2 Your new washer dryer You have chosen a Bosch washer dryer. Please take a few minutes to read and become familiar with the advantages of your washer dryer. To meet the high quality demands required by Bosch, every washer dryer that leaves our factory is carefully checked to ensure that it functions correctly and is in perfect condition. For more information on our products, accessories, replacement parts and services, see our website www.bosch- home.comor contact our after-sales service centres. If the operating and installation instructions describe different models, any differences will be pointed out at the relevant points in the text. Read these operating and installation instructions before switching on the washer dryer. Display rules : Warning! This combination of symbol and signal word indicates a possibly dangerous situation. Not heeding the warning can cause death or injuries. Caution! This signal word indicates a possibly dangerous situation. Not heeding the caution can cause property and/or environmental damage. Note/tip Information about the optimum use of the appliance/any other useful information.

en 3 ContentsenInstruction Manual and Installation Instructions 8 Intended use. . . . . . . . . . . . . . . . .4 ( Safety instructions . . . . . . . . . . .5 Electrical safety. . . . . . . . . . . . . . . . . . 5 Risk of injury. . . . . . . . . . . . . . . . . . . . 5 Safety for children. . . . . . . . . . . . . . . . 5 7 Protection of the environment . .6 Packaging/old appliance . . . . . . . . . . 6 Hints and tips . . . . . . . . . . . . . . . . . . . 6 Y The main points in brief . . . . . . .7

en Intended use 4 4 Customer service . . . . . . . . . . . 35 J Technical specifications . . . . . 35 [ Consumption values . . . . . . . . 36 5 Positioning and connecting. . . 37 Included with the appliance . . . . . . . 37 Safety instructions . . . . . . . . . . . . . . 38 Installation surface. . . . . . . . . . . . . . 38 Installing the appliance on a base or on a wooden joist ceiling. . . . . . . 38 Installing the appliance in a kitchenette . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38 Removing the transport locks . . . . . 39 Hose and cable lengths. . . . . . . . . . 39 Water inlet . . . . . . . . . . . . . . . . . . . . 40 Water outlet . . . . . . . . . . . . . . . . . . . 41 Alignment . . . . . . . . . . . . . . . . . . . . 42 Electrical connection . . . . . . . . . . . . 42 Before washing/drying for the first time . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43 Transportation . . . . . . . . . . . . . . . . . 43 8 Intended use Intended use■ For private domestic use only. ■ The washer dryer is suitable for machine washable textiles and hand washable wool and for drying certain types of textiles according to care instructions. ■ The appliance is suitable for operation with cold mains water and commercially available detergents and care products which are suitable for use in a washer dryer. ■ Always follow the manufacturer's instructions when dosing all detergents, cleaning aids, cleaning products and cleaning agents. ■ The washer dryer may be operated by children from 8 years of age, by persons who have limited physical, sensory or mental abilities and by persons who have inadequate experience or knowledge, provided they are supervised or have been instructed by a responsible person.Children must not perform any cleaning or maintenance work without supervision. ■ Keep children under the age of 3 years away from the washer dryer. ■ Keep pets away from the washer dryer. ■ Install and operate the washer dryer in a room which has an outflow. Before operating the appliance: Read the installation and operating instructions and all other information enclosed with the washing machine, and use the machine accordingly. Retain documents for subsequent use.

Safety instructions en 5 ( Safety instructions Safety instructionsElectrical safety :Warning Danger of death! Danger of death if live parts are touched. ■ When disconnecting the mains plug, always pull the plug itself and not the cable, otherwise the cable could be damaged. ■ Never touch or hold the mains plug with wet hands. Risk of injury :Warning Risk of injury! ■ If the washer dryer is lifted using projecting parts (e.g. the washer dryer door), these components may break off and cause injuries. Do not lift the washer dryer by its projecting parts. ■ If you climb onto the washer dryer, the worktop may break and cause injuries. Do not climb onto the washer dryer. ■ If you lean/support yourself on the open door, the washer dryer may overturn and cause injuries. Do not lean on the open washer dryer door. ■ If you reach into the rotating drum, you may injure your hands. Do not grip the rotating drum. Wait until the drum stops rotating. :Warning Risk of scalding! ■ When washing at high temperatures, you may be scalded if you touch the hot washing water (e.g. if draining hot washing water into a washbasin). Do not touch the hot washing water. ■ If a drying programme was interrupted, the washer dryer and laundry may be very hot. Select Intensive Dry 5 or Gentle Dry ‰ and select 15 min drying time to cool down the washing and then remove. Safety for children :Warning Danger of death! If children play with the washer dryer, they may get into life- threatening situations or injure themselves. ■ Do not leave children unattended near the washer dryer. ■ Do not let children play with the washer dryer. :Warning Danger of death! Children may lock themselves in appliances, putting their lives at risk. For appliances that have reached the end of their service life: ■ Disconnect the mains plug.

en Protection of the environment 6 ■ Cut through the mains cable and remove it, along with plug. ■ Destroy the lock on the washer dryer door. :Warning Risk of choking! Children may become wrapped in packaging/film or packing parts if allowed to play with them, or they may pull them over their heads and suffocate. Keep packaging, film and packaging parts out of the reach of children. :Warning Risk of poisoning! Detergents and care products may be poisonous if consumed. Keep detergents and care products out of the reach of children. :Warning Eye / skin irritation! Detergents and care products may cause irritation if they come into contact with the eyes or skin. Keep detergents and care products out of the reach of children. :Warning Risk of injury! When you wash/dry at high temperatures, the glass in the washer dryer door gets hot. Do not let children touch the hot washer dryer door. 7 Protection of the environment Protection of the environmentPackaging/old appliance ) Dispose of packaging in an environmentally friendly manner. This appliance has been identified in accordance with the European Directive 2012/19/EU on Waste Electrical and Electronic Equipment (WEEE). The Directive specifies the framework for an EU-wide valid return and recycling of waste appliances. Hints and tips ■ Utilise the maximum amount of washing for the particular programme. Overview of programmes ~ Page 20 ■ Wash normally soiled laundry without prewash. ■ Energy saving mode: The display panel light goes out after several minutes, I flashes. To reactivate the display, select any button. The energy-saving mode is not activated if a programme is running. ■ The selectable temperatures apply to the care labels on the textiles. The temperatures in the machine may deviate from this so that you get the optimum mix of energy-saving and washing results. ■ If the laundry is then dried in the appliance, select the maximum possible spin speed. The less water the laundry contains, the less time and energy are required for drying. Do not dry dripping wet laundry.

The main points in brief en 7 Y The main points in brief The main points in brief -------- -------- -------- -------- 1 @ @ @ Plug into the mains. Turn the tap on. Open the washer dryer door. Select the washing/ drying programme Max. load and/or remaining time in display panel. 2 @ @ If required, change the programme default settings and/or select additional functions. Sort the laundry. Load the laundry. 3 @ @ @

Fodfn

en Getting to know your appliance 8

( Detergent drawer 0 Operating/display panel 8 Door with handle 9S Open the door 9T Close the door @ Service flap

Getting to know your appliance en 9 Control panel Change the default settings for the selected programme and select additional functions:  #

( Select a programme. Can be rotated in either direction. To switch off the washer dryer, set the programme selector to Off. 0 Select buttons °C Temp.(Temperature), 0 rpm (Spin speed), 5 Finished in and Š Dry for changing default settings.~ Page 24 Select buttons G Speed Perfect/F Eco Perfect and O Rinse Plus for additional functions. 8 Display panel for information. @ Start programme. Select the A Start/Reload button to start, interrupt (e.g. reload laundry) and cancel the programme.

en Getting to know your appliance 10 Display panel Displays for the programme

  # + (: Temperature for washing programme Ž (cold) – 90° Temperature in °C 0: Programme information 1:50* Programme duration after programme selection in h:min (hours:minutes) 1 – 24 h Finish in time in h (h=hour) 8.0 kg* Max. load for selected programmes 0 – 1500 0* Spin speed in revolutions per minute. If spin speed is selected as 0, all spinning pro- cesses will be cancelled and the water after final rinse cycle will be pumped out. Programme status: End Programme end 0:00 Wrinkle guard process is running ~ Page 19 – – – – End of programme with spin speed setting – – – – Further information:

E : - -*

N

O

Š

Getting to know your appliance en 11 @: Programme information and additional function symbols E lights up On if childproof lock has been activated ~ Page 18 E flashes The childproof lock is actived, and if the pro- gramme selector has been adjusted or the buttons have been pressed Õ lights up When the door is locked Õ flashes When pressing the Start/Reload button to start the programme, the door is not closed properly. r lights up Water pressure too low. This extends the programme duration r flashes The tap has not been turned on or there is no water pressure

Å

G

F

Ï

Š

A

en Laundry 12 Z Laundry LaundryPreparing laundry for washing Sorting laundry according to: Sort your laundry according to the care instructions and specifications of the manufacturer on the care labels: ■ Type of fabric/fibre ■ Colour Note: Laundry can discolour or not be cleaned correctly. Wash white and coloured items separately. Wash new bright fabrics separately the first time you wash them. ■ Soiling – light do not prewash; if necessary select the ( speed additional function. – normal Select programme with prewash. If required, pretreat stains. – heavy Load less washing. Select programme with prewash. If required, pretreat stains. – Stains: Remove/pretreat stains while they are fresh. Firstly, dab with a soap water; do not rub. Then select the appropriate programme and wash the items. Stubborn or dried-in stains can sometimes only be removed by washing several times. – Symbols on the care labels Note: The numbers in the symbols indicate the maximum washing temperature that may be used. Protecting your laundry and appliance Caution! Damage to the appliance/textiles Foreign objects (e.g. coins, paper clips, needles, nails) may damage the washing or components of the appliance. The following instructions must be observed when preparing your laundry: ■ Always follow the manufacturer's instructions when dosing all detergents, cleaning aids, care products and cleaning agents. ■ Do not exceed maximum load. Overfilling will impair the washing result. ■ Keep detergents and agents for the pretreatment of laundry (e.g. stain remover, prewash sprays, etc.) away from the surfaces of the appliance. Using a damp cloth, immediately remove any fine spray residue and other residue or droplets. ■ Empty any pockets. Remove any foreign objects.

M

N

O

W

Ž

Laundry en 13 ■ Remove metal parts (paper clips, etc.). ■ Trousers, knitwear and knitted textiles, e.g. jersey garments, T-shirts or sweatshirts, should be turned inside out. ■ Ensure that underwired bras are appliance-washable. ■ Wash delicates in a net or bag (tights, underwired bras, etc). ■ Close zips, button up covers. ■ Brush sand out of pockets and collars. ■ Remove curtain fittings or include in the net/bag. Preparing laundry for drying Note: To ensure an even drying result, sort the laundry according to the: ■ Type of fabric ■ Drying programme ■ Care symbols which are indicated on the care labels. Only dry laundry which is labelled “dryer-proof” or which has the following care symbols: ■ a = Dry at normal temperature (Intensive Dry Š ) ■ ` = Dry at low temperature (Gentle Dry ‰ ) The following textiles must not be dried: ■ b = care symbol “Do not dry” ■ Wool or textiles containing wool. ■ Delicates (silk, synthetic curtains). ■ Textiles which contain foam rubber or similar materials. ■ Textiles which were treated with flammable liquids, e.g. with stain remover, petroleum ether, thinners. Risk of explosion! ■ Textiles which still contain hairspray or similar substances. Notes ■ Before drying, hand-washed textiles must be spun at the appropriate spin speed. ■ Before drying, spin at the optimum speed. A spin speed of more than 1000 rpm is recommended for cotton, more than 800 rpm for easy- care textiles. ■ Do not iron washing immediately after drying. It is recommended to roll the washing up first to distribute residual moisture evenly. ■ To ensure a good drying performance, quilts, terry cloths and other large textiles should be dried separately. Do not dry more than 5 terry cloths (or 4 kg). ■ Do not exceed the maximum load.

en Operating the appliance 14 1 Operating the appliance Operating the appliancePreparing the washer dryer The washer dryer was tested before delivery. To remove residual water from the test procedure, the first wash cycle should be run without laundry using the Drum Clean Û programme. Before washing/drying for the first time ~ Page 43 Note: ■ Never switch on a damaged washer dryer! ■ Inform your customer service!~ Page 35

Operating the appliance en 15 Adjusting the washing programme You can use the displayed default settings or adjust the selected programme optimally to the laundry items by changing the default settings or selecting additional functions. The selectable settings and additional functions depend on the selected washing/drying programme. Overview of programmes~ Page 20 Notes ■ Options can be selected, deselected or changed depending on the progress of the programme. ■ The buttons are sensitive, they only need to be touched gently. If the button °C Temp., 0 rpm, ñ Finished in is held down, the setting options are automatically scrolled through. Changing default settings for a washing programme, e. g. washing temperature: ■ Touch the °C Temp. button to set desired washing temperature. Changing the additional functions for a washing programme, e.g. select G Speed Perfect: ■ Touch the G Speed Perfect/F Eco Perfect button until the G indicator light comes on. Note: After changing the programme default settings and/or additional functions, the programme duration may change. Adjusting the drying programme Note: If an individual drying programme or washing and drying without interruption is selected, you can change the default settings for the drying programme if required. Overview of programmes~ Page 20 Changing the default settings for a drying programme: ■ Touch the Š Drying button to set the desired drying mode or drying time (only for an individual drying programme). Note: After changing the default settings for the drying programme, the programme duration may change.

en Operating the appliance 16 Loading the laundry :Warning Danger of death! Laundry items pretreated with solvent- based detergents, e.g. stain remover/ petroleum ether, may cause an explosion if loaded into the washer dryer. Thoroughly rinse laundry items by hand before washing. Notes ■ Mix large and small items. Laundry items of different sizes distribute themselves better during the spin cycle. Individual laundry items may cause an unbalanced load. ■ Observe the indicated maximum load. Overfilling adversely affects the washing result and promotes creasing.

Operating the appliance en 17

en Operating the appliance 18 Childproof lock You can secure the washer dryer to prevent the set functions from being changed inadvertently. To do this, activate the childproof lock when the programme has started. Activating/deactivating: Touch and hold the buttons 0 rpm and û Finish in for approx. 3 seconds. The symbol w is indicated in the display. If the button signal is activated, an acoustic signal sounds. ■ w lights up: The childproof lock is activated. ■ w flashes: The childproof lock is active and the programme selector has been adjusted. To prevent the w symbol from flashing, reset the programme selector to the initial programme. The symbol lights up again. Note: The childproof lock may remain activated until the next programme starts, even after the washer dryer has been switched off. If this is the case, deactivate the childproof lock before the programme starts and, if required, re- activate after the programme starts. Reloading the laundry When the programme has started, the laundry can be reloaded or taken out as required. Touch the Start/Reload button. The washer dryer checks whether reloading is possible. Notes ■ If there is a high water level, high temperature or if the drum is rotating, the door remains locked for safety reasons and reloading is not possible. If the following is indicated on the display panel: Õ is lit ~ Reloading is not possible. To continue the programme, select the I Start/ Reload button. ■ Do not open the door until the door lock symbol Õ goes out. ■ Do not leave door open for a prolonged period – water could run out of the laundry. ■ The reloading function cannot be activated during the drying phase. Changing the programme If you have started the wrong programme by mistake, you can change the programme as follows:

O.

Operating the appliance en 19 For drying programmes:

en Overview of programmes 20 / Overview of programmes Overview of programmesProgramme on the programme selector Programme/Type of washing Options/Information Name of the programme Brief explanation of the programme and which textiles it is suitable for. maximum load according to

En50229

G, F, Ï

G, F, Ï

G, F, Ï

G, F, Ï

Overview of programmes en 21 Anti-allergy ; Hardwearing textiles made of cotton or linen. Notes ■ Especially suitable for increased hygienic demands or particu- larly sensitive skin on account of prolonged washing at a defined temperature, with a higher water level and longer rins- ing cycle. ■

G, F, Ï

G, F, Ï

G, F, Ï

Ï

en Overview of programmes 22 W Wool ã Hand and machine-washable fabrics made of wool or wool blend; particularly gentle wash programme to prevent shrinkage of laun- dry, with longer programme breaks (soaking garments in the deter- gent solution). Note: ■ Wool is of animal origin, e.g.: Angora, alpaca, llama, sheep. ■ Use a detergent suitable for machine washable wool. max. 2 kg Ž (cold) – 40 °C – – – –, 0 – 800 rpm – – Delicate/Silk “ For delicate, washable textiles, e.g.made of silk, satin, synthetic fibres or blended fabrics. Note: Use a detergent suitable for machine washable delicate fabrics or silk. max. 2 kg Ž (cold) – 40 °C – – – –, 0 – 800 rpm

G, F, Ï

Overview of programmes en 23 Drying table Estimated drying time (min) Load type Recommended drying pro- gramme Drying load (kg) Cupboard dry » Extra dry · Cottons/coloureds (color fast tex- tiles made of cotton or linen such as underwear, T-shirts, pullover, kitchen towels, terry cloths, bed sheets, table cloths, work clothes, bath towels) Intensive dryŠ 0.5 - 2.0 40 - 90 60 - 100 2.0 - 3.5 90 - 160 100 - 180 3.5 - 5.0 160 - 220 180 - 225 Easy-care (textiles made of syn- thetic materials or blended fabrics such as shirts, sportswear) Gentle Dry‰ 0.5 - 1.5 35 - 75 40 - 120 1.5 - 2.5 75 - 120 120 - 190 Drying pro- gramme Drying load (kg) Adjustable drying time (min) Time Dry ~1.0 60 ~2.5 120 ± The times are approximate and refer to a normal load, standard spin programme and room tempera- ture. ± The maximum selectable drying time is 120 min. If the laundry weighs more than 2.5 kg, select auto- matic drying. This function is recommended to ensure good drying results and save energy. The 15-min- ute drying programme is used to cool the laundry. ± To get evenly dried result, separate thick layered fabric from lightweight ones. For example, separate terry cloth from shirts. ± Extra dry · is recommended for terry cloth and other large or thick layered textiles. ± Reduce the maximum load mass for terry cloth to 4kg for throughout drying. ± Wool must not be dried in the washer dryer. ± To receive less wrinkled drying result, load less laundry.

en Changing programme default settings 24 Starching Note: The laundry should not be treated with fabric softener. Liquid starch can be used in all wash programmes. Pour starch into the dispenser M according to manufacturer’s specifications (if required, clean beforehand). Dyeing/Bleaching Dye in household quantities only. Salt may attack stainless steel! Observe specifications of the dye manufacturer! Do not bleach laundry in the washer dryer! Soaking

Changing programme default settings en 25 Finish in @:Define the Finish in time (end of programme). Note: The respective programme duration is displayed by selecting the programme. The programme duration is automatically adjusted while the programme is running if the programme duration needs to be changed, e.g. due to changes in the programme default settings. Before the programme starts, the end of the programme can be preselected in hourly increments up to a maximum of 24h. When the programme has started, the preselected time is displayed e.g. 8h and counts down until the programme starts. Then the programme duration is displayed, e.g. 2:30. When the programme has started, the preselected time can be changed as follows:

en Selecting additional functions 26 \ Selecting additional functions Selecting additional functionsYou can select your desired additional functions by touching the respective buttons. G (SpeedPerfect) For a shorter wash time with a comparable washing result to the standard programme. Note: Do not exceed maximum load. Overview of programmes~ Page 20 EcoPerfect F 0: Energy-optimised washing by reducing the temperature while achieving a consistent washing result. Note: The washing temperature is lower than the selected temperature. For special hygiene requirements, the Anti-allergy ; programme is recommended. à RinsePlus Increased water level and extended wash time. For areas with very soft water or for further enhancing the washing result.

Setting the signal en 27 MSetting the signal Setting the signal Setting signal volume

en Cleaning and maintenance 28 2 Cleaning and maintenance Cleaning and maintenance:Warning Risk of electric shock! Danger of death if live parts are touched. Switch off the appliance and disconnect at the mains plug. :Warning Risk of poisoning! Solvent-based cleaning agents, e.g. petroleum ether, in the washer dryer may cause toxic vapours. Do not use solvent-based cleaning agents. Caution! Damage to the appliance Solvent-based cleaning agents, e.g. petroleum ether, may damage the surfaces and components of the washer dryer. Do not use solvent-based cleaning agents. Appliance housing/control panel ■ Remove the detergent residue immediately. ■ Wipe the housing and the control panel with a soft, damp cloth. ■ Do not use abrasive cloths, sponges or detergents (stainless steel cleaner). ■ Do not clean the appliance with a water jet. Drum Use chlorine-free cleaning agents, do not use steel wool. Descaling Not required if detergent dosed correctly. However, if this does occur, follow the instructions of the descaling agent manufacturer. Suitable descalers can be purchased on our website or from customer service. ~ Page 35 Cleaning the detergent dispenser If it contains detergent or fabric softener residue:

Cleaning and maintenance en 29 Drain pump blocked :Warning Risk of scalding! When you wash at high temperatures, the water gets very hot. If you come into contact with the hot water, you may be scalded. Allow the water to cool down.

en Cleaning and maintenance 30 Filter in the water inlet hose blocked :Warning Danger of death! Do not immerse the Aqua-Stop safety device in water (it contains an electric valve). First, reduce the water pressure in the supply hose:

Faults and what to do about them en 31 3 Faults and what to do about them Faults and what to do about themEmergency release, e.g. if a power failure occurs e.g. in the event of a power cut The programme will continue running when the power supply has been restored. However, if the laundry has to be removed, the washer dryer door can be opened as follows: :Warning Risk of scalding! When you are washing at high temperatures, there is a risk of scalding if you come into contact with detergent solution and laundry. If possible, leave it to cool down. :Warning Risk of injury! You may injure your hands if you reach into the drum while it is turning. Do not reach into the drum when it is turning. Wait until the drum has stopped turning. Caution! Water damage Any escaping water may cause water damage. Do not open the washer dryer door if water can be seen through the glass.

en Faults and what to do about them 32 Information on the display panel Faults and what to do about them Information Cause/Remedy

Õ

E:18

E:32

E:95

Faults and what to do about them en 33 Programme does not start. ■ I (Start/Reload) or û Finish in selected? ■ Door closed? ■ Childproof lock active? Deactivate. ~ Page 18 Detergent solution is not drained. ■

en Faults and what to do about them 34 Fluff found on the washed laundry. Run the Drum Clean Ž (cold) programme without laundry and detergent to remove fluff which have accumulated inside the drum during the previous dry- ing cycle. Water inlet noise during the drying phase. The washer dryer uses water condensation technology, water is constantly needed to dry the laundry. Therefore the tap must be on all the time, till the end of drying phase. Drying duration extended. ■ Run the Drum Clean Ž (cold) programme to remove fluff which has col- lected in the washer drum during the drying phase. Drying programme does not start. ■ Drying programme not selected? Overview of programmes ~ Page 20 ■ Door not closed properly? The drying result is not satisfactory (laundry is not dry enough). ■ Excessively high ambient temperature (above 30 °C) or inadequate venti- lation in the room in which the washer dryer is situated. ■ The laundry has not been spun well enough before drying. Always set the highest selectable spin speed for the particular washing programme. ■ Washer dryer overloaded: Observe the recommendations for the maxi- mum load in the programme table and on the load display. Do not overload the washer dryer, as the maximum load for the drying phase is less than the maximum load for the wash cycle. Unload the washer dryer after wash- ing with the maximum load and divide the laundry into two drying cycles. ■ The power supply voltage is too low (below 200 V) – provide a suitable power supply. ■ The water pressure is low. According to water condensing principle, low water pressure will cause evaporated steam not condensed totally. ■ The tap is closed during drying. Due to the use of the water condensation technology for drying, please keep the connected water tap open during the drying process, otherwise proper drying cannot be guaranteed. ■ Thick multilayered textiles or textiles with thick fillings dry easily on the sur- face, but not inside. This equalisation process may take longer. For these types of textiles, select drying mode · (Extra dry), or select additional time drying via Intensive Dry Š or Gentle Dry ‰ programmes. If a fault cannot be rectified (switching the machine on and off) or a repair is required: ■ Set the programme selector to $ Off and pull out the mains plug. ■ Turn off the tap and call customer service. ~ Page 35 Faults Cause/Remedy

Customer service en 35 4 Customer service Customer serviceIf you cannot correct the fault yourself, see section, Faults and what to do about them ~ Page 32 Please contact our customer service. We will always find a suitable solution and aim to avoid unnecessary visits by technicians Please give customer service the product number (E-Nr.) and the production number (FD) of the appliance. You can find this information on: the inside of the door */opened service flap * and the back of the appliance. *depending on model Rely on the competence of the manufacturer. Contact us. You can therefore be sure that the repair is carried out by trained service technicians who carry original spare parts. J Technical specifications Technical specificationsDimensions: 850 x 600 x 590 mm (height x width x depth) Weight: 80 kg Mains connection: Mains voltage 220 - 240 V/50 Hz Nominal current 10 A Nominal power 1900 - 2300 W Water pressure: 100 - 1000 kPa (1 - 10 bar) Drain height: 60 - 100 cm Power consumption when switched off:

0,12 W

0,48 W

(1U

en Consumption values 36 [ Consumption values Consumption values Programme Option Load (kg) Energy consumption *** (kWh) Water Consumption *** (liter) Programme duration *** (hours) Cottons i20 °C* 8,0 0,30 78 3 Cottons i40 °C* 8,0 1,06 78 3 Cottons i60 °C 8,0 1,08 78 3 Cottons i90 °C 8,0 2,20 88 3 Easy-Care f 40 °C* 4,0 0,76 65 2 Mix o 40 °C 4,0 0,62 46 1 ] Delicate/Silk “ 30 °C 2,0 0,16 36 ¾ h Wool ã30 °C 2,0 0,20 40 ¾ Intensive Dry 5 5,0 2,82 24 3 ] Gentle Dry ‰ 2,5 1,49 25 2 Cottons i60 °C ** ¦ eco 8,0 0,83 71 7 Cottons i 60 °C + Intensive Dry 5 ** ¦ eco 8,0/ 5,0+3,0 5,44 118 13 ½

Positioning and connecting en 37 5 Positioning and connecting Positioning and connectingIncluded with the appliance Note: Check the machine for transport damage. Never use a damaged machine. If you have any complaints, contact the dealer from whom you purchased the appliance or our customer services. ~ Page 35 In addition, a hose clamp (24 - 40 mm diameter, available from specialist dealers) is required to connect the water drain hose to a siphon. Useful tools ■ Spirit level for aligning ■ Spanner with: – WAF13 for loosening the transport braces, and – WAF17 for aligning the appliance feet ( Mains cable 0 Bag: ■ Installation and operating instructions ■ Customer services location directory* ■ Warranty* ■ Cover caps for openings after the transport braces have been removed 8 Water supply hose on Aqua-Stop models 3 +

#   @ Water drain hose

H

P

en Positioning and connecting 38 Safety instructions :Warning Risk of injury! ■ The washer dryer is very heavy. Be careful when lifting/transporting the washer dryer. ■ When the washer dryer is lifted by its protruding parts (e.g. the washer dryer door), the components may break off and cause injuries. Do not lift the washer dryer by protruding parts. ■ If the hose and mains cables are not routed properly, there is a risk of tripping and injury. Lay hoses and cables in such a way that there is no risk of tripping. Caution! Damage to the appliance Frozen hoses may rip/burst. Do not install the washer dryer in areas exposed to frost or outdoors. Caution! Water damage The connection points for the water supply hose and water drain hose are under high water pressure. To prevent leaks and water damage, you must follow the instructions in this section. Notes ■ In addition to the safety information listed here, the local water and electricity supplier may have special requirements. ■ If in doubt, have the appliance connected by a specialist. Installation surface Note: The washer dryer must be stable so that it does not move around. ■ The installation surface must be firm and level. ■ Soft floors/floor coverings are not suitable. Installing the appliance on a base or on a wooden joist ceiling Caution! Damage to the appliance The washer dryer may wander during the spin cycle and topple or fall off its base. Always secure the washer dryer feet with holding brackets. Holding brackets: order no.

Wmz 2200, Wx 975600, Cz 110600,

Z 7080X0.

Positioning and connecting en 39 Removing the transport locks Caution! Damage to the appliance ■ The machine is secured for transportation using transport locks. If the transport locks are not removed, the drum, for example, may become damaged when the machine is operated. Before using the appliance for the first time, make sure that you completely remove all four transport locks. Keep the locks in a safe place. ■ To prevent transport damage from occurring if the appliance is moved at a later date, you must refit the transport locks before transporting the appliance. Note: Keep the screws and sleeves in a safe place.

11350, Z 7070X0.

Plq

Fp

Pd[

Fp

en Positioning and connecting 40 Water inlet :Warning Danger of death! There is a risk of electric shock if you touch live components. Do not immerse the Aqua-Stop safety valve in water (it contains an electric valve). Notes ■ Only operate the washer dryer using cold mains water. ■ Do not connect the machine to the mixer tap of an unpressurised hot- water boiler. ■ Do not use a used supply hose. Only use the supply hose supplied or one that was purchased from an authorised specialist retailer. ■ Do not kink or squash the water supply hose. ■ Do not alter (shorten, cut through) the water supply hose (otherwise its strength is no longer guaranteed). ■ Only tighten the screw connections by hand. If the screw connections are tightened too much with a tool (pliers), the thread may become damaged. Optimum water pressure in the supply network At least 100 kPa (1 bar) Maximum 1000 kPa (10 bar) When the tap is open, the water flow rate is at least 8 l/min. If the water pressure is higher than this, a pressure-reducing valve must be installed. Connection Connect the water supply hose to the tap (26.4 mm = ¾") and to the appliance (not necessary for Aqua-Stop models as this is permanently installed): ■ Model: Standard ■ Model: Aqua-Secure ■ Model: Aqua-Stop Note: Turn on the tap carefully, checking the leak tightness of the connection points. The screw connection is under mains water pressure.

Positioning and connecting en 41 Water outlet :Warning Risk of scalding! When you are washing at high temperatures, there is a risk of scalding if you come into contact with hot water (e.g. when draining hot water into a washbasin). Do not reach into the hot water. Caution! Water damage If the drain hose slips out of the washbasin or the connection point during draining due to high water pressure, any escaping water may cause water damage. Secure the drain hose so that it cannot slip out. Caution! Damage to the appliance/fabrics If the end of the drain hose is immersed in the drained water, water may be sucked back into the appliance and may damage the appliance/fabrics. Make sure that: ■ The plug does not block drainage from the washbasin. ■ The end of the drain hose is not immersed in the drained water. ■ The water drains away quickly enough. Note: Do not kink the water drain hose or put strain on it lengthways. Connection ■ Drainage into a washbasin ■ Drainage into a siphon The connection point must be secured using a hose clamp with a diameter of 24 - 40 mm (available from specialist dealers). ■ Drainage into a plastic pipe with rubber bushing or into a drainage pit

en Positioning and connecting 42 Alignment

Positioning and connecting en 43 Before washing/drying for the first time The washer dryer was inspected thoroughly before leaving the factory. To remove any residual test water, run the Drum Clean Ûprogramme the first time without laundry. Note: ■ The washer dryer must have been installed and connected properly. Installation and connection ■ Never switch on a damaged washer dryer. Inform your customer service.~ Page 35
