Frigidaire Ffhs2611Lw9
Owner's Manual Shop genuine replacement parts for FRIGIDAIREFfhs2611Lw9
Find Your FRIGIDAIRE Refrigerator Parts - Select From 5957 Models -------- Manual continues below --------
Table Of Contents
www.frigidaire.com USA 1-800-944-9044 www.frigidaire.ca Canada 1-800-265-8352 All about the Use & Care of your Refrigerator Important Safety Instructions..................................2 Features at a Glance...............................................4 Installation............................................................5 Door Removal Instructions......................................7 Connecting Water Supply........................................8 Controls.................................................................9 Storage Features..................................................13 242065101 (July 2010) Automatic Ice & Water Dispenser..........................14 Changing the Filter...............................................18 Normal Operating Sounds and Sights.....................19 Care and Cleaning................................................20 Before you Call.....................................................21 Major Appliance Warranty.....................................23
2
Warning
WARNING indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.Important
IMPORTANT indicates installation, operation or maintenance information which is important but not hazard-related.Danger
DANGER indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury. Definitions This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death. Doors Handles are secure and tight Door seals completely to cabinet on all sides Freezer door is level across the top Leveling Refrigerator is level, side-to-side and tilted 1/4” (6mm) front-to-back Toe grille is properly attached to refrigerator Cabinet is setting solid on all corners Electrical Power House power turned on Refrigerator plugged in Ice Maker House water supply connected to refrigerator No water leaks present at all connections - recheck in 24 hours Ice maker is turned ON Ice & water dispenser operates correctly Front filter must be flush with filter housing (select models) Final Checks Shipping material removed Fresh food and freezer temperatures set Crisper humidity controls set Registration card sent in Installation ChecklistCaution
CAUTION indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury. Important Safety Instructions For your SafetyWarning
Please read all instructions before using this refrigerator.
3 Important Safety Instructions Electrical information
Warning
These guidelines must be followed to ensure that safety mechanisms in this refrigerator will operate properly.Important
Pressing and holding the On/Off button for 3 seconds, located on the left side of the temperature control panel (Electronic controls), or turning the Freezer and Fresh Food controls to “0” (Mechanical controls) will disable your refrigerator’s cooling system, but does not disconnect the power to the light bulb and other electrical components. To turn off power to your refrigerator you must unplug the power cord from the electrical outlet.Caution
To avoid personal injury or property damage, handle tempered glass shelves carefully. Shelves may break suddenly if nicked, scratched, or exposed to sudden temperature change. Child Safety Destroy or recycle the carton, plastic bags, and any exterior wrapping material immediately after the refrigerator is unpacked. Children should never use these items to play. Cartons covered with rugs, bedspreads, plastic sheets or stretch wrap may become airtight chambers, and can quickly cause suffocation. Proper Disposal of your Refrigerator or Freezer Risk of child entrapment Child entrapment and suffocation are not problems of the past. Junked or abandoned refrigerators or freezers are still dangerous – even if they will sit for “just a few days”. If you are getting rid of your old refrigerator or freezer, please follow the instructions below to help prevent accidents. Proper Disposal of Refrigerators/Freezers We strongly encourage responsible appliance recycling/ disposal methods. Check with your utility company or visit www.recyclemyoldfridge.com for more information on recycling your old refrigerator. Before you throw away your old refrigerator/ freezer:
4 Features At A Glance Features may vary according to model SpillSafe ® Adjustable Shelf SpillSafe ® Adjustable Shelf
Important
Features not included with your refrigerator can be purchased at www.frigidaire.com or by calling 1-800- 944-9044.
5
Note
If your refrigerator is placed with the door hinge side against a wall, you may have to allow additional space so the door can be opened wider. InstallationCaution
Do Not install the refrigerator where the temperature will drop below 55°F (13°C) or rise above 110°F (43°C). The compressor will not be able to maintain proper temperatures inside the refrigerator. Do Not block the toe grille on the lower front of your refrigerator. Sufficient air circulation is essential for the proper operation of your refrigerator. This Use & Care Guide provides general operating instructions for your model. Use the refrigerator only as instructed in this Use & Care Guide. Before starting the refrigerator, follow these important first steps. LocationSides & Top 3/8 inch
Back
1 inch Toe Grille Installation and Removal To install toe grille
1 Open both doors. Slide left and right sides of toe grille over lower hinges of refrigerator.
2 While pushing toe grille firmly against cabinet, fasten bottom clips of toe grille to cabinet.
3 Fasten top clips to cabinet.
4 Close the doors. Fasten right and left side clips into groove of bottom hinge. To remove toe grille
1 With both doors closed, unfasten right and left side clips of toe grille from bottom hinge groove.
2 Open both doors. Press firmly on top of toe grille until top of toe grille pops off.
3 Pull toe grille outward toward your body and off of lower hinges.
6 Installation
Note
The refrigerator doors are designed to shut by themselves within a 20 degree opening. Door Opening Your refrigerator should be positioned to allow easy access to a counter or table when removing food. For best use of drawers and freezer baskets, the refrigerator should be in a position where both the refrigerator and freezer doors can be fully opened. Guidelines for final positioning of your refrigerator:1 Open both doors and remove the toe grille (see “Toe Grille Installation and Removal” in the “Installation” section).
2 Close the doors and use a flat-blade screwdriver or 3/8 inch socket wrench to raise or lower the front rollers.
3 Ensure both doors are bind-free with their seals touching the cabinet on all four sides. Hinge Flange Set Screw (some models) Door Stop Flange Hinge Open Door 7/16” Wrench and 3/32” Hex Key (some models)
6 Replace the toe grille by fitting it into place (see “Toe Grille Installation and Removal” in the “Installation” section). To level the doors using the adjustable lower hinge:
4 After leveling, verify door stop contacts lower hinge and top of door does not contact upper hinge through full movement of door (from fully closed to fully open).
5 Reinstall set screw, locking the door height.
Note
Some models will not have a set screw. For those models follow steps 2 through 4.1 Before leveling either door, remove set screw that locks door height into position. (The door cannot be adjusted without set screw removed).
2 If the refrigerator door is lower than the freezer door, raise the refrigerator door by turning the adjustment screw clockwise using a 7/16 inch wrench. (See illustration.)
3 If the freezer door is lower than the refrigerator door, raise the freezer door by turning the adjustment screw clockwise using a 7/16 inch wrench. (See illustration.)
7 Door Removal Instructions Getting through narrow spaces If your refrigerator will not fit through an entrance area, you can reduce its size by removing the doors. Check first by measuring the entrance. Required Tools You will need the following tools: To prepare for removing the doors:
1 Make sure the electrical power cord is unplugged from the wall outlet.
2 Open both doors and remove the toe grille (as explained in the Installation Instructions that came with your appliance).
3 Remove any food from the door shelves.
4 Close the doors. To remove the refrigerator top hinge cover:
1 Remove the three screws from each cover over the top door hinges.
2 Lift hinge cover straight up and off. To remove the refrigerator door:
1 Trace lightly around the door’s top hinge with a pencil. This makes reinstallation easier.
2 Remove the two screws from the top hinge. Lift the door off of the bottom hinge and set it aside.
3 Remove the two bottom hinge screws and hinge if necessary. Adjustable Wrench Socket Wrench Set
Or
Phillips Head ™ Tools Necessary: 3/8” Fixed WrenchAnd
Or
Top Hinge Cover Rear Screw Top Hinge Cover Front Screw Bottom Hinge Screw Top Hinge Screw Adjustable Hinge (some models) Non-Adjusting Hinge (some models) To reinstall the refrigerator door, reverse the above steps.Caution
Be sure doors are set aside in a secure position where they cannot fall and cause personal injury.
8 To remove the freezer top hinge cover:
1 Remove the two screws from each cover over the top door hinges.
2 Lift hinge cover straight up and off. To remove the freezer door:
1 Detach the multi-wire cable connector located above the top hinge. Grasp both sides of the connector firmly and pull apart.
3 Detach the water tube from the connector located below the freezer door. The connector releases when you press its outer sleeve inward.
4 Remove the screws from the top hinge and pull the multi-wire cable through it. Lift the
door off of the bottom hinge.
5 Remove the two bottom hinge screws and
hinge if necessary. 6 Lay the door on its side to avoid damage to the water tube extending from the bottom
hinge. To reinstall the freezer door, reverse the above steps. Once both doors are in place, ensure they are aligned with each other and level (Please see “To level the doors using the lower hinge” for models with adjustable lower hinges or “To level the cabinet using the front rollers” for models with the non-adjustable lower hinges in the “Installation” section.), then replace the top hinge cover. Non-Adjusting Hinge (some models) Adjustable Hinge (some models)
2 Trace lightly around the hinge with a pencil. This makes reinstallation easier. Door Removal Instructions
9
Warning
To avoid electric shock, which can cause death or severe personal injury, disconnect the refrigerator from electrical power before connecting a water supply line to the refrigerator.Note
Check with your local building authority for recommendations on water lines and associated materials prior to installing your new refrigerator. Depending on your local/state building codes, Frigidaire recommends for homes with existing valves its Smart Choice® water line kit 5305513409 (with a 6 ft. Stainless Steel Water Line) and for homes without an existing valve, Frigidaire recommends its Smart Choice water® line kit 5305510264 (with a 20 ft. Copper Water Line with self-tapping saddle valve). Please refer to www.frigidaire.com/store for more information.Caution
To Avoid Property Damage:Important
Ensure that your water supply line connections comply with all local plumbing codes.Important
After connecting the water supply, refer to “How to Prime the Water Supply System” for important information about priming an empty water supply system. Your refrigerator’s water supply system includes several tubing lines, a water filter, a water valve, and a water tank. To ensure that your water dispenser works properly, this system must be completely filled with water when your refrigerator is first connected to the household water supply line. Connecting the Water Supply Before Installing The Water Supply Line, You Will Need:If you use stainless steel tubing - The nut and ferrule are already assembled on the tubing. Slide compression nut onto valve inlet and finger tighten compression nut onto valve. Tighten another half turn with a wrench; DO NOT over tighten. See Figure 2.
10
Note
When changing control settings, wait 24 hours for the temperature to stabilize before making additional changes.Important
Turning the Freezer and Fresh Food Controls to “0” turns off the compressor and prevents your refrigerator from cooling, but does not disconnect the power to the light bulb and other electrical components. To turn off power to your refrigerator you must unplug the power cord from the electrical outlet. Controls Cool Down Period To ensure safe food storage, allow the refrigerator to operate with the doors closed for at least 8 to 12 hours before loading it with food. Refrigerator & freezer controls Refrigerator & Freezer Controls (Features may vary according to model.) Temperature adjustment
11 Allowing Cooling Time Before Use To ensure safe food storage, allow your refrigerator to operate with the doors closed for at least 8 to 12 hours before placing food inside. During this cooling period, you do not need to adjust the controls, which are preset at the factory. Setting Cooling Temperatures Your refrigerator comes with a state-of-the-art electronic digital control system. The system’s control panel is located at the top of the the fresh food compartment. The two digital displays on the left half of the control panel indicate the current settings or temperatures of your freezer and fresh food compartments. The models with a 2-digit temperature display are for reference only, and do not display the current accurate compartment temperature. Should you desire to see what the current accurate temperature is, place a separate thermometer inside the freezer or fresh food compartment in the desired location. (Single Digit Display - Features may vary.)
Temperature Adjustment
To adjust the temperature to a higher or lower setting, press the Up (Cold) or Down (Colder) button closest to the display. The first time you press the button, the display shows current setting you entered. Each press of the button after that changes the setting by one. The display shows your new setting momentarily, then changes back to the current temperature.If Temperature Displays Flash...
If ever you see both temperature displays continuously flashing, it may indicate that the control system has detected a performance problem. Call your service representative, who can interpret the flashing message. To maintain temperatures, a fan circulates air in the refrigerator and freezer compartments. For good circulation, do not block cold air vents with food items. Temperature Control Range Freezer Fresh Food Fahrenheit Centigrade Fahrenheit Centigrade Warmest 6º -14º 47º 8º Warmer Factory Setting Midpoint 0º -18º 37º 3º Colder Coldest -6º -21º 33º 1º Temperature Adjustment If Fresh Food compartment is too warm Adjust Fresh Food control one degree colder by pressing Down (Colder) button. If Fresh Food compartment is too cold Adjust Fresh Food control one degree warmer by pressing the Up (Cold) button. If Freezer compartment is too warm Adjust Freezer control one degree colder by pressing Down (Colder) button. If Freezer compartment is too cold Adjust Freezer control one degree warmer by pressing the Up (Cold) button. Numeric Display Freezer Fresh Food Warmest 1 1 Factory Setting 6 6 Coldest 9 9 ControlsNote
The advanced electronic control system in your refrigerator includes additional display modes that service professionals can use to rapidly diagnose performance issues.
12 Turning the Cooling system on and off You can disable the cooling system in your refrigerator by pressing the On/Off button located on the left side of the temperature control panel. To ensure that you do not accidentally turn off the cooling system, the button does not work unless you press and hold it for three seconds. Once you disable the cooling system, all refrigeration to the freezer and fresh food compartments stops. To turn the cooling system back on, you must again press and hold the On/Off button for three more seconds. Cooling System On/Off Button Indicator Controls
Note
Pressing the On/Off button on the control panel disables your refrigerator’s cooling system but does not disconnect power to lights and other electrical components. To turn off power to your refrigerator you must unplug the power cord from the wall outlet. Each time you make settings on the control panel, a single audible tone acknowledges your input.
13
Caution
To avoid personal injury or property damage, handle tempered glass shelves carefully. Shelves may break suddenly if nicked, scratched, or exposed to sudden temperature change. See “Glass Shelves” in Care & Cleaning Chart. Storage Features Cantilever Sliding Glass Shelf 1 2 Cantilever Glass Shelf 1 2 Cantilever Shelf Adjustment Refrigerator shelves are easily adjusted to suit individual needs. Before adjusting the shelves, remove all food. Cantilever shelves are supported at the back of the refrigerator. To adjust cantilever shelves: 1 Lift front edge up. 2 Pull shelf out. Replace the shelf by inserting the hooks at rear of the shelf into the wall bracket. Lower the shelf into the desired slots and lock into position. SpillSafeTM glass shelves (some models) catch and hold accidental spills. In some models, the SpillSafeTM shelves slide out for easy access to food and for fast cleaning. The shelves slide out independently of their mounting brackets. Just pull the front of the shelf forward. Shelves can be extended as far as the stopper will allow but are not removable from their mounting brackets. Door storage Door bins and shelves are provided for convenient storage of jars, bottles, and cans. Frequently used items can be quickly selected. Some models have door bins that can accommodate gallon-sized plastic drink containers and economy- sized jars and containers. Some bins are adjustable for maximum storage capacity. The dairy compartment, which is warmer than the general food storage section, is intended for short term storage of cheese, spreads, or butter. Fresh Drawers with Humidity Control (some models) The fresh drawers, located under the bottom refrigerator shelf, are designed for storing fruits, vegetables, and other Crisper Drawer Crisper Humidity Control Cool Drawer (some models) Some models are equipped with a Cool Drawer for storage of luncheon meats, spreads, cheeses, and other deli items. This drawer does not have a separate temperature control Chill Drawer (some models) Some models are equipped with a Chill Drawer. Chill Drawer temperatures can be adjusted by sliding the Chill Drawer Temperature Control in either direction. Use this pan for short term storage of bulk meat items. If meats are to be kept longer than one or two days, they should be frozen. The Chill Drawer is fixed and cannot be moved up or down. If fruits or vegetables are to be stored in the Chill Drawer, set the Chill Drawer Temperature Control to a warmer setting to prevent freezing.Note
Leafy vegetables keep best when stored with the humidity control set on Higher Humidity, or in a drawer without a Humidity Control. This keeps incoming air to a minimum and maintains maximum moisture content. Crispers Crispers allow you the flexibility to store any manner of items including fruits, vegetables, nuts, etc. Crispers do not feature humidity controls. Chill Drawer with Temperature Control fresh produce. The fresh drawers feature humidity control which allows you to adjust the humidity within the drawer. This can extend the life of fresh vegetables that keep best in high humidity. Wash items in clear water and remove excess water before placing them in the crispers. Items with strong odors or high moisture content should be wrapped before storing.
14 Automatic Ice & Water Dispenser Features may vary according to model.
Extreme
Freeze
To freeze food at a faster rate to preserve freshness, push the Touch Pad for 3-5 seconds to activate this feature. A green light will appear above the Touch Pad. Push the Touch Pad again for 3-5 seconds to deactivate.Extra Ice
To increase ice production for special occasions, such as parties, push the Touch Pad for 3-5 seconds to activate this feature. A green light will appear above the Touch Pad. Push the Touch Pad again for 3-5 seconds to deactivate. EXTRA ICE should produce 25 percent to 50 percent more ice every 24 hours.Cube
Press the CUBE Touch Pad to get cubed ice. A green light will appear above the Touch Pad. Press glass against ICE dispensing paddle as far up as possible to catch all ice.Crush
Press the CRUSH Touch Pad to get crushed ice. A green light will appear above the Touch Pad. Press glass against ICE dispensing paddle as far up as possible to catch all ice.Light
Press the LIGHT Touch Pad to turn on dispenser light. Press again to turn the light off. The light also turns on automatically when ice and/or water is dispensed. Replace light bulb with an appliance bulb of the same wattage.Filter
Status
The FILTER STATUS indicator light above the Touch Pad will light up each time the dispenser is used. The following filter light indications are: Green The filter is still operating within its specified life cycle. Amber The filter has reached approximately 80 percent of its useful life. This is the recommended time to purchase a replacement filter. RedThe filter is 100 percent used up. Change the filter as soon as possible. After the filter cartridge has been changed, press and hold the FILTER RESET Touch Pad for 10-15 seconds. NOTE: The Green, Amber and Red lights will flash when reset is completed.
Lock
The Ice & Water Dispenser can be locked out to prevent unwanted use. To Lock Out Press the LOCK Touch Pad for 3-5 seconds. A red light will appear above the Touch Pad. To Unlock Press the LOCK Touch Pad for 3-5 seconds until the red light above the Touch Pad goes out.Water
To operate the water dispenser, press a glass against the WATER dispensing paddle. To stop dispensing water, pull the glass away from the dispensing paddle. Dispensed water is not cold. For colder water, add crushed ice or cubes before dispensing water. A drip tray located at the base of the dispenser catches small spills and allows them to evaporate. This drip tray is removable and dishwasher safe. Do not pour water and excess ice in this area because there is no drain.
15 Features may vary according to model. Crushed Press the Crushed Touch Pad to get crushed ice. A red indicator will appear above the Touch Pad. Press glass against ICE dispensing paddle as far up as possible to catch all ice. Cubed Press the Cubed Touch Pad to get cubed ice. A red indicator will appear above the Touch Pad. Press glass against ICE dispensing paddle as far up as possible to catch all ice. Light On Press the Light On Touch Pad to turn on dispenser light. A red indicator will appear above the Touch Pad. Light Off Press the Light Off Touch Pad to turn off dispenser light. A red indicator will appear above the Touch Pad. Water To operate the water dispenser, press a glass against the WATER dispensing paddle. To stop dispensing water, pull the glass away from the dispensing paddle. Dispensed water is not cold. For colder water, add crushed ice or cubes before dispensing water. A drip tray located at the base of the dispenser catches small spills and allows them to evaporate. This drip tray is removable and dishwasher safe. Do not pour water and excess ice in this area because there is no drain. Automatic Ice & Water Dispenser light off light on ice water crush cube
16
Important
Your ice maker is shipped from the factory with the wire signal arm in the ON position (side mounted) or with the switch turned ON (rear mounted). To ensure proper function of your ice maker, hook up water supply immediately or turn ice maker OFF by lifting the wire signal arm until it clicks and locks in the UP position (side mounted) or turn the On/Off switch to the Off (0) position (rear mounted). If the ice maker is not turned off and the water supply is not connected, the water valve will make a loud chattering noise.. Automatic Ice & Water Dispenser Priming the Water Supply System Your refrigerator’s water supply system includes several tubing lines, an advanced water filter, a distribution valve bank, and a reserve tank to ensure ample supply to the ice and water dispenser at all times. This system needs to be completely filled with water when first connected to an external supply line. To prime the water supply system:1 Begin filling the tank by pressing and holding a drinking glass against the water dispenser paddle.
2 Keep the glass in this position until water comes out of the dispenser. It may take about 1½ minutes.
3 Continue dispensing water for about four (4) minutes to flush the system and plumbing connections of any impurities (stopping to empty the glass as necessary). Ice Maker Operation & Care The ice maker, ice bin, and dispenser feeding mechanism are located in the top of the freezer compartment. After the refrigerator is installed properly and has cooled for several hours, the ice maker can produce ice within 24 hours. It can completely fill an ice bin in about two days. Using the Ice Maker after Installation Before making ice for the first time, be sure to prime the water supply system. Air in new plumbing lines can result in two or three empty ice maker cycles. Furthermore, if the system is not flushed, the first ice cubes may be discolored or have an odd flavor.
Note
The water dispenser has a built-in device that shuts off the water flow after three minutes of continuous use. To reset this shutoff device, simply release the dispenser paddle.Caution
For proper dispenser operation, recommended water supply pressure should fall between 30 psi and 100 psi. Excessive pressure may cause water filter to malfunction.Off
On
Wire Signal ArmOn
Off
Wire Signal Arm Turning the SIDE MOUNTED Ice Maker On and Off To begin ice production, lower the wire signal arm to the DOWN or ON position. The ice maker turns off automatically when the ice container becomes full. To stop the ice maker, raise the wire signal arm until it clicks and locks in the UP or OFF position. Turning the REAR MOUNTED Ice Maker On and Off Ice production is controlled by the ice maker’s ON/OFF power switch. To gain access to the ice maker, pull the ice cream shelf out. Press the switch to the “O” position to turn it Off and press it to the “I” position to turn it On. The ice maker also has a built-in wire signal arm, which automatically stops ice production when the ice bin is full. DO NOT use this signal arm to manually stop the ice maker. Ice Production: What to Expect How Much Ice Will a Side Mounted Ice Maker Produce in 24 Hours? A side mounted ice maker will produce 4 to 4.5 pounds of ice every 24 hours, depending on usage conditions. Ice is produced at a rate of 8 cubes every 75 to 90 minutes. How Much Ice Will a Rear Mounted Ice Maker Produce in 24 Hours? A rear mounted ice maker will produce 3 to 4 pounds of ice every 24 hours, depending on usage conditions. Ice is produced at a rate of 8 cubes every 75 to 90 minutes.
17
Important
Small ice cubes or ice chips jamming in the ice maker may be a sign that your water filter needs changing. If you have a side mounted ice maker you may also experience hollow cubes partially frozen cubes with water inside. When these cubes are harvested, they break open and spill water over the other ice cubes in the ice container, forming a solid mass of ice. As the water filter nears the end of its useful life and becomes clogged with particles, less water is delivered to the ice maker during each cycle. The ice maker can’t fill every cube in the ice maker mold, leading to small cubes or chips that can get caught between the ice ejector blades and the stripper. Remember, if your ice maker is jamming with small ice cubes or it’s been six months or longer since you last changed your water filter replace the water filter with a new one. Poor quality household water may require the filter to be changed more frequently.Caution
Chemicals from a malfunctioning water softener can damage the ice maker. If the water supply to your refrigerator is softened, be sure the softener is maintained to work properly.Caution
NEVER use an ice pick or similar sharp instrument to break up the ice. This could damage the ice storage bin and dispenser mechanism.Important
When removing or replacing the ice bin, DO NOT rotate the auger in the ice bin. If the auger is accidentally rotated, you must realign the auger by turning it in 90 degree turns (see below) until the ice bin fits into place with the drive mechanism. If the auger is not properly aligned when replacing the ice bin, the refrigerator will only dispense Crushed Ice. The freezer door may also not close properly causing warm air to leak into the freezer. Automatic Ice & Water Dispenser Ice Maker/Dispenser Tips1 Turn Off the ice maker.
2 Remove the ice bin by lifting up and out.
3 Empty and carefully clean the ice bin with mild detergent. Rinse with clear water. Do not use harsh or abrasive cleaners.
4 Allow the ice bin to dry completely before replacing in the freezer.
5 Remove ice chips and clean the ice bin shelf and the freezer door chute.
6 Replace the ice bin. Turn On the ice maker to resume ice production. Remove and empty the ice storage bin if:
18
Changing The Filter
Locating the Filter Your refrigerator is equipped with a water filtering system. The water filter system filters all dispensed drinking water, as well as the water used to produce ice. Water Filter The water filter is located at the top right side of the fresh food compartment. Do not use with water that is microbiologically unsafe or of unknown quality without adequate disinfection before or after the system. Systems certified for cyst reduction may be used on disinfected waters that may contain filterable cysts. Test & certification results:1 Turn Off the ice maker.
2 Remove the filter by pushing on the end/face of the filter.
3 Slide the old water filter cartridge straight out of the housing and discard it.
4 Unpackage the new filter cartridge. Using the alignment guide, slide it gently into the filter housing until it stops against the snap-in connector at the back of the housing.
5 Push firmly until the cartridge snaps into place (you should hear a click as the cartridge engages the snap-in connector).
6 Press a drinking glass against the water dispenser while checking for any leaks at the filter housing. Any spurts and sputters that occur as the system purges air out of the dispenser system are normal.
7 After filling one glass of water, continue flushing the system for about four (4) minutes.
8 Turn On the ice maker.
9 Press and hold the Water Filter button on the Ice & Water Dispenser control panel for three seconds. When the display changes from “Red” to “Green,” the status has been reset. Ordering Replacement Filters To order your replacement filters, please visit our online store at www.frigidaire.com/store, by calling toll-free at 877-808-4195, or by visiting the dealer where you purchased your refrigerator. Electrolux recommends that you order extra filters when you first install your refrigerator, and that you replace your filters at least once every six months. Here are the product numbers to request when ordering: PureSource 3TM Water Filter Part #WF3CB Replacing the Water Filter In general, you should change the water filter every six months to ensure the highest possible water quality. Water Filter Status on the user interface prompts you to replace the filter after a standard amount of water (200 gallons/757 liters for PureSource 3TM) has flowed through the system. If your refrigerator has not been used for a period of time (during moving for example), change the filter before reinstalling the refrigerator. The PureSource 3TM ice and water filter system is tested and certified to NSF/ANSI Standards 42 and 53 for the reduction of claims specified on the performance data sheet. More about your Advanced Water Filter
19
Note
Energy efficient foam in your refrigerator is not a sound insulator. Understanding the Sounds you may Hear Your new, high-efficiency refrigerator may introduce unfamiliar sounds. These sounds normally indicate your refrigerator is operating correctly. Some surfaces on floors, walls, and kitchen cabinets may make these sounds more noticeable. Following is a list of major components in your refrigerator and the sounds they can cause:A Evaporator Refrigerant through the evaporator may create a boiling or gurgling sound.
B Evaporator fan You may hear air being forced through the refrigerator by the evaporator fan.
C Defrost heater During defrost cycles, water dripping onto the defrost heater may cause a hissing or sizzling sound. After defrosting, a popping sound may occur. D Automatic ice maker When ice has been produced, you will hear ice cubes falling into the ice bin.
E Electronic control & automatic defrost control These parts can produce a snapping or clicking sound when turning the cooling system on and off.
F Condenser fan You may hear air being forced through the condenser. G Compressor Modern, high-efficiency compressors run much faster than in the past. The compressor may have a high-pitched hum or pulsating sound. H Water valve Makes a buzzing sound each time it opens to fill the ice maker.
I Drain pan (not removable) You may hear water dripping into the drain pan during the defrost cycle.
J Condenser May create minimal sounds from forced air. K Motorized damper May produce a light humming during operation.
L Ice chute When dispensing ice, you will hear a snapping or clicking sound when the solenoid opens and closes the ice chute.
Note
During automatic defrost cycle, a red glow in the back wall vents of your freezer compartment is normal.D
Or
Normal Operating Sounds and sights
20
Important
If you store or move your refrigerator in freezing temperatures, be sure to completely drain the water supply system. Failure to do so could result in water leaks when the refrigerator is put back into service. Contact a service representative to perform this operation.Caution
Note
If you set your temperature controls to turn off cooling, power to lights and other electrical components will continue until you unplug the power cord from the wall outlet. Protecting your investment Keeping your refrigerator clean maintains appearance and prevents odor build-up. Wipe up any spills immediately and clean the freezer and fresh food compartments at least twice a year. When cleaning, take the following precautions:
21 Before You Call Visit our web site at www.frigidaire.com. 1-800-944-9044 (United States) 1-800-265-8352 (Canada)
Problem
Cause
Correction
Automatic Ice Maker
Ice maker is not mak- ing any ice. Ice maker wire signal arm is in • the “up” or OFF position. Ice maker power switch is Off. • Ice maker has small cube • caught in mechanism. Saddle valve on cold water • pipe is clogged or restricted by foreign material. Move wire signal arm to the “down” or • ON position. (side mounted) Turn power switch to On (“ • I”) position. (rear mounted) Remove small cube from ice maker. The ice and water • filter cartridge may be clogged. Replace filter cartridge. Turn off household water line valve. Remove valve. En- • sure that valve is not a self-piercing saddle valve. Clean valve. Replace valve if necessary. Ice maker is not mak- ing enough ice. Ice maker is producing less ice • than you expect. Check to see if water dispenser • is dispensing slower than normal. Side mounted ice maker should produce 4 to 4.5 pounds • (approximately 4 quarts) of ice every 24 hours. A rear mounted ice maker should produce 3 to 4 pounds (ap- proximately 3½ quarts) of ice every 24 hours. Quick Ice option should produce up to 50% more ice every 24 hours. If it is, replace the ice and water filter cartridge. • Ice maker will not stop making ice. Ice maker wire signal arm is • being held down by some item in the freezer. Move item and release wire signal arm. Remove any ice • cubes that are frozen together over the wire signal arm. Ice cubes are freezing together. Ice cubes are not being used • frequently enough. Ice cubes are hollow (partially • frozen cubes with water inside). Freezer control is set too warm. • Remove ice container and discard ice from container. Ice • maker will produce fresh supply. The ice and water filter cartridge may be clogged. Replace • filter cartridge. Set freezer control to colder setting. Allow 24 hours for • temperature to stabilize.Ice Dispenser
Dispenser will not dis- pense ice. Ice storage container is empty. • Freezer temperature is set too • warm. Household water line valve is • not open. Ice dispensing arm has been held • in for more than 4-5 minutes. When the first supply of ice is dropped into the container, • the dispenser should operate. Turn freezer control to a higher setting so that ice cubes • will be made. When first supply of ice is made, dispenser should operate. Open household water line valve. Allow sufficient time • for the ice to be made. When ice is made, the dispenser should operate. Motor is overloaded. Motor over load protector will reset in • approximately 3 minutes. Ice can then be dispensed. Ice dispenser is jammed. Ice has melted and frozen • around auger due to infrequent use, temperature fluctuations, and/or power outages. Ice cubes are jammed between • ice maker and back of ice container. Remove ice container, thaw, and empty the contents. • Clean container, wipe dry, and replace in proper position. When new ice is made, dispenser should operate. Remove ice cubes that are jamming the dispenser. •Opening/Closing Of Doors/Drawers
Door(s) will not close. Door was closed too hard, caus- • ing other door to open slightly. Refrigerator is not level. It • rocks on the floor when moved slightly. Refrigerator is touching a wall • or cabinet. Close both doors gently. • Ensure floor is level and solid, and can adequately support • the refrigerator. Contact a carpenter to correct a sagging or sloping floor. Ensure floor is level and solid, and can adequately support • the refrigerator. Contact a carpenter to correct a sagging or sloping floor. Drawers are difficult to move. Food is touching shelf on top of • drawer. Track that drawers slide on is • dirty. Remove top layer of items in drawer. • Ensure drawer is properly installed on track. • Clean drawer, rollers, and track. See • Care & Cleaning.
22 Before You Call (continued)
Problem
Cause
Correction
Running Of Refrigerator
Compressor does not run. Freezer control is set to “OF” • or “0”. Refrigerator is in defrost cycle. • Plug at electrical outlet is dis- • connected. House fuse blown or tripped • circuit breaker. Power outage. • Set freezer control. • This is normal for a fully automatic defrost refrigerator. • The defrost cycle occurs periodically, lasting about 30 minutes. Ensure plug is tightly pushed into outlet. • Check/replace fuse with a 15 amp time-delay fuse. Reset • circuit breaker. Check house lights. Call local electric company. • Refrigerator runs too much or too long. Room or outside weather is • hot. Doors are opened too frequent- • ly or too long. Fresh Food/freezer door may • be slightly open. Freezer control is set too cold. • Fresh Food/freezer gasket is • dirty, worn, cracked, or poorly fitted. Condenser is dirty. • It’s normal for the refrigerator to work longer under these • conditions. Warm air entering the refrigerator causes it to run more. • Open doors less often. Ensure refrigerator is level. Keep food and contains from • blocking door. See PROBLEM column OPENING/CLOSINGOf Doors/Drawers.
Set Fresh Food control to warmer setting until refrigerator • temperature is satisfactory. Allow 24 hours for tempera- ture to stabilize. Clean or change gasket. Leaks in door seal will cause • refrigerator to run longer in order to maintain desired temperatures. Clean condenser. See Care & Cleaning. • Compressor goes off and on frequently. Thermostat keeps the refrigera- • tor at a constant temperature. This is normal. Refrigerator goes on and off to keep tem- • perature constant.Digital Temperature Display
Digital temperature displays are flashing. Electronic control system has • detected a performance prob- lem. Call your Frigidaire service representative, who can inter- • pret any messages or number codes flashing on the digital displays.Water Dispenser
Dispenser will not dis- pense water. Household water line valve is • not open. Ice and water filter cartridge is • clogged. Filter not fully installed. • Open household water line valve. See • PROBLEM columnAutomatic Ice Maker.
Replace filter cartridge. • Push filter in until you hear a “click”. • Water has an odd taste and/or odor. Water has been in the tank for • a period of time. Unit not properly connected to • cold water line. Draw and discard 10-12 glasses of water to freshen the • supply and completely rinse out the tank. Connect unit to cold water line that supplies water to the • kitchen faucet. Water pressure is ex- tremely low. Cut-off and cut-on pressures • are too low (well systems only). Reverse osmosis system is in • regenerative phase. Have someone turn up the cut-off and cut-on pressure on • the water pump system (well systems only). It is normal for a reverse osmosis system to be below 20 • psi during the regenerative phase.Water/Moisture/Frost Inside Refrigerator
Moisture collects on inside of refrigerator walls. Weather is hot and humid. • Door is slightly open. • The rate of frost buildup and internal sweating increases. • See • PROBLEM column OPENING/CLOSING OFDoors/Drawers.
Water collects on bot- tom side of drawer cover. Vegetables contain and give off • moisture. It is not unusual to have moisture on the bottom side of • the cover. Move humidity control (some models) to lower setting. • Water collects in bot- tom of drawer. Washed vegetables and fruit • drain while in the drawer. Dry items before putting them in the drawer. Water col- • lecting in bottom of drawer is normal.Water/Moisture/Frost Outside Refrigerator
Moisture collects on outside of refrigerator or between doors. Weather is humid. • Door is slightly open, causing • cold air from inside refrigerator to meet warm air from outside. This is normal in humid weather. When humidity is lower, • the moisture should disappear. See • PROBLEM column OPENING/CLOSING OFDoors/Drawers.
23 major appliance warranty Your appliance is covered by a one year limited warranty. For one year from your original date of purchase, Electrolux will pay all costs for repairing or replacing any parts of this appliance that prove to be defective in materials or workmanship when such appliance is installed, used and maintained in accordance with the provided instructions. This warranty does not cover the following:
knobs, handles, or other cosmetic parts.
genuine Electrolux parts or parts obtained from persons other than authorized service companies; or
external causes such as abuse, misuse, inadequate power supply, accidents, fires, or acts of God.
