Bosch 500 Series SHXM63WS5N Dishwasher

Operating instructions Dishwasher

Shxm63Ws5N

3 Table of contents

Operating instructions

Safety Definitions. . . . . . . . . . .5 Important Safety Instructions . . . . . . . . . . . .6 Causes of Damage. . . . . . . . .9 Getting Started . . . . . . . . . . . .10 Water softening system / special salt . . . . . . . . . . . . . . .13 Rinse Aid. . . . . . . . . . . . . . . . .15 Loading the Dishwasher . . . .16 Detergent . . . . . . . . . . . . . . . .24 Dishwasher Cycles . . . . . . . .26 Dishwasher Cycle Options . .27 Operating the Dishwasher. . .29 Care and Maintenance. . . . . .33 Troubleshooting . . . . . . . . . . .37 Customer Service. . . . . . . . . .41 Statement of Limited Product Warranty . . . . . . . . . . . . . . . . . .42

Valued Customer

Thank you for selecting a Bosch dishwasher. You have joined the many consumers who demand quiet and superior performance from their dishwashers.

If you have any questions or comments, please contact us by phone at:

While there, don't forget to register your new dishwasher by clicking on the "Support" tab or by filling out the product registration card enclosed with your new unit.

www.BoschhomeUS.com USA

or

www.BoschhomeUS.ca Canada

To learn more about your dishwasher and available accessories, as well as many other top quality Bosch appliances, visit our website at:

This manual was written with your safety and convenience in mind and the information contained herein is very important. We highly recommend that you read this manual before using your dishwasher for the first time.

BSH Home Appliances Corporation

Main Street, Suite

or write us at:

Irvine, CA

Safety Definitions

Safety Definitions

Warning

Caution

Notice

Note: This alerts you to important information and/or tips.

9 Important Safety Instructions

Read And Save These Instructions

Important Safety Instructions

Important Safety Instructions

Read And Save These Instructions

9 Warning

Risk Of Injury Or Death!

9 Warning

Risk Of Injury!

9 Warning

Risk Of Electrical Shock

Or Fire!

9 Warning

Health Hazard!

9 Important Safety Instructions

Read And Save These Instructions

Grounding Instructions

9 Warning

Risk Of Electric Shock!

9 Caution

9 Warning

Risk Of Injury!

9 Important Safety Instructions

Read And Save These Instructions

9 Warning

Risk Of Explosion!

Notice

9 Warning

State Of California

Proposition 65 Warnings!

Causes of Damage

ƒ Causes of Damage

Causes of Damage NOTICES

■ Never use steam cleaning products to clean your dishwasher. The manufacturer will not be liable for the possible damages or consequences.

■ Bleach-based wipes can cause stainless-steel doors and tubs to rust.

■ Using harsh chemicals (e.g. bleach), abrasive cleaners, scouring pads (metal or plastic), or abrasive cloths/paper towels can damage your dishwasher's exterior door panel, fascia panel and buttons.

■ To avoid dishwasher damage, do not load the dishwasher with paper products, plastic bags, packing materials or anything other than normal, dishwasher safe dishware and kitchenware.

Getting Started

Getting StartedAppliance overview

The dotted lines show optional features which may or may not be included with your dishwasher.

Getting Started

11

The numbers stated below refer to the overview images on the previous page of this manual.

Operating panel Dishwasher interior components

Display indicators

On/Off button Wash cycles Digital display Delay start button Wash cycle options Start button Interior light * Third rack Upper rack Upper spray arm Detergent tab tray Vent hole Lower spray arm Dispenser for special salt* Filters Silverware basket Lower rack Rinse aid dispenser Detergent dispenser Lock for detergent dispenser Rating plate

Cycle time remaining Clean Lights up when dishes are clean

Sanitize Lights up when sanitation requirements are met

Add Rinse Aid Lights up when rinse aid is low

Add Salt Lights up when salt is low

Getting Started 12 Menu overview The dishwasher has been preset with certain settings for your convenience. You can change these factory settings. Use the function keys #, + and 3 to change the settings. -------- Setting Factory setting Description Water hardness Setting the water hardness. When using Multitabs, select the lowest setting. Rinse aid Amount of rinse aid affects drying. When using Multitabs, select setting 0. Intensive drying Improved drying for glasses and plasticware. Cycle completion signal Signal sounds when wash cycle is complete. Info light Light is projected to signal an active wash cycle. Auto power off Dishwasher switches off automatically after wash cycle is complete.

Getting Started

+ Water softening system / special salt

Your water hardness level directly impacts your dishwasher's performance. Hard water will increase spotting and reduce detergent performance. Some dishwasher models are equipped with a water softener that uses a special salt to adjust the water hardness to obtain optimal performance. The dishwasher salt is added to the salt chamber 1Z located under the lower dishwasher rack. The amount of salt that is dispensed is based on your home water hardness. The home water hardness can be determined by using the water hardness test strip included in your manual set (or from your local hardware store). The dishwasher water softener setting must be adjusted to match your water hardness.

Instructions for use of included "Water Hardness Test Strip"

Only use salt designed for automatic dishwashers. Never use household water softener salt or table salt. Follow the instructions below for the included test strip. (If purchasing a different test strip, follow manufacturers instructions).

Adjusting the water softener settings

Using the test strip included with your dishwasher (Purchased test strips may have a different scale)

Water softener setting | Add salt to salt dispenser | Water hardness conversion chart ppm | gpg/°dH 0 | No | 0-116 | 0-6 1 | Yes | 117-152 | 7-8 2 | Yes | 153-188 | 9-10 3 | Yes | 189-223 | 11-13 4 | Yes | 224-293 | 14-17 5 | Yes | 295-383 | 18-22 6 | Yes | 384-544 | 23-31 7 | Yes | 545-890 | 32-52

Getting Started 14 Adjusting the water softening system The amount of salt dispensed can be set from •:‹‹ to •:‹ˆ. Salt is not required at the set value •:‹‹. Set the softening system as follows:

Rinse Aid

To achieve proper drying, always use a liquid rinse aid, even if your detergent contains a rinse aid or drying additive.

Note: The dishwasher indicates low rinse aid by turning on the Rinse Aid indicator on the display. If this indicator lights up, you need to refill the rinse aid dispenser by following the directions below.

Adding rinse aid

Notice To avoid oversudsing or clogging, do not overfill the rinse aid dispenser. Wipe up any spills with a damp cloth.

The indicator light will go out a few moments after the dishwasher door is shut.

Notice Do not fill the rinse aid dispenser with detergent. Doing so will damage the dishwasher.

Setting the amount of rinse aid used

The amount of rinse aid dispensed can be set from 1 to 4. The factory setting is 3.

You should only change the setting if streaks remain on the dishes (lower the amount), or if dishes are not getting dry enough (increase the amount).

Setting Amount 1 dispenser is OFF 2 lowest setting 3 low setting

Loading the Dishwasher 16

Notice Using no rinse aid or setting the dispenser to off may result in longer cycle times consuming more energy and water. The higher temperatures and longer cycle times can damage fine china or glassware.

Loading the Dishwasher

Dishware material Note: Before using your dishwasher for the first time, check the information in this section. Some items are not dishwasher-safe and should be hand washed; others require special loading.

Medium setting Medium/high setting High setting Highest setting

Setting | Amount Recommended ---|--- Aluminum | Colored anodized aluminum may fade over time. Minerals in your water may cause the aluminum to darken or spot. This can usually be removed with a soap-filled steel wool pad. China, Crystal, Stoneware | Some hand-painted utensils may discolor, fade or spot. Hand wash these utensils. Position fragile glassware so that it will not topple over or come in contact with other utensils during the wash cycle. Glass | Milk glass may discolor or become yellow. Non-stick Coatings | Apply a light coating of vegetable oil to non-stick surfaces after drying. Plastics | Make sure the plasticware is dishwasher-safe. Stainless Steel, Sterling Silver and Silver Plates | Load these so they do not come in contact with other metals, stainless steel dishwasher tub walls or the inner door.

Loading the Dishwasher

Loading the racks

For best dishwashing results, observe the following when loading the dishwasher:

■ Do not pre-wash items with loosely attached food soil. ■ Remove all food particles, bones, toothpicks and excessive grease. ■ Pre-treat items having burned-on, baked-on or starchy soils. ■ Load dishes in the dishwasher racks so the insides of bowls, pots and pans are facing the spray arms. ■ Avoid nesting and contact points between dishes. ■ Separate items of dissimilar metals. Use care to not block movement of the spray arms. ■ Only wash household dishware and kitchenware rated as dishwasher-safe.

Refer to the Dishware Materials section for more information about dishware suitability.

Notice

To avoid dishwasher damage, do not load the dishwasher with paper products, plastic bags, packing materials or anything other than normal, dishwasher safe dishware and kitchenware.

Loading the upper rack

Ensure items do not protrude through the bottom of the racks and block the spray arms.

Note: When pushing the upper rack into the dishwasher, push it until it stops against the back of the tub so the upper rack spray arm connects to the water supply at the back of the tub. Do not push racks in using the door.

Loading the lower rack

Place large items in the lower rack. Load pots, pans and bowls upside down. Do not block the vent hole with tall baking sheets. Load these items on the right side of the dishwasher.

Not Recommended

Acrylic — Crazing or small cracks throughout the acrylic may occur.

Adhesive-Joined Pieces — Adhesives that join materials such as plastic, wood, bone, steel, copper, tin, etc. may loosen.

Bone-Handled Utensils — Handles may separate.

Iron — Iron will rust. Hand wash and dry immediately.

Non-Dishware Items — Your dishwasher is intended for use in cleaning only standard household dishware and kitchenware.

Pewter, Brass, Bronze — These items will tarnish. Hand wash and dry immediately.

Tin — Tin will stain. Hand wash and dry immediately.

Wood — Wooden bowls, wooden utensils and utensils with wooden handles can crack, warp and lose their finish.

Loading the Dishwasher

Recommended loading pattern

For daily, regular or typical use 12 place setting Lower rack 9" Upper rack 12 Note: Folding the cup shelves down will allow the cups to sit at an increased angle and reduce water pooling on cup bottoms. Third rack 1*

Additional loading pattern

10 place setting Lower rack 9" Upper rack 12 Note: Folding the cup shelves down will allow the cups to sit at an increased angle and reduce water pooling on cup bottoms.

Loading the Dishwasher 19 Third rack 1* Loading the silverware basket Place knives and sharp utensils with their handles up and forks and spoons with their handles down. If large or oddly-shaped items are loaded in the silverware basket, be sure they do not nest together.

9 Warning

Risk Of Injury!

Loading the Dishwasher 20 Adjusting the height of the rack If required, the height of the upper rack 12 can be adjusted to create more space for taller utensils either in the upper or lower rack. Arrange large plates up to a diameter of 13.4 in (34 cm) in the lower basket 9" as illustrated. RackMatic® The height of the upper rack 12 can be adjusted in 3 steps to create more space.

Loading the Dishwasher 21 Rack accessories Flip tines The upper and lower rack are fitted with flip tines that can be folded down depending on what you may need to load in the rack. Lower rack flip tines: To fold down, pull flip tine gently forward and release it from the notch. Push the flip tine downward. To fold up, push flip tines into an upright position until the holder engages in the notch. Upper rack flip tines: To fold down, push flip tines downward with gentle pressure. To fold up, push flip tines into an upright position until the holder engages in the notch. Third rack The third rack 1* horizontally positions knives, spatulas and other oversized tools for improved cleaning and easier loading and unloading. Arrange cutlery in third rack as illustrated. Cup shelves The cup shelves and the space underneath them can be used for small cups or for larger serving utensils.

Loading the Dishwasher

Removing/Installing third rack

Removing third rack 1*

Installing third rack 1*

Loading the Dishwasher 23 Removing/Installing upper rack with Rackmatic® Removing upper rack 12

Detergent

Use only detergent specifically designed for dishwashers. For best results, use fresh powdered dishwashing detergent or detergent tabs.

Notice

This dishwasher uses less water than most, therefore, less detergent is required. With soft water, 1 tablespoon (15 ml) of detergent will clean most loads. The detergent dispenser cup has lines that measure detergent to 1 tablespoon (15 ml) and 1.75 tablespoons (25 ml). 3 tablespoons (45 ml) of detergent will completely fill the detergent dispenser.

Note: If you do not know the hardness of your water supply, use 15 ml of detergent. Increase the amount if necessary to the least amount required to get your kitchenware clean.

Use the measuring lines in the detergent dispenser cup as a guide to measure the amount of detergent recommended in the following table.

| Wash Cycle | Hard Water/Heavy Soil | Medium Water/Medium Soil | Soft Water/Little Soil | |---|---|---|---| | Heavy | 3 tbsp (45 ml) | 3 tbsp (45 ml) | 1.75 - 3 tbsp (25 - 45 ml) | | Auto | 1.75 - 3 tbsp (25 - 45 ml) | 1.75 tbsp (25 ml) | 1 - 1.75 tbsp (15 - 25 ml) | | Normal | 1.75 - 3 tbsp (25 - 45 ml) | 1.75 tbsp (25 ml) | 1 - 1.75 tbsp (15 - 25 ml) | | Speed60® | 1.75 tbsp (25 ml) | 1 - 1.75 tbsp (15 - 25 ml) | 1 tbsp (15 ml) | | Rinse | none | none | none |

Detergent

Adding detergent

Dishwasher Cycles 26 / Dishwasher Cycles

Dishwasher Cycles

Note: The Energy Guide label was based on the Normal soil sensing cycle as follows: The unit was tested without any rinse aid (liquid) in the rinse aid dispenser 9*. A single dose of detergent was inserted into the detergent dispenser 92, with no detergent being used in the prewash. The unit was not subjected to truncated testing per the definitions in the test procedure. We recommend that dish loads such as the one in the energy certification test have the rack position set in the highest position.

Wash cycle | Recommended use | Possible wash cycle option ---|---|--- Heavy | Best for cleaning items with baked-on food or grease. These dishes would normally require soaking or hand scouring. | all Auto | Smartest cycle, with most flexible soil sensing, which is ideal for mixed dishware and food soils. | all Normal (see note at bottom of table) | Recommended for daily, regular or typical use to completely wash a full load of normally soiled dishes. | all Speed60® | Cleans freshly soiled dishes with easy to remove soils. This cycle reduces cycle time while still including drying. | Delay, Extra Dry® Rinse | Use this cycle if you need to pre-rinse dishes to avoid odors. Place unrinsed dishes inside the dishwasher and select the Rinse cycle. Uses less water than hand rinsing and very low energy. | Delay

Note: In order to obtain optimal performance with minimum energy consumption, it is recommended to disable all available options and settings, except Auto Power Off - set to "Auto power off" on page 31

Dishwasher Cycle Options

0 Dishwasher Cycle Options

Dishwasher Cycle Options Delay Allows you to delay the start time of your dishwasher up to 24 hours.

Half Load Can reduce water consumption when washing small, lightly soiled loads that fill approximately half of the dishwasher's capacity.

Sanitize Increases the temperatures and retains them for an extra long time to obtain a defined disinfecting performance. Continuous use of this function increases the hygiene status. This additional option is ideal for cleaning items such as chopping boards and baby bottles.

Using the Sanitize option may also improve drying. The cycle time and energy usage may be increased.

Extra Dry Used in combination with a wash cycle (except Rinse), the Extra Dry option raises the temperature and extends the drying time to further enhance drying results and provide a brilliant shine. The energy usage may be increased.

Dishwasher Cycle Options

Wash Cycle Information To save energy, this dishwasher has EcoSense where the sensors in the dishwasher automatically adjust the cycle length, temperature and water changes based on the amount of food soil and the incoming water temperature. The "Smart Control" makes decisions that can cause the cycle time and water usage to adjust intermittently. Wash cycle times are based on 120°F (49° C) water supply. If your household water supply is different than 120°F (49° C), your dishwasher's cycle times may be impacted.

Note: Only sanitizing cycles have been designed to meet the requirements of Section 6 of the NSF/ANSI Standard for Residential Equipment for soil removal and sanitization efficacy. There is no intention, either directly or indirectly, to imply that all cycles have passed sanitization performance tests.

Heavy Auto Normal Speed60® Rinse Cycle time min. 110 - 135 105 - 129 130 - 135 60 9 Water usage gal/L 4.9-6.4/ 18.6-24.2 3.4-6.4/ 12.9-24.1 2.3-5.5/ 8.8-21.0 3.8/ 14.3 1.1/ 4.1 Wash temp. °F/°C 151-160/ 66-71 127-131/ 53-55 113-131/ 45-55 122/ 50 incoming Rinse temp. °F/°C 162/ 72 153-162/ 67-72 156/ 69 158/ 70 incoming Half Load Cycle time min. 114 90-105 90-99 N/A N/A Water usage gal/L 4.7/ 17.9 2.7-4.4/ 10.2-16.5 2.8-3.7/ 10.8-13.9 N/A N/A Rinse temp. °F/°C 162/ 72 131-151/ 55-60 162/ 72 N/A N/A Sanitize Cycle time min. 130-150 125-150 135-155 N/A N/A Water usage gal/L 4.9-6.4/ 18.6-24.2 3.4-6.4/ 12.9-24.1 2.3-5.5/ 8.8-21.0 N/A N/A Rinse temp. °F/°C 162/ 72 162/ 72 162/ 72 N/A N/A Extra Dry Cycle time min. 130-150 125-150 135-155 60 N/A Water usage gal/L 4.9-6.4/ 18.6-24.2 3.5-6.5/ 13.1-24.5 2.4-5.5/ 8.8-20.8 3.8/ 14.3 N/A Rinse temp. °F/°C 162/ 72 162/ 72 162/ 72 158/ 70 N/A

Operating the Dishwasher

29

1 Operating the Dishwasher Operating the Dishwasher Note: With hidden controls, the door must be opened before changing settings and closed after changing settings.

Warning

Risk Of Injury!

Protection against unintentional operation Your dishwasher is equipped with a function that helps to prevent unintentional operation (e.g. by children). After setting the dishwasher, the dishwasher door has to be closed within 4 seconds, otherwise the operation will be paused. There will be a signal on the control panel advising you to press the Start button again and close the door. This function will be activated when: ■ pressing Start to begin a wash cycle ■ setting Delay time and pressing Start ■ opening the door while Delay time is active ■ opening the door during a wash cycle.

Note: This function cannot be deactivated.

Operating the touch buttons Buttons are sensitive and should be touched gently. Avoid any grease or food particles resting on the buttons as they could activate the dishwasher. Wiping and cleaning can also activate the dishwasher. For best results, use bare, clean hands when touching the buttons. To clean the touch buttons wipe them with a dry or slightly damp cloth.

AquaSensor The AquaSensor is an optical measuring device which measures the cleanliness of the rinse water. The AquaSensor is used according to the wash cycle. If the AquaSensor is active, "clean" rinse water can be transferred to the next rinse and water consumption can be reduced by 0.8–1.5 gal (3–6 liters). If the rinse water is not yet clear, the water is drained and is replaced with fresh water. In the automatic wash cycles the temperature and running time can also be adjusted to the degree of soiling.

Operating the Dishwasher

Switching the appliance on

Note: Your dishwasher is protected against unintentional operation. If the appliance door remains open for more than 4 seconds after pressing the Start button, the operation will be paused. Close the appliance door and press the Start button P again.

Time display

When a wash cycle is selected the remaining wash cycle time is shown on the display 8. The wash cycle time is determined during the wash cycle by the water temperature, the amount of dishes, as well as the degree of soiling and may vary (depending on the selected wash cycle).

Delay Start

You can delay the start of the cycle in one hour increments up to 24 hours.

To set Delay start:

To cancel Delay start:

Note: Your dishwasher is protected against unintentional operation. If the appliance door remains open for more than 4 seconds after pressing the Start button, the operation will be paused. Press the Start button again and close the appliance door.

Wash cycle end

The wash cycle has ended when the display 8 reads the end time. If the signal tone has been set, the wash cycle end is also indicated by a buzzer.

To change the signal volume:

Off Low Medium Loud

Operating the Dishwasher 31 Auto power off This setting determines the length of time the control panel stays illuminated after the cycle is complete. To save energy the recommended setting is 1:02. This setting can be adjusted from 1:00 to 1:03. To change the setting:

9 Warning

Risk Of Injury!

9 Caution

Operating the Dishwasher

Cancel a cycle (Reset)

Changing the wash cycle When the Start button ( has been pressed, the wash cycle cannot be changed. The only way a wash cycle can be changed is by terminating the wash cycle (Reset).

Intensive drying The final rinse uses a higher temperature which improves the drying result. The cycle time may increase slightly. (Caution if utensils are delicate!)

This feature has two settings: To change the setting:

InfoLight® While the wash cycle is running, a light spot shines on the floor under the appliance door.

Do not open the appliance door until the light point is no longer visible on the floor.

If the appliance door is not completely closed, the light spot flashes*.

If the appliance is installed at eye-level, with flush furniture front, the light point is not visible.

In darkened rooms, some light scattering may be visible. This is normal and cannot be changed.

You can switch the Infolight on or off. To change the setting:

š:‹‹ Off

š:‹‚ On

‚:‹‹ Off

‚:‹‚ Low

Care and Maintenance

33

2 Care and Maintenance

Care and Maintenance A regular inspection and maintenance of your machine will help to prevent faults. This saves time and prevents future problems.

Overall condition of the dishwasher

Notice

Warning

Filters

The Bosch® filter system is designed to prevent the need to pre-rinse normally attached food soils from your dishes. Simply scrape leftover food soils off of dishware before loading. This process will conserve time, water and the energy required to heat your household water supply.

Your dishwasher filter system is designed to filter 100% of the water entering the spray arms to provide a continuous supply of clean water to remove food soils from your dishware.

Filter components

The filter system consists of three parts.

Large Object Trap

Prevents objects that should not be placed in your dishwasher from damaging the dishwasher pump system or clogging your household drain.

Care and Maintenance

Cleaning intervals

The filter system 1b is designed to minimize maintenance while providing premium cleaning performance and minimum energy consumption.

Depending on use habits and water hardness, the filter system will require some maintenance to sustain premium cleaning performance.

Your filter system may need to be cleaned when:

■ You notice food soils remaining on the filter system or objects trapped in the Large Object Trap.

■ A drop in cleaning performance or a gritty film forms on the dishware.

When washing normally attached food soils that have been scraped before loading, in a household that runs the dishwasher every other day, your filter should be cleaned:

Note: Clean the filter after washing loads with large amounts of food soils or loads with a heavy starch content, like potatoes and pasta, to maintain optimal performance.

To check or clean the filter system:

B Flat Fine Filter

Prevents food particles from entering the wash chamber and directs particles toward the micro filter.

C Micro Filter

Directs the smallest of particles to the household plumbing drain.

Cleaning interval

Use this setting,

3-6 times a year if you rinse before loading

4-12 times a year if you only scrape before loading

12 times a year if you have hard water

Care and Maintenance 35 Spray arms Check spray arms 1:, 1R for grease and limescale deposits. If you find such deposits: ■ Fill detergent dispenser 92 with detergent and start the appliance without utensils in the cycle with the highest rinsing temperature. ~ "Wash Cycle Information" on page 28 ■ Clean the appliance with detergents/appliance cleaners which are particularly suitable for use with dishwashers. ■ Unscrew the upper spray arm 1: and pull off the lower spray 1R arm as shown. Inspect for deposits. Drain pump Large food remnants in the rinsing water not retained by the filters may block the waste water pump. In this case: ■ Disconnect the appliance from the power supply. ■ Remove the filters. ~ "Filters" on page 33 ■ Scoop out standing water - use a sponge if necessary. ■ Using a spoon, pry off the pump cover until it clicks, then grip the cover and pull upward until it resists and then pull forward. ■ Check inner compartment and remove any foreign objects. 9

Warning

Care and Maintenance

Preparing your unit for vacation

Notice

Winterizing your unit

Notice

Troubleshooting 37 3 Troubleshooting Troubleshooting Dishwashers may occasionally exhibit problems that are unrelated to a malfunction of the dishwasher itself. The following information may help you with a dishwasher problem without involving a repair professional.

Problem Cause Action Dishwasher does not start Door may not be properly latched. Shut the door completely until you hear a click. Dishwasher may not be turned on. Press the main power switch to turn dishwasher on. Dishwasher not reset or previous cycle not completed. Reset the dishwasher. See "Cancel a cycle (Reset)" on page 32 Delay start engaged. Reset Delay start. See "Delay Start" on page 30 Interruption of electrical power supply to dishwasher or blown fuse. Check circuit breaker. The door may have been closed without first selecting a cycle. Select a cycle and close the door. Water supply may not be turned on. Check and turn on water supply. Cycle does not resume after door is opened and closed during cycle. Door is opened longer than 4 seconds after a cycle has started. Press Start button again to resume cycle. Display does not illuminate A fuse may have been blown or circuit breaker tripped. Check the fuse or circuit breaker box and replace the fuse or reset the breaker if necessary. Door not closed or latched. Note: For models with controls on top of the door, the display only illuminates when the door is opened and controls are visible. Ensure door is properly latched and completely closed.

Troubleshooting

Dishwasher seems to run a long time Incoming water is not warm enough. Before starting a cycle, run hot water faucet at the sink closest to the dishwasher. Cycle time can vary due to soil and water conditions. Sensors in the dishwasher automatically increase the cycle time to ensure a good wash when heavy soil is detected. Rinse aid dispenser 9* is empty, or rinse aid setting has been set to "0". Add rinse aid, or change rinse aid setting. Dishwasher connected to cold water supply. Verify dishwasher is connected to hot water supply plumbing. Note: Check the typical wash cycle length. ~ "Wash Cycle Information" on page 28

Dishes are not getting clean enough Spray arm movement obstructed. Ensure that spray arm movement is not blocked by hand rotating spray arms 1:, 1R before starting cycle. Spray arm nozzles clogged. Remove spray arms 1:, 1R and clean them. ~ "Spray arms" on page 35 Improper use of detergents. Increase or decrease detergent depending on the water hardness. Filters 1b could be clogged. Clean the filters 1b. ~ "Filter components" on page 33 Dishes are nested or loaded too closely together. Rearrange load such that water spray can reach all items in the dishwasher. ~ "Loading the Dishwasher" on page 16 Selected wash cycle is not suitable for food soil conditions. Refer to Wash Cycle Information. ~ "Wash Cycle Information" on page 28

Streaks on glassware or residue on the dishes Incorrect rinse aid setting. Depending on the hardness of water, adjust the rinse agent dispenser 9*. ~ "Rinse Aid" on page 15

Dishes are not getting dry enough Note: Plastic or Teflon do not typically dry as well as other items due to their inherent properties. Rinse aid dispenser 9* is empty or incorrect rinse aid amount is set. Add rinse aid or adjust setting - the use of rinse agent improves drying, use the Auto cycle, use the Sanitize option. Improper loading of dishes. Rearrange load to ensure items are not nesting. ~ "Loading the Dishwasher" on page 16 Note: Select models offer an extra heating option to improve drying performance.

Troubleshooting 39

Odor

Note: Water testing is done in the factory. Occasionally water may still appear in dishwasher at purchase which may create an odor.

Food debris is present at the bottom of the dishwasher. Remove the filters and clean them. ~ "Care and Maintenance" on page 33

Food particles are present near the door seal. ~ "Care and Maintenance" on page 33

Residual water is present at the bottom of the dishwasher. Ensure the dishwasher has completely drained from the last cycle.

Drain hose is obstructed. Remove any obstructions from the drain hose by calling qualified personnel.

Note: If odor still persists, run the Normal/Regular cycle until it flushes and interrupt the cycle and place an 8 oz. cup of distilled white vinegar solution on the upper rack and then finish the cycle.

Dishwasher not filling with water or "Check water supply" display lights up

Restriction in the water supply system. Ensure that the water supply valve (typically located under kitchen sink) is open and check that the water supply line has no kinks or clogs.

Previous wash cycle was not completed. ~ "Operating the Dishwasher" on page 29

Delay start is active. Cancel the delay start or wait until delay start time completes.

Household water supply turned off. Turn on water supply.

Fascia panel discolored or marked

Abrasive cleaner used. Use mild detergents with soft damp cloth.

Noise during wash cycle

Dishes may not be arranged properly. Water circulation sound is normal, but if you suspect items are banging into each other or into the spray arms, check optimal arrangement of dishes. ~ "Loading the Dishwasher" on page 16

Water leaks

Suds. Using wrong type of detergent or overfilling the rinse aid dispenser results in suds and leaks - use only dishwasher detergents. If suds still persist, add one tablespoon of vegetable oil at the bottom of the dishwasher and run the desired cycle.

Door seal could be pulled away from track. Ensure the door seal is in the track.

Condensation vent is blocked. Ensure that condensation vent is not blocked.

Improper installation. Have proper installation verified by qualified personnel (water supply, drain system, leveling, plumbing).

Troubleshooting 40 -------- Tub stains Stains on the dishwasher interior are due to water hardness. Concentrated lemon juice can reduce the build-up of hard water stains. Run Normal/Regular cycle until it flushes and interrupt the cycle and then place an 8 oz. cup of the concentrated lemon solution on the upper rack and finish the cycle. This can be done periodically to avoid build-up. Silverware in contact with tub. Ensure that silverware does not make contact with the tub while running a cycle. Detergent dispenser cover will not shut Improper operation of detergent cover. For instructions on opening and closing the dispenser ~ "Detergent" on page 24 Previous cycle was not finished or interrupted. ~ "Operating the Dishwasher" on page 29 Unable to select desired cycle Previous cycle not finished. ~ "Operating the Dishwasher" on page 29 Touch sensitive keys not activating easily or activating without being touched

Customer Service 41 4 Customer Service Customer Service Your Bosch® dishwasher requires no special care other than that described in the Care and Maintenance section of this manual. If you are having a problem with your dishwasher, before calling for service please refer to the Troubleshooting Guide section of the manual. If service is necessary, contact your dealer or installer or an authorized service center. Do not attempt to repair the appliance yourself. Any work performed by unauthorized personnel may void the warranty. If you are having a problem with your Bosch® dishwasher and are not pleased with the service you have received, please take the following steps until the problem is corrected to your satisfaction:

Statement of Limited Product Warranty 42 ‡ Statement of Limited Product Warranty Statement of Limited Product Warranty What this Warranty Covers & Who it Applies to: The limited warranty provided by BSH Home Appliances Corporation (BSH) in this Statement of Limited Product Warranty applies only to Bosch® dishwashers ("Product") sold to you, the first using purchaser, provided that the Product was purchased: ■ for your normal, household (non-commercial) use, and has in fact at all times only been used for normal household purposes; ■ new at retail (not a display, "as is", or previously returned model), and not for resale, or commercial use; and ■ within the United States or Canada, and has at all times remained within the country of original purchase. The warranties stated herein apply only to the first purchaser of the Product and are not transferable. Please make sure to return your registration card; while not necessary to effectuate warranty coverage, it is the best way for BSH to notify you in the unlikely event of a safety notice or product recall. How Long the Warranty Lasts BSH warrants that the Product is free from defects in materials and workmanship for a period of three hundred sixty five (365) days from the date of purchase. The foregoing timeline begins to run upon the date of purchase, and shall not be stalled, tolled, extended, or suspended, for any reason whatsoever. This Product is also warranted to be free from cosmetic defects in material and workmanship (such as scratches of stainless steel, paint/porcelain blemishes, chip, dents, or other damage to the finish of the Product), for a period of thirty (30) days from the date of purchase or closing date for new construction. This cosmetic warranty excludes slight color variations due to inherent differences in painted and porcelain parts, as well as differences caused by kitchen lighting, product location, or other similar factors. This cosmetic warranty specifically excludes any display, floor, "As Is", or "B" stock appliances. Extended Limited Warranty BSH also provides these additional limited warranties: ■ 5 year limited warranty on electronics: BSH will repair or replace any BSH microprocessor or printed circuit board if it proves to be defective in materials or workmanship (excludes labor charges). ■ 5 year limited warranty on dish racks: BSH will replace the upper or lower dish rack (excluding rack components), if the rack proves defective in materials or workmanship (excludes labor charges). ■ Lifetime warranty against stainless steel rust through: BSH will repair or replace your dishwasher with the same model or a current model that is substantially equivalent or better in functionality, if the inner liner should rust through (excludes labor charges). ■ BSH will repair or replace the stainless steel door if the door should rust through (excludes labor charges).

Statement of Limited Product Warranty

43

Repair/Replace as Your Exclusive Remedy

During this warranty period, BSH or one of its authorized service providers will repair your Product without charge to you (subject to certain limitations stated herein) if your Product proves to have been manufactured with a defect in materials or workmanship. If reasonable attempts to repair the Product have been made without success, then BSH will replace your Product (upgraded models may be available to you, in the sole discretion of BSH, for an additional charge). All removed parts and components shall become the property of BSH at its sole option. All replaced and/or repaired parts shall assume the identity of the original part for purposes of this warranty and this warranty shall not be extended with respect to such parts. BSH's sole liability and responsibility hereunder is to repair manufacturer-defective Product only, using a BSH-authorized service provider during normal business hours. For safety and property damage concerns, BSH highly recommends that you do not attempt to repair the Product yourself, or use an unauthorized servicer; BSH will have no responsibility or liability for repairs or work performed by a non-authorized servicer. If you choose to have someone other than an authorized service provider work on your Product, THIS WARRANTY WILL AUTOMATICALLY BECOME NULL AND VOID. Authorized service providers are those persons or companies that have been specially trained on BSH products, and who possess, in the opinion of BSH, a superior reputation for customer service and technical ability (note that they are independent entities and are not agents, partners, affiliates or representatives of BSH). Notwithstanding the foregoing, BSH will not incur any liability, or have responsibility, for the Product if it is located in a remote area (more than 100 miles from an authorized service provider) or is reasonably inaccessible, hazardous, threatening, or treacherous locale, surroundings, or environment; in any such event, if you request, BSH would still pay for labor and parts and ship the parts to the nearest authorized service provider, but you would still be fully liable and responsible for any travel time or other special charges by the service company, assuming they agree to make the service call.

Out of Warranty Product

BSH is under no obligation, at law or otherwise, to provide you with any concessions, including repairs, pro-rates, or Product replacement, once this warranty has expired.

Warranty Exclusions

The warranty coverage described herein excludes all defects or damage that are not the direct fault of BSH, including without limitation, one or more of the following:

■ Use of the Product in anything other than its normal, customary and intended manner (including without limitation, any form of commercial use, use or storage of an indoor product outdoors, use of the Product in conjunction with air or water-going vessels);

Statement of Limited Product Warranty 44

■ Any party's willful misconduct, negligence, misuse, abuse, accidents, neglect, improper operation, failure to maintain, improper or negligent installation, tampering, failure to follow operating instructions, mishandling, unauthorized service (including self-performed "fixing" or exploration of the appliance's internal workings);

■ Adjustment, alteration or modification of any kind;

■ A failure to comply with any applicable state, local, city, or county electrical, plumbing and/or building codes, regulations, or laws, including failure to install the product in strict conformity with local fire and building codes and regulations;

■ Ordinary wear and tear, spills of food, liquid, grease accumulations, or other substances that accumulate on, in, or around the Product;

■ Any external, elemental and/or environmental forces and factors, including without limitation, rain, wind, sand, floods, fires, mud slides, freezing temperatures, excessive moisture or extended exposure to humidity, lightning, power surges, structural failures surrounding the appliance, and acts of God.

In no event shall BSH have any liability or responsibility whatsoever for damage to surrounding property, including cabinetry, floors, ceilings, and other structures or objects around the Product. Also excluded from this warranty are Products on which the serial numbers have been altered, defaced, or removed; service visits to teach you how to use the Product, or visits where there is nothing wrong with the Product; correction of installation problems (you are solely responsible for any structure and setting for the Product, including all electrical, plumbing or other connecting facilities, for proper foundation/flooring, and for any alterations including without limitation cabinetry, walls, floors, shelving, etc.); and resetting of breakers or fuses.

To The Extent Allowed By Law, This Warranty Sets Out Your Exclusive Remedies With Respect To Product, Whether The Claim Arises In Contract Or Tort (Including Strict Liability, Or Negligence) Or Otherwise. This Warranty Is In Lieu Of All Other Warranties, Whether Express Or Implied. Any Warranty Implied By Law, Whether For Merchantability Or Fitness For A Particular Purpose, Or Otherwise, Shall Be Effective Only For The Period That This Express Limited Warranty Is Effective. In No Event Will The Manufacturer Be Liable For Consequential, Special, Incidental, Indirect, "Business Loss", And/Or Punitive Damages, Losses, Or Expenses, Including Without Limitation Time Away From Work, Hotels And/Or Restaurant Meals, Remodelling Expenses In Excess Of Direct Damages Which Are Definitively Caused Exclusively By BSH, Or Otherwise. Some States Do Not Allow The Exclusion Or Limitation Of Incidental Or Consequential Damages, And Some States Do Not Allow Limitations On How Long An Implied Warranty Lasts, So The Above Limitations May Not Apply To You. This Warranty Gives You Specific Legal Rights, And You May Also Have Other Rights Which Vary From State To State. No attempt to alter, modify or amend this warranty.

Statement of Limited Product Warranty

45 shall be effective unless authorized in writing by an officer of BSH Home Appliances Corporation.

How to Obtain Warranty Service

To Obtain Warranty Service

For Your Product, You

Should Contact The Nearest

BSH Authorized Service

Center, Or Call 1-800-944-2904

Statement of Limited Product Warranty

47

Dishwasher

And Enjoy Your New Bosch Dishwasher

If You Have

Other Questions or Comments

Don't Forget

To Register Your New Dishwasher

www.BosuchHome.Com.us (EU)

Or

www.BosuchHome.Ca (Canada)

For More

Information About Your Dishwasher and Accessories

BSHH Home Appliances Corporation

Main Street, Suite

Address

Irvine, CA

Dear Customer

One of Many Consumers Who Require Your Dishwasher

This Manual Has Been Prepared Keeping Your Safety and Your Entire Satisfaction and The Information That

It Contains Are

Of Capital Importance. We Strongly Recommend You Read It

Available and Other Bosch High Quality Equipment

Address

Dishwasher By Clicking On The

"Assistance" Tab or Filling Out The

Product Registration Form Sent With Your New Appliance

Please Contact Us By Calling

9 Important Safety Instructions

Read and Keep These Instructions

Grounding Instructions

9 Warning

Risk of Electric Shock!

Improper connection of the grounding conductor can create a risk of electric shock. In the presence of a qualified electrician, verify, if in doubt, that the appliance is properly grounded.

Normal Operation Use this dishwasher only for the specified purposes, including washing dishes and kitchen utensils indicated as dishwasher safe.

Use only detergents or rinse products recommended for a dishwasher, and keep them out of the reach of children.

9 Caution

Getting Started 54

Controls

Door

Latch

Reset Tab

Options

Cycle Status

Results

Getting Started

The numbers mentioned below refer to the overview images on the previous page of this manual.

Control Panel Internal Components of the Dishwasher

Indicators

( On/Off Button 0 Wash Cycles 8 Digital Display @ Delayed Start

H

P

1B

1J

1R

1Z

9B

Clean Lights when dishes are clean

Sanitize Lights when sanitization requirements are met

Add Rinse Aid Lights when rinse aid quantity is low

Add Salt Lights when salt quantity is low

Settings

The dishwasher has been configured with certain settings for your convenience. It is possible to modify these factory settings.

Use the function buttons #, +, and 3 to modify these values.

--------

Setting | Factory Settings | Description

Getting Started 58 Adjusting the Water Softening System Adjusting the Water Softening System The amount of salt deposited can be adjusted from 0:00 to 0:08. Salt is not required for a setting of 0:00. Adjust the water softening system as follows:

Using Special Dishwasher Salts

Fill the salt reservoir to the maximum as soon as the salt level indicator lights up on the digital display.

Notice

Detergent damages the water softening system! Never pour detergent into the salt dispenser.

Fill the salts to the maximum as follows:

Water is drained.

For more information about purchasing dishwasher salts, please contact customer service (1-800-944-2904).

Using Salt-Loaded Detergents

Salt-Loaded Detergent

If you use a salt-loaded detergent, special salts are not required if the water hardness does not exceed 375 ppm (37 °fH, 21 °dH, 26 °Clarke, 3.7 mmol/l). If the water hardness exceeds 375 ppm, salts must be used.

Turning Off the Low Salt Level Indicator/Water Softening System

Turning Off the Water Softening System

If the use of salt-containing detergents compromises the operation of the low salt level indicator on the digital display8, you can turn off the low salt level indicator.

Proceed as described in "Adjusting the Water Softening System" and set the value to •:‹‹. The water softening system and salt filling indicator are now activated.

Loading the Dishwasher

Dishwasher-Safe Materials

Note: Before first use of your dishwasher, review the information in this section. Some items cannot be washed in the dishwasher and must be hand washed; others must be loaded in a special way.

Recommended

Aluminum Anodized and colored aluminum may discolor over time. Minerals in water can dull or spot aluminum. Generally, they can be removed using a steel wool pad dampened with soap.

China, Crystal, Stoneware Some hand-painted utensils may discolor or stain. Hand wash these utensils. Position delicate glassware so it will not tip over or contact other utensils during the wash cycle.

Glass Milk glass may discolor or become yellowed.

Non-stick Coatings Apply a light coat of vegetable oil to non-stick surfaces after drying.

Plastics Make sure plastic items are dishwasher safe.

Stainless Steel, Sterling Silver, and Silverplate Load these items so they do not contact other metals, the stainless steel dishwasher tub walls, or the inner door.

Not Recommended

Acrylic Crazing or small cracks may occur on acrylic.

Items Assembled with Adhesive Adhesives used to bond materials such as plastic, wood, bone, steel, copper, tin, etc. may lose their bonding strength.

Bone-Handled Utensils Handles may separate.

Iron Iron will rust. Hand wash and dry immediately.

Non-Tableware Items Your dishwasher is intended for cleaning standard dishes and kitchen items only.

Pewter, Brass, Bronze These items will tarnish. Hand wash and dry immediately.

Tin Tin may spot. Hand wash and dry immediately.

Wood Wood bowls and utensils, as well as utensils with wood handles may crack, warp, and lose their luster.

Loading the Dishwasher

63

Loading the Baskets

For best results, follow these instructions when loading dishes:

■ Items with light food residue buildup do not need to be pre-washed.

■ Remove all food particles, bones, toothpicks, and excess grease.

■ Pre-wash items soiled by burnt, cooked, or starchy materials.

■ Load dishes in the dishwasher baskets so that the inside walls of bowls, pots, and pans face the spray arms.

■ Avoid nesting and contact points between dishes.

■ Separate items made of different metals. Make sure not to block the spray arms.

■ Wash only dishes and kitchen items marked as dishwasher safe. Refer to the Dishwasher Safe Materials section for more information on suitable dishes.

Notice

To avoid damaging the dishwasher, do not load paper items, plastic bags, packaging materials, or any item other than normal dishes, tableware, or kitchen utensils that are dishwasher safe.

Loading the Upper Basket

Make sure items do not extend below the basket bottoms and do not block the spray arms.

Note: When inserting the upper basket into the dishwasher, push it until it contacts the rear wall of the wash tub. This allows the upper basket spray arm to connect to the water supply at the rear of the wash tub. Do not push the baskets using the door.

Loading the Lower Basket

Place large items in the lower basket. Load pots, pans, and bowls upside down. Do not block the ventilation holes with large baking sheets. Load these items on the right side of the dishwasher.

Recommended Loading Pattern

For daily, regular, or normal use

12 Place Setting

Lower Basket

Loading the Dishwasher

65

Third Basket 1*

Loading the Utensil Basket

Knives and sharp utensils must be placed with handles up, spoons and forks with handles down. If bulky or irregularly shaped objects are loaded in the utensil basket, make sure they do not pile up.

9 Warning

Risk of Injury!

The points and sharp edges of knives and other cutting utensils can cause serious injuries. When loading, the tips of knives and other sharp utensils must be turned downward. Children should not use or play near knives and sharp utensils.

Long Utensil Baskets

Note: The utensil basket cover can also be folded down to leave the basket open.

This dishwasher is equipped with a silverware drawer that should meet most of your loading needs for this type of object. However, if you are washing without a silverware drawer or if you have too much silverware, a silverware basket is also included.

When loading the silverware basket, avoid excessive contact points and nesting of utensils (e.g., one spoon nested inside another).

To do this, close the silverware basket covers and insert each utensil into each individual hole, as illustrated.

Unloading the Dishwasher

When unloading the dishwasher, to prevent water from dripping onto dry dishes, empty the lower basket first. Then unload the silverware basket followed by the upper basket and the third basket (if equipped).

Note: Dishes are more likely to chip when unloaded before they have cooled.

Adjusting Basket Height

If needed, the height of the upper basket can be adjusted to free up more space for large utensils in both the upper and lower baskets.

Place large plates with a maximum diameter of 34 cm (13.4 in.) in the lower basket as illustrated.

RackMatic®

The height of the upper basket can be adjusted to 3 levels to create more space.

Note: Verify that the spray arm is not blocked after adjustment.

With the Silverware Basket

| Configuration | Upper Basket | Lower Basket | |---|---|---| | Configuration 1 | ø max. 24 cm (9.4 in.) | 34 cm (13.4 in.) | | Configuration 2 | ø max. 26.5 cm (10.4 in.) | 30.5 cm (12 in.) | | Configuration 3 | ø max. 29 cm (11.4 in.) | 28 cm (11 in.) |

With the Third Basket

| Configuration | Upper Basket | Lower Basket | |---|---|---| | Configuration 1 | ø max. 18 cm (7 in.) | 34 cm (13.4 in.) | | Configuration 2 | ø max. 20.5 cm (8 in.) | 30.5 cm (12 in.) | | Configuration 3 | ø max. 23 cm (9 in.) | 28 cm (11 in.) |

Loading the Dishwasher

Basket Accessories

Folding Tines

The upper and lower baskets are equipped with folding tines that can be folded depending on the items you want to load into the basket.

Lower Basket Folding Tines: To lower them, gently pull the folding tine forward and disengage it from the notch. Push the folding tine downward. To raise them, push the folding tines into a vertical position until the support clicks into the notch.

Upper Basket Folding Tines: To lower them, gently push the folding tines downward. To raise them, push the folding tines into a vertical position until the support clicks into the notch.

3rd Basket

The 3rd basket allows you to place knives, spatulas, and other large tools horizontally for better cleaning and easy loading and unloading. Arrange the cutlery in the 3rd basket as illustrated.

Cup Shelf

The cup shelves and the space below can be used for small cups or wider utensils.

Loading the Dishwasher

Removing/Installing the Upper Basket with Rackmatic®

Removing the Upper Basket

Installing the Upper Basket

Detergent

Use only detergent specially designed for dishwashers. For best results, use powder dishwasher detergent or detergent tablets.

Notice

To avoid damaging the dishwasher:

■ Avoid using hand dishwashing detergents in your dishwasher. ■ Do not use too much detergent if the water used is soft. Using an excessive amount of detergent with soft water can scratch glassware and fine china.

This dishwasher requires less water than others, and consequently, less detergent. With cold water, 1 tablespoon (15 ml) of detergent will be sufficient for cleaning. The detergent dispenser has graduation marks corresponding to 1 tablespoon (15 ml) and 1.75 tablespoons (25 ml). 3 tablespoons (45 ml) of detergent will completely fill the detergent dispenser.

Note: If you are unsure of your water hardness, use 15 ml of detergent. If necessary, add the minimum amount needed for spotless cleaning of your dishes.

Use the reference lines on the detergent dispenser as an aid in measuring the recommended amount of detergent in the table below.

| Wash Cycle | Hard Water / Heavy Soil | Medium Water Hardness / Medium Soil | Soft Water / Light Soil | |---|---|---|---| | Heavy | 3 tbsp (45 ml) | 3 tbsp (45 ml) | 1.75 to 3 tbsp (25 to 45 ml) | | Auto | 1.75 to 3 tbsp (25 to 45 ml) | 1.75 tbsp (25 ml) | 1 to 1.75 tbsp (15 to 25 ml) | | Normal | 1.75 to 3 tbsp (25 to 45 ml) | 1.75 tbsp (25 ml) | 1 to 1.75 tbsp (15 to 25 ml) | | Speed60MC | 1.75 tbsp (25 ml) | 1 to 1.75 tbsp (15 to 25 ml) | 1 tbsp (15 ml) | | Rinse | None | None | None |

Detergent

Adding Detergent

When using detergent tablets, position them so they do not contact the cover. Insert them flat, not on their side.

Note: Do not place detergent tablets in the detergent compartment 1B. Place tablets or other forms of detergent directly into the detergent dispenser 92.

Dosage: see the manufacturer's instructions on the packaging.

The detergent dispenser will open automatically at the appropriate time for the selected cycle. Liquid or powder detergent is dispersed into the appliance and dissolved; detergent tablets drop into the detergent compartment 1B where they dissolve throughout the cycle.

Max

CLICK

Dishwasher Cycles

Tip: If dishes are lightly soiled, a quantity of detergent slightly less than the recommended amount is sufficient.

Dishwasher Cycles

Note: The Energy Guide label is based on the Normal soil level detection cycle as follows: the unit was tested with an empty rinse aid dispenser (liquid) 9*. A single dose of detergent was introduced into the detergent dispenser 92, with no detergent used in the pre-wash cycle. The appliance was not subjected to a truncated test process as defined in the test procedure. We recommend, for dishloads such as those described in the energy performance certification test, that the basket be placed in the highest position.

Cleaning Cycle | Recommended Usage | Possible Cleaning Cycle Option ---|---|--- Heavy | Ideal for cleaning dishes soiled by cooked foods or grease. They generally require soaking time or hand scrubbing. | All Auto | The most intelligent cycle, with the most flexible soil detection, ideal for mixed dishes and soiled by food. | All Normal (see note at bottom of table) | Recommended for daily, regular or typical use for complete washing of a full load of normally soiled dishes. | All Speed60 | Cleans freshly soiled and easy-to-clean dishes. This cycle has a reduced duration, but still includes a drying cycle. | Delay, Extra Dry Rinse | Use this cycle if you want to pre-rinse your dishes to avoid odors. Place unrinsed dishes in the dishwasher and select the Rinse cycle. Uses less water than manual washing and very low power. | Delay

Note: For optimal performance with minimal energy consumption, it is recommended to disable all available options and settings except the Auto Power Off option - set to "Auto power off" on page 77.

Dishwasher Cycle Options

Delay Allows you to delay the start of your dishwasher up to 24 hours.

Half Load Can reduce water consumption when cleaning small dishes with light soil, filling approximately half the dishwasher capacity.

Sanitize This function increases temperatures and maintains them for an extended period to achieve preset sanitation performance. Continuous use of this function improves hygiene levels. This additional option is ideal for washing items such as cutting boards and baby bottles.

This option can also improve drying. This could extend the cycle and increase energy consumption.

Extra Dry Used in conjunction with a cleaning cycle (with the exception of rinse), the Extra Dry option increases temperature and extends drying time for better results and a brighter finish. This could increase energy consumption.

Wash Cycle Information To save energy, this dishwasher features an EcoSense system in which dishwasher sensors automatically adjust variations in cycle length, temperature, and water based on food soil level and incoming water temperature. Decisions made by the "Intelligent Control" can cause intermittent adjustment of the time and water used for the cycle. Wash cycle times are established based on water supply temperature of 120°F (49°C). If your home's water supply temperature is other than 120°F (49°C), your dishwasher's cycle times may be affected.

Starting Your Dishwasher

75

1 Starting Your Dishwasher

Starting Your Dishwasher

Note: With hidden functions, the door must be opened before changing settings and closed once settings are complete.

Warning

Risk of Injury!

To avoid risk of injury, always be careful when opening the door during or after a wash cycle as hot water or steam discharge may occur. Do not fully open the door until water sounds have stopped and steam has dissipated.

Protection Against Unintended Operation

Your dishwasher is equipped with a function that helps prevent unintended use (for example by children).

After setting the dishwasher, the door must be closed within 4 seconds or the operation will be interrupted. A signal will then appear on the control panel, prompting you to press the Start button again and close the door.

This function activates when: ■ you press Start to begin a wash cycle ■ you set Delayed Start and press Start ■ you open the door while Delayed Start is engaged ■ you open the door during a wash cycle

Note: It is not possible to deactivate this function.

Using Touch Buttons

The buttons are sensitive and should be touched lightly. Prevent grease or food particles from depositing on the buttons, as this may activate the dishwasher.

Wiping and cleaning may also activate the dishwasher. For optimal performance, touch buttons with clean, bare hands.

To clean the touch buttons, wipe them with a dry or slightly damp cloth.

AquaSensor

AquaSensor is an optical measuring tool that evaluates the cleanliness of rinse water.

AquaSensor is used depending on the wash cycle. If AquaSensor is activated, "clean" rinse water can be reused for the next rinse and water consumption can be reduced by 0.8 to 1.5 gallons (3 to 6 liters). If rinse water is not yet clean, it is drained and replaced with fresh water. For automatic wash cycles, temperature and cycle duration can also be adjusted based on the degree of soiling.

End of Cleaning Cycle

The cleaning cycle is complete when display 8 shows ‹:‹‹. If the sound signal is activated, a sound should ring at the end of the wash cycle.

To change the signal volume:

until the display

Auto Power Off

This setting determines how long the control panel remains illuminated once the cycle is complete. To save energy, the recommended setting is ˜:‹‚. This parameter can be set in a range from ˜:‹‹ to ˜:‹ƒ.

To change the setting:

until display 8

›:‹‹ Off

›:‹‚ Low

›:‹ƒ Medium

›:‹„ Loud

˜:‹‹ Dishwasher does not automatically shut off

˜:‹‚ Dishwasher automatically shuts off after 1 minute

˜:‹ƒ Dishwasher automatically shuts off after 120 minutes (2 hours)

2 Care and Maintenance

Care and Maintenance Regular inspection and maintenance of your appliance will help prevent potential breakdowns. This saves you time and prevents new problems.

General Condition of the Dishwasher

Notice

■ Never use a steam cleaner to wash your dishwasher. The manufacturer will not be responsible for any damage caused.

■ Wipe the front of the appliance regularly with a slightly damp cloth (it is important to use water and a small amount of liquid soap). Avoid using sponges, as they could scratch the surfaces.

■ Do not use bleach-based wipes, as they could damage the surface or printing.

■ Stainless steel appliances: to prevent corrosion, do not use sponges or chlorine-based detergents. Use a stainless steel polish product to seal and protect the surface. Do not use chlorine-based cleaners or wipes.

■ Regularly clean the outer edges of the inner door panel to remove residue deposited during normal loading. If stains appear on stainless steel, make sure the rinse aid is filled and working properly.

■ Regularly clean the door seal with a slightly damp cloth to remove food particles deposited during normal loading that can cause odors. A soiled door seal may prevent proper door locking.

Warning

Exercise caution when disassembling parts for cleaning, as some debris may be sharp.

Filters

The Bosch® filter system is designed to eliminate the need for pre-cleaning stubborn food residue from your dishes. Simply scrape the dishes to remove food residue before loading. This process saves time, water, and energy needed to heat your home's water supply.

Your dishwasher's filtration system is designed to filter 100% of the water entering the spray arms, ensuring a continuous supply of clean water needed to remove food residue from your dishes.

3 Troubleshooting

Troubleshooting

Dishwashers may occasionally experience problems that are not related to a malfunction of the dishwasher. The following information may help you resolve a dishwasher-related problem without the need to call a professional.

Problem | Cause | Solution ---|---|--- The dishwasher will not start | The door may not be properly latched. | Close the door completely until it clicks into place. | The unit may not be powered on. | Press the main power switch to turn it on. | Unit not reset or previous cycle incomplete. | Reset the unit. See "Canceling a Cycle (Reset)" on page 78 | Delayed start is enabled. | Reset the delayed start. See "Delayed Start" on page 76 | Power supply to the dishwasher has been interrupted or a fuse has blown. | Check the circuit breaker. | The door was probably closed without a cycle being selected first. | Select a cycle and close the door. | Water supply is probably turned off. | Check and restore water supply. The cycle does not continue after the door is opened and closed during a cycle. | The door was open for more than 4 seconds after a cycle began. | Press the Start button again. The display will not light up | A fuse may have blown or the circuit breaker has tripped. | Check the fuse or circuit breaker box and replace the fuse or reset the circuit breaker if necessary. | Door not closed or locked. Note: For models with controls located on the top of the door, the display only lights up when the door is open and the controls are visible. | Make sure the door is properly closed and fully locked.

Troubleshooting

Touchpad buttons are not activating easily or are activating without being touched

Water or other liquids on the surface.

Cleaning the face with a damp cloth beforehand can cause unintended activation of functions. Clean the front face with a soft, dry cloth. If you must use a damp cloth for cleaning, dry immediately. Never pour water on the controls.

Touchpad buttons not activated properly.

Press the center of the touchpad button with the flat area of your fingertip. A signal will sound to indicate that the selection has been made. Light touching of the buttons should work.

Note: A preset delay alerts the user against performing multiple actions simultaneously after accidentally passing your hand (or cleaning cloth) over the control panel.


.Bjo
4Usffu

#4)
)Pnf
"Qqmjbodft
$Psqpsbujpo

*Swjof

#4)
Tf
Sîtfswf
Mf
Espju
Ef
Npejgjfs
Mft
Epooîft
Ufdiojrvft
Pv
Mf
Eftjho

Tbot
Qsîbwjt
$Fsubjot
Npeñmft
Tpou
Dfsujgjît
Qpvs
Vof
Vujmjtbujpo
Bv
$Bobeb

#4)
OFtu
Qbt
Sftqpotbcmf
Qpvs
Mft
Qspevjut
Usbotqpsuît
Eft
±Ubut6Ojt
Qpvs

#4)
Sftfswft
Uif
Sjhiu
Up
Dibohf
Tqfdjgjdbujpot
Ps
Eftjho
Xjuipvu
Opujdf

4Pnf
Npefmt
Bsf
Dfsujgjfe
Gps
Vtf
Jo
$Bobeb
#4)
Jt
Opu
Sftqpotjcmf
Gps

Qspevdut
Xijdi
Bsf
Usbotqpsufe
Gspn
Uif
6Ojufe
4Ubuft
Gps
Vtf
Jo
$Bobeb

$Ifdl
Xjui
Zpvs
Mpdbm
$Bobejbo
Ejtusjcvups
Ps
Efbmfs
