts become too light, or you see dark or light bands across them, you may need to clean the print head nozzles. Cleaning uses ink, so clean the nozzles only if print quality declines. You can check for clogged nozzles before you clean them so you don’t clean them unnecessarily. Note: You cannot clean the print head if an ink cartridge is expended, and may not be able to clean it when a cartridge is low. You must replace the cartridge first. Print Head Nozzle Check Print Head Cleaning Print Head Alignment Parent topic: Adjusting Print Quality Related topics Replacing Ink Cartridges Print Head Nozzle Check You can print a nozzle check pattern to check for clogged nozzles. Checking the Nozzles Using the Product Buttons Checking the Nozzles Using a Computer Utility Parent topic: Print Head Maintenance Checking the Nozzles Using the Product Buttons You can check the print head nozzles using the buttons on your product.

Parent topic: Print Head Nozzle Check Related topics Replacing Ink Cartridges Checking the Nozzles Using a Computer Utility You can check the print head nozzles using a utility on your Windows or Mac computer.

The power light flashes throughout the cleaning cycle and stays on when the cleaning cycle is finished. Caution: Never turn off the product during a cleaning cycle or you may damage it.

Print head needs cleaning

Cleaning the Paper Path If you see ink on the back of a printout, you can clean the paper path to remove any excess ink.

Cleaning and Transporting the Product If your product gets dirty or you need to move it some distance, follow the instructions in these sections. Cleaning the Product Transporting the Product Cleaning the Product To keep your product working at its best, you should clean it several times a year. Caution: Do not use a hard brush, benzine, alcohol, or paint thinner to clean the product or you may damage it. Do not place anything on top of the cover or use the cover as a writing surface, or it could get permanently scratched. Do not use oil or other lubricants inside the product or let water get inside.

Solving Problems Check these sections for solutions to problems you may have using your product. Checking for Software Updates Printer Light Status Running a Printer Check Solving Setup Problems Solving Network Problems Solving Paper Problems Solving Problems Printing from a Computer Solving Page Layout and Content Problems Solving Print Quality Problems When to Uninstall Your Product Software Where to Get Help Checking for Software Updates Periodically, it's a good idea to check Epson's support website for free updates to your product software. You can select Download the Latest Software from the Home screen of this manual or visit Epson's driver download site (U.S. downloads or Canadian downloads). With Windows, your printer software automatically checks for updates. You can also manually update the software by selecting Software Update or Driver Update here:

Lights 1 power 2 Ethernet 3 paper 4 ink out Light status Condition/solution The printer is turned on. The power light is on The power light is The printer is busy. Wait for the power light to stop flashing before turning flashing off the printer. The paper light is on Paper may be out. Load more paper in the cassette and press the paper feed button to continue. If multiple sheets have fed, press the paper feed button to eject the paper. The paper size selected may not match any of the sizes set for the paper sources. Press the paper feed button to clear the error, and select the right paper size. If the paper cassette is not installed, install it and press the paper feed button. 116

Light status Condition/solution Paper has jammed in the printer. Check in the cassette, inside the printer, The paper light is flashing and in the duplexer to remove the jammed paper. Then press the paper feed button to clear the error. The cover is open. Close the cover. The power, ink out, and paper light are flashing An ink cartridge is low. Make sure you have a replacement cartridge. An ink out light is flashing An ink cartridge is expended or not installed correctly. Replace the indicated An ink out light is on cartridge. Make sure the cartridge is installed correctly All lights are flashing Printer error. Check in the cassette, inside the printer, and in the duplexer to remove the jammed paper. Turn the printer off and then back on again. If the error does not clear, contact Epson. The black and yellow The firmware update has failed, and the printer is in recovery mode. Visit Epson's support website at www.epson.com/support (U.S.) or ink out lights are www.epson.ca/support (Canada) for instructions on repeating the firmware flashing update. The ink pads are near or at the end of their service life. Contact Epson for The paper and ink out lights are flashing support. (To continue printing, press the paper button.) alternately Parent topic: Solving Problems Related references Paper Jam Problems Inside the Product Paper Jam Problems in the Cassette Paper Jam Problems in the Duplexer Where to Get Help Related topics Loading Paper Replacing Ink Cartridges Running a Printer Check Running a printer check helps you determine if the printer is operating properly. 117

Related concepts Print Head Cleaning Print Head Alignment When to Uninstall Your Product Software Related references Where to Get Help Solving Setup Problems Check these sections if you have problems while setting up your product. Noise After Ink Installation Software Installation Problems Parent topic: Solving Problems Noise After Ink Installation If you hear noises from your product after installing ink, try these solutions:

Paper Feeding Problems If you have problems feeding paper, try these solutions:

Paper Jam Problems in the Duplexer If paper has jammed in the duplexer (rear unit), try these solutions:

Paper Ejection Problems If you have problems with paper ejecting properly, try these solutions:

Product Icon Does Not Appear in Windows Taskbar If you do not see your product icon in the Windows taskbar, first try restarting your computer. If that does not work, try this solution:

Printing is Slow If printing becomes slow, try these solutions:

Selecting Basic Print Settings - Mac OS X 10.4 Solving Page Layout and Content Problems Check these sections if you have problems with the layout or content of your printed pages. Inverted Image Too Many Copies Print Blank Pages Print Incorrect Margins on Printout Incorrect Characters Print Incorrect Image Size or Position Parent topic: Solving Problems Inverted Image If your printed image is inverted unexpectedly, try these solutions:

Related tasks Selecting Basic Print Settings - Windows Selecting Basic Print Settings - Mac OS X 10.5/10.6/10.7 Selecting Basic Print Settings - Mac OS X 10.4 Selecting Additional Layout and Print Options - Windows Blank Pages Print If blank pages print unexpectedly, try these solutions:

Parent topic: Solving Page Layout and Content Problems Related tasks Selecting Basic Print Settings - Windows Selecting Basic Print Settings - Mac OS X 10.5/10.6/10.7 Selecting Basic Print Settings - Mac OS X 10.4 Related topics Loading Paper Incorrect Characters Print If incorrect characters appear in your prints, try these solutions before reprinting:

Parent topic: Solving Page Layout and Content Problems Related tasks Selecting Basic Print Settings - Windows Selecting Additional Layout and Print Options - Windows Selecting Basic Print Settings - Mac OS X 10.5/10.6/10.7 Selecting Print Layout Options - Mac OS X 10.5/10.6/10.7 Selecting Page Setup Settings - Mac OS X 10.4 Selecting Print Layout Options - Mac OS X 10.4 Solving Print Quality Problems Check these sections if your printouts have problems with print quality, but your image looks fine on your computer screen. White or Dark Lines in Printout Blurry or Smeared Printout Faint Printout or Printout Has Gaps Grainy Printout Incorrect Colors Slanted Printout Parent topic: Solving Problems White or Dark Lines in Printout If you notice white or dark lines in your prints (also called banding), try these solutions before you reprint:

Related concepts Print Head Cleaning Print Head Alignment Related references Paper or Media Type Settings Related tasks Selecting Additional Layout and Print Options - Windows Selecting Printing Preferences - Mac OS X 10.5/10.6/10.7 Selecting Printing Preferences - Mac OS X 10.4 Blurry or Smeared Printout If your printouts are blurry or smeared, try these solutions:

Parent topic: Solving Print Quality Problems Related concepts Print Head Cleaning Print Head Alignment Related references Available EPSON Papers Paper Specifications Related tasks Selecting Basic Print Settings - Windows Selecting Additional Layout and Print Options - Windows Selecting Basic Print Settings - Mac OS X 10.5/10.6/10.7 Selecting Printing Preferences - Mac OS X 10.5/10.6/10.7 Selecting Basic Print Settings - Mac OS X 10.4 Selecting Printing Preferences - Mac OS X 10.4 Selecting Double-sided Printing Settings - Windows Selecting Double-sided Printing Settings - Mac OS X 10.5/10.6/10.7 Selecting Double-sided Printing Settings - Mac OS X 10.4 Cleaning the Paper Path Related topics Loading Paper Faint Printout or Printout Has Gaps If your printouts are faint or have gaps, try these solutions:

Related concepts Print Head Cleaning Related tasks Selecting Basic Print Settings - Windows Selecting Basic Print Settings - Mac OS X 10.5/10.6/10.7 Selecting Basic Print Settings - Mac OS X 10.4 Cleaning the Paper Path Related topics Replacing Ink Cartridges Grainy Printout If your printouts are grainy, try these solutions:

Incorrect Colors If your printouts have incorrect colors, try these solutions:

Related tasks Selecting Basic Print Settings - Windows Selecting Basic Print Settings - Mac OS X 10.5/10.6/10.7 Selecting Basic Print Settings - Mac OS X 10.4 Related topics Loading Paper When to Uninstall Your Product Software If you have a problem that requires you to uninstall and re-install your software, follow the instructions for your operating system. Uninstalling Printing Software - Windows Uninstalling Product Software - Mac OS X Parent topic: Solving Problems Uninstalling Printing Software - Windows You can uninstall and then re-install your printer software to solve certain problems.

Uninstalling Product Software - Mac OS X In most cases, you do not need to uninstall your product software before re-installing it. However, you can download the Uninstall Center utility from the Epson support website to uninstall your product software as described here. Note: If you find that re-installing your product software does not solve a problem, contact Epson.

Technical Specifications These sections list the technical specifications for your product. Note: Epson offers a recycling program for end of life products. Please go to www.epson.com/recycle for information on how to return your products for proper disposal. Windows System Requirements Mac System Requirements Printing Specifications Paper Specifications Printable Area Specifications Ink Cartridge Specifications Dimension Specifications Electrical Specifications Environmental Specifications Interface Specifications Network Interface Specifications Safety and Approvals Specifications Windows System Requirements To use your product and its software, your computer should use one of these operating systems:

Mac System Requirements To use your product and its software, your Mac should use one of these operating systems:

Single-sheets Size A4 (8.3 × 11.7 inches [210 × 297 mm]) A6 (4.1 × 5.8 inches [105 × 148 mm]) Letter (8.5 × 11 inches [216 × 279 mm]) Legal (8.5 × 14 inches [216 × 357 mm]) 4 × 6 inches (102 × 152 mm) 5 × 7 inches (127 × 178 mm) 8 × 10 inches (203 × 254 mm) 3.5 × 5 inches (89 × 127 mm) 16:9 wide (4 × 7.1 inches [102 × 181 mm]) Half Letter (5.5 × 8.5 inches [140 × 279 mm]) 13 × 19 inches (330 × 483 mm) Paper types Plain paper and paper distributed by Epson Thickness 0.003 to 0.004 inch (0.08 to 0.11mm) Weight 17 lb (64 g/m2) to 24 lb (90 g/m2) Envelopes Size No. 10 (4.1 × 9.5 inches [105 × 241 mm]) Paper types Plain bond paper Weight 20 lb (75 g/m2) to 24 lb (90 g/m2) Parent topic: Technical Specifications 146

Printable Area Specifications Single sheets 1 Top: 0.12 inch (3 mm) minimum 2 Left: 0.12 inch (3 mm) minimum 3 Right: 0.12 inch (3 mm) minimum 4 Bottom: 0.12 inch (3 mm) minimum Envelopes 147

1 Left: 0.12 inch (3 mm) minimum 2 Bottom: 0.20 inch (5 mm) minimum 3 Top: 0.20 inch (5 mm) minimum 4 Right: 0.78 inch (20 mm) minimum Parent topic: Technical Specifications Ink Cartridge Specifications Note: We recommend that you use genuine EPSON cartridges and do not refill them. The use of other products may affect your print quality and could result in printer damage. The printer ships with full cartridges and part of the ink from this first set of cartridges is used for priming the printer. Yields vary considerably based on images printed, print settings, paper type, frequency of use, and temperature. For print quality, a variable amount of ink remains in the cartridge after the "replace cartridge" indicator comes on. Color Black, Cyan, Magenta, Yellow Cartridge life Opened package: 6 months Unopened package: do not use if the date on the package has expired Temperature Storage: –4 to 104 ºF (–20 to 40 ºC) 1 month at 104 ºF (40 ºC) Ink freezes at 8.6 ºF (–13 ºC) Ink thaws and is usable after 3 hours at 77 ºF (25 ºC) Note: For best printing results, use up a cartridge within 6 months of opening the package. Parent topic: Technical Specifications Related references Ink Cartridge Part Numbers 148

Dimension Specifications Height Stored: 11.2 inches (284 mm) Printing: 15.1 inches (383 mm) Width Stored: 18.1 inches (460 mm) Printing: 18.1 inches (460 mm) Depth Stored: 16.5 inches (420 mm) Printing: 25.7 inches (654 mm) Weight 24.0 lb (10.9 kg) (without ink cartridges) Parent topic: Technical Specifications Electrical Specifications Power supply rating 100 to 240 V Input voltage range 90 to 264 V Rated frequency range 50/60 Hz Input frequency range 49.5/60.5 Hz Rated current

0.5/0.25 A

Environmental Specifications Temperature Operating: 50 to 95 ºF (10 to 35 ºC) Storage: –4 to 104 ºF (–20 to 40 ºC) 1 month at 104 ºF (40 ºC) Humidity Operating: 20 to 80% RH (non-condensing) Storage: 5 to 85% RH Parent topic: Technical Specifications Interface Specifications Interface type Hi-Speed USB (Device Class for computers) Parent topic: Technical Specifications Network Interface Specifications Ethernet standard

100 Base-Tx/10Base-T

Notices Check these sections for important notices about your product. Note: Epson offers a recycling program for end of life products. Please go to www.epson.com/recycle for information on how to return your products for proper disposal. FCC Compliance Statement Software Notices Trademarks Copyright Notice FCC Compliance Statement For United States Users This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio or television reception. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause interference to radio and television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

Warning

For Canadian Users This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations. Cet appareil numérique de la classe B respecte toutes les exigences du Règlement sur le materiel brouilleur du Canada. Parent topic: Notices Software Notices

Open Source Software License

Gnu Gpl

busybox-1.2.2.1 ifupdown-0.6.8 kernel-2.6.18 lsp-arm-versatile926ejs-2.6.18_pro500 module-init-tools-3.2pre1 mount-2.12 net-tools-1.60 netbase-4.29 psmisc-21.5 readline-libs-5.0 sysvinit-2.86 udev-0.093 udhcp 0.9.8cvs20050124-5 util-linux-2.12

Gnu Lgpl

OpenSSL License/Original SSLeay License This printer product includes the open source software program "OpenSSL toolkit" which applies the license terms of OpenSSL License and Original SSLeay License. BSD License (Berkeley Software Distribution License) This printer product includes the open source software programs which apply the Berkeley Software Distribution License ("BSD Programs"). The list of BSD Programs: busybox-1.2.2.1 util-linux-2.12 mount-2.12 mvlutils-2.8.4 netkit-ftp-0.17 netkit-base-0.17 portmap-5beta Sun RPC License This printer product includes the open source software programs which apply the Sun RPC License ("Sun RPC Programs"). The list of Sun RPC Programs: busybox- 1 .2.2.1 netkit-inetd-0.17 portmap-5beta TCP Wrappers license This printer product includes the open source software program "TCP Wrappers" which applies the terms and conditions provided by owner of the copyright to the "TCP Wrappers". "TCP Wrappers" Program: libwrap-libs-7.6 libncurses license This printer product includes the open source software program "libncurses" which applies the terms and conditions provided by owner of the copyright to the "libncurses". "libncurses" Program : 154

libncurses-5.4 linux-ftpd license This printer product includes the open source software program "linux-ftpd" which applies the terms and conditions provided by owner of the copyright to the "linux-ftpd". "linux-ftpd" Program: linux-ftpd-0.17 ARC4 license This printer product includes the open source software program "ARC4" which applies the terms and conditions provided by owner of the copyright to the "ARC4". "ARC4" Program:

Arc4

Sha1

Copyright Notice All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior written permission of Seiko Epson Corporation. The information contained herein is designed only for use with this EPSON product. Epson is not responsible for any use of this information as applied to other products. Neither Seiko Epson Corporation nor its affiliates shall be liable to the purchaser of this product or third parties for damages, losses, costs, or expenses incurred by purchaser or third parties as a result of: accident, misuse, or abuse of this product or unauthorized modifications, repairs, or alterations to this product, or (excluding the U.S.) failure to strictly comply with Seiko Epson Corporation's operating and maintenance instructions. Seiko Epson Corporation shall not be liable for any damages or problems arising from the use of any options or any consumable products other than those designated as Original EPSON Products or EPSON Approved Products by Seiko Epson Corporation. Seiko Epson Corporation shall not be held liable for any damage resulting from electromagnetic interference that occurs from the use of any interface cables other than those designated as EPSON approved Products by Seiko Epson Corporation. This information is subject to change without notice. A Note Concerning Responsible Use of Copyrighted Materials Default Delay Times for Power Management for EPSON Products Copyright Attribution Parent topic: Notices A Note Concerning Responsible Use of Copyrighted Materials Epson encourages each user to be responsible and respectful of the copyright laws when using any EPSON product. While some countries' laws permit limited copying or reuse of copyrighted material in certain circumstances, those circumstances may not be as broad as some people assume. Contact your legal advisor for any questions regarding copyright law. Parent topic: Copyright Notice Default Delay Times for Power Management for EPSON Products This product will enter sleep mode after a period of nonuse. The time interval has been set at the factory to ensure that the product meets Energy Star standards of energy efficiency, and cannot be modified by the consumer. 156

Parent topic: Copyright Notice Copyright Attribution © 2012 Epson America, Inc. 3/12

Cpd-34380R2
