Bosch 800 Series B36IT900NP Built-In Refrigerator

en Instruction manual .............................................................. 2 fr Notice d'utilisation ............................................................ 26 es Instrucciones de uso ........................................................ 51 Fridge-freezer Réfrigérateur / congélateur combiné Refrigerador/congelador

B36It900Np B36Bt930Ns

B30Ib900Sp B30Bb930Ss

Table of contents Instruction manual Important safety instructions . . . . . . . . . . . . 4 Definitions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 About these instructions . . . . . . . . . . . . . . . . . . . . . 4 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Risk of explosion. . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Risk of electric shock . . . . . . . . . . . . . . . . . . . . . . . 4 Risk of cold burns . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Risk of Injury . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Risk of fire. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Avoiding placing children and vulnerable people at risk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Damage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 State of California Proposition 65 Warnings . . . . . . 5 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . 6 Environmental protection . . . . . . . . . . . . . . 6 Packaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Old appliances . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Installation and connection . . . . . . . . . . . . . . 7 Contents of package. . . . . . . . . . . . . . . . . . . . . . . . 7 Technical data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Installing the appliance . . . . . . . . . . . . . . . . . . . . . . 7 Check built-in cut-out. . . . . . . . . . . . . . . . . . . . . . . . 7 Side-by-side installation . . . . . . . . . . . . . . . . . . . . . . 7 Saving energy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Before using for the first time . . . . . . . . . . . . . . . . . 9 Water connection . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Electrical connection . . . . . . . . . . . . . . . . . . . . . . . . 9 Getting to know your appliance . . . . . . . . . 10 2-door appliance . . . . . . . . . . . . . . . . . . . . . . . . . .10 3-door appliance . . . . . . . . . . . . . . . . . . . . . . . . . .11 Operating controls. . . . . . . . . . . . . . . . . . . . . . . . .12 Interior fittings . . . . . . . . . . . . . . . . . . . . . . . . . . .13 Operating the appliance . . . . . . . . . . . . . . . . 15 Switching the appliance on . . . . . . . . . . . . . . . . . .15 Switching off and disconnecting the appliance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15 Setting the temperature. . . . . . . . . . . . . . . . . . . . .15 Super cooling . . . . . . . . . . . . . . . . . . . . . . . . . . .15 Super freezing . . . . . . . . . . . . . . . . . . . . . . . . . . .15 Eco mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16 Vacation mode . . . . . . . . . . . . . . . . . . . . . . . . . .16 Sabbath mode. . . . . . . . . . . . . . . . . . . . . . . . . . .16 Switching ice cube production on or off . . . . . . . .16 Switching Prevent condensation on or off . . . . . . .16 Home Connect. . . . . . . . . . . . . . . . . . . . . . . . 17 Setting up Home Connect . . . . . . . . . . . . . . . . . . 17 Connecting the refrigerator to the Home Connect app . . . . . . . . . . . . . . . . . . . . . . . 17 Installing updates for the Home Connect software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 Customer Service access. . . . . . . . . . . . . . . . . . . 18 Reset settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 Switch on or off the connection to the home WLAN network (Wi-Fi). . . . . . . . . . . . . . . . . . . . . . 18 Information on data protection . . . . . . . . . . . . . . . 18 Alarm. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 Door alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 Refrigerator compartment. . . .

3 4 Customer service . . . . . . . . . . . . . . . . . . . . . 25 Appliance self-test . . . . . . . . . . . . . . . . . . . . . . . . .25 Repair order and advice on faults . . . . . . . . . . . . .25

9 Important safety instructions

Read Instructions - Do Not Discard!

Important safety instructions

Definitions

9 Warning

9 Caution

NOTICE: Non-observance of this information could damage the appliance.

Note: This indicates important information and/or tips.

About these instructions ■ Read and follow the operating and installation instructions. They contain important information on how to install, use and maintain the appliance.

■ The manufacturer is not liable if you disregard the instructions and warnings in the operating and installation instructions.

■ Retain all documents for subsequent use or for the next owner.

Introduction ■ This appliance complies with the relevant safety regulations for electrical appliances.

■ The refrigeration circuit has been checked for leaks.

Risk of explosion ■ Never use electric devices inside the appliance (e.g. heaters or electric ice makers).

■ Do not store products which contain flammable propellants (e.g. spray cans) or explosive substances in the appliance.

■ Only store high-proof alcohol tightly closed and standing up.

■ Do not use other means to accelerate the defrosting process other than those recommended by the manufacturer.

Risk of electric shock Improper installations or repairs may put the user at considerable risk.

■ When installing the appliance, make sure that the power cord does not get jammed or is not damaged.

■ If the power cord is damaged, immediately disconnect appliance from the power supply.

■ Do not use multiple outlets, extension leads, or adapters.

■ Before servicing or modifying the appliance, pull out the power plug or switch off the circuit breaker.

■ Before cleaning the appliance, press main On/Off switch to switch the appliance off.

■ Glass shelves or other fittings can be safely moved while the appliance is switched on.

■ Never cut through or remove the power cord's third conductor (earthing conductor).

■ Never defrost or clean the appliance with a steam cleaner. The steam may penetrate electrical parts and cause a short circuit.

■ The appliance, cable and accessories should only be repaired or replaced by the manufacturer, customer services, or a similarly qualified person.

■ Only use original parts supplied by the manufacturer.

9 Important safety instructions

Read Instructions - Do Not Discard!

5 Risk of cold burns ■ Never put frozen food straight from the freezer compartment into your mouth. ■ Avoid prolonged contact of skin with frozen food, ice and the tubes in the freezer compartment. Risk of Injury Containers which contain carbonated drinks may burst. Do not store containers which contain carbonated drinks in the freezer compartment. Risk of fire Portable multi-outlet power strips and portable power supplies may overheat, causing a fire. Never leave portable multi-outlet power strips or portable power supplies behind the appliance. Avoiding placing children and vulnerable people at risk At risk are: ■ Children, ■ People who have limited physical, mental or sensory abilities, ■ People who have inadequate knowledge concerning safe operation of the appliance. Measures: ■ Never allow children to play with the appliance. ■ Ensure that children and vulnerable people have understood the hazards. ■ Supervise children who are cleaning and maintaining the appliance. Risk of suffocation ■ If the appliance features a door lock: keep the key out of the reach of children. ■ Keep children away from the packaging and its parts. Damage To avoid damage: ■ Do not stand or support yourself on the base, runners or doors. ■ Keep plastic parts and door seals free of oil and grease. ■ Pull the power plug – not the power cord. Weight The appliance is very heavy. The appliance should always be transported and set up by at least 2 people. ~ "Installing the appliance" on page 7 State of California Proposition 65 Warnings This product may contain a chemical known to the State of California, which can cause cancer or reproductive harm. Therefore, the packaging of your product may bear the following label as required by California:

Intended use

Use this appliance ■ only for cooling and freezing food and for making ice. ■ only in the home and in the home environment. ■ only according to these operating instructions.

This appliance is intended for use at an elevation of no more than 2000 meters above sea level.

Environmental protection

Packaging

All materials are environmentally safe and recyclable: ■ Dispose of packaging in an environmentally responsible manner. ■ Please ask your dealer or inquire at your local authority about current means of disposal.

Old appliances

Valuable raw materials can be reclaimed by recycling old appliances.

Warning

Children May Become Locked In The Appliance And Suffocate!

Before disposing of your old appliance: ■ Remove the door. ■ Leave shelves and containers in the appliance to prevent children from climbing in. ■ Keep children away from the redundant appliance.

Caution

Refrigerant And Harmful Gases May Escape.

Do not damage the tubes of the refrigeration circuit or insulation.

Installation and connection 7 5 Installation and connection Installation and connectionContents of package After unpacking all parts, check for any damage during transport. If you have any complaints, please contact the dealer from whom you purchased the appliance or our customer service. ~ "Customer service" on page 25 The delivery consists of the following parts: ■ Built-in appliance ■ Interior fittings (depending on model) ■ Installation material ■ Instruction manual ■ Installation instructions ■ Customer service booklet ■ Warranty enclosure ■ Information on the energy consumption and noises Technical data Refrigerant, cubic capacity and further technical specifications can be found on the rating plate. ~ "Getting to know your appliance" on page 10 Installing the appliance Installation location The weight of the appliance may be up to 460 kg depending on the model. The base must be sufficiently stable and should not give. If necessary, reinforce the floor. Check built-in cut-out The cut-out must fulfill these criteria: ■ Anti-tilt bracket must be fitted ■ Cut-out depth min. 24" (610 mm), for flush installation 25" (635 mm) ■ rectangular ■ stable – the side panels and the top must be min. 5/8" (16 mm) thick and securely attached to the floor or wall ■ Depth of shortest side panels min. 4" (100 mm) Side-by-side installation Observe the specifications in the installation instructions for a side-by-side installation. If a partition wall is required between the appliances it must be at least 5/8" (16 mm) wide.

Installation and connection

Saving energy If you follow the instructions below, your appliance will use less power. Note: The arrangement of the fittings does not affect the energy consumption of the appliance.

Installing the appliance Keep the appliance out of direct sunlight. The appliance needs to cool less frequently at low ambient temperatures and therefore consumes less power. Install the appliance as far away as possible from heating elements, cooker and other heat sources: At least 1¼" (3 cm) from electric or gas cookers. At least 11¾" (30 cm) from oil or solid-fuel cookers. Select an installation location at a room temperature of approx. 68 °F (20 °C). Do not cover or block the ventilation openings. The appliance needs to cool less frequently if the warm air can escape and therefore consumes less power. Ventilate the room daily.

Using the appliance Open the appliance door only briefly. The air in the appliance does not warm up so intensely. The appliance needs to cool less frequently and therefore consumes less power. Transport purchased food in a cool bag and place in the appliance quickly. Allow warm food and drink to cool down before placing in the appliance. Thaw frozen food in the refrigerator compartment to utilize the low temperature of the frozen food. Always leave a space between the food and the back panel. The air can circulate and the humidity will remain constant. The appliance needs to cool less frequently and therefore consumes less power. Pack food airtight. Do not cover or block the ventilation openings. The appliance consumes less power if the warm air can escape. Vacuum the ventilation openings once a year.

Installation and connection 9

Before using for the first time

Water connection

9 Caution

Water pressure of drinking water system

9 Caution

Note: If the water pressure is too low, this will impair the relevant functions of the appliance. ■ Min. 0.2 Mpa (2 bar / 29 psi) ■ Max. 0.8 Mpa (8 bar / 116 psi)

Electrical connection

9 Caution

Note: You can connect the appliance to mains- controlled and sine-controlled inverters. Mains-controlled inverters are used for photovoltaic systems which are connected directly to the national grid. Sine-controlled inverters must be used for isolated applications. Isolated applications, e.g. on ships or in mountain lodges, are not directly connected to the national grid.

Requirements for outlets Maximum simultaneous load

9 Warning

Risk Of Electric Shock!

9 Warning

Risk Of Electric Shock!

Outlet with

110 V ... 120 V

10 A ... 16 A

6 A

Getting to know your appliance

Getting to know your appliance 2-door appliance

Refrigerator compartment

Freezer compartment

Operating controls

Main On/Off switch

Shelf for large bottles

Vegetable container with humidity controller

Chill compartment

Rating plate

Ice maker

Ice cube container

Frozen food container

Frozen food container (large)

Ventilation opening

Particle filter

Getting to know your appliance

3-door appliance

Refrigerator compartment Freezer compartment

Operating controls

Main On/Off switch Shelf for large bottles Vegetable container with humidity controller Chill compartment Rating plate Ice maker Ice cube container Frozen food container Frozen food container (large) Ventilation opening Particle filter Door pillar with condensation protection

Getting to know your appliance 12 Operating controls Mode selection To open mode selection, press menu button. To switch on a mode, tap on it. When a mode is switched on, it is highlighted in red in the mode selection menu. An Info window with additional information on the mode selected appears. Settings Tap Ò to open the settings. ( menu button Opens mode selection. 0 Ò button Opens the Settings menu. ~ "Settings" on page 12 8 Refrigerator compartment temperature display Indicates the set temperature in °C/°F. @ Freezer compartment temperature display Indicates the set temperature in °C/°F. Eco mode Switch the appliance to energy- saving mode. ~ "Eco mode" on page 16 Vacation mode If absent for a long time, you will save energy here. ~ "Vacation mode" on page 16 Sabbath mode All non-essential functions are switched off so you can also use the appliance on the Sabbath. ~ "Sabbath mode" on page 16 39

°F

°F

( 0 8 @ Language Change the display language. Home Connect Connect your refrigerator to your mobile device. ~ "Home Connect" on page 17 Tones Set the volume of the button tone and the signal tone. Display brightness Adjust the brightness of the display. Temperature unit Select the temperature unit °C/°F. Ice cube production Start or stop ice cube production. Stopping ice cube production is a good idea before cleaning the freezer compartment, or if you are going to be absent for a long time. Water filter counter If you have changed the water filter, you must reset the water filter counter. If you have replaced it with a bypass cartridge, you can switch the water filter counter off. ~ "Water filter" on page 14 Factory settings Set the settings of the appliance back to its factory settings on delivery. Self-test Start fault analysis on your appliance. Condensation protection (only on 3-door appliances) On 3-door appliances, a heater is built into the door pillar to prevent condensation. This menu is used to switch condensation protection on or off. ~ "Switching Prevent condensation on or off" on page 16 Demo mode Note: Do not store any food items while in demo mode, as the appliance then remains at room temperature. The cooling function of the appliance is switched off. You can use all other functions. After switching on the appliance, this menu item is displayed for 3 minutes. To switch demo mode on or off later, switch the appliance off and back on. The mode is displayed again for 3 minutes.

Getting to know your appliance 13 Interior fittings (not all models) Storage compartment You can remove and adjust the height of the storage compartments:

Getting to know your appliance 14 Ice pack In the event of a power failure or a fault: ■ The ice pack delays the warming of stored frozen food. Note: The longest storage time is obtained by placing the ice pack on the food in the top compartment. You can take out the ice pack to temporarily keep food cool, e.g. in a cool bag. Ice maker

Caution

Damage To The Appliance!

Operating the appliance

15

Operating the appliance

Switching the appliance on

Operating tips

■ When the appliance has been switched on, it may take several hours until the set temperatures have been reached. Do not put in any food until the selected temperature has been reached. ■ The fully automatic NoFrost system ensures that the freezer compartment remains free of ice. Defrosting is not required. ■ The front sides of the housing are partly heated slightly. This prevents condensation in the area of the door seal. ■ If the freezer compartment door cannot be immediately re-opened after it has been closed, wait until the resulting low pressure has equalized.

Switching off and disconnecting the appliance

Switching off the appliance

■ Press the main On/Off switch. The appliance is no longer cooling.

Disconnecting the appliance

Caution

Deterioration in water quality

The water supply must be turned off 3 hours before disconnecting. This prevents mold forming with any unused water.

If you do not use the appliance for a prolonged period:

Setting the temperature

Recommended temperature

Setting the refrigerator and freezer compartment temperature

Super cooling

Super cooling cools the refrigerator compartment as cold as possible.

Switch on super cooling, e.g.:

■ Before placing large quantities of food into the compartment ■ For cooling drinks quickly

Note: When super cooling is switched on, increased operating noises may occur.

After approx. 6 hours, the appliance switches to normal operation.

Switching super cooling on or off

Note: If you have made a setting to stop the pop-up window from appearing, you can return to the main screen with the x button. If the button is not pressed, the appliance saves the setting and automatically returns to the main screen after a few seconds.

Super freezing

Super freezing cools the freezer compartment as cold as possible.

Switch on super freezing, e.g.:

■ to quickly freeze food right through to the center ■ 4 ... 6 hours before freezing food weighing 2 kg or more

Note: When super freezing is switched on, increased operating noise may occur.

After approx. 2 days the appliance switches to normal operation.

Cooling compartment:

+39 °F (+4 °C)

Freezer compartment:

0 °F (–18 °C)

Operating the appliance

Switching super freezing on or off

Note: If you have made a setting to stop the pop-up window from appearing, you can return to the main screen with the x button. If the button is not pressed, the appliance saves the setting and automatically returns to the main screen after a few seconds.

Eco mode

Eco mode switches the appliance to energy-saving operation. The appliance automatically sets the following temperatures: ■ Refrigerator compartment: +43 °F (6 °C) ■ Freezer compartment: +3 °F (–16 °C)

Vacation mode

If leaving the appliance for a long period of time, you can switch it over to energy-saving holiday mode. Do not store any food in the refrigerator compartment during this time. The appliance automatically sets the following temperatures: ■ Refrigerator compartment: +57 °F (+14 °C) ■ Freezer compartment: unchanged

Ice cube production is deactivated.

Sabbath mode

All non-essential functions are switched off so you can also use the appliance on the Sabbath. Once Sabbath mode is switched on, you can also use the appliance on the Sabbath. ■ You can select a time between 1–96 hours. ■ After the selected time elapses, the appliance switches to normal operation. ■ To end Sabbath mode before the selected time elapses, touch the display and tap Switch off.

The appliance switches off the following: ■ Ice maker ■ Audible signals ■ Interior light ■ Messages on the display ■ Background illumination of display is reduced

Switching ice cube production on or off

Caution Damage to the appliance! Never store bottles or food in the ice cube container, even for short periods. This can block and damage the ice maker.

Ice cube production starts as soon as the appliance has reached the set temperature.

Note: Ice cube production stops automatically when the ice cube container is full.

Switching Prevent condensation on or off

This function is only available with 3-door appliances. 3-door appliances are equipped with a door pillar featuring condensation protection. You can open the left-hand door of the refrigerator compartment without opening the right-hand door beforehand.

Caution Never unfold the door pillar when the door is open! It can get jammed when closing the door and become damaged, or itself damage the front panel of the right-hand door.

A heater is built into the door pillar to prevent condensation. Switching condensation protection on or off switches the heater on or off.

~ "Condensation protection (only on 3-door appliances)" on page 12

Home Connect 17

Home Connect

This appliance is Wi-Fi-capable and can be controlled remotely using a mobile device.

Note: Wi-Fi is a registered trade mark of the Wi-Fi Alliance.

In the following cases, the appliance functions like a refrigerator without a network connection and can still be operated manually via the controls: ■ The appliance is not connected to a home network. ■ The availability of the Home Connect function depends on the availability of Home Connect services in your country. Home Connect services are not available in every country. You can find more information on www.home-connect.com.

Note: Please observe the safety information in this instruction manual. Ensure that this is also observed if you operate the appliance via the Home Connect app and are not at home when doing so.

~ "Important safety instructions" on page 4

Follow the instructions in the Home Connect app as well.

The appliance has a wireless transmitting module, via which the intelligent function of the appliance is realized. The CMIIT ID of the appliance is shown in the rating plate.

Setting up Home Connect

Notes ■ Wait at least 2 minutes after switching on the appliance before setting up Home Connect. Only then is internal appliance initialization complete. ■ Take note of the Home Connect supplementary sheet, which is supplied with the appliance or is available for download at www.bosch-home.com together with the instructions. Enter the E-number of your appliance in the search field.

You can connect your appliance to the home WLAN network (Wi-Fi) in 3 basic steps.

The first time you open the menu, you will be automatically guided through initial setup. Follow the instructions on the control panel. For further information, please also see the following chapters.

The following submenus can be found in the Home Connect menu: ■ Switching Wi-Fi on and off ■ Connect to app ■ Software update ■ Deleting network settings

Setting up the connection to the home network (WLAN)

The first time you open the menu, you will be automatically guided through initial setup. Follow the instructions on the control panel.

The refrigerator temporarily generates its own network for connecting the mobile device.

As soon as the refrigerator is connected to the mobile device, a connection between the refrigerator and your home network (WLAN) is established.

Note: If the connection cannot be established, check whether there is sufficient reception.

Verifying signal strength

The signal strength is displayed on the control panel. The signal strength should be at least 1 bar in addition to the dot. If the signal strength is too weak, the connection may be interrupted temporarily.

Improving signal strength

■ Place the router closer to the refrigerator. ■ Check that screening walls do not interfere with the connection. ■ Install a repeater to make the signal stronger.

Connecting the refrigerator to the Home Connect app

Use this menu to connect your refrigerator to mobile devices.

Home Connect 18 If the refrigerator is not automatically displayed, click on Add appliance in the app and follow the instructions. As soon as your refrigerator is displayed, add it with +.

Alarm 19

Door alarm

If the appliance door is open for a long time, the door alarm (continuous audible signal) switches on.

■ Close door.

The audible warning signal is switched off.

Refrigerator compartment

The refrigerator compartment is suitable for storing meat, sausages, fish, dairy products, eggs, ready meals and pastries.

The temperature can be set from +36 °F (+2 °C)... +46 °F (+8 °C).

The refrigerator compartment can also be used to store highly perishable groceries in the short to medium term. The lower the selected temperature, the slower the enzymatic and chemical processes and deterioration by microorganisms. A temperature of +39 °F (+4 °C) or lower ensures optimum freshness and safety of the stored groceries.

Note when storing food

Note: Avoid contact between food and the back panel.

Otherwise, the air circulation will be impaired and food or packaging may freeze to the back panel.

■ Store fresh, undamaged food.

The quality and freshness will then be retained for longer.

■ In the case of ready products and bottled goods, do not exceed the minimum sell-by date or use- by date indicated by the manufacturer.

■ To retain aroma, color and freshness, pack or cover food well before placing it into the appliance.

This will prevent flavors being transferred between foods and the plastic parts from becoming discolored.

■ Leave warm food and drinks to cool down before placing them into the refrigerator compartment.

Note the chill zones in the refrigerator compartment

The air circulation in the refrigerator compartment creates different chill zones.

Coldest zone

The coldest zone is in the interior at the back panel and in the chill compartment.

Note: Store delicate food (e.g. fish, sausages and meat) in the coldest zone.

Warmest zone

The warmest zone is at the very top of the door.

Note: Store e.g. hard cheese and butter in the warmest zone. Cheese can continue to release its aroma and the butter will still be easy to spread.

Vegetable container with humidity controller

The vegetable container is the optimum storage location for fresh fruit and vegetables. You can adjust the humidity in the vegetable container via the humidity controller and a special seal. This allows fresh fruit and vegetables to be stored up to twice as long as with conventional storage.

The humidity in the vegetable container can be set according to the type and quantity of products to be stored:

■ Mainly fruit as well as for a large load – set lower humidity with controller position Ú

■ Mainly vegetables as well as for a mixed or small load – set higher humidity with controller position Ù

Notes

■ For optimum preservation of quality and flavor store fruit sensitive to cold (e.g. pineapple, banana, papaya and citrus fruit) and vegetables sensitive to cold (e.g. eggplant, cucumbers, zucchini, peppers, tomatoes and potatoes) outside of the appliance at temperatures of approx. +46 °F (+8 °C) ... +54 °F (+12 °C).

■ Condensation may form in the vegetable container depending on the type and quantity of products stored.

Remove condensation with a dry cloth and adjust the humidity in the vegetable container with the humidity controller.

Chill compartment

The chill compartment has lower temperatures than the refrigerator compartment. Temperatures below +32 °F (0 °C) may occur.

Ideal for storing fish, meat and sausage. Not suitable for salads, vegetables and groceries sensitive to cold.

The temperature in the chill compartment can be adjusted.

Freezer compartment

Freezer compartment

The freezer compartment is suitable for: ■ storing frozen food ■ making ice cubes ■ freezing food

The temperature can be set from -11 °F (-24 °C)... +7 °F (-14 °C).

The freezer compartment can be used to store perishable foods long-term almost without any noticeable reduction in quality, as the low temperatures considerably slow down or stop deterioration. Appearance, flavor and all valuable ingredients are largely retained.

The time between putting fresh food in the freezer compartment and it freezing solid depends on the following factors: ■ temperature set ■ type of food ■ amount of food in the freezer compartment ■ quantity and type of storage

Fully utilizing the freezer volume

To place the maximum quantity of frozen food in the freezer compartment: ■ Remove all fittings. ■ Store food directly on the shelves and on the floor of the freezer compartment.

Purchasing frozen food

■ Ensure the packaging is not damaged. ■ Check there is a sell-by date. ■ The temperature in the supermarket freezer must be 0 °F (-18 °C) or lower. ■ Do not interrupt the freezing chain. If possible, transport frozen food in a cool bag and place in the freezer compartment quickly.

When loading products

■ Freeze large quantities of food in the top compartment. This is where it will freeze especially quickly and gently. ■ Distribute food in the compartments or frozen food containers. ■ Do not bring food which is to be frozen into contact with frozen food. If required, restack frozen food in the frozen food containers. ■ Important for unrestricted air circulation in the appliance: push in frozen food containers up to the limit stop.

Freezing fresh food

Freeze only fresh and undamaged food.

Food which is boiled, fried or baked is more suitable for freezing than food which is eaten raw.

Before freezing food, make preparations appropriate to the food in order to retain the best possible nutritional value, flavor and color: ■ Vegetables: wash, chop, blanch. ■ Fruit: wash, pit and perhaps peel, possibly add sugar or ascorbic acid solution.

Information on how to do this can be found in relevant literature.

Suitable for freezing

■ Baked goods ■ Fish and seafood ■ Meat ■ Poultry and game ■ Vegetables, fruit and herbs ■ Eggs without shells ■ Dairy products, e.g. cheese, butter and quark ■ Ready meals and leftovers, e.g. soups, stews, cooked meat and fish, potato dishes, soufflés and desserts

Not suitable for freezing

■ Types of vegetables which are usually eaten raw, e.g. lettuce or radishes ■ Unpeeled or hard-boiled eggs ■ Grapes ■ Whole apples, pears and peaches ■ Yoghurt, soured milk, sour cream, creme fraiche and mayonnaise

Packing frozen food

The correct type of packaging and material selection are decisive factors in the retention of the product quality and prevent the development of freezer burn.

Suitable packaging: ■ Plastic foil ■ Tubular foil made of polyethylene (PE) ■ Aluminum foil ■ Freezer containers

Suitable closures: ■ Rubber bands ■ Plastic clips ■ Cold-resistant adhesive tape

Defrosting

Unsuitable packaging: ■ Wrapping paper ■ Greaseproof paper ■ Cellophane ■ Garbage bags and used grocery bags

Shelf life of frozen food at 0 °F (-18 °C)

Fish, sausage, ready meals, and cakes and pastries: up to 6 months

Meat, poultry: up to 8 months

Vegetables, fruit: up to 12 months

Thawing frozen food

The thawing method must be adjusted to the food and application in order to retain the best possible product quality.

Thawing methods: ■ in the refrigerator compartment (especially suitable for animal-based foods such as fish, meat, cheese, quark) ■ at room temperature (bread) ■ in the microwave (food for immediate consumption or immediate preparation) ■ in the oven/cooker (food for immediate consumption or immediate preparation)

Caution

Do not refreeze partly or completely thawed food. You can only refreeze food once it has been cooked (boiled or fried).

The frozen food can no longer be stored for the maximum duration.

Defrosting Freezer compartment

The fully automatic NoFrost system ensures that the freezer compartment remains free of ice. Defrosting is no longer required.

Cleaning

Caution — Avoid Damaging The Appliance And The Fittings

■ Do not use abrasive, chloride-based or acidic cleaning agents or solvents. ■ Do not use scouring or abrasive sponges. The metallic surfaces may corrode. ■ Never clean the shelves or containers in the dishwasher. The parts may become deformed.

Cleaning the display

The change in temperature and humidity can cause the controls to steam up. Use a clean micro-fiber cloth for cleaning.

Cleaning the appliance interior

Proceed as follows:

Caution

The rinsing water must not run into the light or through the drainage hole into the evaporation area.

Cleaning the fittings

To clean, take the variable parts out of the appliance.

See "Interior fittings" on page 13

Care instructions for stainless steel surfaces

When taking care of and cleaning stainless steel surfaces, use only cleaning agents suitable for stainless steel and a stainless steel cleaning cloth. You can purchase a suitable stainless steel cleaning cloth from customer service.

To prevent visible scratches, clean the stainless steel surface in the direction of the structure.

Odors

If you experience unpleasant odors:

Changing the odor filter

Replacement filters are available from your customer service.

Lighting

Your appliance features a maintenance-free LED light. Only customer service or authorized technicians may repair the light.

Noises

Normal noises

Droning: A motor is running, e.g. refrigerating unit, ventilator. Bubbling, buzzing or gurgling: Refrigerant is flowing through the tubes. Clicking: Motor, switches or solenoid valves are switching on or off. Cracking: Automatic defrosting is running.

Preventing noises

Appliance is not level: Align appliance using a water level. If required, place a little packing underneath. Containers, shelves or storage compartments wobble or stick: Check the removable fittings and re-insert if required.

Faults – what to do? 23 3 Faults – what to do?

Before you call customer service, use this table to check whether you can rectify the fault yourself.

Appliance

Temperature differs greatly from the set value. Switch off appliance for 5 minutes. ~ "Switching off and disconnecting the appliance" on page 15 If the temperature is too warm, check temperature again after a couple of hours. If the temperature is too cold, check temperature again on the following day.

Displays do not illuminate. The power plug has not been inserted properly. Connect the power plug. The fuse has tripped. Check the fuses. The power has failed. Check whether the power is on.

The refrigeration unit is switching on more frequently and for longer. The appliance was opened frequently. Do not open the appliance unnecessarily. The ventilation openings are covered up. Remove obstacles. Large quantities of fresh food have been put in. Switch on super cooling promptly in advance.

Appliance is not cooling, display and lighting are lit. Demo mode is switched on. Switch demo mode off. ~ "Settings" on page 12

Faults – what to do? 24 Ice maker -------- The ice maker is not functioning. Ice cube production is switched off. Switch on ice cube production. Freezer compartment is too warm. Set the temperature lower. ~ "Operating the appliance" on page 15 Ice cube container is not properly inserted. Insert ice cube container fully. Ice maker without power. Call customer service. ~ "Customer service" on page 25 No water supply. Check water connection and contact technician if necessary. Low water pressure. Only connect appliance to pipes with sufficient water pressure. Kink in water hose. Turn off water supply, straighten out kink. Replace water hose, if necessary. Too few or deformed ice cubes, water pressure lower than usual. After switching on or removing many ice cubes, there will be too few in the ice cube container. It takes around 24 hours for an empty ice cube container to fill up. Ice cube production stops even though the ice cube container is still not full. Do not store the ice shovel on the ice in the ice cube container. Otherwise, the sensor will not detect the actual fill level of the container. Low water pressure. Only connect appliance to pipes with sufficient water pressure. The water filter is blocked or needs to be replaced. Replace water filter. Freezer compartment is too warm. Set the temperature lower. ~ "Operating the appliance" on page 15 Water is leaking out of the appliance. Water connection is not tight. Check if the connections are fastened firmly and the water hose is undamaged. If the water hose is damaged, contact customer service and have it replaced. Replacement must be performed by customer service or a similarly qualified person only. Use original parts supplied by the manufacturer only.

Customer service 25 Customer service

If you are unable to rectify the fault, please contact our customer service. We will always find an appropriate solution in order to avoid unnecessary visits by engineers.

The contact information for your nearest customer service can be found here or on the enclosed customer service list.

When calling, please state the product number (E-Nr.) and the production number (FD), which can be found on the rating plate.

~ "Getting to know your appliance" on page 10

Trust the expertise of the manufacturer. You can therefore be sure that the repair is carried out by trained service engineers who carry original spare parts for your home appliances.

Appliance self-test

Your appliance features a self-test program which displays the fault your customer service can rectify.

The self-test program starts.

When the self-test has ended, the appliance switches to normal operation.

Repair order and advice on faults

Contact information for all countries can be found on the enclosed customer service list.

GB 0344 892 8979 Calls charged at local or mobile rate

IE 01450 2655 0.03 € per minute at peak. Off peak 0.0088 € per minute.

US 800 944 2904 toll-free

Customer service

Important Safety Instructions

Definitions

⚠ Warning

⚠ Caution

NOTICE: This caution indicates a risk of damage to the appliance.

Note: This symbol is used to identify important information or tips.

About This Manual

■ Please read and follow the contents of this user and installation manual. It contains important information regarding the installation, use, and maintenance of the appliance.

■ The manufacturer assumes no responsibility if you do not follow the notes and warnings contained in the installation and user manuals.

■ Please keep all of these documents for future reference or in case the appliance changes ownership.

Introduction

■ This appliance complies with applicable safety regulations for electrical appliances.

■ The refrigeration circuit has undergone a leak test.

Explosion Risk

■ Do not use electrical appliances inside the appliance (for example, heating devices, ice makers).

■ Do not store any products containing flammable propellant gases (for example, aerosol cans) or explosive substances in the appliance.

■ Keep bottles of high-alcohol beverages only tightly sealed and upright.

■ Except for manufacturer instructions, do not take any measures to accelerate the defrosting of the appliance.

Electrical Shock Risk

Incorrect installation or repair can pose serious risks to the user.

■ Be careful not to pinch or damage the power cord when positioning the appliance.

■ If the power cord is damaged: immediately unplug the appliance from the power outlet.

■ Do not use extension cords, power strips, or adapters.

■ Unplug the power plug or switch the circuit breaker to the off position before performing maintenance or modifications to the appliance.

Before cleaning the appliance, operate the main On/Off switch to turn off the appliance.

Glass shelves and other equipment can be safely moved while the appliance is running.

■ Never remove or cut the third conductor (grounding conductor) from the power cord.

■ Never defrost or clean the appliance with a steam cleaner. Steam may reach electrical parts and cause a short circuit.

Proper Use

Use this appliance only for refrigerating and freezing food products and for preparing ice. ■ Only in a household and domestic environment. ■ Only in compliance with this user manual.

This appliance is designed for use up to a maximum altitude of 2000 m.

Environmental Protection

Packaging

All materials are non-polluting and recyclable: ■ Dispose of packaging in an environmentally responsible manner. ■ Please inquire about waste disposal methods from your retailer or local authority.

Used Appliance

Environmentally responsible disposal allows for recovery of valuable raw materials.

Warning

Risk of children becoming trapped in the appliance and suffocating.

Before sending the appliance for recycling: ■ Remove the door. ■ To discourage children from climbing into the appliance, do not remove the shelves and bins. ■ Keep children away from the appliance that is no longer in use.

Caution

Refrigerant fluid and harmful gases may be released.

Take care not to damage the refrigerant circuit tubing or insulation.

Installation and Setup

Installation and Setup

Delivery Contents

After unpacking the product, inspect all parts for any damage from transport.

In case of claims, please contact the retailer where you purchased the appliance or our customer service.

~ "Customer Service" on page 50

The delivery includes the following parts:

■ Built-in appliance ■ Equipment (depending on model) ■ Mounting hardware ■ User manual ■ Installation instructions ■ Customer service booklet ■ Warranty addendum ■ Energy consumption and noise information

Technical Data

The rating plate indicates the refrigerant, useful volume, and other information.

~ "Appliance Overview" on page 34

Installing the Appliance

Installation Location

Depending on the model, the appliance weight can reach 460 kg. The floor must be sufficiently stable; it must not sag. Reinforce the floor if needed.

Check the Installation Cavity

The cavity must meet the following criteria:

■ The anti-tip bracket must be installed ■ The cavity must have a depth of at least 24 in (610 mm) or 25 in (635 mm) for a flush installation ■ At right angles ■ Stable – the side walls and ceiling must be at least 5/8 in (16mm) thick and be securely connected to the floor or wall ■ Depth of shortened side walls of at least 4 in (100 mm)

Side-by-Side Installation

If you choose a side-by-side installation, follow the instructions in the installation manual.

If a partition wall is necessary between the appliances, it must be at least 5/8 in (16 mm) wide.

Saving Energy

If you follow the instructions below, your appliance will consume less electricity.

Note: The arrangement of equipment parts has no influence on the appliance's energy consumption.

Installing the Appliance

Protect the appliance from direct sunlight. In the presence of low ambient temperatures, the appliance needs to refrigerate less frequently and therefore consumes less electricity.

Install the appliance as far as possible from a radiator, stove, and other heat sources: Minimum 1¼" (3 cm) from an electric or gas stove. Minimum 11¾" (30 cm) from an oil or charcoal heating appliance.

Choose an installation location where the ambient temperature is approximately 68 °F (20 °C).

Do not cover or block the ventilation openings. The appliance consumes less electricity if hot air can escape.

Ventilate the room daily.

Using the Appliance

Open the appliance door only briefly. The air inside the appliance does not heat up as strongly. The appliance needs to refrigerate less frequently and consumes less electricity in this way.

Transport purchased food products in an insulated bag and store them quickly in the appliance.

Allow hot dishes to cool before storing them in the appliance.

To thaw frozen products, store them in the refrigerator compartment to benefit from the cold of the frozen products.

Always leave a little space between food products and the rear wall. Air can circulate in this way and air humidity remains constant. The appliance needs to refrigerate less frequently and consumes less electricity in this way.

Wrap food products hermetically.

Do not cover or block the ventilation openings. The appliance consumes less electricity if hot air can escape.

Once a year, vacuum the back of the appliance.

Product Overview 34

*Product Overview Two-Door Refrigerator

Refrigerator Compartment

Freezer Compartment

Control Elements

Main Power Switch

Shelf for Large Bottles

Vegetable Drawer with Humidity Control

Cold Compartment

Nameplate

Ice Dispenser

Ice Cube Tray

Frozen Product Tray

Large Frozen Product Tray

Air Intake

Particle Filter

Three-Door Refrigerator

Refrigerator Compartment

Freezer Compartment

Control Elements

Main Power Switch

Shelf for Large Bottles

Vegetable Drawer with Humidity Control

Cold Compartment

Rating Plate

Ice Dispenser

Ice Bin

Frozen Food Bin

Large Frozen Food Bin

Air Vent

Particle Filter

Door Frame with Anti-Condensation Protection

36 Control Elements Operating Mode Selection To open the operating mode selection, press the menu key. Press an operating mode to activate it. If an operating mode is activated, it appears with a red background in the Operating Mode Selection menu. A window appears with additional information about the operating mode. Settings To open the settings, press Ò.

( Menu Key Opens the operating mode selection. 0 Ò Key Opens the Settings menu.

8 Refrigerator Compartment Temperature Display Displays the set temperature in °C/°F.

@ Freezer Compartment Temperature Display Displays the set temperature in °C/°F.

Eco Mode Eco mode allows you to save energy during appliance operation.

Holiday Mode Save energy during extended absences.

Sabbath Mode In Sabbath mode, all non-essential functions are turned off so you can use the appliance even on the Sabbath.

Language Change the display language.

Home Connect Connect your refrigerator to your mobile device.

Sounds Adjust the volume of button and signal sounds.

Display Brightness Adjust the screen brightness.

Temperature Unit Select temperature unit °C/°F.

Ice Cube Production Start or stop ice cube production. Stopping ice cube production is useful before cleaning the appliance or during extended absences.

Water Filter Counter Reset the water filter counter when you change the water filter. If you replace it with a bypass filter cartridge, you can disable the water filter counter.

Factory Settings To reset the appliance factory settings.

Autodiagnostic To run an error analysis of your appliance.

Anti-Condensation Protection (exclusive to 3-door appliance) The door frame of the 3-door appliance contains a heating element to prevent condensation. This menu allows you to activate or deactivate anti-condensation protection.

Demo Mode Note: Do not fill the appliance with food products in demo mode, as it remains at room temperature. The appliance refrigeration function is deactivated. All other functions are available to you. This menu item remains lit for 3 minutes after the appliance starts up. To activate or deactivate demo mode later, you must restart the appliance. The mode becomes visible again for 3 minutes.

Equipment (depending on model)

Shelves You can remove the shelves and adjust their height:

Note: Insert the shelf carefully to avoid scratching the appliance.

Drawers You can remove the drawer and adjust its position:

Note: Place the drawer carefully to avoid scratching the appliance.

Tray You can remove the tray: ■ Push the tray toward the back ■ Lift it from the rear and remove it

You can insert the tray: ■ Fully extend the slide rails ■ Place the tray on the slide rails and push it into the appliance until it clicks into place

Cold Accumulators In case of power failure or malfunction: ■ The cold accumulator slows the warming of frozen products stored in it.

Note: Maximum storage duration is achieved if you place the cold accumulator on food products located in the highest compartment.

You can remove the cold accumulator to temporarily keep food products cool, for example in an insulated bag.

Using the Appliance 39

1 Using the Appliance

Turning On the Appliance

Notes Regarding Appliance Operation

■ Once turned on, the appliance may take several hours to reach the set temperatures. Do not store food products until the desired temperature is reached. ■ Thanks to the fully automatic NoFrost system, the freezer compartment does not become covered with frost. Defrosting is not necessary. ■ The appliance slightly heats part of its front surfaces. This prevents water condensation in the door seal area. ■ If the freezer compartment door cannot be reopened immediately after closing, wait a moment to allow the pressure difference in the compartment to equalize.

Stopping and Storing the Appliance

Turning Off the Appliance

■ Press the main power switch On/Off. The appliance no longer refrigerates.

9 Caution

Water Supply Degradation

The water supply must be stopped 3 hours before the appliance is turned off. This will prevent mold formation due to water residue.

If the appliance is to remain unused for a long time:

Setting the Temperature

Recommended Temperature

Setting the Temperature of the Refrigerator and Freezer Compartments

Super-Refrigeration

During super-refrigeration, the refrigerator compartment cools to maximum. Activate super-refrigeration for example in the following cases: ■ before storing large quantities of food. ■ to quickly chill beverages.

Note: If you have activated super-refrigeration, the appliance may operate more noisily.

After 6 hours, the appliance returns to normal operation.

Activating or Deactivating Super-Refrigeration

Note: If you have disabled the window display in your settings, press the x button to return to the main screen. If you do not press the button, the appliance registers the setting and automatically returns to the main screen after a few seconds.

Super-Freezing

During super-freezing, the freezer compartment cools to maximum. Activate super-freezing for example: ■ to freeze food products to the core quickly ■ 4...6 hours before storing 2 kg or more of food products

Note: If you have activated super-freezing, the appliance may operate more noisily.

After 2 days and approximately, the appliance returns to normal mode.

Refrigerator Compartment:

39 °F (4 °C)

Freezer Compartment:

0 °F (–18 °C)

Using the Appliance

Activate or Deactivate Super Freezing

Note: If you have disabled the popup window in your settings, press the x button to return to the main screen. If you do not press the button, the appliance saves the setting and automatically returns to the main screen after a few seconds.

Eco Mode Eco mode allows you to save energy when operating the appliance. The appliance automatically sets the following temperatures: ■ Refrigeration compartment: +43 °F (6 °C) ■ Freezing compartment: +3 °F (–16 °C)

Vacation Mode If you will be absent for an extended period, you can set the appliance to Vacation mode, which saves energy. During this period, do not store food products in the refrigeration compartment. The appliance automatically sets the following temperatures: ■ Refrigeration compartment: +57 °F (+14 °C) ■ Freezing compartment: unchanged

Ice production is deactivated.

Sabbath Mode In Sabbath mode, all non-essential functions are turned off so you can use the appliance even on the Sabbath. Sabbath mode allows you to use the appliance even on the Sabbath. ■ It can be set for a duration of 1 to 96 hours. ■ Once the set duration has elapsed, the appliance returns to normal mode. ■ To end Sabbath mode before the period expires, touch the screen and press Off.

The appliance turns off the following components: ■ Ice dispenser ■ Audio signals ■ Interior lighting ■ On-screen messages ■ The brightness of the screen backlight is reduced

Starting and Stopping Ice Production

Warning

Ice production begins as soon as the appliance reaches the set temperature.

Note: Ice production stops automatically when the ice reservoir is full.

Activate or Deactivate Anti-Condensation Protection This function is only available for 3-door appliances. 3-door appliances are equipped with a door mullion with anti-condensation protection.

You can open the left door of the refrigeration compartment without opening the right door first.

Warning

The door mullion contains a heating element to prevent condensation. Turn it on or off by activating or deactivating anti-condensation protection.

~ "Anti-condensation protection (exclusive to 3-door appliance)" on page 36

Home Connect 41

o Home Connect

The appliance has a wireless transmitting module, via which the intelligent function of the appliance is realized. The CMIIT ID of the appliance is shown in the rating plate.

Configuring Home Connect

Notes ■ After switching on the appliance, wait at least 2 minutes before configuring Home Connect. The internal initialization of the appliance will then be complete. ■ Observe the Home Connect information sheet supplied with the appliance or available at www.bosch-home.com among the instructions for download. Enter the E number of your appliance in the search field.

Three basic steps are required to connect your appliance to the home network WLAN (Wi-Fi).

When you open the menu for the first time, you are automatically guided through the initial setup. Follow the instructions on the control panel. You will find additional information in the following chapters.

The Home Connect menu includes the following submenus: ■ Enable/disable Wi-Fi ■ Connect with application ■ Software update ■ Delete network settings

Configuring the connection to the home network (WLAN)

When you open the menu for the first time, you are automatically guided through the initial setup. Follow the instructions on the control panel.

The refrigerator temporarily generates its own network to which the mobile device is connected.

Once the connection between the refrigerator and mobile device is established, a connection is established between the refrigerator and your home network (Wi-Fi).

Note: If you are unable to establish the connection, check the signal quality.

Checking signal strength

The signal strength is indicated on the control panel. The signal must have a minimum strength of 1 bar. The connection may be disrupted if the signal strength is too weak.

Improving signal strength

■ Move the router closer to the refrigerator. ■ Make sure the connection is not obstructed by walls. ■ Install a repeater to amplify the signal.

Home Connect 42

Connecting the refrigerator to the Home Connect app

With this menu, you can connect your refrigerator to mobile devices.

Installing a Home Connect software update

The refrigerator regularly checks whether Home Connect software updates are available. A notification window appears on the control panel as soon as an update is available. To install the update, press Install now.

Postponing a software update installation:

Accessing customer service

When you contact customer service, they can access your appliance and its status with your consent. To do this, your appliance must have been connected to the home network. You will find more information about customer service access and its availability in your country at www.home-connect.com, under Help & Support.

Resetting settings

If a problem occurs when attempting to connect or if you want to connect the appliance to another home network WLAN (Wi-Fi), the Home Connect settings can be reset.

Enabling or disabling the home network WLAN (Wi-Fi) connection

Door Alarm

If the refrigerator door remains open for an extended period, the door alarm sounds (continuous tone).

■ Close the door. The alarm sound will turn off.

Refrigerator Compartment

The refrigerator compartment is suitable for storing meat, cold cuts, fish, dairy products, eggs, prepared meals, and pastries.

The temperature is adjustable between 36 °F (2 °C) and 46 °F (8 °C).

With cold storage, you can also store highly perishable food items for short to medium periods. The lower the selected temperature, the slower the enzymatic and chemical processes and deterioration from microorganisms. A temperature of 39 °F (4 °C) or lower ensures optimal cooling and food safety for stored products.

Storage Guidelines

Note: Avoid allowing food products to come into contact with the rear wall.

This can obstruct air circulation and food or its packaging may stick to the rear wall.

■ Store fresh, intact food products. They will maintain their quality and freshness longer this way.

■ Observe the minimum shelf life or expiration date indicated by the manufacturer for prepared and packaged liquid products.

■ To preserve aroma, color, and freshness, store food products well wrapped or covered. This also prevents certain foods from transferring their flavor to others and prevents discoloration of plastic components.

■ Allow hot food products and beverages to cool before placing them in the refrigerator compartment.

Temperature Zones in the Refrigerator Compartment

Air circulation in the refrigerator compartment creates different temperature zones.

Coldest Zone

The coldest zone is located in the interior compartment, against the rear wall and in the cold compartment.

Note: Store the most delicate foods here (such as fish, cold cuts, meat).

Least Cold Zone

The least cold zone is located at the very top, near the door.

Note: Store items such as hard cheese and butter here. Cheese can continue to develop its flavor and butter remains spreadable.

Freezer Compartment

Freezer Compartment

The freezer compartment is used to: ■ store frozen products ■ prepare ice cubes ■ freeze food products

The temperature is adjustable between –11 °F (–24 °C) and +7 °F (–14 °C).

Freezing allows you to store perishable foods for extended periods without significant loss of quality, as low temperatures slow down or stop deterioration. Appearance, aroma, and all ingredients remain largely preserved.

The time required for fresh products placed in the freezer to freeze solid depends on the following factors: ■ Set temperature ■ Type of food product ■ Degree of fullness of the freezer compartment ■ Quantity and type of storage

Using the full freezing capacity

To accommodate the maximum amount of frozen products: ■ remove all equipment pieces. ■ Place food products directly on the shelves and bottom of the freezer compartment.

Purchasing frozen products ■ Check that the packaging is intact. ■ Do not exceed the expiration date. ■ The temperature in the supermarket freezer must be a maximum of 0 °F (–18 °C). ■ Do not break the cold chain: preferably use an insulated bag for transport, then store the products as quickly as possible in the freezer compartment.

Storage guidelines ■ Freeze larger quantities of food in the upper compartment. They will freeze fastest and most gently there. ■ Spread food products over a large surface in the compartments or frozen product drawers. ■ Ensure that food products to be frozen do not come into contact with already frozen products. If necessary, rearrange already solid frozen products in the drawers. ■ Important instruction for proper air circulation in the appliance: Insert the frozen product drawer until it stops.

Freezer Compartment

Freezing Fresh Products

To freeze foods, use only fresh foods with an impeccable appearance.

Foods consumed cooked (including oven-baked) and roasted are better suited for freezing than foods consumed raw.

Before freezing, foods must be subjected to different preparation processes depending on the variety, to best preserve their nutritional value, aroma and color:

■ Vegetables: Washing, grinding, blanching. ■ Fruits: Washing, pitting and peeling as needed; add sugar or ascorbic acid solution if appropriate.

You will find advice on this in specialized literature.

Suitable for Freezing

■ Bread and pastries ■ Fish and seafood ■ Meat ■ Game and poultry ■ Fruits, vegetables and herbs ■ Eggs without shells ■ Dairy products, e.g. cheese, butter and quark ■ Ready-made dishes and leftover dishes, for example soups, stews, cooked meat, cooked fish, potato-based dishes, soufflés and sweet dishes

Not Suitable for Freezing

■ Varieties of vegetables usually consumed raw, for example salads or radishes ■ Eggs with shells or hard-boiled eggs ■ Grapes ■ Whole apples, pears, peaches ■ Yogurt, sour milk, sour cream, fresh cream and mayonnaise

Wrapping Frozen Foods

The correct nature of packaging and choice of material decisively affect the preservation of product quality and prevent the appearance of freezer burn.

Suitable Packaging:

■ Plastic sheets ■ Polyethylene sheets ■ Aluminum foil ■ Freezing boxes

Appropriate Closure Methods:

■ Rubber bands ■ Plastic clips ■ Cold-resistant adhesive tapes

Unsuitable Packaging:

■ Wrapping paper ■ Parchment paper ■ Cellophane ■ Trash bags and already-used shopping bags

Storage Duration of Foods Frozen at –18 °C

Fish, cold cuts, ready-made dishes, pastries: up to 6 months

Meat, poultry: up to 8 months

Fruits and vegetables: up to 12 months

Thawing Products

The thawing method must be adapted to the food product concerned and the intended use in order to best preserve product quality.

Thawing Methods:

■ In the refrigerator compartment (particularly suitable for animal-origin foods such as fish, meat, cheese and quark) ■ At room temperature (bread) ■ In the microwave (food products intended for immediate consumption or preparation) ■ Oven/stove (food products intended for immediate consumption or preparation)

Caution

Do not refreeze food products that are partially or completely thawed. You can only refreeze after transforming the food into a ready-to-eat dish (cooked dish, including oven-baked).

Do not use the full maximum storage duration of the frozen product.

Cleaning

ATTENTION Avoid Damaging the Appliance and Its Equipment Parts.

■ Do not use any cleaning products or solvents containing sand, chloride, or acid. ■ Never use abrasive sponges or sponges that may scratch. Corrosion may appear on metal surfaces. ■ Never clean shelves and containers in the dishwasher. These parts could become deformed!

Cleaning the Display

Due to temperature changes and air humidity, the control elements may fog up. Use a microfiber cloth for cleaning.

Cleaning the Interior Compartment of the Appliance

Proceed as follows:

Attention Ensure that rinsing water does not enter the lighting system and does not reach the evaporation area via the drainage opening.

Cleaning the Equipment

To clean, remove the variable parts from the appliance.

Maintenance Instructions for Stainless Steel Surfaces

For cleaning stainless steel surfaces, use only cleaners and cloths specially designed for this type of surface.

To obtain a cloth specially designed for stainless steel surfaces, contact customer service.

To prevent marks on the appliance surface, wipe the stainless steel surface in the direction of its grain.

Odors

If unpleasant odors manifest:

Change the Odor Filter

Replacement filters are available from your customer service.

Lighting

Your appliance is equipped with maintenance-free LED lighting. Only customer service or authorized specialists are permitted to repair the lighting.

Noises

Normal Noises

Humming: A motor is running, for example the cooling unit, a fan. Gurgling, humming or sloshing: Refrigerant is circulating through the pipes. Clicking: The motor, switches, or solenoid valves are turning on/off. Cracking: Automatic defrosting is in progress.

Preventing Noises

The appliance is not level: Adjust the appliance using a bubble level. If necessary, insert something under the appliance. Containers, shelves, or storage are wobbling or getting stuck: Check the removable equipment parts and reposition them as needed.

Troubleshooting

Before calling customer service, please check if the table below does not already contain the solution you need.

Appliance

The actual temperature differs significantly from the set temperature.

Turn off the appliance for 5 minutes. See "Stopping and Storing the Appliance" on page 39

If the temperature is too high, check it again after a few hours.

If the temperature is too low, check it again the next day.

No indicator light turns on.

Male plug incorrectly connected to the power outlet.

Reconnect the contact plug.

Fuse triggered.

Inspect the fuses.

Power is out.

Check for power.

The refrigeration unit switches on more and more frequently and for longer periods.

The appliance was opened frequently.

Do not open the appliance unnecessarily.

Ventilation openings are blocked.

Remove obstacles.

The appliance is filled with large quantities of fresh food products.

Activate super-refrigeration sufficiently in advance.

The appliance does not refrigerate, the display and lighting are on.

Demo mode is activated.

Turn off Vacation mode. See "Settings" on page 36

51

8 Intended Use . . . . . . . . . . . . . . . . . . . . . . . . . 55 7 Environmental Protection . . . . . . . . . . . . . . 55 Packaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55 Used Appliance . . . . . . . . . . . . . . . . . . . . . . . . . . .55 5 Installation and Connection . . . . . . . . . . . . 56 Material Supplied . . . . . . . . . . . . . . . . . . . . . . . . .56 Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . .56 Install the Appliance . . . . . . . . . . . . . . . . . . . . . . .56 Check the Recess . . . . . . . . . . . . . . . . . . . . . . . . .56 Side by Side Installation . . . . . . . . . . . . . . . . . . .56 Save Energy . . . . . . . . . . . . . . . . . . . . . . . . . . . . .57 Before First Use . . . . . . . . . . . . . . . . . . . . . . . . . .58 Water Supply Connection . . . . . . . . . . . . . . . . . . .58 Electrical Connection . . . . . . . . . . . . . . . . . . . . . .58

9 Important Safety Instructions

Read and Keep These Instructions!

Important Safety Instructions 53

Definitions

9 Warning

9 Caution

NOTICE: Disregarding this warning can cause damage to the appliance.

Note: This indicates important information and/or advice.

About This Manual

■ Read and follow the operating and assembly instructions. They contain important information about the installation, use, and maintenance of the appliance.

■ The manufacturer is not responsible if you disregard the instructions and warnings in the operating and assembly instructions.

■ Keep all operating and assembly instructions for future reference and for subsequent owners.

Introduction

■ This appliance complies with specific safety standards for electrical appliances.

■ The sealing of the refrigeration circuit is verified at the factory.

Explosion Hazard

■ Never use electrical appliances inside the appliance (for example, heaters or electric ice makers).

■ Do not store products containing propellant gases or flammable substances (for example, aerosol cans), nor explosive materials in the appliance.

■ Store high-proof alcohol only in sealed containers and in an upright position.

■ Except as indicated by the manufacturer, do not take additional measures to accelerate defrosting.

Risk of Electric Shock

Improper installation or repair can pose serious dangers to the user.

■ When installing the appliance, ensure that the power cord is not trapped or damaged.

■ If the power cord is damaged: unplug the appliance from the electrical outlet immediately.

■ Never use multiple outlets, extension cords, or adapters.

■ Before performing maintenance or modifications to the appliance, disconnect the plug or turn off the circuit breaker.

Before cleaning the appliance, press the main switch for connection/disconnection to turn it off.

Glass shelves and other equipment pieces can be safely moved while the appliance is connected.

■ Never cut or remove the third conductor (ground conductor) from the power cord.

■ Never use any type of steam cleaner to melt frost or clean the appliance. Steam can reach electrical parts and cause a short circuit.

Intended Use 55

Intended Use Use this appliance ■ For the refrigeration and freezing of food, as well as for the preparation of ice cubes. ■ Only for domestic use or in the home environment. ■ Only in accordance with these instructions for use.

This appliance is designed to be used up to a maximum altitude of 2,000 meters above sea level.

Environmental Protection

Packaging All materials are environmentally friendly and recyclable: ■ Dispose of packaging in accordance with environmental regulations. ■ Ask your distributor or public administration about disposal methods.

Dispose of the appliance packaging in accordance with regulations for environmental protection.

Dispose of packaging in an environmentally responsible manner.

Used Appliance Through environmentally responsible disposal, valuable raw materials can be recovered.

Warning Children Can Become Trapped and Suffocate in the Appliance!

Before disposing of a used appliance: ■ Disassemble the doors. ■ Leave the shelves and containers inside the appliance to make it difficult for children to climb in. ■ Keep children away from used appliances.

Caution Refrigerants and Harmful Gases Can Escape.

Do not damage the refrigeration circuit tubing and insulation.

Installation and Connection

Installation and Connection

Delivered Material

Verify that the parts are not damaged or defective due to transport after unpacking them.

If you have any complaints, contact the distributor where you purchased your appliance or our Customer Service.

~ "Customer Service" on page 75

The delivery includes the following items:

■ Appliance for built-in installation ■ Equipment (depending on model) ■ Mounting material ■ Operating instructions ■ Installation instructions ■ Customer Service notebook ■ Warranty supplement ■ Information on energy consumption and appliance noise

Technical Data

The refrigerant used, usable capacity, and other technical data are found on the identification plate.

~ "Getting to Know Your Appliance" on page 59

Installing the Appliance

Installation Location

Your appliance may weigh up to 460 kg, depending on the model. The floor must be sufficiently stable and must not give way under the weight. If necessary, reinforce the floor.

Checking the Built-In Opening

The opening must meet the following criteria:

■ Anti-tip brackets must be installed ■ Minimum opening depth of 24" (610 mm), for flush installation 25" (635 mm) ■ Rectangular ■ Stable – side walls and ceiling must be at least 5/8" (16 mm) thick and securely fastened to the floor or wall ■ Minimum depth of shortened side walls 4" (100 mm)

Side-by-Side Installation

For side-by-side installation, please note the requirements contained in the assembly instructions.

If a dividing wall between the appliances is necessary, it must be at least 5/8" (16 mm) wide.

Energy Saving

If you follow these instructions, the appliance consumes less electricity.

Note: The arrangement of equipment parts will not affect the appliance's energy consumption.

--------

Installing the Appliance

Protect the appliance from direct sunlight.

When the ambient temperature is lower, the appliance cools less frequently, consuming less electricity.

Place the appliance as far as possible from radiators, stoves, or other heat sources:

Minimum distance of 1¼" (3 cm) from electric or gas stoves.

Minimum distance of 11¾" (30 cm) from oil or coal stoves.

Select the installation location with an ambient temperature of approximately 68 °F (20 °C).

Do not cover or obstruct the ventilation openings.

When hot air can escape, the appliance cools less frequently and therefore consumes less electricity.

Ventilate the room daily.

Using the Appliance

Open the appliance door only briefly.

The air in the appliance does not heat up as much. The appliance must cool less frequently and thus consume less electricity.

Transport food in a cooler and place it immediately in the appliance.

Allow hot food or beverages to cool to room temperature before placing them in the appliance.

To use the cold from frozen products, thaw frozen products in the refrigerator compartment.

Always leave a little space between the food and the back panel.

Air can circulate and the air humidity remains constant. The appliance must cool less frequently and thus consume less electricity.

Package food hermetically.

Do not cover or obstruct the ventilation openings.

The appliance consumes less electricity when hot air can escape.

Vacuum the ventilation openings once a year.

Before First Use

Connection to Water Outlet

Attention ■ Installation and connection of the appliance must be carried out by specialized personnel in accordance with the attached installation instructions. ■ To prevent damage to the appliance and to ensure correct operation of the unit, connect the appliance only to a drinking water pipe. ■ To prevent water damage, a shut-off valve must be installed.

Water Pressure of the Drinking Water Pipe

Attention To prevent damage to the appliance, a pressure limiter must be installed between the water outlet and the hose set if the water pressure exceeds the maximum value.

Note: If the water pressure is too low, the corresponding functions of the appliance will be impaired.

■ Minimum 0.2 Mpa (2 bar / 29 psi) ■ Maximum 0.8 Mpa (8 bar / 116 psi)

Connection to Electrical Outlet

Attention Do not connect the appliance to electronic energy-saving outlets.

Note: The appliance can be connected to grid-switching converters or sine wave converters. Grid-switching converters are used in photovoltaic systems connected directly to the public electricity supply network. Sine wave converters must be used in isolated systems. Isolated systems, for example on boats or mountain shelters, do not have a direct connection to the public electricity network.

Requirements for Electrical Outlets

Maximum Simultaneous Load

Warning Risk of Electric Shock! Never use multiple outlets, extension cables, or adapters. The appliance must be properly grounded. Never cut or remove the third conductor (ground conductor) from the electrical connection cable.

Warning Risk of Electric Shock! If the length of the electrical connection cable is not sufficient, never use multiple outlets or extension cables. Contact Customer Service for more information.

Outlet of 110 V ... 120 V Protective Conductor 60 Hz Fuse 10 A ... 16 A Appliance 6 A

Refrigerator Compartment Freezer Controls Main Power Switch On/Off Shelf for Large Bottles Vegetable Container with Humidity Control Fresh Food Compartment Nameplate Ice Maker Ice Cube Bin Frozen Food Container Frozen Food Container (Large) Ventilation Opening Particulate Filter

61

Controls

Operating Mode Selection

To open the operating mode selection, press the menu key.

To activate an operating mode, it must be pressed briefly. When the operating mode is activated, it appears in red in the Operating Mode Selection menu.

An information window appears with additional data about the selected operating mode.

Settings

To open settings, press Ò.

( Menu Key

Opens the operating mode selection.

0 Ò Key

Opens the Settings menu.

~ "Settings" on page 61

8 Refrigerator Compartment Temperature Display

Shows the programmed temperature in °C/°F.

@ Freezer Temperature Display

Shows the programmed temperature in °C/°F.

Eco Mode

Switch the appliance to energy-saving operation.

~ "Eco Mode" on page 65

Holiday Mode

Energy savings in case of prolonged absence.

~ "Holiday Mode" on page 65

Sabbath Mode

This mode disconnects all functions that are not necessary so you can also use the appliance on Sabbath.

~ "Sabbath Mode" on page 65

Language

Changes the display language.

Home Connect

Connects your refrigerator appliance with your mobile device.

~ "Home Connect" on page 66

Tones

Adjusts the volume of key tones and acoustic signals.

Display Brightness

Adjusts the display brightness.

Temperature Unit

Selects the temperature unit °C/°F.

Ice Cube Production

Starts or stops ice cube production. It is useful to stop ice cube production before cleaning the freezer or in case of prolonged absence.

Water Filter Counter

Resets the water filter counter when the water filter is replaced. If it is replaced with a bypass filter cartridge, the water filter counter can be turned off.

~ "Water Filter" on page 63

Factory Settings

The appliance settings are reset to the delivery state.

Self-Check

Initiates error analysis on your appliance.

Condensation Protection (3-door appliances only)

In the door frame of 3-door appliances there is integrated heating that prevents condensation. In this menu you can activate or deactivate condensation protection.

~ "Activating or Deactivating Condensation Protection" on page 65

Demo Mode

Note: In Demo Mode do not store food; the appliance will remain at room temperature.

The refrigeration function of the appliance is switched off. All other functions can continue to be used.

After connecting the appliance, this menu option is visible for 3 minutes. To activate or deactivate Demo Mode later, disconnect and reconnect the appliance. The mode becomes visible again for 3 minutes.

Operating the Appliance

Operating the Appliance

Switching On the Appliance

Warnings Relating to Appliance Operation ■ After switching on, the appliance may need several hours to reach the set temperatures. Do not insert food into the appliance before the selected temperatures have been reached. ■ Due to the fully automatic NoFrost system, the freezer remains free of ice. Defrosting is not necessary. ■ The front sides of the compartment become slightly warm in parts. This prevents condensation in the area of the door seal. ■ If you cannot open the freezer door immediately after closing it, wait a moment until the vacuum that has formed has equalized.

Switching Off and Closing the Appliance

Switching Off the Appliance ■ Press the main on/off switch. The appliance stops cooling.

Disconnecting the Appliance

Caution Water Quality Reduction The water supply must be turned off 3 hours before disconnecting the appliance. This prevents mold formation from stagnant water.

When you do not use the appliance for an extended period:

Adjusting the Temperature

Recommended Temperature Adjusting the Temperature of the Refrigerator and Freezer Compartments

Super Cool This function cools the refrigerator compartment to the lowest possible temperature.

Activate the super cool function, for example: ■ Before inserting large quantities of food. ■ To cool beverages quickly.

Note: If the super cool function is activated, the sound level of the appliance may increase. After approximately 6 hours, the appliance returns to normal operation.

Turning the Super Cool Function On or Off

Note: If you have configured the option so that the pop-up window does not appear again, you can return to the main display with the x key. If you do not press the key, the appliance saves the setting and automatically returns to the main display after a few seconds.

Super Freezing This function cools the freezer to the lowest possible temperature.

Activate the super freezing function, for example: ■ To freeze food quickly through to the core ■ 4 ... 6 hours before inserting fresh food from a quantity greater than 2 kg

Note: If the super freezing function is activated, there may be an increase in noise. After approximately 2 days, the appliance returns to normal operation.

Refrigerator Compartment: +39 °F (+4 °C)

Freezer: 0 °F (–18 °C)

Home Connect

Home Connect

This appliance operates with Wi-Fi and can be controlled remotely via a mobile device.

Note: Wi-Fi is a registered trademark of Wi-Fi Alliance.

The appliance functions as a refrigeration appliance without a home network connection and can continue to be operated manually via the controls in the following cases:

■ The appliance is not connected to a home network. ■ The Home Connect service is not offered in the country where the appliance is installed. You will find a list of countries where Home Connect is available at www.home-connect.com.

Note: Please observe the safety instructions in this manual. Be sure to follow them also when using the appliance via the Home Connect application from outside the home.

~ "Important Safety Instructions" on page 53

Also observe the instructions in the Home Connect application.

The appliance has a wireless transmitting module, via which the intelligent function of the appliance is realized. The CMIIT ID of the appliance is shown in the rating plate.

Setting Up Home Connect

Notes

■ After connecting the appliance, wait at least 2 minutes before setting up Home Connect. Only then is the internal initialization of the appliance complete. ■ Note the attached Home Connect sheet that comes with the appliance or is available for download at www.bosch-home.com in the instructions section. To do this, enter the product number (E-Nr.) of your appliance in the search box.

To connect your appliance to the home network WLAN (Wi-Fi), 3 basic steps are necessary.

When you open the menu for the first time, you will be guided automatically through the initial setup. Follow the instructions on the control panel. You will find more information in the following chapters.

In the Home Connect menu you will find the following submenus:

■ Enable and disable Wi-Fi ■ Connect with the application ■ Software update ■ Clear network settings

Setting Up the Home Network Connection (WLAN)

When you open the menu for the first time, you will be guided automatically through the initial setup. Follow the instructions on the control panel.

The refrigerator appliance temporarily generates its own network to which the mobile device connects.

As soon as the refrigerator appliance is connected to the mobile device, a connection will be established between the refrigerator appliance and the home network (Wi-Fi).

Note: If the connection cannot be established, check if there is sufficient reception.

Checking Signal Strength

Signal strength is displayed on the control panel. The signal strength value should be at least 1 bar in addition to the point. If the signal strength is too low, the connection may be temporarily interrupted.

Improving Signal Strength

■ Place the router closer to the refrigerator appliance. ■ Make sure the connection is not interrupted by shielding walls. ■ Install a repeater to boost the signal.

Alarm

Door Alarm

If the door of the appliance remains open for an extended period of time, the door alarm (continuous sound) activates.

■ Close the door. The acoustic signal deactivates.

Refrigerator Compartment

The refrigerator compartment is the ideal place to store meat, cold cuts, fish, dairy products, eggs and cooked dishes, as well as baked goods.

The temperature can be adjusted from 36 °F (2 °C) to 46 °F (8 °C).

With cold storage you can also preserve perishable foods for the short and medium term. The lower the temperature selected, the more slowly the enzymatic, chemical and deterioration processes of food caused by microorganisms will develop. A temperature of +39 °F (+4 °C) or lower ensures optimal freshness and preservation of stored food.

Points to observe when storing food

Note: Avoid contact between food and the rear panel.

Otherwise, free air circulation will be affected and food or containers could adhere to the rear panel.

■ Store fresh food in perfect condition. In this way they will retain their quality and freshness for longer.

■ In the case of pre-cooked products or packaged food, the expiration or consumption dates indicated by the manufacturer must be observed.

■ To preserve aroma, color and freshness, store food well wrapped or covered. This prevents the mixing of odors and flavors, as well as discoloration of plastic parts.

■ Allow hot food or beverages to cool to room temperature before placing them in the appliance.

Pay attention to the different cold zones of the refrigerator compartment

Depending on air circulation inside the refrigerator compartment, different cold zones are created.

The coldest zone

The coldest zone is located in the interior part of the rear panel and in the fresh compartment.

Note: Store the most delicate foods (for example, fish, cold cuts, meat) in the coldest zone.

When Storing Pay Attention to the Following ■ Freeze the largest quantities of food on the upper shelf. Foods freeze particularly quickly and optimally there. ■ Distribute food widely in the freezer compartments or containers. ■ Frozen foods should not come into contact with fresh foods to be frozen. If necessary, restack frozen foods in the freezer containers. ■ To ensure good air circulation in the appliance, it is important to: Insert the freezer containers all the way in.

Freezing Fresh Foods For freezing, use only fresh foods in good condition. Foods that are consumed cooked, fried or baked are more suitable for freezing than foods consumed raw. Before freezing, preparation processes must be carried out according to the type of food to best preserve nutritional value, aroma and color: ■ Vegetables: wash, chop, blanch. ■ Fruit: wash, remove seeds and possibly peel. If necessary, add sugar or an ascorbic acid solution. You will find instructions in specialized literature.

Foods Suitable for Freezing ■ Baked goods ■ Fish and seafood ■ Meat ■ Game and poultry ■ Vegetables, fruits and herbs ■ Eggs without shells ■ Dairy products such as cheese, butter and cottage cheese ■ Cooked dishes and food leftovers, such as soups, stews, cooked meats or fish, potato dishes, casseroles and desserts

Foods Not Suitable for Freezing ■ Vegetables normally consumed raw, such as lettuce or radishes ■ Eggs in shells or hard-boiled eggs ■ Grapes ■ Whole apples, pears and peaches ■ Yogurt, sour milk, sour cream, whipped cream and mayonnaise

Packaging Frozen Products The correct type of containers and materials are crucial for preserving product quality and preventing freezer burn.

Suitable Packaging Materials: ■ Plastic film ■ Polyethylene (PE) film rolls ■ Aluminum foil ■ Freezer containers

Suitable Closures: ■ Rubber rings ■ Plastic clips ■ Non-freezable adhesive tape

Unsuitable Packaging Materials: ■ Kraft paper ■ Parchment paper ■ Cellophane ■ Trash bags and used shopping bags

Storage Time for Frozen Products at 0 °F (-18 °C) Fish, cured meats, prepared meals, baked goods: up to 6 months Poultry, meat: up to 8 months Fruit, vegetables: up to 12 months

Thawing Frozen Products

The thawing method should be adapted to the type of food and intended use to maintain product quality as well as possible.

Thawing methods: ■ In the refrigerator (especially suitable for foods of animal origin such as fish, meat, cheese, and cottage cheese) ■ At room temperature (bread) ■ Microwave (foods to be prepared and consumed immediately) ■ Oven/stove (foods to be prepared and consumed immediately)

Attention Do not refreeze foods that have been thawed or begun to thaw. You may only refreeze them after they have been prepared (cooked or fried). The maximum storage time for frozen products should no longer be used.

Freezer Thawing

Due to the completely automatic NoFrost system, the freezer remains free of ice. Thawing is no longer necessary.

Cleaning

Attention Avoid Damage To The Unit And Equipment Parts. ■ Do not use detergents and solvents containing sand, chlorine, or acids. ■ Do not use abrasive sponges. Corrosion may occur on metal surfaces. ■ Never clean the shelves and containers in the dishwasher. Parts may become deformed.

Cleaning The Display

Due to temperature changes and air humidity, the controls may become foggy. Use a clean microfiber cloth for cleaning.

Cleaning The Interior Of The Unit

Proceed as follows:

Attention Wash water must not enter the lighting or drain hole to the evaporation area.

Cleaning Accessories

For cleaning, remove the movable elements from the unit.

Care Instructions For Stainless Steel Surfaces

For care and cleaning of stainless steel surfaces, only use cleaning products suitable for stainless steel and a stainless steel cleaning cloth. An appropriate stainless steel cleaning cloth can be obtained through after-sales service.

Stainless steel surface care should be performed in the direction of the grain to avoid visible scratches.

Odors

If unpleasant odors are detected:

Replace the Deodorizing Filter

Replacement filters can be purchased from the Official After-Sales Service.

Lighting

Your appliance is equipped with maintenance-free LED lighting.

Only customer service or authorized personnel can repair the lighting.

Noises

Normal Noises

Humming: A motor is running, for example, refrigeration unit, fan. Bubbling, humming or gurgling: refrigerant flows through the tubes. Clicking: motor, switch or solenoid valves, an on or off switch. Cracking: Automatic defrosting is being performed.

Avoiding Noises

The appliance is not level: Level the appliance with the help of a bubble level. Shim the appliance if necessary.

Containers, trays or shelves vibrate or are stuck: Check the removable elements and, if necessary, reposition them.

73 3 Troubleshooting

Before calling Customer Service, attempt to solve the problem using this table.

Appliance -------- The temperature differs considerably from the set value. Turn off the appliance for 5 minutes. ~ "Turning Off and Closing the Appliance" on page 64 If the temperature is too high, check it again after a few hours. If the temperature is too low, check it again the next day.

No indicator lights up. The plug is not correctly inserted. Connect the plug. The fuse has blown. Check the fuses. Power supply was interrupted. Verify that there is power.

The refrigerator turns on more frequently and for longer periods. The appliance door has been opened too frequently. Do not open the appliance door unnecessarily. The ventilation grilles are covered. Remove the cause of the obstruction. Large quantities of fresh food were placed inside. Activate the super cool function with sufficient advance notice.

The appliance does not cool, the display and lighting illuminate. Demo Mode is activated. Deactivate Demo Mode. ~ "Settings" on page 61

Ice Machine -------- The ice machine does not work. Ice production has been deactivated. Turn on ice production. The freezer is too warm. Set the temperature colder. ~ "Operating the Appliance" on page 64 The ice cube bin is not positioned correctly. Position the ice cube bin correctly. The ice machine has no power. Call Customer Service. ~ "Customer Service" on page 75 No water is coming through. Check the water connection and, if necessary, contact the installer. The water pressure is too low. Connect the appliance only to lines with sufficient water pressure. There is a kink in the water hose. Turn off the water supply, straighten the kink. If necessary, replace the water hose. Very few ice cubes or deformed, lower water pressure than usual. After switching on or after removing several ice cubes, there are very few ice cubes in the ice cube bin. An empty ice cube bin takes approximately 24 hours to fill. Ice production stops automatically but the ice cube bin is still not full. Do not store the ice scoop on the ice in the ice cube bin. Otherwise the sensor will not recognize the actual fill level of the bin. The water pressure is too low. Connect the appliance only to lines with sufficient water pressure. The water filter is blocked or needs to be replaced. Replace the water filter. The freezer is too warm. Set the temperature colder. ~ "Operating the Appliance" on page 64 Water is leaking from the appliance. The water connection is not tight. Check that the connections are firmly tightened and the water hose is in good condition. If the water hose is damaged, contact customer service to have it replaced. Replacement can be performed by a customer service representative or by a person with similar qualifications. Use only original parts from the manufacturer.

75 4Customer Service

If you are unable to repair the malfunction, please contact Customer Service. We will always find an appropriate solution and also avoid unnecessary visits from technicians.

The contact details of the nearest service centers can be found here or in the attached customer service directory.

When calling, please provide the product number (E-Nr.) and the manufacturing number (FD) of your unit, which are located on the appliance's rating plate.

~ "Getting to Know Your Appliance" on page 59

Trust in the manufacturer's experience. This way, you can be sure that the repair is carried out by specialized technical personnel who also have original spare parts available for your appliance.

Appliance Self-Test

Your appliance has an automatic self-test program that indicates faults that your Customer Service can resolve.

Repair Request and Troubleshooting Advice

The contact details for all countries can be found in the attached Customer Service directory.

*8001077621* 8001077621 (9901)
