LG WM3431HW Washing Machine

Washer/Dryer Combo

Wm3431Hw

Wm3431Hs

All-In-One Washer and Dryer Performance

NeveRust™Stainless Steel Drum

2.44 Cu.Ft. Capacity (IEC)

Direct Drive Motor is Highly Reliable, Durable

and Quiet

1400 RPM Maximum Spin Speed

Ventless Condensing Drying System

115V Power Source

Intelligent Fabric Care

SenseClean™System Automatically Adjusts Water

and Wash Time for Optimal Care

Sensor Dry System Measures Moisture in the

Drum and Automatically Adjusts Drying Time and Temperature for Optimal Care

Flexibility of Wash to Dry, Wash Only or Dry Only

9 Wash Programs

5 Rinse Temperatures

Sanitary Cycle

Delay Wash up to 19 hours

Style and Design

24" Installation Under Counter

Premium Finishes in Titanium and White

Upfront Electronic Controls with Dial-A-Cycle™

Chrome Trimmed Door with Clear Glass

Environmentally Friendly

Energy Star Rated

LoDecibel™Quiet Operation

W M 3 4 3 1 H W W M 3 4 3 1 H S

L G a p p l i a n c e s . c o m

L A U N D R Y

LG front load washers exceed Energy Star® classifications by a minimum of 39%. Titanium White

Printed in April 2006 SS-WM3431HW/WM3431HS

Wm3431Hw

Wm3431Hs

Type

Front Loader
Design Look Front Panel Intelligent Electronic Controls with Dial-A-Cycle™
Drying System Ventless Condensing

Capacity

Total Capacity 2.44 cu.ft. (IEC) Maximum Dry Capacity 8.8 lbs.

Energy

Energy Star

Programs

9 Wash Programs Sanitary, Cotton/Towels, Normal, Permanent Press, Delicates, Wool/Silk, Hand Wash, Speed Wash, Drain & Spin 5 Wash/Rinse Temperature Levels Extra Hot/Cold, Hot/Cold, Warm/Warm, Warm/Cold, Cold/Cold Spin Speeds 1400 RPM, Extra High, High, Medium, Low, No Spin 5 Dry Times 150 min, 120 min, 90 min, 60 min, 30 min Temperature Options Normal, Low Temperature No. of Water Levels Automatically adjusts to size of load No. of Soil Levels 5 Options Extra Rinse, Rinse & Spin, Soak, Extra Wash, Spin Only, Dry Only, Delay Wash up to 19 Hours

Fabric Care Features

SenseClean™
Sensor Dry

Convenience Features

3 Tray Dispenser (Main Wash, Bleach, Softener)
End of Cycle Beeper
Child Lock
Self Diagnosis
Auto-Balancing
Auto Suds Removal
Forced Drain System
Remaining Time Display/Status Indicator
Water Heater
Leveling Legs 4 Adjustable LoDecibel™Quiet Operation

Motor And Agitator

Motor Type / Motor Speed Direct Drive / Variable Agitator Type Horizontal Axis

Materials And Finishes

NeveRust™Stainless Steel Drum
Transparent Glass Window Door
Door Rim Chrome Cabinet Painted Steel Cabinet Top Premium Plastic Control Panel Plastic Colors White, Titanium

Power Source

Ratings/Requirements UL Listed/120V, 60Hz, 10 Amps Type Electric

Dimensions

Product (WxHxD) 23 5/8" x 33 1/4" x 23 13/16" (25"D including door) Weight (lbs): Net / Gross 147 / 163

Warranty

1 year parts and labor 2 years on the control board 7 years on the motor Lifetime on the drum

Upc Code

White 048231 008594 Titanium 048231 008600 All trademarks are property of their respective owners. Design and specifications are subject to change without notice.

Washer/Dryer Combo

Lg Electronics Inc.

1000 Sylvan Ave., Englewood Cliffs, NJ 07632 800.243.0000 LGappliances.com All-in-One Washer and Dryer This laundry dream washes and dries all in one machine. Who Is It for? People who want to be able to do laundry at home but don't have an external venting source which conventional dryers require. It's great for busy people who want to start a load and return to clean clothes. The Delay Start feature allows convenient completion of laundry to fit your schedule. Homes, apartments, businesses and vacation homes where there may be space constraints. What Are The Advantages? No outside venting is required because it is ventless condensing. It runs on a standard 115V electricity and not gas. No need to wait to transfer from the washer to the dryer. What Else Should I Know? Ventless condensing dries from within the drum so the water that is extracted from the clothes drains through the drum and out the water pump. This drying process takes longer than conventional drying. It requires installation where a water hook-up is available.
