Bosch B30BB130SS Counter-Depth French Door Refrigerator

Register your appliance and join the Bosch family of perks: bosch-home.com/us/ mybosch Freezer refrigerator

B30BB130SS

B30IB100SP

2

Further information and explanations are available online:

Table of contents

1 Safety......................................................................... 4 1.1 Safety definitions....................................................... 4 1.2 General information................................................... 4 1.3 Intended use ............................................................. 4 1.4 Restrictive Use.......................................................... 4 1.5 Safe transport ........................................................... 4 1.6 Safe installation......................................................... 4 1.7 Safe use.................................................................... 5 1.8 Damaged appliance .................................................. 6 1.9 State of California Proposition 65 Warnings .............. 6 2 Preventing material damage .................................... 7 3 Environmental protection and energy-saving ........ 7 3.1 Disposal of packaging............................................... 7 3.2 Saving energy........................................................... 7 4 Installation and connection...................................... 7 4.1 Included in delivery ................................................... 7 4.2 Criteria for the installation location ............................ 8 4.3 Installing the appliance.............................................. 8 4.4 Preparing the appliance for first use.......................... 8 4.5 Connecting the appliance to the drinking water connection ................................................................ 8 4.6 Connecting the appliance to the electricity supply ..... 8 5 Familiarizing yourself with your appliance ............. 9 5.1 Appliance.................................................................. 9 5.2 Control panel........................................................... 10 5.3 Control panel (submenu)......................................... 11 6 Features................................................................... 11 6.1 Shelf ....................................................................... 11 6.2 Storage container.................................................... 11 6.3 Cool-fresh container................................................ 12 6.4 Frozen food pull-out container................................. 12 6.5 Suspended frozen food container............................ 12 6.6 Door tray................................................................. 12 6.7 Ice storage container............................................... 12 6.8 Odor filter................................................................ 12 6.9 Accessories ............................................................ 12 7 Before using the appliance for the first time ........ 13 7.1 Performing initial start-up ........................................ 13 8 Basic Operation ...................................................... 13 8.1 Switching on the appliance...................................... 13 8.2 Operating tips.......................................................... 13 8.3 Switching off the appliance...................................... 13 8.4 Setting the temperature........................................... 13 8.5 Cool-fresh compartment storage setting................... 13 8.6 Keylock .................................................................... 13 9 Basic settings........................................................... 14 9.1 Changing the basic settings ..................................... 14 9.2 Overview of the basic settings.................................. 14 10 Additional functions.............................................. 16 10.1 Super cooling ....................................................... 16 10.2 Automatic Super freezing ...................................... 16 10.3 Manual Super freezing .....

19 Cleaning and maintenance................................... 22 19.1 Care instructions for stainless steel surfaces ........ 22 19.2 Preparing the appliance for cleaning ..................... 22 19.3 Cleaning the appliance.......................................... 22 19.4 Removing the fittings............................................. 23 19.5 Replacing the odor filter ........................................ 24 20 Troubleshooting.................................................... 25 20.1 Power failure......................................................... 27 21 Storage and disposal............................................ 27 21.1 Taking the appliance out of operation ................... 27 21.2 Disposal of your old appliance .............................. 28 22 Customer Service ................................................. 28 22.1 Model number (E-Nr.), production number (FD) and consecutive numbering (Z-Nr.)....................... 28 23 Technical specifications....................................... 28 23.1 Information regarding Free and Open Source Software................................................................ 28

Observe the following safety instructions.

1.1 Safety definitions

Here you can find explanations of the safety signal words used in this manual.

Warning

This indicates that death or serious injuries may occur as a result of non-observance of this warning.

Caution

This indicates that minor or moderate injuries may occur as a result of non-observance of this warning.

Notice:

This indicates that damage to the appliance or property may occur as a result of non-compliance with this advisory.

Note: This alerts you to important information and/or tips.

1.2 General information

• Read this manual carefully. • Keep the manual and the product information in a safe place for future reference or for the next owner. • Do not connect the appliance if it has been damaged in transit.

1.3 Intended use

Only use this appliance:

• for chilling and freezing food, making ice and dispensing water. • for normal household use and in enclosed spaces in a residential environment. • Up to an altitude of 2000 m above sea level.

1.4 Restrictive Use

This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.

Do not let children play with the appliance.

Cleaning and user maintenance must not be performed by children unless they are being supervised.

1.5 Safe transport

Warning

The appliance is very top-heavy and may tip over.

▶ The appliance must be transported by two or more people. ▶ Do not remove the appliance from the pallet until it is ready for installation. ▶ Keep the doors and drawers closed until the appliance is fully installed.

Warning

The heavy weight of the appliance may result in injury when lifted.

▶ Do not lift the appliance on your own.

1.6 Safe installation

Warning

To avoid risk of injury from incorrect repairs, observe the following.

▶ Connect and operate the appliance only in accordance with the specifications on the rating plate. ▶ Connect the appliance to a power supply with alternating current only via a correctly installed socket outlet with grounding. ▶ The protective conductor system of the domestic electrical installation must be properly installed. ▶ Never equip the appliance with an external switching device, e.g. a timer or remote control. ▶ When the appliance is installed, the mains plug of the power cord must be freely accessible. If free access is not possible, an isolating switch must be integrated into the permanent electrical installation according to the installation regulations. ▶ When installing the appliance, check that the power cord is not trapped or damaged.

To avoid risk of injury from damaged insulation of the power cord, observe the following.

▶ Never let the power cord come into contact with heat sources.

Warning

If the appliance's ventilation openings are closed off, a leak in the refrigeration circuit may result in a flammable mixture of gas and air.

▶ Keep ventilation openings in the appliance casing or in the integrated casing clear of obstruction.

Important Safety Instructions

Read And Save These Instructions

Warning

Warning

Caution

1.7 Safe use

Warning

Warning

Warning

Warning

Warning

Warning

Caution

Important Safety Instructions

Read And Save These Instructions

6

▶If water has not been dispensed for 5 days, flush the water system. ▶Store raw meat and fish in suitable containers in the refrigerator so that they do not touch or drip on other food. ▶If the fridge/freezer is empty for an extended period of time, switch off the appliance, defrost it, clean it and leave the door open to prevent the formation of mold. Metal or metal-style parts in the appliance may contain aluminum. If acidic food comes into contact with aluminum in the appliance, aluminum ions may pass into the food. ▶Do not consume soiled food.

1.8 Damaged appliance

Warning

To avoid risk of injury from a damaged appliance or power cord, observe the following. ▶Never operate a damaged appliance. ▶Never pull on the power cord to unplug the appliance. Always unplug the appliance at the power outlet. ▶If the appliance or the power cord is damaged, immediately unplug the power cord or switch off the breaker in the circuit breaker box and turn off the water tap. ▶Call Customer Service. → Page 28

To avoid risk of injury from improper repairs, observe the following. ▶Only qualified technicians or authorized service providers should perform repairs. ▶Only genuine spare parts may be used to repair the appliance. ▶If the power cord or the appliance power cable of this appliance becomes damaged, it must be replaced with a special power cord or special appliance power cable, which is available from the manufacturer or the manufacturer's Customer Service.

Warning

If the tubes are damaged, flammable refrigerant and harmful gases may escape and ignite. ▶Keep open flames and ignition sources away from the appliance. ▶Ventilate the room. ▶Switch off the appliance. ▶Unplug the appliance from the power source or switch off the circuit breaker in the fuse box. ▶Call Customer Service. → Page 28

1.9 State of California Proposition 65 Warnings

This product may contain a chemical known to the State of California, which can cause cancer or reproductive harm. Therefore, the packaging of your product may bear the following label as required by California:

Important Safety Instructions

Read And Save These Instructions

Preventing material damage

Notice:

Environmental protection and energy-saving

3.1 Disposal of packaging The packaging materials are environmentally compatible and can be recycled. ▶Sort the individual components by type and dispose of them separately.

3.2 Saving energy If you follow these instructions, your appliance will use less power.

Selecting the installation location ¡ Keep the appliance out of direct sunlight. ¡ Install the appliance as far away as possible from heating elements, stoves and other heat sources: – Maintain a 1¼" (30 mm) clearance to electric or gas stoves. – Maintain an 11¾" (300 mm) clearance to oil or solid-fuel stoves. ¡ Never cover or block the external ventilation openings.

Saving energy during use Note: The arrangement of the fittings does not affect the energy consumption of the appliance. ¡ Open the appliance only briefly and then close it carefully. ¡ Never cover or block the interior ventilation openings or the exterior ventilation openings. ¡ Transport purchased food in a cooler and place quickly in the appliance. ¡ Allow warm food and drinks to cool down before storing them. ¡ Thaw frozen food in the refrigerator compartment to utilize the low temperature of the food. ¡ Always leave some space between the food and to the back panel. ¡ Vacuum the external ventilation grilles when they are dusty.

Installation and connection

4.1 Included in delivery After unpacking all the parts, check for any damage in transit and for completeness of delivery. If you have any concerns, contact your dealer or our Customer Service → Page 28. The delivery consists of the following: ¡ Equipment and accessories ¡ Installation material ¡ Installation instructions ¡ User manual ¡ Explanation of the limited product warranty ¡ Warranty enclosure ¡ Energy label ¡ Information on energy consumption and noises ¡ Information about Home Connect®

Installation and connection 8

4.2 Criteria for the installation location

Warning

4.3 Installing the appliance ▶Install the appliance in accordance with the enclosed installation instructions.

4.4 Preparing the appliance for first use

4.5 Connecting the appliance to the drinking water connection Requirements ¡ A shut-off valve must be installed on the water connection and be freely accessible following installation of the appliance. ¡ Ensure that the water coming from the water connection is potable. ¡ The water hose has a sealing ring.

4.6 Connecting the appliance to the electricity supply

Familiarizing yourself with your appliance

5 Familiarizing yourself with your appliance

5.1 Appliance

Here you can find an overview of the parts of your appliance.

A

B

C

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 15 16

Your appliance may differ from the diagrams with regard to cosmetic features and dimensions.

A

B

C

1 Main switch

2 Inner ventilation openings (refrigerator compartment)

3 Odor filter → Page 12

Familiarizing yourself with your appliance 10 4 Water dispenser → Page 21 5 Control panel → Page 10 6 Cool-fresh container → Page 12 7 Ice cube maker → Page 21 8 Ice storage container → Page 12 9 Suspended frozen food container → Page 12 10 Water filter → Page 20 11 Interior lighting 12 Storage container → Page 11 13 Door tray for large bottles → Page 12 14 Rating label → Page 28 15 Frozen food pull-out container → Page 12 16 Screw foot 5.2 Control panel You can use the control panel to configure all functions of your appliance and to obtain information about the operating status. 1 2 3 4 2 1 Opens the submenu. 2 Allows the refrigerator compartment to be set. 3 Shows the status of Home Connect®, for example, whether Home Connect® is switched on or off. 4 Opens the menu. Operating logic Some areas of the display respond to touch. You can activate settings by touching the buttons. The activated settings are highlighted on the display. You can change or deactivate the activated settings by repeatedly pressing the relevant buttons on the display. Notice: Pressing on the display with force may cause damage. Do not apply heavy pressure on the display. Do not press on the display using pointed or sharp objects. Symbol Description Navigate back Display additional information Switch on the function Switch off the function Opening the notification center

Features 11 5.3 Control panel (submenu) You can see the current settings and navigate to them in the submenu. 1 2 3 4 3 1 Allows the cool-fresh compartment to be set. 2 Allows the refrigerator compartment to be set. 3 Allows ice cube production to be set. 4 Allows the freezer compartment to be set. Features 6 Features Features The features of your appliance depend on the model. 6.1 Shelf

Notice:

Features 12

6.3 Cool-fresh container To automatically set the cool-fresh container to the right humidity and temperature for your food, use the different cool-fresh container storage settings. Store fresh fruit and vegetables loose in the cool-fresh container. Cover any chopped fruit and vegetables, or store in air- tight packaging. For hygiene reasons, do not store fruit and vegetables in a cool-fresh container with meat and fish. Condensation may form in the cool-fresh container depending on the type and quantity of food stored. Remove the condensation with a dry cloth. To ensure that the quality and aroma are retained, store fruit and vegetables that are sensitive to cold outside of the appliance at temperatures of approximately 46 °F (8 °C) to 54 °F (12 °C), e.g. pineapple, bananas, citrus fruits, cucumbers, zucchinis, bell peppers, tomatoes and potatoes.

6.4 Frozen food pull-out container In order to achieve an improved overview and to remove frozen food more quickly, remove the frozen food pull-out container.

6.5 Suspended frozen food container Store large frozen items in the suspended frozen food container.

6.6 Door tray To adjust the door tray as desired, you can remove the door tray, and re-insert it elsewhere. → "Removing the door tray", Page 23

6.7 Ice storage container If ice cube production is switched on, the ice cubes are automatically stored in the ice storage container.

Notice: The ice maker may become blocked or damaged by food or objects stored in the ice storage container. ▶Never store food or objects in the ice storage container.

Note: To prevent the ice storage container from being overfilled, do not manually distribute the ice cubes throughout the ice storage container.

Tip: To ensure that no ice cubes fall into the freezer compartment from the ice storage container, do not slam the freezer compartment drawer shut.

6.8 Odor filter The odor filter filters odors in the refrigerator compartment and can be replaced if required. → "Replacing the odor filter", Page 24

6.9 Accessories Only use genuine accessories. These are designed especially for your appliance. The accessories for your appliance depend on the model.

Ethylene absorber For important safety instructions and information about installation and use, see the enclosed installation instructions for the ethylene absorber. The ethylene absorber slows down the ripening of ethylene-sensitive fruit and vegetables to keep them fresher for longer.

Installing the ethylene absorber ▶Install the ethylene absorber in accordance with the installation instructions for the ethylene absorber.

Using the refill set

Note: Refill sets can be purchased from customer service or our website.

Ice scoop You can use the ice scoop to remove a portion of ice cubes.

Tip Position the ice shovel on the front side of the ice storage container.

Before using the appliance for the first time

Before using the appliance for the first time

7 Before using the appliance for the first time

7.1 Performing initial start-up

Requirements ¡ The appliance is installed in accordance with the enclosed installation instructions. ¡ The appliance is connected to the electricity supply. → Page 8

Note: If you skip "Home Connect Assistant", further manual settings appear on the display. ‒ Select the temperature unit "Celsius" or "Fahrenheit". ‒ Select the time format "24 hours" or "12 hours". ‒ Set the time and touch "Next". ‒ Press "Activate" to activate oxidation protection or press "Skip" to skip it. ‒ Press "Install" to start the ethylene absorber installation and follow the instructions on the display, or press "Skip" to skip it.

Basic Operation

8 Basic Operation

8.1 Switching on the appliance

8.2 Operating tips

¡ Once you have switched on the appliance, the set temperature is only reached after several hours. Do not put any food in the appliance until the set temperature has been reached. ¡ The front and side panels of the housing heat up occasionally. This prevents condensation from forming. ¡ When closing the door, make sure that the door is not blocked by stored items. ¡ When you close the door, a vacuum may be created. The door is then difficult to open again. Wait a moment until the vacuum is offset. ¡ The temperature in the appliance varies due to the following conditions: – How often the appliance is opened – Load capacity – Temperature of newly stored food – Ambient temperature – Direct sunlight

8.3 Switching off the appliance

▶ Switch off the appliance at the main switch. → "Appliance", Fig. 1 / 1 , Page 9

8.4 Setting the temperature

Setting the refrigerator compartment temperature

The recommended temperature in the refrigerator compartment is 37 °F (3 °C).

Setting the freezer compartment temperature

The recommended temperature in the freezer compartment is 0 °F (−18 °C).

8.5 Cool-fresh compartment storage setting

You can set the temperature and humidity of the cool-fresh compartment using predefined storage settings.

Tip: Further settings are available in the Home Connect® app.

Setting the cool-fresh compartment storage setting

8.6 Keylock

The button lock prevents the appliance from being operated accidentally or incorrectly while running.

Note: You can permanently activate or deactivate the automatic button lock.

Basic settings

Switching off the keylock

Activating the automatic keylock

Deactivating the automatic keylock

Basic settings

9 Basic settings

9.1 Changing the basic settings

9.2 Overview of the basic settings Here you can find an overview of the basic settings and factory settings. The basic settings depend on the features of your appliance.

"Appliance" Setting | Selection | Description Automatic-super Function | On/Off | Activate or deactivate the automatic Super freezing. → "Automatic Super freezing", Page 16

Introduction to the appliance Get to know the appliance and personalize settings.

"Modes" Setting | Selection | Description Normal Mode | On/Off | Switch standard mode on or off. Vacation Mode | On/Off | Switch vacation mode on or off. → "Vacation mode", Page 16 Eco Mode | On/Off | Switch energy-saving mode on or off. Sabbath Mode | On/Off | Switch Sabbath mode on or off. Select a preset time and follow the instructions on the display. → "Sabbath mode", Page 16 Shopping Mode | On/Off | Switch shopping mode on or off.

"Home Network" Setting | Selection | Description WiFi | On/Off | Switch the "Wi-Fi" on or off. Status WiFi | See the information on the display. | Displays the Wi-Fi status. → Page 18 Home Connect Assistant | See the information on the display. | Set up Home Connect®. → Page 17 Network Information | See the information on the display. | Displays the Home Connect® network information. Delete Network Settings | Delete | Reset the Home Connect® settings.

Basic settings 15 "Display" Setting Selection Description Brightness / "Level 1" - "Level 5" Switch the automatic display lighting on or off. Set the display lighting from 1 to 5. "Sounds" Setting Selection Description Volume "Level 1" - "Level 5" Off Set the display volume from 1 to 5. Switch off the display volume. Notification sounds / Switch on, set or switch off the volume for the notification sounds. "Interior Lighting" Setting Selection Description Brightness / "Level 1" - "Level 5" Switch the automatic interior lighting on or off. Set the interior lighting from 1 to 5. Light Interaction / Switch the lighting assistant on or off. Theater Lighting / Switch the theater lighting on or off. "Notifications" Setting Selection Description Hidden notifications Reset Display hidden notifications again. "Language" Setting Selection Description Language English Select the menu language. "Time & Units" Setting Selection Description Time adjustment See the information on the display / Follow the instructions on the display and set the time. Switch the automatically set time on or off. Time format "12"/"24" Set the time format. Temperature unit "°F"/"°C" Set the temperature unit. "Advanced" Setting Selection Description Demo Mode / Switch demo mode on or off. The appliance does not cool in demo mode. Note: Demo mode is only available for a limited time after the appliance is switched on. Factory Settings Restore Reset the appliance to the factory settings.

Additional functions

Additional functions

Find out which additional functions can be used for your appliance. Additional functions can be set via the Home Connect® app.

10.1 Super cooling

With Super cooling, the refrigerator compartment cools as cold as possible.

Switch on Super cooling before placing large quantities of food in the refrigerator compartment.

Note: When Super cooling is switched on, increased noise may occur.

Switching on Super cooling

a "Super Cooling" lights up on the temperature display (refrigerator compartment).

Note: After approximately 6 hours, the appliance switches to normal operation.

Switching off Super cooling

a "Super Cooling" goes out on the temperature display (refrigerator compartment). a The previously set temperature is displayed.

10.2 Automatic Super freezing

With automatic Super freezing, the freezer compartment cools down to a much lower temperature than in normal mode. This freezes food more quickly.

The automatic Super freezing switches on if you place fresh food in the suspended frozen food container, starting from the right-hand side.

If automatic Super freezing is switched on, "Super Freezing" lights up and increased noise may occur.

After operation, the appliance switches from automatic Super freezing to normal operation.

Note: You can find out how to activate and deactivate automatic Super freezing in the basic settings. → Page 14

Canceling automatic Super freezing

a "Super Freezing" goes out on the temperature display (freezer compartment). a The previously set temperature is displayed.

10.3 Manual Super freezing

With Super freezing, the freezer compartment cools as cold as possible.

Switch on Super freezing 4 to 6 hours before placing food weighing 4.4 lbs (2 kg) or more into the freezer compartment.

Use Super freezing to accelerate ice cube production.

Note: When Super freezing is switched on, increased noise may occur.

Switching on manual Super freezing

a "Super Freezing" lights up on the temperature display (freezer compartment).

Note: After approximately 8 hours, the appliance switches to normal operation.

Switching off manual Super freezing

a "Super Freezing" goes out on the temperature display (freezer compartment). a The previously set temperature is displayed.

10.4 Vacation mode

If you are going to be away for a long time, you can switch on energy-saving vacation mode on the appliance.

Caution

The refrigerator compartment heats up while the vacation mode is switched on. The increased temperature may cause bacteria to increase and spoil the food.

When the vacation mode is switched on, do not store any food in the refrigerator compartment.

The appliance automatically sets the temperatures.

Refrigerator compartment 58 °F (14 °C)

Cool-fresh compartment Temperature remains unchanged

Freezer compartment Temperature remains unchanged

Notes

• While the vacation mode is activated, the ice cube production and the water dispenser are switched off. • You can find out how to switch on vacation mode in the basic settings. → Page 14

10.5 Sabbath mode

To ensure that you can also use the appliance on the Sabbath, the Sabbath mode switches off all non-essential functions.

During Sabbath mode, the following functions are switched off:

• Super cooling

Alarm

17

¡ Automatic Super freezing and manual Super freezing ¡ Alarm ¡ Water dispensing ¡ Ice cube production ¡ Interior lighting ¡ Audible signals ¡ Messages on the control panel

Notes

¡ The brightness of the control panel lighting is reduced during the Sabbath mode. ¡ You can find out how to switch on Sabbath mode in the basic settings. → Page 14

Alarm

11 Alarm

Alarm

11.1 Door alarm

If the appliance door is open for a while, the door alarm switches on.

A warning tone sounds and "Door Alarm" appears.

Switching off the door alarm

▶Close the appliance door or touch the designated button.

a The warning tone is switched off.

11.2 Temperature alarm

If the freezer compartment becomes too warm, the temperature alarm will switch on.

A warning tone sounds and "Temperature Alarm" lights up.

Caution

During the thawing process, bacteria may multiply and spoil the frozen food.

▶Do not refreeze partly or completely thawed food.

▶Refreeze food only after cooking.

▶The frozen items should no longer be stored for the maximum storage period.

The temperature alarm can be switched on in the following cases:

¡ The appliance is switched on. Do not store any food until the appliance has reached the set temperature.

¡ Large quantities of fresh food are being placed inside. Switch on Super freezing before placing large quantities of food in the appliance.

¡ The freezer compartment door is open for too long. Check whether the frozen food has defrosted or thawed.

Switching off the temperature alarm

▶Touch "Okay".

a The warning tone is switched off.

a The display indicates the warmest temperature reached in the freezer compartment. The display will then indicate the set temperature again.

a From this time on, the warmest temperature is recalculated and saved.

Home Connect®

12 Home Connect®

Home Connect®

This appliance is network-capable. Connecting your appliance to a mobile device lets you control its functions via the Home Connect® app.

The Home Connect® services are not available in every country. The availability of the Home Connect® function depends on the availability of Home Connect® services in your country. You can find information on this at: www.home-connect.com.

To be able to use Home Connect®, you must first set up the connection to the WLAN home network (Wi-Fi 1) and to the Home Connect® app.

After switching on the appliance, wait at least 2 minutes until internal device initialization is complete. Only then should you set up Home Connect®.

The Home Connect® app guides you through the entire registration process. Follow the instructions in the Home Connect® app to implement the settings.

Tip: Follow the instructions in the Home Connect® app as well.

Notes

¡ Also note the safety information in this instruction manual and ensure that it is also observed when operating the appliance using the Home Connect® app. → "Safety", Page 4

¡ Operating the appliance on the appliance itself always takes priority. It is not possible to operate the appliance using the Home Connect® app during this time.

12.1 Setting up the Home Connect® app

The Home Connect® app guides you through the entire registration process.

12.2 Setting up Home Connect®

Requirement: The appliance receives signals from the WLAN home network (Wi-Fi) at its installation location.

1 Wi-Fi is a registered trade mark of the Wi-Fi Alliance.

Service settings 18

Refrigerator compartment

19

⁠ "Filter Management" Setting Selection Description Water Filter Air Filter Ethylene Absorber See the information on the display. Displays the water filter status. Displays the odor filter status. Displays the ethylene absorber status.

⁠ "Appliance Information" Setting Selection Description See the information on the display. E-Number: Serial Number: FD (Production Date): // Z Number: SSID: MAC: IPv4-address: IPv6-address: Displays information about your appliance.

Refrigerator compartment

14 Refrigerator compartment

Refrigerator compartment

You can keep dairy products, eggs, prepared meals, pastries, open preserves and hard cheese in the refrigerator compartment.

The temperature can be set from 33 °F (1 °C) to 43 °F (6 °C).

The refrigerator compartment can also be used to store highly perishable foods in the short to medium term. The lower the selected temperature, the longer the food remains fresh.

14.1 Tips for storing food in the refrigerator compartment

¡ Only store food when fresh and undamaged. ¡ Store food covered or in air-tight packaging. ¡ To avoid impeding the circulation of air and to prevent food from freezing, do not place food in front of the inner ventilation openings or in direct contact with the back wall. ¡ Allow hot food and drinks to cool down first before placing in the appliance. ¡ Observe the best-before date or expiration date specified by the manufacturer.

14.2 Chill zones in the refrigerator compartment

The air recirculation cooling system allows the air to circulate evenly in the refrigerator compartment and ensures a constant temperature at all shelves.

Coldest zone

The coldest zone is in the bottom area at the back panel.

Tip: Store highly perishable food such as fish, sausages and meat in the cool-fresh compartment.

→ "Cool-fresh compartment", Page 19

Cool-fresh compartment

15 Cool-fresh compartment

Cool-fresh compartment

In the cool-fresh compartment, you can keep fresh food fresh up to three times longer than in the refrigerator compartment.

The temperature can be set from 32 °F (0 °C) to 37 °F (3 °C) using pre-defined storage settings.

Storing food in the cool-fresh compartment retains the quality of the food better. The low temperature and the optimum moisture provide ideal storage conditions for fresh food.

15.1 Storage recommendations for the cool- fresh compartment

Storage setting Food

⁠ Vegetables Vegetables

⁠ Fruit Fruit

⁠ Vegetables & Fruit Mixed load with fruit and vegetables

⁠ Meat Meat

⁠ Fish Fish and seafood

⁠ Deli Cold cuts and sausage products

⁠ Cheese Cheese and dairy products

⁠ Beverages Drinks

Tip: Fruit, vegetables, drinks and snacks may freeze below 32 °F (0 °C).

Use the storage settings for "Meat" and "Fish" only.

Freezer compartment

16 Freezer compartment

Freezer compartment

You can store frozen food, freeze food and make ice cubes in the freezer compartment.

The temperature can be set from 3 °F (−16 °C) to −11 °F (−24 °C).

Long-term storage of food should be at 0 °F (−18 °C) or lower.

To protect foods from freezer burn, a temperature setting of −11 °F (−24 °C) is possible.

Water system

To protect fatty foods such as fish and meat from oxidation, a permanent temperature setting of −11 °F (−24 °C) is possible.

The freezer compartment can be used to store perishable foods long-term. The low temperatures slow down or stop the spoilage.

16.1 Tips for storing food in the freezer compartment

¡ Store food in air-tight packaging. ¡ Do not bring food which is to be frozen into contact with frozen food. ¡ Distribute the food over a wide area in the suspended frozen food container.

16.2 Tips for freezing fresh food

¡ Freeze fresh and undamaged food only. ¡ Freeze food in portions. ¡ Cooked food is more suitable for freezing than food that can be eaten raw. ¡ Vegetables: Wash, chop up and blanch before freezing. ¡ Fruit: Wash, pit and perhaps peel, possibly add sugar or ascorbic acid solution. ¡ Food that is suitable for freezing includes baked items, fish and seafood, meat, game, poultry, eggs without shells, cheese, butter and curd cheese, prepared meals and leftovers. ¡ Food that is unsuitable for freezing includes lettuce, radishes, eggs in shells, grapes, raw apples and pears, yogurt, sour cream, crème fraîche and mayonnaise.

Packing frozen food

If you select suitable packaging material and the correct type of packaging, you can determine the product quality and prevent freezer burn.

16.3 Defrosting methods for frozen food

Caution

During the thawing process, bacteria may multiply and spoil the frozen food.

▶Do not refreeze partly or completely thawed food. ▶Refreeze food only after cooking. ▶The frozen items should no longer be stored for the maximum storage period.

¡ Defrost animal-based food, such as fish, meat, cheese, curd cheese, in the refrigerator compartment. ¡ Defrost bread at room temperature. ¡ Prepare food for immediate consumption in the microwave, in the oven, or on the cooktop.

17 Water system

Your appliance is equipped with water-carrying components.

The water system only works if a water filter or a bypass cap is installed.

Switch off ice cube production before disconnecting the appliance from the drinking water connection.

17.1 Water filter

The water filter filters particles and the taste of chlorine out of the water.

The water filter reduces further contamination, e.g. from chloramines, lead and pharmaceutical products.

Note: The water filter does not filter bacteria or microbes out of the water.

Change the water filter:

¡ Every 6 months. ¡ If "Clean Filter" lights up. ¡ If the water output has visibly reduced. ¡ If ice cube production has visibly reduced.

Tips

¡ A new water filter can be purchased from our customer service, your dealer or our website. ¡ If you do not want to use a water filter in your appliance or an external water filter system is installed, you can permanently replace the water filter with a bypass cap. The bypass cap filters only large particles out of the water and can be cleaned as required. A bypass cap can be purchased from customer service or our website.

Changing the water filter or replacing it with a bypass cap

Water system 21

Defrosting 22 Note: The ice cube maker automatically detects that the ice storage container is full and stops producing ice cubes. It may take up to 48 hours until the ice storage container is full. Tip: If the ice cubes taste stale, dispose of the remaining ice cubes and the cubes produced over the next 24 hours. If the ice cubes still taste stale, change the water filter. Putting the ice maker into operation Notes ¡ Ice cube production starts as soon as the appliance is switched on and the freezer compartment has reached the set temperature. ¡ As soon as the freezer compartment reaches the set temperature, the first batch of ice cubes will be ready in approximately 4 hours. Requirement: The appliance is connected to the drinking water connection. ▶For hygiene reasons, discard the ice cubes produced within the first 24 hours. Switching on ice cube production

Cleaning and maintenance 23 19.4 Removing the fittings If you want to clean the fittings thoroughly, remove these from your appliance. Removing the shelf ▶Lift the shelf and remove it ⁠. Removing the door tray ▶Lift the door tray and remove it. Removing the storage container

Cleaning and maintenance 24

Troubleshooting 25 Troubleshooting You can eliminate minor issues on your appliance yourself. Please read the information on eliminating issues before contacting Customer Service. This may avoid unnecessary repair costs.

Warning

Issue Cause and troubleshooting

The appliance is not cooling, the displays and lighting are lit. Showroom mode is switched on.

The LED lighting does not work. Various causes are possible. ▶Call customer service. → "Customer Service", Page 28

The refrigeration unit is switching on more frequently and for longer. The appliance has been opened frequently. ▶Do not open appliance door unnecessarily. External ventilation openings are covered up. ▶Remove any obstructions from in front of the external ventilation openings. Not a fault. Modern refrigeration machines switch on more frequently and have different power levels to cool more efficiently. ▶Remove any obstructions from in front of the external ventilation openings. ▶Install the appliance as far away as possible from heating elements, cookers and other heat sources. Avoid prolonged exposure of the appliance to direct sunlight. ▶Only open the appliance door as briefly as necessary. ▶Allow hot food and drinks to cool down first before storing in the appliance.

A layer of frost forms on the back wall of the refrigerator compartment. Not a fault. Modern refrigeration machines ensure a more even temperature in the refrigerator compartment. The back wall of the refrigerator compartment is defrosted automatically at regular intervals. ▶Only open the appliance door as briefly as necessary. ▶Pack the food airtight or cover it. ▶Allow hot food and drinks to cool down first before storing in the appliance. ▶Always leave some space between the food and the interior walls.

Home Connect® is not working properly. Various causes are possible. ▶Go to www.home-connect.com.

A message with "D" or "E" appears on the display. The electronics have detected a fault.

A warning tone sounds and "Door Alarm" appears. The door alarm is switched on. The appliance door is open. ▶Close the appliance door.

Troubleshooting 26 Issue Cause and troubleshooting A warning tone sounds and "Temperature Alarm" lights up. The temperature alarm is switched on. Various causes are possible.

Storage and disposal 27 Issue Cause and troubleshooting Ice cube production is low.

Customer Service 28

Warning

Warning

1-800-944-2904 www.bosch-home.com/us/owner-support/get-support www.bosch-home.com/us/shop

1-800-944-2904 www.bosch-home.ca/en/service/get-support www.bosch-home.ca/en/service/cleaners-and-accessories

For assistance with connecting to Home Connect®, you can also view instructions here: www.home-connect.com/us/en/help-support/set-up

22.1 Model number (E-Nr.), production number (FD) and consecutive numbering (Z-Nr.) You can find the model number (E-Nr.), the production number (FD) and the consecutive numbering (Z-Nr.) on the appliance's rating plate. → "Appliance", Fig. 1 /14, Page 10 Making a note of your appliance's details and the Customer Service telephone number will enable you to find them again quickly. Technical specifications 23 Technical specifications Technical specifications Refrigerant, cubic capacity and further technical specifications can be found on the rating plate. → "Appliance", Fig. 1 /14, Page 10 23.1 Information regarding Free and Open Source Software This product includes software components that are licensed by the copyright holders as free or open source software. The applicable license information is stored on your home appliance. You can also access the applicable license information via your Home Connect® app: "Profile -> Legal information -> License Information". You can download the license information on the brand product website. (Please search on the product website for your appliance model and additional documents). Alternatively, you can request the relevant information from ossrequest@bshg.com or BSH Hausgeräte GmbH, Carl- Wery-Str. 34, 81739 Munich, Germany. The source code will be made available to you on request. Please send your request to ossrequest@bshg.com or BSH Hausgeräte GmbH, Carl-Wery-Str. 34, 81739 Munich, Germany. Subject: "OSSREQUEST" The cost of performing your request will be charged to you. This offer is valid for three years from the date of purchase or at least as long as we offer support and spare parts for the relevant appliance.

32

Important Safety Instructions

Read and Keep These Instructions

Safe Installation

To avoid risk of injury from damaged power cord insulation, observe the following: ▶Never allow the power cord to come into contact with heat sources.

Warning

Warning

Power strips or mobile power blocks can overheat and cause fire. ▶Do not place power strips or mobile power blocks behind appliances.

Warning

Caution

1.7 Safe Use

Warning

Warning

Children may inhale or swallow small pieces and choke. ▶Keep small pieces away from children. ▶Never allow children to play with small pieces.

Warning

Products containing flammable propellant gases and explosive materials may explode, e.g., aerosol cans. ▶Do not store products containing flammable propellant gases and explosive materials in the appliance.

Warning

Warning

Important Safety Instructions

Damaged Appliance

Warning

▶Never use a damaged appliance. ▶Never pull on the power cord to disconnect the appliance from the outlet. Always disconnect the male plug of the power cord. ▶If the appliance or power cord is damaged, immediately disconnect the male plug of the power cord or cut the fuse in the fuse box and close the water shut-off valve. ▶Call service. → Page 57

To avoid risk of injury from incorrect repairs, observe the following:

▶Only qualified technicians or authorized service providers can perform repairs. ▶Only original replacement parts can be used to repair the appliance. ▶If the power cord or appliance cord is damaged, they must be replaced by specific cords available from the manufacturer or its service department.

Warning

▶Keep the appliance away from any open flame or source of ignition. ▶Ventilate the room. ▶Turn off the appliance. ▶Remove the plug from the power cord or deactivate the fuse in the fuse box. ▶Call service. → Page 57

Read and Keep These Instructions

Prevent Material Damage

Notice:

▶ Transport the appliance with a hand truck. ▶ When moving the appliance, protect the floor and do not move in zigzags.

Using the base, glides, or doors of the appliance as a seating surface or stepping surface can damage the appliance.

▶ Never use the base, glides, or doors as steps and never lean on them.

Water pressure that is too low or too high may interfere with appliance operation.

▶ Ensure that the water pressure at the water supply is between 29 psi (200 kPa) minimum and 116 psi (800 kPa) maximum.

▶ If the water pressure exceeds the maximum value indicated, a pressure reducer between the drinking water connection and the appliance's hose kit must be installed.

Modified or damaged water hoses can cause material damage or harm the appliance.

▶ Never bend, crush, modify, or cut water hoses. ▶ Never reuse used water hoses. ▶ Never pull on the water hose or the back wall of the appliance.

If soiled by oil or grease, plastic parts and door seals may become porous.

▶ Ensure that plastic parts and door seals are free of oil and grease.

Metal or metallic-looking parts of the appliance may contain aluminum. When in contact with acidic foods, aluminum corrodes and discolors.

▶ Store food in the appliance only if it is packaged.

If you clean equipment parts and accessories in the dishwasher, they may warp or fade.

▶ Never clean equipment and accessories in the dishwasher.

Protecting the Environment and Saving Energy

3.1 Disposal of Packaging

Packaging materials are environmentally friendly and recyclable.

▶ Please dispose of individual parts after sorting them by material.

3.2 Saving Energy

If you follow the instructions below, your appliance will consume less electricity.

Choosing the Installation Location

¡ Protect the appliance from direct sunlight. ¡ Install the appliance as far as possible from radiators, stoves, and other heat sources: – Maintain a distance of 1 1/4″ (30 mm) from electric or gas stoves. – Maintain a distance of 11 13/16″ (300 mm) from an oil or coal heating appliance. ¡ Never cover or block external ventilation openings.

Saving Energy During Use

Note: The arrangement of equipment parts has no effect on the appliance's energy consumption.

¡ Open the appliance only briefly and close it carefully. ¡ Never cover or obstruct internal ventilation grilles or external ventilation openings. ¡ Transport purchased food products in an insulated bag and store them quickly in the appliance. ¡ Allow hot food and beverages to cool before storing. ¡ To take advantage of the cold from frozen products, place products to be thawed in the refrigeration compartment. ¡ Always leave a little space between food products and the back wall. ¡ Vacuum dust from external ventilation grilles.

Installation and Connection

4 Installation and Connection

4.1 Delivery Contents

After unpacking the product, inspect all parts for any damage caused by transport and ensure the complete delivery.

In case of complaints, please contact your dealer or our customer service → Page 57.

The delivery includes: ¡ Equipment and accessories1 ¡ Assembly material ¡ Assembly instructions ¡ User manual ¡ Limited product warranty declaration ¡ Warranty supplementary document2 ¡ Energy label ¡ Information on energy consumption and noise ¡ Information on Home Connect®

4.2 Installation Location Requirements

Warning

If the appliance is installed in a room that is too small, a possible leak in the refrigeration circuit could result in an inflammable mixture of gas and air.

▶ Place the appliance only in a room with a minimum volume of 35 ft3 (1 m3) per 8 g of refrigerant. The amount of refrigerant is indicated on the rating plate. → "Appliance", Fig. 1 /14, Page 38

Depending on the model, the appliance weight at the factory may reach 440 lbs (220 kg).

The floor must be stable enough to support the appliance weight.

4.3 Assembling the Appliance

▶ Assemble the appliance according to the enclosed assembly instructions.

4.4 Preparing the Appliance for First Use

4.5 Connecting the Appliance to the Drinking Water Connection

Requirements ¡ A shut-off valve is installed at the water connection and is freely accessible after the appliance is installed. ¡ The water connection is tested and water quality is drinking water. ¡ The water drain hose is provided with a sealing ring.

If there are permanent deposits or turbidity in the drinking water, install an external water filter system.

4.6 Electrical Connection of the Appliance

The appliance connection data is indicated on the rating plate. → "Appliance", Fig. 1 /14, Page 38

a The appliance is now ready to operate.

1 depending on appliance equipment 2 Not in all countries

Description of the Appliance 37 Description of the Appliance 5 Description of the Appliance Description of the Appliance 5.1 Appliance This section contains an overview of the components of your appliance.

A

B

C

A

B

C

6.3 Fresh Food Drawer To automatically adjust the correct humidity and temperature for your food in the fresh food drawer, use the different setting levels of the fresh food compartment.

Store fresh unpackaged fruits and vegetables in the fresh food drawer.

Store cut fruits and vegetables covered or in airtight packaging.

For hygiene reasons, do not store fruits and vegetables in contact with meat and fish in a fresh food drawer.

Depending on the quantity and nature of the stored products, water may condense in the fresh food drawer. Wipe condensed water with a dry cloth.

To preserve their quality and flavors, store cold-sensitive fruits and vegetables outside the appliance at temperatures between approximately 46 °F (8 °C) to 54 °F (12 °C), for example pineapples, bananas, citrus fruits, cucumbers, zucchini, peppers, tomatoes, and potatoes.

6.4 Frozen Food Drawer For a better overview and to remove frozen food more quickly, pull out the frozen food drawer.

6.5 Suspended Frozen Food Bin Store bulky frozen food in the suspended frozen food bin.

6.6 Door Compartment To vary the position of the compartment in the door according to your needs, you can remove it and replace it in another location.

→ "Removing the Door Compartment", Page 52

6.7 Ice Cube Reserve If ice cube production is activated, ice cubes are automatically stored in the ice cube reserve.

Notice:

▶ Never store food or objects in the ice cube bin.

Note: To avoid overfilling the ice cube reserve, do not manually distribute ice cubes in it.

Tip: To prevent ice cubes from falling from the ice cube reserve into the freezer compartment, do not close the freezer drawer.

6.8 Odor Filter The odor filter filters odors and can be replaced if necessary.

→ "Replacing the Odor Filter", Page 52

6.9 Accessories Use only genuine accessories. They have been specially designed for your appliance.

The accessory for your appliance depends on the model.

Ethylene Absorber Important safety instructions and information about installation and use are included in the ethylene absorber assembly instructions.

The ethylene absorber slows the ripening of ethylene-sensitive fruits and vegetables to preserve their freshness longer.

Installing the Ethylene Absorber

▶ Install the ethylene absorber according to its assembly instructions.

Using the Refill Kit

Note: To obtain refill kits, contact our after-sales service or visit our website.

Ice Scoop

Use the ice scoop to remove a portion of ice cubes.

Tip

Place the ice scoop at the front of the ice cube reserve.

Before First Use

7 Before First Use

Before First Use

7.1 First Start-Up

Requirements

¡ The appliance is installed in accordance with the enclosed installation instructions. ¡ The appliance is electrically connected. → Page 36

Note: If you skip "Home Connect Assistant", additional manual settings will be displayed. ‒ Select the temperature unit "Celsius" or "Fahrenheit". ‒ Select the time format "24 hours" or "12 hours". ‒ Set the time and press "Next". ‒ Enable oxidation protection with "Activate" or skip it with "Skip". ‒ Start ethylene absorber installation with "Install" and follow the on-screen instructions or skip them with "Skip".

Basic Operation

8 Basic Operation

Basic Operation

8.1 Turn On the Appliance

8.2 Notes Regarding Appliance Operation

¡ When you turn on the appliance, it may take several hours before the set temperature is reached. Do not store any food until the set temperature is reached. ¡ The front surfaces and side walls of the housing are slightly heated temporarily. This prevents condensation. ¡ When closing the door, ensure it is not blocked by stored food. ¡ When closing the door, a vacuum may form. The door will then be difficult to reopen. Wait a few moments until the vacuum is equalized. ¡ The appliance temperature varies depending on the following conditions: – Frequency of appliance openings – Load – Temperature of newly stored food – Ambient temperature – Direct exposure to sunlight

8.3 Turn Off the Appliance

▶ Turn off the appliance using the main switch. → "Appliance", Fig. 1 / 1 , Page 37

8.4 Set the Temperature

Set the Refrigerator Temperature

The recommended temperature in the refrigeration compartment is 37 °F (3 °C).

Set the Freezer Temperature

The recommended temperature in the freezer compartment is 0 °F (−18 °C).

8.5 Fresh Food Compartment Levels

You can adjust the temperature and humidity of the fresh food compartment using predefined storage settings.

Tip: Additional settings are available in the Home Connect® app.

Set the Fresh Food Compartment Levels

8.6 Touch Key Lock The touch key lock prevents any unintentional or incorrect use of the appliance.

Note: You can enable or disable automatic lock permanently.

Disable Lock

Enable Automatic Touch Key Lock

Disable Automatic Touch Key Lock

Basic Settings 9 Basic Settings

9.1 Modify Basic Settings

9.2 Overview of Basic Settings This section contains an overview of basic and factory settings. The basic settings depend on your appliance's equipment.

"Appliance" Setting | Selection | Description Automatic-Super Function | / | Enable or disable the automatic Super-Freeze function. → "Automatic Super-Freeze", Page 44

Introduction to the Appliance Familiarize yourself with the appliance and customize the settings.

"Modes" Setting | Selection | Description Normal Mode | / | Enable or disable standard mode. Vacation Mode | / | Enable or disable Vacation mode. → "Vacation Mode", Page 45 Eco Mode | / | Enable or disable Energy Saving mode. Sabbath Mode | / | Enable or disable Sabbath mode. Select a preset time and follow the on-screen instructions. → "Sabbath Mode", Page 45 Shopping Mode | / | Enable or disable Shopping mode.

"Home Network" Setting | Selection | Description WiFi | / | Enable or disable "Wi-Fi". Status WiFi | | Display Wi-Fi status information. → Page 46 Home Connect Assistant | | Configure Home Connect®. → Page 46

"Display" Setting Selection Description Brightness / "Level 1" - "Level 5" Enable or disable automatic screen lighting. Adjust screen lighting from 1 to 5.

"Sounds" Setting Selection Description Volume "Level 1" - "Level 5" Off Adjust screen volume from 1 to 5. Disable screen volume. Notification sounds / Enable, adjust, or disable notification volume.

"Interior Lighting" Setting Selection Description Brightness / "Level 1" - "Level 5" Turn interior lighting on or off automatically. Adjust interior lighting from 1 to 5. Light Interaction / Enable or disable lighting assistants. Theater Lighting / Enable or disable Theater lighting.

"Notifications" Setting Selection Description Hidden notifications Reset Display hidden notifications again.

"Language" Setting Selection Description Language English Français Español Select menu language.

"Time & Units" Setting Selection Description Time adjustment / Follow on-screen instructions and set the time. Enable or disable automatic time adjustment. Time format "12"/"24" Set time format. Temperature unit "°F"/"°C" Set temperature unit.

11 Alarm

11.1 Door Alarm

The door alarm sounds when the appliance door remains open for a long time.

An alarm sounds and "Door Alarm" is displayed.

Deactivating the Door Alarm

▶Close the appliance door or press the alarm button.

a The alarm sound is deactivated.

11.2 Temperature Alarm

If the temperature in the freezer compartment rises too high, the temperature alarm sounds.

An alarm sounds and "Temperature Alarm" is displayed.

Warning

During thawing, bacteria can multiply and frozen food can be damaged.

▶Do not refreeze food that is partially or completely thawed.

▶Only refreeze food after cooking or roasting it.

▶Do not use the full shelf life.

The temperature alarm can be triggered in the following cases:

¡ The appliance is being started. Wait until the set temperature is reached before storing food.

¡ Storage of large quantities of fresh food. Activate Super Freezing before storing large quantities of food.

¡ The freezer compartment door remained open too long. Check if frozen products have thawed.

Turning Off the Temperature Alarm

▶Press "Okay".

a The alarm sound is deactivated.

a The display shows the highest temperature that occurred in the freezer compartment. Then the display shows the set temperature again.

a From this point on, the appliance determines and records the highest temperature again.

12 Home Connect®

Home Connect®

This appliance can be networked. Connect your appliance to a mobile device to control it via the Home Connect® application.

Home Connect® is not available in all countries. The availability of the Home Connect® function depends on the Home Connect® service offerings in your country.

For more information, visit: www.home-connect.com.

To use Home Connect®, first configure the connection to your home WLAN (Wi-Fi) network and the Home Connect® application.

Wait at least 2 minutes after starting the appliance until the internal initialization of the appliance is complete. Then set up Home Connect® first.

The Home Connect® app guides you through the entire connection process. Follow the steps prescribed by the Home Connect® application to proceed with the settings.

Tip: Also observe the instructions in the Home Connect® application.

Notes ¡ Observe the safety instructions in this user manual and ensure that they are also followed if you use the appliance via the Home Connect® application. → "Safety", Page 31 ¡ Commands on the appliance itself always have priority. During this time, control via the Home Connect® application is not possible.

12.1 Configure the Home Connect® Application

12.2 Configure Home Connect®

Requirement: The appliance has access to the home WLAN (Wi-Fi) network at the installation location.

The QR code allows you to install the Home Connect® app and connect your appliance.

12.3 Remote Diagnostics

Customer service can access your appliance using Remote Diagnostics if you request it, provided that your appliance is connected to the Home Connect® server and Remote Diagnostics is available for your appliance and country. For information on Remote Diagnostics availability in your country, see the Service/Support section of your local website: www.home-connect.com.

Please note that while Remote Diagnostics can help resolve certain issues, an on-site visit may be necessary if the problem cannot be resolved remotely.

12.4 Data Protection

Observe the data protection guidelines.

When your appliance first connects to an Internet-connected home network, your appliance transmits the following data categories to the Home Connect® server (initial registration):

¡ Unique appliance code (consisting of appliance keys and the MAC address of the integrated Wi-Fi communication module). ¡ Security certificate of the Wi-Fi communication module (to protect connection information). ¡ The current version of your appliance's software and hardware. ¡ Status of any previous factory settings restoration.

This initial registration prepares the use of Home Connect® functions and is only necessary when you want to use Home Connect® functions for the first time.

Note: Please note that Home Connect® functions are only usable with the Home Connect® application. You can view data protection information in the Home Connect® app.

12.5 Home Connect® Connection Status

Here you will find an overview of the Home Connect® connection status.

Symbol | Description ---|--- | The appliance is connected to the Home Connect® app. | The appliance is not connected to the Home Connect® app. | The appliance has no connection to the home network. | Remote diagnostics is enabled.

13 Service Settings

Service Settings

You can make various service settings.

13.1 Modify Service Settings

How-To Guides

Setting Selection Description Reset Appliance Water Filter Cleaning Ethylene Absorber Replacement Displays step-by-step instructions on the screen. Press the desired instructions and follow them on screen.

Filter Management

Setting Selection Description Water Filter Air Filter Ethylene Absorber Displays the status of the water filter. Displays the status of the odor filter. Displays the status of the ethylene absorber.

Appliance Information

Setting Selection Description E-Number: Serial Number: FD (Production Date): // Z Number: SSID: MAC: IPv4-address: IPv6-address: Displays information about the appliance.

Refrigeration Compartment

14 Refrigeration Compartment

You can store dairy products, eggs, prepared dishes, pastries, opened preserves, and hard cheeses in the refrigeration compartment.

The temperature is adjustable from 33 °F (1 °C) to 43 °F (6 °C).

Cold storage also allows you to store perishable foods for short to medium-term storage. The lower the temperature you choose, the longer foods stay fresh.

14.1 Tips for storing food in the refrigeration compartment

¡ Store only fresh and intact foods. ¡ Keep food in an airtight or covered container. ¡ Do not place food in front of internal ventilation openings or in direct contact with the rear wall to avoid obstructing air circulation and preventing food from freezing. ¡ Allow hot beverages and food to cool before storing. ¡ Observe the expiration date or use-by date indicated by the manufacturer.

14.2 Cold zones of the refrigerator

The air recirculation cooling system circulates air evenly throughout the refrigeration compartment and ensures a constant temperature across all shelves.

Coldest Zone

The lower part near the rear panel is the coldest zone.

Tip: Store perishable foods such as fish, cold cuts, and meat in the fresh food compartment.

Fresh Food Compartment

15 Fresh Food Compartment

You can preserve fresh food up to three times longer in the fresh food compartment compared to the refrigeration compartment.

The temperature can be adjusted from 32 °F (0 °C) to 37 °F (3 °C) through preset level settings.

The quality of stored food is better preserved through cool storage. The low temperature and optimal air humidity create ideal storage conditions for fresh food products.

48

15.1 Storage Recommendations in Fresh Food Compartment

Storage Setting | Foods ---|--- Vegetables | Vegetables Fruit | Fruit Vegetables & Fruit | Mixed groceries with fruits and vegetables Meat | Meat Fish | Fish and seafood Deli | Deli and sausages Cheese | Cheese and dairy products Beverages | Beverages

Tip: Fruits, vegetables, beverages and snacks can be frozen at a temperature below 32 °F (0 °C).

Use storage settings and only for "Meat" and "Fish".

16 Freezer Compartment

Freezer Compartment

In the freezer compartment, you can store frozen foods, freeze foods and make ice cubes.

The temperature is adjustable from 3 °F (−16 °C) to −11 °F (−24 °C).

The long-term storage temperature for food should be 0 °F (–18 °C) or lower.

To protect food from freezer burn, you can set a permanent temperature of −11 °F (−24 °C).

To protect fatty foods such as fish and meat from oxidation, you can set a permanent temperature of −11 °F (−24 °C).

Freezing allows you to store highly perishable foods long-term. Low temperatures slow down or stop food spoilage.

16.1 Tips for Storing Food in the Freezer Compartment

• Keep food in airtight packaging. • Make sure food to be frozen does not come into contact with already frozen food. • Distribute food over a large surface in the suspended frozen product bin.

16.2 Tips for Freezing Fresh Food

• Freeze only fresh food in perfect condition. • Freeze food in portions. • Cooked dishes are more suitable than raw edible foods. • Wash, chop and blanch vegetables before freezing. • Before freezing, wash fruit, remove seeds and peel fruit if necessary, add sugar or ascorbic acid solution if necessary. • Baked goods, fish and seafood, meat, game and poultry, shelled eggs, cheese, butter, curd, prepared dishes and leftovers are suitable for freezing. • Lettuce, radishes, shelled eggs, grapes, raw apples and pears, yogurt, sour cream, fresh cream and mayonnaise are not suitable for freezing.

Wrapping Frozen Foods

Appropriate packaging material and the right type of packaging are essential to maintain product quality and prevent freezer burn.

16.3 Thawing Methods for Frozen Foods

Warning

During thawing, bacteria can multiply and frozen foods can spoil.

▶Do not refreeze partially or fully thawed food products. ▶Only refreeze food after cooking or roasting. ▶Do not use the entire shelf life.

• Thaw animal-origin foods in the refrigeration compartment, for example fish, meat, cheese and curd milk. • Thaw bread at room temperature. • Prepare food in the microwave, oven or on the stovetop for immediate consumption.

17 Hydraulic System

Hydraulic System

Your appliance has components containing water. The hydraulic system only works if a water filter or bypass cap is installed.

Disable ice cube production

Water Filter

The water filter filters particles and chlorine taste from the water.

The water filter reduces other impurities, for example chloramines, lead, and pharmaceuticals.

Note: The water filter does not filter bacteria or microbes.

Change the water filter: • every 6 months. • when "Clean Filter" lights up. • when water flow is visibly reduced. • when ice production is visibly reduced.

Tips • For a new water filter, contact our after-sales service, your dealer, or consult our website. • If you do not want to use a water filter in your appliance or have an external water filter system installed, you can permanently replace the water filter with a bypass cap.

The bypass cap filters only coarse water particles and can be cleaned if necessary.

For a bypass cap, contact our after-sales service or consult our website.

Changing the water filter or replacing it with a bypass cap

Note: Some water will drip from the water filter when you remove it. Wipe dripping water with a dry paper towel.

Tip: You can dispose of the used water filter with household waste.

Water Dispenser

Draw cold water from the water dispenser.

Putting the water dispenser into service

Note: The water system of a newly connected appliance, or one with a new water filter, contains air.

Requirement: The appliance is connected to drinking water.

Water Dispenser

Dispensing Water

▶Press the glass against the dispenser button or place the glass under the water dispenser and press.

Notes

¡ After a certain amount of continuous dispensing, the water and ice dispenser stops. Wait a few seconds before dispensing water again.

¡ After several consecutive dispensing cycles, the water and ice dispenser stops. Wait a few minutes before dispensing water again.

Water Dispenser Button Lock

The button lock prevents unintended or incorrect use of the water dispenser.

Enabling Automatic Water Dispenser Button Lock

Disabling Automatic Water Dispenser Button Lock

Ice Maker

Use the various functions of the ice maker to produce ice cubes.

Warning

Rotating parts can cause injury.

▶Never put your hand under or in the ice maker.

Ice Cubes Production of ice cubes

Quick Ice Acceleration of ice cube production

Note:

"Quick Ice" is only available when ice cube production is enabled.

Note: The ice maker automatically detects when the ice reservoir is full and stops ice production.

Filling the ice reservoir may take up to 48 hours.

Tip: If ice cubes taste unpleasant, discard the remaining ice cubes and ice production for the next 24 hours. If ice cubes continue to taste bad afterward, change the water filter.

Putting the Ice Maker into Service

Notes

¡ Ice production starts as soon as the appliance is turned on and the freezer compartment reaches the set temperature.

¡ The first ice cubes are ready approximately 4 hours after the freezer compartment reaches the set temperature.

Requirement: The appliance is connected to drinking water.

▶For hygiene reasons, discard all ice produced during the first 24 hours.

Starting Ice Production

Stopping Ice Production

51 Defrosting 18 Defrosting 18.1 Defrosting the refrigeration compartment The refrigeration compartment of your appliance defrosts automatically. 18.2 Defrosting the fresh compartment The fresh compartment of your appliance defrosts automatically. 18.3 Defrosting the freezer compartment Thanks to the fully automatic "NoFrost" system, the freezer compartment does not frost over. No defrosting is necessary. No defrosting is necessary. Cleaning and Maintenance 19 Cleaning and Maintenance To keep your appliance operational for a long time, clean and maintain it carefully. Cleaning of inaccessible points must be performed by after-sales service. Cleaning by after-sales service may incur charges. 19.1 Maintenance instructions for stainless steel surfaces For maintenance and cleaning of stainless steel surfaces, use only cleaning products and cloths suitable for stainless steel. Tips • To avoid visible scratches, wipe the stainless steel surface in the direction of its structure. • You can obtain appropriate cleaning products and cloths from our After-sales Service, your retailer, or our website. 19.2 Preparing the appliance for cleaning

Troubleshooting

You can eliminate minor defects in your appliance yourself. Please read the troubleshooting information before contacting customer service. This can avoid unnecessary repair costs.

Warning

To avoid risk of injury from incorrect repairs, follow these points.

▶Only qualified technicians or authorized service providers can perform repairs.

▶Only original replacement parts can be used to repair the appliance.

▶If the power cord or appliance power cord is damaged, they must be replaced with specific cords available from the manufacturer or its after-sales service.

| Defect | Cause and Troubleshooting | |--------|--------------------------| | The appliance does not refrigerate, but displays and lighting are on. | The appliance is in Demo Mode. 1. Press the button. 2. Press "Appliance Settings". 3. Press "Advanced". 4. Press "Demo Mode". | | The LED lighting does not work. | This problem can have many causes. ▶Call after-sales service. → "Customer Service", Page 57 | | The refrigeration unit engages more often and longer. | The appliance door has been opened frequently. ▶Do not open the appliance door unnecessarily. The external ventilation openings are blocked. ▶Remove obstacles in front of the external ventilation openings. This is not a defect. Modern refrigeration appliances start more often and have different power levels to cool more efficiently. ▶Remove obstacles in front of the external ventilation openings. ▶Install the appliance as far as possible from radiators, stoves, and other heat sources. Avoid prolonged exposure of the appliance to direct sunlight. ▶Open the appliance door only as long as necessary. ▶Let hot beverages and food cool first before storing them. | | A layer of frost forms on the rear wall of the refrigeration compartment. | This is not a defect. Modern refrigeration appliances maintain uniform temperature in the refrigeration compartment. The rear wall of the refrigeration compartment is regularly defrosted automatically. ▶Open the appliance door only as long as necessary. ▶Pack food hermetically or cover it. ▶Let hot beverages and food cool first before storing them. ▶Always leave some space between food and interior walls. | | Home Connect® does not work correctly. | This problem can have many causes. ▶Go to www.home-connect.com. | | A message with "D" or "E" appears on the display. | The electronics detected a defect. 1. Turn off the appliance. 2. Unplug the appliance from the outlet. Remove the plug from the power cord or disable the fuse in the fuse box. 3. Reconnect the appliance after 5 minutes. 4. If this message persists, contact after-sales service. → "Customer Service", Page 57 |

Troubleshooting 56

Problem Cause and Troubleshooting

Ice cubes are produced in insufficient quantity.

Food or objects are blocking the ice dispenser level sensor. ▶Remove all objects or food from the ice bucket.

Ice dispenser malfunction.

The ice dispenser does not work.

Ice cube production is disabled. ▶Start ice cube production. → Page 50

No water supply. ▶Make sure there is a water supply and the shut-off valve on the water connection is open. Contact an installer if necessary.

The inlet tube is bent. ▶Turn off the water supply and straighten the water pipe bend. If necessary, replace the water pipe.

Ice dispenser malfunction.

The appliance hums, bubbles, buzzes, clicks, pops, or rumbles.

This is not a defect. A motor is running, e.g., refrigeration unit, fan. Refrigerant circulates through the pipes. The motor, switches, solenoid valves, and water valves turn on or off. Automatic defrosting is in progress. Ice cubes fall into the ice bucket. No action necessary.

The appliance makes noise.

The appliance is not level. ▶Level the appliance using a spirit level and adjustable feet.

Equipment parts wobble or stick. ▶Check removable equipment parts and reposition them correctly if necessary.

Bottles or containers are touching. ▶Separate the containers or bottles from each other.

Super-freezing function is activated. No action necessary.

20.1 Power Outage

In case of a power outage, the temperature inside the appliance increases, which shortens the shelf life and reduces the quality of frozen food.

Notes ¡ Open the appliance as little as possible in case of a power outage and do not store additional food. ¡ Check the quality of food immediately after the power outage. – Discard frozen food that is thawed and has a temperature above 41 °F (5 °C). – Boil or fry slightly thawed frozen food and consume it or refreeze it.

Storage and Disposal

21 Storage and Disposal

Storage and Disposal

21.1 Putting the Appliance Out of Service

21.2 Disposing of a Used Appliance

Environmentally responsible disposal allows for the recovery of valuable raw materials.

Warning

Children risk being trapped in the appliance and endangering their lives.

▶Remove the doors from the appliance. ▶To complicate children's access to the appliance, do not remove the shelves and bins. ▶Keep children away from the appliance that is no longer in use.

Warning

If the tubing is damaged, flammable refrigerant and harmful gases may escape and ignite.

▶Be careful not to damage the refrigeration circuit tubing or insulation.

Customer Service

22 Customer Service

Customer Service

For any repairs carried out under warranty, we ensure that your appliance is repaired with genuine replacement parts by a properly trained and authorized technician. We use only genuine replacement parts in repairs.

For more information on warranty duration and conditions in your country, consult our warranty terms with your retailer or on our website.

When contacting customer service, provide the model number (E-Nr.), serial number (FD), and counting number (Z-Nr.) of the appliance.

USA:

1-800-944-2904 www.bosch-home.com/us/owner-support/get-support www.bosch-home.com/us/shop

Canada:

1-800-944-2904 www.bosch-home.ca/en/service/get-support www.bosch-home.ca/en/service/cleaners-and-accessories

You will also find help for contacting Home Connect® at: www.home-connect.com/us/en/help-support/set-up

22.1 Model Number (E-Nr.), Serial Number (FD), and Counting Number (Z-Nr.)

The model number (E-Nr.), serial number (FD), and counting number (Z-Nr.) are indicated on the appliance's rating plate.

→ "Appliance", Fig. 1 /14, Page 38

To quickly locate your appliance data and the customer service phone number, feel free to copy them elsewhere.

Technical Data

23 Technical Data

Technical Data

The rating plate indicates the refrigerant, net volume, and other technical data.

→ "Appliance", Fig. 1 /14, Page 38

23.1 Open Source Software Information

This product contains software components distributed as open source software by the copyright holder. The corresponding license information is provided on the appliance. License information can also be accessed through the Home Connect® application; "Profile -> Legal Information -> License Information". You can download the license information on the product brand website. (Please search for your appliance model and related documentation on the product website.) You can also request the necessary information by email at ossrequest@bshg.com or by mail to BSH Hausgeräte GmbH, Carl-Wery-Str. 34, D-81739 München.

59 Table of Contents 1 Safety ................................................................ 61 1.1 Safety Definitions....................................... 61 1.2 General Instructions ........................................... 61 1.3 Intended Use............................................................ 61 1.4 User Group Limitations............................. 61 1.5 Safe Transport................................................... 61 1.6 Safe Installation................................................... 61 1.7 Safe Use ............................................................. 62 1.8 Damaged Appliance ...................................................... 63 1.9 Warnings under California Proposition 65 ................................................ 64 2 Avoiding Material Damage.......................................... 65 3 Environmental Protection and Savings .............. 65 3.1 Packaging Disposal Tips ............. 65 3.2 Saving Energy....................................................... 65 4 Installation and Connection............................................ 65 4.1 Delivered Material .................................................. 65 4.2 Requirements for Selecting the Installation Location............................................................... 66 4.3 Appliance Installation............................................ 66 4.4 Preparing the Appliance for First Use.................... 66 4.5 Connecting the Appliance to Water Outlet ................... 66 4.6 Connecting the Appliance to Electrical Outlet...................... 66 5 Getting to Know Your Appliance............................ 67 5.1 Appliance ................................................................... 67 5.2 Control Panel...................................................... 68 5.3 Control Panel (Submenu) .................................... 69 6 Equipment .......................................................... 69 6.1 Tray................................................................... 69 6.2 Storage Container ............................... 69 6.3 Fresh Drawer............................................................ 70 6.4 Frozen Product Sliding Drawer ............. 70 6.5 Suspended Container for Frozen Products ............................................................. 70 6.6 Door Shelves for Bottles......................... 70 6.7 Ice Cube Storage Container ................................ 70 6.8 Odor Filter......................................................... 70 6.9 Accessories .............................................................. 70 7 Before Using the Appliance for the First Time............. 71 7.1 Perform Initial Start-Up..................... 71 8 Basic Operation ......................................................... 71 8.1 Turning On the Appliance................................................ 71 8.2 Warnings Regarding Appliance Operation.................................................................... 71 8.3 Turning Off the Appliance..................................... 71 8.4 Adjusting Temperature .............................................. 71 8.5 Fresh Drawer Storage Settings............ 71 8.6 Key Lock..................................... 72 9 Basic Settings........................................................ 72 9.1 Modifying Basic Settings.......................... 72 9.2 Overview of Basic Settings......................... 72 10 Additional Functions.......................................... 74 10.1 Super Cooling .............................................................. 74 10.2 Automatic Super Freezing Function..................

Important Safety Instructions

Read and Keep These Instructions

Important Safety Instructions

Read and Keep These Instructions

Avoiding Material Damage

Warning:

▶ Transport the appliance with a dolly. ▶ Protect the floor with something when moving the appliance and do not move it in a zigzag pattern.

Standing on or leaning on pedestals, drawers, or doors can damage the appliance.

▶ Do not step on or lean on the pedestal, drawers, or doors.

Water pressure that is too low or too high can negatively affect appliance operation.

▶ Ensure that the water pressure from the water supply device is a minimum of 29 psi (200 kPa) and a maximum of 116 psi (800 kPa).

▶ If water pressure exceeds the maximum value indicated, a pressure reduction valve must be installed between the water outlet and the appliance hose set.

Modified or damaged water hoses can cause damage to property or the appliance.

▶ Do not bend, crush, modify, or cut water hoses. ▶ Never reuse water hoses that have already been used. ▶ Never pull the water hose from the back of the appliance.

Dirt with oil or grease can create pores in plastic parts and door seals.

▶ Keep plastic parts and rubber seals clean of oils and greases.

Metal or metallic-looking parts may contain aluminum. In contact with acidic food, aluminum corrodes and discolors.

▶ Only store packaged food in the appliance.

If appliance elements and accessories are washed in the dishwasher, they could become deformed or discolored.

▶ Never wash appliance elements and accessories in the dishwasher.

Environmental Protection and Energy Savings

3.1 Disposal of Packaging

All packaging materials are environmentally friendly and recyclable.

▶ Dispose of different materials separately according to their nature.

3.2 Save Energy

If you follow these instructions, your appliance will consume less electricity.

Selection of Installation Location

¡ Protect the appliance from direct sunlight. ¡ Install the appliance as far as possible from radiators, ovens, and other heat sources: – Maintain a distance of 1¼" (30 mm) from gas or electric stoves. – Maintain a distance of 11¾" (300 mm) from coal or oil ovens. ¡ Never cover or obstruct exterior ventilation openings.

Energy Savings During Operation

Note: The arrangement of equipment parts does not affect appliance energy consumption.

¡ Open the appliance briefly and close it properly. ¡ Never cover or block interior ventilation openings or exterior ventilation openings. ¡ Transport food in an insulated bag and place it immediately in the freezer. ¡ Allow hot food or beverages to cool to room temperature before storing. ¡ Thaw frozen products inside the refrigerator compartment to take advantage of the cold they release. ¡ Always leave a little space between food and the back panel. ¡ Vacuum dust from exterior ventilation grills.

Installation and Connection

4.1 Delivered Material

After unpacking the appliance, verify that no parts have been damaged during transport and that the supply volume is complete.

If you have any complaints, contact the distributor where you purchased your appliance or our customer service → Page 87.

The scope of delivery consists of:

¡ Equipment and accessories ¡ Installation material ¡ Installation instructions ¡ User manual ¡ Declaration of

5 Getting Familiar with the Appliance

5.1 Appliance

Here you will find an overview of the components of your appliance.

A

B

C

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 15 16

1 The illustrations may show details and equipment features and sizes that do not match those of your specific appliance.

A

B

C

1 Main Switch

2 Interior Ventilation Openings (Refrigeration Compartment)

Control Panel

The control panel allows you to adjust all appliance functions and obtain information about the operating status.

1 2 3 4

1 Opens the submenu.

2 Allows adjustment of the refrigeration compartment.

3 Shows the status of Home Connect®, e.g., if Home Connect® is activated or deactivated.

4 Opens the menu.

Operating Logic

Some areas of the control panel respond to touch. Settings are activated by touching the keys. Activated settings are highlighted on the display panel. Active settings can be modified or deactivated by pressing the corresponding key again.

Warning: Strong impact against the display can cause damage. ▶Do not apply pressure to the display. ▶Do not press the display with sharp or pointed objects.

Symbol Description Go back Show more information on the display panel Activate the function Deactivate the function Open the notification center

6.3 Fresh Drawer

To automatically adjust the temperature and humidity in the fresh drawer for your food, use the different storage settings of the fresh compartment.

Store fresh fruits and vegetables unwrapped in the fresh drawer.

Cover cut fruit and vegetables or store them in airtight containers.

For hygiene reasons, do not store fruit and vegetables with meat and fish together in the fresh drawer.

Depending on the quantity and type of food stored, condensation water may form in the fresh drawer.

Remove condensation water with a dry cloth.

To preserve the quality and flavor of cold-sensitive fruits and vegetables (e.g. pineapples, bananas, citrus, cucumbers, zucchini, peppers, tomatoes and potatoes), it is recommended to store them outside the appliance at an approximate temperature between 46 °F (8 °C) and 54 °F (12 °C).

6.4 Frozen Food Sliding Drawer

For a better overview and to remove frozen products more quickly, the frozen food sliding drawer can be pulled out.

6.5 Suspended Container for Frozen Products

The suspended container allows you to store large frozen products.

6.6 Door Shelves for Bottles

The bottle shelves can be removed and repositioned elsewhere to modify their position as needed.

→ "Remove the door bottle rack", Page 82

6.7 Ice Cube Bin

When ice cube production is activated, ice cubes are automatically stored in the ice cube bin.

Warning:

The ice cube maker device may be damaged or blocked if food or objects are inserted into the ice cube bin.

▶Never place food or objects in the ice cube bin.

Note: To avoid overfilling the ice cube bin, do not distribute ice cubes in the ice cube bin by hand.

Tip: To prevent ice cubes from falling out of the ice cube bin into the freezer, do not slam the freezer drawer shut.

6.8 Odor Filter

The deodorizing filter filters odors and can be replaced if necessary.

→ "Replace the deodorizing filter", Page 82

6.9 Accessories

Use original accessories. They are designed for your appliance.

The appliance accessories depend on the model.

Ethylene Absorber

The ethylene absorber assembly instructions include important safety information and information about its assembly and handling.

The ethylene absorber slows the ripening of fruits and vegetables that are sensitive to this substance, keeping them fresh longer.

Install the Ethylene Absorber

▶Install the ethylene absorber according to its assembly and use instructions.

Use the Replenishment Kit

Note: The replenishment kit can be purchased through our Customer Service or on our website.

Ice Scoop

The ice scoop allows you to remove a portion of ice cubes.

Tip

Place the ice scoop in the front of the ice cube bin.

Before Using the Appliance for the First Time

7 Before Using the Appliance for the First Time

7.1 Performing the First Start-Up

Requirements

¡ The appliance must have been assembled in accordance with the enclosed assembly instructions. ¡ The appliance is electrically connected. → Page 66

Note: If "Home Connect Assistant" is skipped, other manual settings appear on the indicator. ‒ Select the temperature unit "Celsius" or "Fahrenheit". ‒ Select the time format "24 hours" or "12 hours". ‒ Set the time and press "Next". ‒ Activate oxidation protection with "Activate" or skip with "Skip". ‒ Start the ethylene absorber assembly with "Install" and follow the indicator instructions or skip with "Skip".

Basic Operation

8 Basic Operation

Basic Operation

8.1 Turning On the Appliance

a The appliance begins to cool.

8.2 Operating Warnings for the Appliance

¡ Once the appliance is turned on, it takes several hours to reach the set temperature. Do not insert food into the appliance before the set temperature is reached.

¡ The front sides and side walls of the appliance heat up slightly at times. This prevents the formation of condensation water.

¡ When closing the door, make sure it is not blocked by stored objects.

¡ When the door closes, negative pressure may be generated. The door becomes difficult to open again. Wait a moment until the pressure stabilizes.

¡ The appliance temperature varies due to the following conditions: – Frequency with which the appliance is opened – Amount of load – Temperature of fresh food stored – Ambient temperature – Direct solar radiation

8.3 Turning Off the Appliance

▶ Turn off the appliance with the main switch. → "Appliance", Fig. 1 / 1 , Page 67

8.4 Adjusting the Temperature

Adjust the Temperature of the Refrigerator Compartment

The recommended temperature for the refrigeration compartment is 37 °F (3 °C).

Adjust the Freezer Temperature

The recommended freezer temperature is 0 °F (−18 °C).

8.5 Fresh Drawer Storage Settings

You can adjust the temperature and humidity of the fresh drawer with the preset storage settings.

Tip There are more settings available in the Home Connect® app.

Configure the Fresh Drawer Storage Settings

Introduction to the appliance

Familiarize yourself with the appliance and personalize the settings.

Display

Setting Option Description Brightness / "Level 1" - "Level 5" Enable or disable automatic display panel lighting. Adjust display panel lighting from 1 to 5.

Sounds

Setting Option Description Volume "Level 1" - "Level 5" Off Adjust display panel volume from 1 to 5. Mute display panel volume. Notification sounds / Enable, adjust, or disable notification volume.

Interior Lighting

Setting Option Description Brightness / "Level 1" - "Level 5" Enable or disable automatic interior lighting. Adjust interior lighting from 1 to 5. Light Interaction / Enable or disable lighting assistant. Theater Lighting / Enable or disable ambient lighting.

Notifications

Setting Option Description Hidden notifications Reset Restore hidden notifications.

Language

Setting Option Description Language English Adjust menu language.

Time & Units

Setting Option Description Time adjustment See display panel information / Follow display panel instructions and adjust time. Enable or disable automatic time adjustment. Time format "12"/"24" Adjust time format. Temperature unit "°F"/"°C" Adjust temperature unit.

10.4 Vacation Mode

If you are away for an extended period of time, vacation mode can be activated.

Caution

While vacation mode is active, the refrigeration compartment warms up. The temperature increase can contribute to bacterial growth and food spoilage.

▶If vacation mode is active, do not store food in the refrigeration compartment.

The appliance automatically resets the following temperatures.

Refrigeration Compartment

58 °F (14 °C)

Fresh Compartment Temperature unchanged

Freezer Temperature unchanged

Notes ¡ During vacation mode, ice cube production and water dispenser are deactivated. ¡ Basic settings show how to activate vacation mode. → Page 72

10.5 Sabbath Mode

With Sabbath mode, all functions that are not necessary for appliance use during Sabbath are disconnected.

During Sabbath mode, the following functions remain disconnected:

¡ Super Cool ¡ Super Freeze automatic and manual function ¡ Alarm ¡ Water dispenser ¡ Ice cube production ¡ Interior lighting ¡ Acoustic signals ¡ Control panel messages

Notes ¡ During Sabbath mode, control panel lighting is dimmed. ¡ Basic settings show how to activate Sabbath mode. → Page 72

11 Alarm

11.1 Door Alarm

If the door remains open for an extended time, the door alarm activates.

An acoustic signal sounds and "Door Alarm" displays.

Turn Off Door Alarm

▶Close the appliance door or touch the alarm icon.

a The acoustic signal stops.

11.2 Temperature Alarm

The temperature alarm activates if the temperature is too high.

An acoustic signal sounds and "Temperature Alarm" displays.

Caution

Bacteria can multiply during the thawing process of food and food can deteriorate.

▶Do not refreeze food that has thawed or begun to thaw.

▶Only after cooking or frying can it be refrozen.

▶The maximum storage period can no longer be used.

The temperature alarm can activate in the following cases:

¡ The appliance is starting up. Do not store food until the set temperature has been reached.

¡ Large quantities of fresh food have been placed inside. Before storing large quantities of fresh food, activate Super Freeze.

¡ When the freezer door has been open for a long time. Check that food has been completely frozen or thawed.

Turn Off Temperature Alarm

▶Press "Okay".

a The acoustic signal stops. a The display shows the highest temperature recorded in the freezer. Then the display shows the set temperature. a From this point on, the highest temperature is determined again and stored.

12 Home Connect®

Home Connect®

This appliance is suitable for network connection. Connect your appliance with a mobile device to operate functions through the Home Connect® application.

Home Connect® services are not available in all countries. The availability of the Home Connect® function depends on the availability of Home Connect® services in your country. For more information, visit: www.home-connect.com.

Home Connect®

After turning on the appliance, wait at least two minutes for the internal initialization to complete. Only then configure Home Connect®.

The Home Connect® application will guide you through the registration process. Follow the instructions indicated in the Home Connect® application to establish the settings.

Tip: Also observe the instructions of the Home Connect® application.

Notes

¡ You must take into account the safety instructions in this instruction manual and ensure compliance with them when operating the appliance through the Home Connect® application. → "Safety", Page 61

¡ In any case, operation from the appliance itself takes priority. During that time, operation of the appliance through the Home Connect® application is not possible.

12.1 Configure the Home Connect® Application

The Home Connect® application will guide you through the registration process.

12.2 Configure Home Connect®

Requirement: At your location, the appliance receives coverage from the WLAN (Wi-Fi) home network.

With the QR code, you can install the Home Connect® application and connect the appliance.

12.3 Remote Diagnostics

Customer service can access your appliance through Remote Diagnostics if you request it, provided your appliance is connected to the Home Connect® server and Remote Diagnostics is available for your appliance and country. For more information about Remote Diagnostics availability in your country, visit the Service/Support section of your local website: www.home-connect.com.

Please note that, although Remote Diagnostics can help troubleshoot certain issues, there may be cases where an on-site service visit is necessary if the problem cannot be resolved remotely.

12.4 Data Protection

Please observe the data protection instructions.

When you first connect your appliance to an Internet-associated home network, the appliance transmits the following categories of data to the Home Connect® server (initial registration):

¡ Clear identification of the appliance (composed of the appliance key and the MAC address of the Wi-Fi communication module used).

¡ Security certificate of the Wi-Fi communication module (for technical protection of connection information).

¡ Current versions of the appliance's software and hardware.

¡ The status of any previous reset to factory settings.

The initial registration prepares the use of Home Connect® functions and is only necessary the first time you will use these Home Connect® functions.

Note: It should be noted that Home Connect® functions can only be used in connection with the Home Connect® application. Information regarding data protection can be found in the Home Connect® application.

12.5 Home Connect® Connection Status

Here is an overview of the Home Connect® connection status.

Symbol | Description ---|--- | The appliance is connected with the Home Connect® application. | The appliance is not connected with the Home Connect® application.

Service Settings

13 Service Settings

Service Settings

Various service settings can be adjusted.

13.1 Modify Service Settings

13.2 Overview of Service Settings

Here is an overview of the service settings.

⁠ "How-To Guides"

Setting Option Description See information on the display panel. Reset Appliance Water Filter Cleaning Ethylene Absorber Replacement Step-by-step instructions are shown on the display panel. Press the desired instructions and follow the display panel guidance.

⁠ "Filter Management"

Setting Option Description Water Filter Air Filter Ethylene Absorber See information on the display panel. Shows the status of the water filter. Shows the status of the air filter. Shows the status of the ethylene absorber.

⁠ "Appliance Information"

Setting Option Description See information on the display panel. E-Number: Serial Number: FD (Production Date): // Z Number: SSID: MAC: IPv4-address: IPv6-address: Shows appliance information.

Refrigerator Compartment

14 Refrigerator Compartment

Refrigerator Compartment

In the refrigerator compartment, you can store dairy products, eggs, prepared dishes, bakery products, opened preserves, and aged cheeses.

The temperature can be adjusted from 33 °F (1 °C) to 43 °F (6 °C).

In the refrigerator compartment, you can also store perishable foods for the short and medium term. The lower the selected temperature, the longer foods stay fresh.

14.1 Tips for Storing Food in the Refrigerator Compartment

• Store only fresh food in perfect condition. • Store packaged foods hermetically sealed or covered appropriately. • Do not place foods in front of interior ventilation openings or in direct contact with the rear panel to avoid impairing air circulation and preventing food from freezing. • Allow hot foods and beverages to cool. • Follow expiration dates or best-by dates indicated by manufacturers.

14.2 Cold Zones in the Refrigerator Compartment

The refrigeration system with air recirculation circulates air evenly throughout the refrigerator compartment and maintains a constant temperature on all shelves.

The Coldest Zone

The coldest zone is the lower section near the rear panel.

Tip: Store perishable foods (such as fish, deli meats, and meat) in the fresh compartment. → "Fresh Compartment", Page 78

Fresh Food Compartment

Fresh Food Compartment

In the fresh food compartment, food stays in good condition up to three times longer than in the refrigeration compartment.

The temperature can be adjusted from 32 °F (0 °C) to 37 °F (3 °C) using the preset storage settings.

By storing food in the fresh food compartment, the quality of stored food is better preserved.

The low temperature and optimal air humidity provide ideal conditions for storing fresh food.

Storage Recommendations for the Fresh Food Compartment

Storage Setting | Food ---|--- Vegetables | Vegetables Fruit | Fruit Vegetables & Fruit | Mixed load with fruits and vegetables Meat | Meat Fish | Fish and seafood Deli | Cold cuts and deli meats Cheese | Cheese and dairy products Beverages | Beverages

Tip: Fruit, vegetables, beverages, and snacks may freeze below 32 °F (0 °C). Use storage settings only for "Meat" and "Fish".

Freezer

Freezer

In the freezer, it is possible to store frozen products, freeze food, and prepare ice cubes.

The temperature can be adjusted from 3 °F (−16 °C) to −11 °F (−24 °C).

Food storage for long periods should be done at a temperature of 0 °F (−18 °C) or lower.

To protect food from freezer burn, a permanent temperature of −11 °F (−24 °C) can be set.

To protect fatty foods such as fish and meat from oxidation, a permanent temperature of −11 °F (−24 °C) can be set.

Perishable foods can be stored frozen for long periods. Low temperatures slow or stop their deterioration.

Tips for Placing Food in the Freezer

Tips for Freezing Fresh Food

Packaging Frozen Products

Using the appropriate type and material of packaging allows you to significantly preserve the quality of products and prevent freezer burn.

Thawing Methods for Frozen Products

Caution

Bacteria can multiply during the food thawing process and food can deteriorate.

Water System

The appliance has components that conduct water.

The water system only functions if a water filter or bypass cap is installed.

Disconnect ice cube production before disconnecting the appliance from the water supply. → Page 80

Water Filter

The water filter filters water particles and chlorine taste.

The water filter reduces other types of impurities, such as chloramine, lead, and pharmaceuticals.

Note: The water filter does not filter bacteria or microbes from water.

Replace the water filter:

¡ every 6 months. ¡ if "Clean Filter" turns on. ¡ if you notice the water dispenser is running low. ¡ if you notice ice cube production is running low.

Recommendations

¡ A new water filter can be obtained through our customer service, your distributor, or our website. ¡ If you do not wish to use a water filter in the appliance or have an external water filter system installed, you can permanently replace the water filter with a bypass cap.

The bypass cap only filters coarse water particles and can be cleaned if necessary.

You can obtain a bypass cap through our Customer Service or on our website.

Replace the water filter or replace it with a bypass cap

Note: A small amount of water will drip when removing the filter. Remove the dripped water with a dry cloth.

Tip: The used water filter can be discarded with household waste.

Water Dispenser

The dispenser allows you to dispense cold water.

Activating the water dispenser

Note: After connecting the appliance or inserting a new water filter, there is air in the water system.

Defrosting 81 Defrosting 18 Defrosting Defrosting 18.1 Defrosting the refrigeration compartment The refrigeration compartment of the appliance defrosts automatically. 18.2 Defrosting the fresh compartment The fresh compartment of the appliance defrosts automatically. 18.3 Defrosting inside the freezer Thanks to the fully automatic "NoFrost" system, no frost is generated in the freezer. It does not need to be defrosted. Cleaning and care 19 Cleaning and care Cleaning and care To keep the appliance functional for a long time, it must be maintained and cleaned carefully. Cleaning in inaccessible areas must be performed by Customer Service. Cleaning by Customer Service incurs costs. 19.1 Instructions for the care of stainless steel surfaces For the care and cleaning of stainless steel surfaces, use only products and cleaning cloths suitable for stainless steel. Recommendations ▶ To avoid visible scratches, wipe the cloth in the direction of the stainless steel surface texture. ▶ Suitable cleaning products and cloths can be purchased from our Customer Service, a distributor, or on our website. 19.2 Prepare the appliance for cleaning

Warning

Notice:

Troubleshooting

84

Troubleshooting

You can solve minor errors on your appliance yourself. Read the information about how to solve errors before contacting Customer Service. This way you can avoid unnecessary repair costs.

Warning

To avoid risks of injuries from improper repairs, it is recommended to follow the following instructions.

▶Only specialist technicians or authorized service providers should carry out repairs.

▶Only original spare parts can be used to repair the appliance.

▶If the mains connection cable or the connection cable of this appliance is damaged, it must be replaced by a special mains connection cable or by a special connection cable for this appliance that can be obtained from the manufacturer or from your customer service.

Fault Causes and troubleshooting

The appliance does not cool; the indicator panels and interior lighting light up.

Demo mode is activated.

The LED lighting does not work.

Different causes are possible.

▶Contact Customer Service. → "Customer Service", Page 87

The frequency and duration of compressor connection increases.

The appliance has been opened frequently.

▶Do not open the appliance door unnecessarily.

External ventilation openings are covered.

▶Remove the cause of the obstruction of the external ventilation openings.

This is not an error. Modern refrigeration machines turn on more frequently and have different power levels to cool more efficiently.

▶Remove the cause of the obstruction of the external ventilation openings.

▶Place the appliance at the greatest distance possible from resistances, ovens and other heat sources. Avoid prolonged exposure of the appliance to direct solar radiation.

▶Do not keep the appliance door open longer than necessary.

▶Allow hot food and drinks to cool before storing them.

A layer of frost forms on the back wall of the refrigeration compartment.

This is not an error. Modern refrigeration machines ensure a more uniform temperature in the refrigeration compartment. The back panel of the refrigeration compartment defrosts automatically at regular intervals.

▶Do not keep the appliance door open longer than necessary.

▶Package food hermetically or cover it.

▶Allow hot food and drinks to cool before storing them.

▶Always leave some space between the food and the inner walls.

Home Connect® does not work correctly.

Different causes are possible.

▶Access www.home-connect.com.

85

Troubleshooting

Fault Causes and solutions

A message with "D" or "E" appears on the display panel. The electronic system has detected a fault.

A beep sounds and "Door Alarm" appears. The door alarm is activated. The appliance door is open. ▶Close the appliance door.

A beep sounds and "Temperature Alarm" illuminates. The temperature alarm is activated. Various causes are possible.

Large quantities of fresh food have been introduced into the interior. ▶Do not exceed the fresh food freezing capacity of the appliance.

The temperature differs considerably from the selected value. Various causes are possible.

Water leaks from the appliance. The water supply connection or hose has a leak. ▶Check that the water supply connections are tightly secured and the water hose is in good condition. If necessary, replace the water hose.

Water dispenser flow is reduced. The water pressure is too low. ▶Check the water pressure of the water supply device or external water filter system, e.g., reverse osmosis system. Connect to a water outlet with sufficient pressure. → Page 65

The water filter is clogged. ▶Replace the water filter.

Water leaks in the form of drops at the water dispenser. There is air in the water system. ▶Dispense water until no air remains.

The water dispenser does not work. There is no water supply. ▶Make sure there is water supply available and the water outlet shutoff valve is open. If necessary, contact an installer.

There is a kink in the water hose. ▶Turn off the water supply and straighten the kink in the water hose. If necessary, replace the water hose.

Ice production is low. The appliance is connected. ▶Wait approximately 4 hours until the first ice production is complete.

The freezer door has been opened frequently or kept open for an extended period.

Troubleshooting

Fault Causes and Solutions

Ice production is low.

▶Check ice production after a few hours. Water pressure is too low. ▶Check the water pressure of the water supply device or the external water filter system, e.g., the reverse osmosis system. Connect to a water outlet with sufficient pressure. → Page 65 The water filter is clogged. ▶Replace the water filter. Food or objects are blocking the ice maker fill level sensor. ▶Remove all food and objects from the ice maker reservoir. Ice maker fault.

The ice maker does not work.

Ice production is disabled. ▶Turn on ice production. → Page 80 There is no water supply. ▶Make sure water supply is available and that the water outlet shut-off valve is open. If necessary, contact an installer. There is a kink in the water hose. ▶Turn off the water supply and straighten the kink in the water hose. If necessary, replace the water hose. Ice maker fault.

The appliance makes sounds, bubbling, rattling, or emits humming, popping, crackling, or running water noises.

This is not a fault. A motor is running (compressors, fan). Refrigerant flows through the tubes. The motor, switches, solenoid valves, or water valves connect or disconnect. Automatic defrosting is running. Ice cubes fall into the ice maker reservoir. No action is necessary.

The appliance makes noise.

The appliance is positioned unevenly. ▶Level the appliance with the help of a bubble level and the adjustable feet. Appliance components are wobbling or stuck. ▶Check the removable components and, if necessary, reinsert them. Bottles or containers are in contact with each other. ▶Separate the bottles or containers from each other. Super Freeze function is activated. No action is necessary.

Register your appliance to enjoy customized benefits. Thank you for being a Bosch customer! Simply create a MyBosch account, then register your appliance. You'll find a variety of customized information in MyBosch such as:
