What is the annual energy consumption rating for the RF28R7551SR?

The RF28R7551SR is ENERGY STAR rated and consumes 755 kWh per year. The refrigerator is ENERGY STAR compliant and features high efficiency LED lighting to help reduce energy usage. (Page 1)

2

How much ice can the RF28R7551SR store at one time?

The RF28R7551SR features Ice Max, which stores up to 4.2 lbs of ice at a time. The refrigerator also includes Power Freeze and Power Cool options to help quickly chill or freeze items. (Page 1)

3

What shelf configuration does the RF28R7551SR refrigerator section include?

The refrigerator section includes 5 tempered glass spill-proof shelves: 1 slide-in, 1 slide-out, 1 foldable half, and 2 fixed shelves. It also has 6 door bins — 3 on the right door and 3 regular bins on the left door — along with 2 humidity-controlled crispers. (Page 2)

4

What are the clearance requirements when installing the RF28R7551SR refrigerator?

Allow 2.5 inches of clearance on the hinge side when installing next to a wall where the handle may make contact. You should also allow 1 inch minimum clearance at the rear for proper air circulation and water/electrical connections, and a 3/8 inch minimum clearance at the sides and top for ease of installation. For optimal usage and to be able to open refrigerator doors completely, do not install next to a wall. (Page 2)

5

What is the total storage capacity of the RF28R7551SR refrigerator?

The total capacity of the RF28R7551SR is 27.7 cubic feet. This is broken down into 15.6 cu. ft. for the refrigerator, 3.8 cu. ft. for the FlexZone Drawer, and 8.3 cu. ft. for the freezer. (Page 2)

6

What are the four temperature settings available in the FlexZone Drawer?

The FlexZone Drawer offers four temperature zones: Meat/Fish (29°F), Cold Drinks (33°F), Deli/Snacks (37°F), and Wine/Party Dishes (42°F). The drawer also includes a Smart Divider to help separate items stored at different temperatures. (Page 2)

Show 32 more questions

What is the warranty coverage for the RF28R7551SR refrigerator?

What are the overall dimensions and weight of the RF28R7551SR refrigerator?

Does the RF28R7551SR refrigerator have Wi-Fi and smart home capabilities?

What are the total capacity and storage dimensions of the RF28R7551SR refrigerator?

What temperature settings are available in the FlexZone™ Drawer?

How much clearance do I need to allow when installing this refrigerator?

What is the warranty coverage on the RF28R7551SR?

How many shelves are in the refrigerator section and what types are they?

What is the ice storage capacity of this refrigerator?

What cooling features does the RF28R7551SR have?

What are the available color finishes for this model?

What smart home features does the Family Hub™ touchscreen offer?

What door and storage bin configuration does this refrigerator have?

Can I see inside the RF28R7551SR refrigerator remotely?

What temperature settings are available in the FlexZone™ Drawer?

What smart home features can be accessed through the Family Hub™?

Does the refrigerator have an ice maker and how much ice can it store?

How much storage capacity does this refrigerator have?

How many built-in cameras does the Family Hub™ touchscreen have?

What are the space requirements I need to measure before installing this refrigerator?

What type of shelving does the refrigerator section have?

What is the total capacity of the RF28R7551SR refrigerator?

How many temperature settings does the FlexZone™ Drawer have?

Can I install this refrigerator directly next to a wall?

What warranty coverage does this refrigerator include?

What are the actual dimensions of this refrigerator with doors and handles?

What smart home features does the Family Hub™ touchscreen offer?

How can I see inside my refrigerator when I'm not home?

What is the energy consumption rating for this model?

How much ice can the Ice Max feature store?

What are the installation clearance requirements for the Samsung RF28R7551SR refrigerator?

What are the exact dimensions of the RF28R7551SR refrigerator?

Full Manual

2 pages
Page 1

Rf28R7551Sr

28 cu. ft. 4-Door French Door Refrigerator with 21.5" Connected Touchscreen Family Hub™ Convenience
  • FlexZone™ Drawer with 4 Temperature
  • Settings and Smart Divider
  • Wi-Fi and Bixby Enabled
  • Adjustable Shelves for
  • Tall Oversized Items
  • Auto Pull-Out Upper Freezer Drawer
  • Water Filter Indicator
  • Design
  • Fingerprint Resistant Finish
  • Modern External Filtered Water
  • and Ice Dispenser
  • High Efficiency LED Lighting
  • EZ-Open Handle™ on Freezer Door
  • and FlexZone™ Drawer
  • Tempered Glass Spill-Proof Shelves
  • Gallon Door Bins
  • Dispenser Light
  • FlexZone™ Drawer Family Hub™ Rating ENERGY STAR® rated: 755 kWh/yr Performance
  • Twin Cooling Plus®
  • Metal Cooling
  • 25W Built-In Speaker
  • Ice Max - Stores up to 4.2 lbs of ice
  • ENERGY STAR® Compliant
  • Power Freeze and Power Cool Options
  • Two Humidity-Controlled Crispers
  • CoolTight Door
  • Door Alarm
  • Signature Features Food
  • See inside your refrigerator from anywhere, with 3 built-in cameras.
  • Create and share shopping lists, plan meals based on the food inside
  • your refrigerator and automically set expiration dates. Family
  • Create your own home screen with Family Board, by adding personalized
  • pictures, stickers and handwritten notes.
  • Customize your screen saver with picture slide show, weather and animations.
  • Fun
  • Stream your favorite music service directly on your Family Hub™ screen.
  • Mirror your Samsung TV or Samsung phone, right on your Family Hub™.
  • Your Home
  • Access your smart devices and Samsung appliances from your Family Hub™
  • screen; set lights, hear and speak to someone at your front door, monitor your baby’s room and receive laundry end-of-cycle notifications.
  • Receive Wi-Fi updates so your fridge stays up to date with the latest
  • features and apps.

  • Intelligent voice assistant allows hands-free navigation.
  • Recognizes user’s voice and provides a personalized experience.
  • Voice 2.0 Available Colors Fingerprint Resistant Stainless Steel (shown) Fingerprint Resistant Black Stainless Steel Fingerprint Resistant Tuscan Stainless Steel

    Page 2

    Actual color may vary. Design, specifications, and color availability are subject to change without notice. Non-metric weights and measurements are approximate. ©2019 Samsung Electronics America, Inc., 85 Challenger Road, Ridgefield Park, NJ 07660. Tel: 800-SAMSUNG. samsung.com. Samsung is a registered trademark of Samsung Electronics Co., Ltd.

    Rf28R7551Sr

    28 cu. ft. 4-Door French Door Refrigerator with 21.5" Connected Touchscreen Family Hub™ Installation Specifications Measure height including flooring. Be sure to allow for hinge clearance height if needed. Measure width including countertop overhang. Measure depth including molding or trim.
  • Measure the height, width and depth of the opening, making sure to include baseboards,
  • molding tile, countertop overhang, etc. Check to be sure there is enough room to open the door (consider walls, islands or other obstacles when measuring).
  • Refer to illustration below to determine dimensions.
  • Allow 2.5" of clearance on hinge side of refrigerator when installing next to a wall
  • where handle may make contact.
  • Allow 1" minimum clearance at rear for proper air circulation and water/electrical
  • connections. Allow a 3/8" minimum clearance at sides and top for ease of installation.
  • Ensure each door and entryway in the home is wide enough for the refrigerator
  • to be moved through easily. For optimal usage and to be able to open refrigerator doors completely, do not install next to a wall. Please note: The following dimension and cutout information is for planning purposes only. For complete installation details, consult manual packed with product, or download manual online at samsung.com. Total Capacity: 27.7 cu. ft. Refrigerator: 15.6 cu. ft.
  • 2 Humidity-Controlled Crispers
  • 5 Tempered Glass Spill-Proof Shelves
  • – 1 Slide-In – 1 Slide-Out – 1 Foldable Half – 2 Fixed
  • 6 Door Bins
  • – Right Door: 3 Door Bins – Left Door: 3 Regular Bins
  • Metal Cooling
  • High Efficiency LED Lighting
  • FlexZone™ Drawer: 3.8 cu. ft.
  • EZ-Open Handle™
  • 4 Temperature Zones with Smart Divider
  • – Meat/Fish (29°F) – Cold Drinks (33°F) – Deli/Snacks (37°F) – Wine/Party Dishes (42°F) Freezer: 8.3 cu. ft.
  • EZ-Open Handle™
  • Take Out Box
  • 1 Drawer Divider
  • High Efficiency LED Lighting
  • Warranty One (1) Year Parts and Labor on Refrigerator Five (5) Years Parts and Labor on Sealed Refrigeration System Only* Ten (10) Years Parts and Five (5) Years Labor on Digital Inverter Compressor *Compressor, evaporator, condenser, drier and connecting tubing. Product Dimensions & Weight Dimensions (WxHxD with hinges, handles and doors): 35 3/4" x 70" x 361/2" Dimensions (WxHxD without hinges and door): 35 3/4" x 68 7/8" x 291/2" Dimensions (WxHxD with hinge and door, no handle): 35 3/4" x 70" x 34" Weight: 346 lbs Shipping Dimensions & Weight (WxHxD) Dimensions: 38 1/4" x 75 3/4" x 361/4" Weight: 368 lbs Color Model # UPC Code Fingerprint Resistant Stainless Steel

    Rf28R7551Sr

    887276345321 Fingerprint Resistant Black Stainless Steel

    Rf28R7551Sg

    887276345314 Fingerprint Resistant Tuscan Stainless Steel

    Rf28R7551Dt

    887276345307 Dimensions

    A

    34"

    B

    35 3/4" 68 7/8"

    D70"

    E

    36 1/2" 621/8" 13 1/4" 125° 125° 2" 29 1/2" 53" 481/4" 35 3/4" 4 3/4" 2 3/8"
