Samsung RF28NDEDBSG French Door Refrigerator manual
Refrigerators · 19 Q&As

Samsung RF28NDEDBSG French Door Refrigerator

Ask AI

— answers from the official manual

Answers from the official manual.

Common questions

Common Questions

19 total
1

What is the total storage capacity of the RF28NDEDBSG refrigerator?

The total capacity of the RF28NDEDBSG is 27.8 cubic feet. The refrigerator section holds 18.9 cubic feet and the freezer section holds 8.9 cubic feet. Samsung states this is large enough to fit up to 28 bags of groceries. (Page 2)

2

What warranty coverage comes with the RF28NDEDBSG refrigerator?

The refrigerator comes with a one-year parts and labor warranty on the full unit. The sealed refrigeration system (compressor, evaporator, condenser, drier, and connecting tubing) is covered for five years parts and labor. The Digital Inverter Compressor is covered for ten years on parts and five years on labor. (Page 2)

3

What temperature options are available for the CoolSelect Pantry on the RF28NDEDBSG?

The CoolSelect Pantry offers three temperature control settings: Deli (41°C), Fresh (38°F), and Chilled (32°F). This feature allows users to customize the pantry drawer temperature based on the type of food being stored. (Page 2)

4

What type of shelves are included in the refrigerator section of the RF28NDEDBSG?

The refrigerator includes five tempered glass spill-proof shelves: one Slide-In, one Slide-Out, one Foldable Half, and two Fixed shelves. These tempered glass shelves are designed to contain spills and prevent them from spreading to other areas of the refrigerator. (Page 2)

5

How many door bins does the RF28NDEDBSG refrigerator include and how are they arranged?

The refrigerator includes a total of 8 clear door bins. The right door has 2 Gallon Bins, 2 Regular Bins, and 1 Dairy Bin, while the left door has 3 Regular Bins. (Page 2)

6

Is the RF28NDEDBSG refrigerator ENERGY STAR certified?

Yes, the RF28NDEDBSG is ENERGY STAR-compliant and rated at CEE Tier 3. The unit consumes approximately 651 kWh per year. (Page 1)

Show 13 more questions

Full Manual

2 pages
Page 1

Rf28Ndedbsg

Samsung 28 cu. ft. 3-Door French Door Food Showcase Refrigerator Features
  • Food Showcase Fridge Door
  • Metal Cooling
  • Large Capacity – 28 cu. ft.
  • Twin Cooling Plus®
  • Ice Master Ice Maker in the Refrigerator
  • ENERGY STAR®-Compliant
  • CoolSelect Pantry™ with
  • Temperature Control
  • External Filtered Water and Ice Dispenser
  • High-Efficiency Top and Side LED Lighting
  • Power Freeze and Power Cool Options
  • EZ-Open Handle™ on Freezer Door
  • Available Color Signature Features Food Showcase Fridge Door • Food ShowCase Door gives you easy reach of key items that are most often used, all visible in one glance. Metal Cooling
  • Locks in cold, seals in freshness.
  • Stainless steel paneling helps maintain consistent temperature
  • throughout the refrigerator. Large Capacity
  • Our 28 cu. ft. large-capacity Four-Door French Door
  • has enough room to fit up to 28 bags of groceries.*
  • Grocery comparison based on each cubic foot of usable space equaling one paper bag.
  • Two Humidity-Controlled Crispers
  • Tempered Glass Spill-Proof Shelves
  • Pantry Divider
  • Convenience
  • CoolTight Door
  • Door Alarm
  • Water Filter Indicator
  • Rating ENERGY STAR®-rated: CEE Tier 3 651 kWh/yr Metal Cooling Food Showcase Fridge Door Fingerprint Resistant Black Stainless Steel

    Page 2

    Actual color may vary. Design, specifications, and color availability are subject to change without notice. Non-metric weights and measurements are approximate. ©2018 Samsung Electronics America, Inc. 85 Challenger Road, Ridgefield Park, NJ 07660. Tel: 800-SAMSUNG. samsung.com. Samsung is a registered trademark of Samsung Electronics Co., Ltd.

    Rf28Ndedbsg

    Samsung 28 cu. ft. 3-Door French Door Food Showcase Refrigerator Installation Specifications Dimensions Measure height including flooring. Be sure to allow for hinge clearance height if needed. Measure width including countertop overhang. Measure depth including molding or trim.
  • Measure the height, width and depth of the opening, making sure to include baseboards,
  • molding tile, countertop overhang, etc. Check to be sure there is enough room to open the door (consider walls, islands or other obstacles when measuring).
  • Refer to illustration below to determine dimensions.
  • Allow 2.5" of clearance on hinge side of refrigerator when installing next to a wall
  • where handle may make contact.
  • Allow 1" minimum clearance at rear for proper air circulation and water/electrical
  • connections. Allow a 3/8" minimum clearance at sides and top for ease of installation.
  • Ensure each door and entryway in the home is wide enough for the refrigerator
  • to be moved through easily. For optimal usage and to be able to open refrigerator doors completely, do not install next to a wall. Please note: The following dimension and cutout information is for planning purposes only. For complete installation details, consult manual packed with product, or download manual online at samsung.com. Total Capacity: 27.8 cu. ft. Refrigerator: 18.9 cu. ft.
  • Food Showcase Fridge Door
  • Premium External Filtered Water and Ice Dispenser
  • Ice Master Ice Maker
  • CoolSelect Pantry™ with Temperature Control –
  • Deli (410C), Fresh (380F) and Chilled (320F) options
  • Pantry Divider
  • 2 Humidity-Controlled Crispers
  • 5 Tempered Glass Spill-Proof Shelves:
  • – 1 Slide-In, 1 Slide-Out, 1 Foldable Half, 2 Fixed
  • 8 Clear Door Bins
  • – Right Door: 2 Gallon Bins, 2 Regular Bins, 1 Dairy Bin – Left Door: 3 Regular Bins
  • High-Efficiency Top and Side LED Lighting
  • Freezer: 8.9 cu. ft.
  • EZ-Open Handle™
  • High-Efficiency LED Lighting
  • Warranty One (1) Year Parts and Labor on Refrigerator Five (5) Years Parts and Labor on Sealed Refrigeration System Only* Ten (10) Years Parts and Five (5) Years Labor on Digital Inverter Compressor *Compressor, evaporator, condenser, drier and connecting tubing. Product Dimensions & Weight Dimensions (WxHxD with hinges, handles and doors): 35 3/4" x 70" x 36" Dimensions (WxHxD without hinges and door): 35 3/4" x 68 7/8" x 29" Dimensions (WxHxD with hinge and door, no handle): 35 3/4" x 70" x 33 1/2" Weight: 370.4 lbs. Shipping Dimensions & Weight (WxHxD) Dimensions: 38 5/8" x 76 5/8" x 36 1/4" Weight: 396.8 lbs. Color Model # UPC Code Fingerprint Resistant Black Stainless Steel

    Rf28Ndedbsg 887276279947

    36" 33 1/2" 70" 11/4" 3/16" 4215/16" 24 9/16" 9/16" 17/8" 50 1/4" 29" 17 5/16" 41/16" 35 3/4"
