27 totalWhat water temperature is required for effective cleaning in the GSD2200?
The entering water must be at least 120°F and not more than 150°F for effective cleaning and to prevent dish damage. You can check the water temperature using a candy or meat thermometer by running hot water into a glass near the dishwasher. (Page 7)
How do I remove spots and film from glasses and flatware?
Use Jet-Dry rinse agent to remove spots and prevent new film build-up. For stubborn spots, run the longest cycle without detergent or metal utensils, and after 18–22 minutes pour 2 cups of white vinegar into the bottom of the tub and allow the cycle to complete. If vinegar doesn't work, repeat using 1/4 cup of citric acid crystals instead. (Page 12)
How much water does the Normal Wash cycle use on the GSD2200, and how long does it take?
The Normal Wash cycle on the GSD2200/GSD2201 uses 6.3 gallons of water and takes 71 minutes to complete. The Heated Dry option, if selected, adds approximately 32 minutes to the cycle. (Page 5)
How do I properly load knives and sharp items in the dishwasher?
Load sharp knives with the handles up to reduce the risk of cut-type injuries. For flatware in general, place fork and knife handles up to protect your hands, and place spoons in the basket with handles down. (Pages 3, 8)
How do I use the Plate Warmer cycle?
Load clean dishware to be warmed, select Heated Dry On, make sure the door is unlatched, then slowly turn the Dial to Plate Warmer and latch the door to start the cycle. This cycle takes approximately 32 minutes to complete. (Page 6)
What warranty coverage does the GSD2200 dishwasher come with?
The dishwasher includes a full one-year warranty covering any part that fails due to defects in materials or workmanship, including free labor and in-home service. Additionally, there is a second-year limited warranty on the Water Distribution System and a ten-year warranty on the PermaTuf tub or door liner if it fails to contain water. (Page 15)
Show 21 more questions
Is it safe to leave a dishwasher in an unheated location during winter, and what precautions should be taken?
What water temperature is required for effective cleaning?
How do I fix suds inside the dishwasher tub?
Why won't water pump out of the tub, and how do I fix it?
How long do the wash cycles take on the GSD2200?
How should knives and flatware be loaded into the dishwasher?
What is the GSD2200 dishwasher warranty coverage?
How do I safely add a forgotten dish after the cycle has started?
What is the normal cycle time and water usage for the Normal Wash cycle on a GSD2200?
How do I load the upper rack properly?
What should I do if there are spots and filming on glasses and flatware?
What safety precautions should I take before attempting maintenance on my dishwasher?
What should I do if my dishwasher won't run?
What should I do if water won't pump out of the tub?
What detergents are approved for use in the GSD2200 dishwasher?
How do I remove spots and film buildup on glasses and flatware?
What water temperature should I use with my GSD2200 dishwasher?
How do I add a forgotten dish during the wash cycle?
What type of detergent should I use in my dishwasher?
How do I use the rinse agent dispenser?
How do I prevent staining from hard water minerals on the interior surfaces?
Full Manual
16 pages
GEAppliances.com
Gsd2200
Gsd2201
Gsd2600
Gsd2700
Owner’s Manual Dishwashers165D4700P242 49-5916 10-01 Jr
Safety Instructions . . . . . . . . 2, 3 Operating Instructions Care and Cleaning . . . . . . . . . . .9 Control Panels . . . . . . . . . . . . . . .4 Control Settings . . . . . . . . . . . . . 5 Dial Cycles . . . . . . . . . . . . . . . . . .6 Loading the Dishwasher Racks . . . . . . . . . . . .8 Optional Accessories . . . . . . . . .10 Using the Dishwasher . . . . . . . . .7 Troubleshooting Tips . . . . 11, 12 Consumer Support Consumer Support . . . Back Cover Product Registration . . . . . . 13, 14 Warranty . . . . . . . . . . . . . . . . . . 15 Write the model and serial numbers here: Model # ____________________ Serial # ____________________ You can find them on a label on the tub wall just inside the door.
2 Operating Instructions Safety Instructions Consumer Support Troubleshooting Tips I Do not tamper with controls. I Do not abuse, sit on, or stand on the door or dish rack of the dishwasher. I Do not discard a dishwasher without first removing the door of the washing compartment. I Do not store or use combustible materials, gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance. I Do not allow children to play around dishwasher when opening or closing door due to the possibility of small fingers being pinched in door. I Do not allow children to play with, on or around this appliance or any discarded appliance.
Do Not…
Warning!
Important Safety Information.
Read All Instructions Before Using.
Warning!
For your safety, the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or to prevent property damage, personal injury, or death. Under certain conditions hydrogen gas may be produced in a water heater that has not been used for two weeks or more. HYDROGEN GAS IS EXPLOSIVE. If the hot water has not been used for two weeks or more, prevent the possibility of damage or injury by turning on all hot water faucets and allow them to run for several minutes. Do this before using any electrical appliance which is connected to the hot water system. This simple procedure will allow any built-up hydrogen gas to escape. Since the gas is flammable, do not smoke or use an open flame or appliance during this process.Water Heater Safety
Use this appliance only for its intended purpose as described in this Owner’s Manual.Proper Installation And Maintenance
This dishwasher must be properly installed and located in accordance with the Installation Instructions before it is used. If you did not receive an Installation Instructions sheet with your dishwasher, you can receive one by visiting our website at GEAppliances.com. I Connect to a grounded metal, permanent wiring system; or run an equipment-grounding conductor with the circuit conductors and connect to the equipment-grounding terminal or lead of the appliance. I Improper connection of the equipment- grounding conductor can result in a risk of electric shock. Check with a qualified electrician or service representative if you are in doubt whether the appliance is properly grounded. I Use supply conductors rated at least 75°C(167°F).
I Dispose of discarded appliances and shipping or packing material properly. I Do not attempt to repair or replace any part of your dishwasher unless it is specifically recommended in this manual. All other servicing should be referred to a qualified technician. I To minimize the possibility of electric shock, disconnect this appliance from the power supply before attempting any maintenance. NOTE: Turning the dishwasher off does not disconnect the appliance from the power supply. We recommend having a qualified technician service your appliance.
Consumer Support Troubleshooting Tips Operating Instructions Safety Instructions 3
Proper Disposal Of The Dishwasher
Junked or abandoned dishwashers are dangerous…even if they will sit for “just a few days.” If you are getting rid of your old dishwasher, please follow the instructions below to help prevent accidents. Before You Throw Away Your Old Dishwasher: ITake off the door of the washing compartment or remove the door latch keeper (as shown).Warning! Risk Of Child Entrapment
When Using Your Dishwasher
IUse only powder, tabs, liquid detergents or rinse agents recommended for use in a dishwasher and keep them out of the reach of children. Cascade®, Cascade Complete® and Electrasol® Automatic Dishwashing Detergents, and Jet-Dry® rinse agent have been approved for use in all GE dishwashers. ILocate sharp items so that they are not likely to damage the door seal. ILoad sharp knives with the handles up to reduce the risk of cut-type injuries. IDo not wash plastic items unless marked dishwasher safe or the equivalent. For plastic items not so marked, check the manufacturer’s recommendations. INon-Dishware Items: Do not wash items such as electronic air cleaner filters, furnace filters and paint brushes in your dishwasher. Damage to dishwasher and discoloration or staining of dishwasher may result. IDo not touch the heating element during or immediately after use. IDo not operate your dishwasher unless all enclosure panels are properly in place. IClose supervision is necessary if this appliance is used by or near children. ILoad light, plastic items so they will not become dislodged and drop to the bottom of the dishwasher–they might come into contact with the heating element and be damaged.Read And Follow This Safety Information Carefully.
Save These Instructions
Door latch keeper GEAppliances.com
Operating Instructions Safety Instructions Consumer Support Troubleshooting Tips 4 About the dishwasher control panel.
Pots &
Pans
Normal
Wash
Heated Dry
On
Off
Cycles
Energy Options
Off
Short Wash
Start
Hot Start
Option
Plate Warmer
(Heated Dry On)
Rinse Only (Heated Dry Off)
Normal
Wash
Heated Dry
On
Off
Hi Temp Wash
On
Off
Cycles
Energy Options
Off
Light Wash
Start
Hot Start
Option
Plate Warmer
(Heated Dry On)
Rinse Only (Heated Dry Off)
Heavy
Wash
Heavy
Wash
Normal
Wash
Heated Dry
On
Off
Hi Temp Wash
On
Off
Cycles
Energy Options
Off
Short Wash
Start
Hot Start
Option
Plate Warmer
(Heated Dry On)
Rinse Only (Heated Dry Off)
Model GSD2600 Models GSD2200, GSD2201 Model GSD2700 You can locate your model number on the tub wall just inside the door. Throughout this manual, features and appearance may vary from your model.
Cycle Chart Model Cycle Water Usage (gal.) Cycle Time (min.)
Gsd2200,
Hot Start Option1 3.4 26Gsd2201
Pots & Pans 9.2 71 Normal Wash* 6.3 71 Short Wash* 3.8 58 Rinse Only* 2.5 13 Drying/Plate Warmer 0.0 27Gsd2600
Hot Start Option1 3.4 26 Heavy Wash 9.2 71 Normal Wash* 6.3 71 Light Wash* 5.0 62 Rinse Only* 2.5 13 Drying/Plate Warmer 0.0 27Gsd2700
Hot Start Option1 3.4 26 Heavy Wash 9.2 71 Normal Wash* 6.3 71 Short Wash* 3.8 58 Rinse Only* 2.5 13 Drying/Plate Warmer 0.0 27Wash On
HI TEMP Turns HI TEMP WASH off.Wash Off
HEATED DRY ON Turns the heating element on for fast drying. This option will extend the time of your wash cycle. Available on all wash cycles except RINSE ONLY. Adds approx. 32 minutes to the cycle. HEATED DRY OFF Turns HEATED DRY off. Dishes air dry naturally and energy is saved. Cycles POTS & PANS/ For heavily soiled dishes or cookware with dried-on or baked-on soils. Everyday dishes may be included. HEAVY WASH This cycle will not remove burned-on foods. NORMAL WASH For loads of everyday dishes, glasses and cookware with medium soils. NOTE: Many dishes have lighter soil than normal. Choosing a cycle other than NORMAL WASH will save energy and water. SHORT WASH For quickly washing loads of everyday dishes with medium soils that have not dried on, such as loads consisting mostly of glasses. LIGHT WASH For dishes with light soils. RINSE ONLY For rinsing partial loads that will be washed later. Do not use detergent. PLATE WARMER For warming clean dishes and serving plates. This cycle will take approximately 30 minutes. HOT START Preheats wash water to the correct temperature. Start Slowly turn the Dial to the START or ON position, or the selected cycle. Don’t turn it past the START, ON or cycle position, or you could accidentally miss a rinse. There is a time delay between start-up and water fill so you will not hear any wash action right away. ILatch the door to begin the cycle. Control Settings GEAppliances.com 5
About the dial cycles. Rinse Only For rinsing partial loads that will be washed later. Do not use detergent. Make sure HEATED DRY OFF is selected. Be sure the door is unlatched. Slowly turn the Dial to RINSE ONLY. Latch the door to start the cycle. 4 3 2 1
Off
Short Wash
Start
Hot Start
Option
Plate Warmer
(Heated Dry On)
Rinse Only (Heated Dry Off)
Hot Start Preheats wash water to the correct temperature. Select the HOT START cycle and any other option. Be sure the door is unlatched. Slowly turn the Dial to HOT START. Latch the door to start the cycle. 4 3 2 1Off
Short Wash
Start
Hot Start
Option
Plate Warmer
(Heated Dry On)
Rinse Only (Heated Dry Off)
Short Wash/Light Wash For quickly washing loads of everyday dishes with light to medium soils that have not dried on. Be sure the door is unlatched. Slowly turn the Dial to SHORT WASH/LIGHT WASH. Latch the door to start the cycle. 3 2 1Off
Short Wash
Start
Hot Start
Option
Plate Warmer
(Heated Dry On)
Rinse Only (Heated Dry Off)
Plate Warmer For warming clean dishes and serving plates. This cycle will take approximately 32 minutes. Load clean dishware to be warmed. Select HEATED DRY ON. Be sure the door is unlatched. Slowly turn the Dial to PLATE WARMER. Latch the door to start the cycle. 5 4 3 2 1Off
Short Wash
Start
Hot Start
Option
Plate Warmer
(Heated Dry On)
Rinse Only (Heated Dry Off)
Operating Instructions Safety Instructions Consumer Support Troubleshooting Tips 6
Filling the Dispenser Fill the rinse agent dispenser until it reaches the bottom of lip inside the opening. Replace cap. To check if rinse agent is needed, remove the cap and look into the dispenser. A full dispenser should last about one month. If rinse agent spills, wipe up the excess. Check the Water Temperature The entering water must be at least 120°F. and not more than 150°F., for effective cleaning and to prevent dish damage. Check the water temperature with a candy or meat thermometer. Turn on the hot water faucet nearest the dishwasher, place the thermometer in a glass and let the water run continuously into the glass until the temperature stops rising. Use Jet-Dry ® Rinse Agent Forget to Add a Dish? A forgotten dish can be added any time before the main wash. Push the door latch to the left. Once the water calms, open the door. Steam may rise out of the dishwasher. Add forgotten dishes. Close the door and push the latch to the far right. 4 3 2 1 Proper Use of Detergent Jet-Dry® rinse agent removes spots and prevents new film build-up on your dishes, glasses, flatware, cookware and plastic. Use only detergent specifically made for use in dishwashers. Cascade®, Cascade® Complete and Electrasol® Automatic Dishwashing Detergents have been approved for use in all GE dishwashers. Keep your detergent fresh and dry. Don’t put powder detergent into the dispenser until you’re ready to wash dishes. The amount of detergent to use depends on whether your water is hard or soft. With hard water, you need extra detergent. With soft water, you need less detergent. Protect your dishes and dishwasher by contacting your water department and asking how hard your water is. Twelve or more grains is extremely hard water. A water softener is recommended. Without it, lime can build up in the water valve, which could stick while open and cause flooding. Too much detergent with soft water can cause a permanent cloudiness of glassware, called etching. You’ll find two detergent dispensers on the inside door of your dishwasher. All wash cycles require detergent in the main cup. Wash cycles with two washes will also use the open cup. When using automatic dishwashing detergent tabs, simply place one tab in the main cup and close. Be sure the Dial is OFF before adding detergent. Otherwise, the detergent cup will not close and latch properly. Add detergent then close the main cup. NOTE: To open detergent cup after it has been closed, simply turn the detergent cup handle counterclockwise until it releases. A snapping sound may be heard. Open cup Main cup 7 Consumer Support Troubleshooting Tips Operating Instructions Safety Instructions Using the dishwasher. GEAppliances.com
Loading the dishwasher racks. Operating Instructions Safety Instructions Consumer Support Troubleshooting Tips 8 Upper Rack The upper rack is for glasses, cups and saucers. Cups and glasses fit best along the sides. This is also a secure place for dishwasher-safe plastics. The upper rack is good for all kinds of odd-shaped utensils. Saucepans, mixing bowls and other items should be placed face down. Secure larger dishwasher-safe plastics over two fingers when possible. Make sure small plastic items are secure so they can’t fall onto the heating element. Don’t block it or load tall things next to it. Also, be careful not to let a portion of an item such as a pot or dish handle extend through the bottom rack. This could block the wash arm and cause poor washing results. Wash Tower Keep the center area clear in the lower rack. The wash tower rises through the center of the lower rack during the wash and rinse portions of the cycle. Lower Rack When loading the lower rack, do not load large platters or trays in the front right corner. They may prevent detergent from circulating during the wash cycle. The lower rack is best used for plates, saucers, and cookware. Large items such as broiler pans and racks should go along the sides. Load platters, pots and bowls along the sides, in corners, or in the back. The soiled side of items should face the center of the rack. Silverware Basket Put flatware in the removable basket with fork and knife handles up to protect your hands. Place spoons in the basket with handles down. Mix knives, forks and spoons so they don’t nest together. Distribute evenly. Small plastic items, such as measuring spoons and lids from small containers, should go in the bottom of the silverware basket with silverware on top. For best dishwashing results, follow these loading guidelines. Features and appearance of racks and silverware baskets may vary from your model. Don’t let any item extend through bottom.
Caring for the dishwasher. GEAppliances.com 9 Consumer Support Troubleshooting Tips Operating Instructions Safety Instructions To clean the control panel use a lightly dampened cloth then dry thoroughly. To clean the exterior use a good appliance polish. Never use sharp object, scouring pads or harsh cleaners on any part of the dishwasher. If your dishwasher is left in an unheated place during the winter, ask a service technician to: Cut off electrical power to the dishwasher. Remove fuses or trip circuit breaker. Turn off the water supply and disconnect the water inlet line from the water valve. Drain water from the inlet line and water valve. (Use a pan to catch the water.) Reconnect the water inlet line to the water valve. Remove the plastic sump cover in the tub bottom and use a sponge to soak up water in the rubber boot. 5 4 3 2 1 Sump cover screws An air gap protects your dishwasher against water backing up into it if a drain clogs. The air gap is not a part of the dishwasher. It is not covered by your warranty. Not all plumbing codes require air gaps, so you may not have one. The air gap is easy to clean. Turn off the dishwasher and lift off the chrome cover. Unscrew the plastic cap and clean with a toothpick. 2 1 Check the air gap any time your dishwasher isn’t draining well. Two types of air gaps Does Your Dishwasher Have an Air Gap? Protect Against Freezing
About optional accessories. Operating Instructions Safety Instructions Consumer Support Troubleshooting Tips 10 You can change the door and lower access panel appearance of your dishwasher by ordering one of these optional accessories: I Color Panels I 1/4” Wood Panel Trim Kit I 3/4” Trimless Wood Panel Kit These accessories are available at extra cost (VISA, MasterCard or Discover cards accepted) by calling 800.626.2002. Specify accessory number when ordering. Descriptions of Optional Accessories Wood panel trim kit–This accessory contains trim and instructions for you to supply and install a 1⁄4″ thick decorative wood door and lower access panel: I GPF325A (Almond) I GPF325C (Bisque) I GPF325B (Black) I GPF325W (White) NOTE: The GPF100 dishwasher door spring kit must also be ordered and installed when the door panel weighs four lbs. or more. Trimless wood panel kit–This accessory contains parts and instructions for you to supply and install a 3 ⁄4″ thick decorative wood door and lower access panel:
I Gpf375
NOTE: The GPF100 dishwasher door spring kit will be included with the trimless wood panel kit and must be installed with it. I Prevents movement of baby bottles during the dishwasher cycle I Snaps easily onto any dishwasher upper rack I Eliminates hand washing I Fits all baby bottles You can order a package of 5 Baby Bottle Holders, at extra cost, by calling 800.626.2002, or through the Internet at GEAppliances.com (Visa, MasterCard or Discover cards accepted). For best results, the Baby Bottle Holder should be installed on the upper rack of the dishwasher. About rack accessories. Baby Bottle Holder Part Number: WX69X200
Consumer Support Troubleshooting Tips Operating Instructions Safety Instructions Problem Possible Causes What To Do Dishwasher won’t run Fuse is blown, or the
Problem Possible Causes What To Do Dishes and flatware Inlet water temperature • Raise the water heater temperature to 120°F. not clean is below 120°F.
Warning
Before cleaning interior, wait at least 20 minutes after a cycle for the heating element to cool down. Failure to do so can result in burns. An overall yellow or
13 General Electric Company Warranty Registration Department P.O. Box 32150 Louisville, KY 40232-2150 GE Service Protection Plus™ GE, a name recognized worldwide for quality and dependability, offers you Service Protection Plus ™–comprehensive protection on all your appliances– No Matter What Brand! Benefits Include:
Consumer Product Ownership Registration Important Mail Today! General Electric Company Louisville, Kentucky GEAppliances.com First Name Mr. I Ms. I Mrs. I Miss I Street Address City State Date Placed In Use Month Day Year Zip Code Apt. # Last Name Phone Number _ _ Consumer Product Ownership Registration Dear Customer: Thank you for purchasing our product and thank you for placing your confidence in us. We are proud to have you as a customer! Follow these three steps to protect your new appliance investment: Important: If you did not get a registration card with your product, detach and return the form below to ensure that your product is registered, or register online at GEAppliances.com. 1 2 3 Model Number Serial Number ! Cut here Complete and mail your Consumer Product Ownership Registration today. Have the peace of mind of knowing we can contact you in the unlikely event of a safety modification. After mailing the registration below, store this document in a safe place. It contains information you will need should you require service. Our service number is 800.GE.CARES (800.432.2737). Read your Owner’s Manual carefully. It will help you operate your new appliance properly. Model Number Serial Number E-mail Address* 14
15 Consumer Support Troubleshooting Tips Operating Instructions Safety Instructions What Is Not Covered: For The Period Of: GE Will Replace: One Year Any part of the dishwasher which fails due to a defect in materials or workmanship. During From the date of the this full one-year warranty, GE will also provide, free of charge, all labor and in-home service original purchase to replace the defective part. Second Year Any part of the Water Distribution System which fails due to a defect in materials or From the date of the workmanship. Associated inlet and drain plumbing parts are not covered by this warranty. original purchase During this second-year limited warranty, you will be responsible for any labor or in-home service costs. Ten Years The PermaTuf ®tub or door liner, if it fails to contain water due to a defect in materials or From the date of the workmanship. During this full warranty, GE will also provide, free of charge, all labor and original purchase in-home service to replace the defective part. GE Dishwasher Warranty. IService trips to your home to teach you how to use the product. IImproper installation. IFailure of the product if it is abused, misused, or used for other than the intended purpose or used commercially. IReplacement of house fuses or resetting of circuit breakers. IDamage to the product caused by accident, fire, floods or acts of God. IIncidental or consequential damage caused by possible defects with this appliance. ICleaning or servicing of the air gap device in the drain line. This warranty is extended to the original purchaser and any succeeding owner for products purchased for home use within the USA. In Alaska, the warranty excludes the cost of shipping or service calls to your home. Some states do not allow the exclusion or limitation of incidental or consequential damages. This warranty gives you specific legal rights, and you may also have other rights which vary from state to state. To know what your legal rights are, consult your local or state consumer affairs office or your state’s Attorney General. Warrantor: General Electric Company. Louisville, KY 40225 All warranty service provided by our Factory Service Centers, or an authorized Customer Care® technician. To schedule service, on-line, 24 hours a day, visit us at GEAppliances.com, or call
800.Ge.Cares (800.432.2737).
Staple your receipt here. Proof of the original purchase date is needed to obtain service under the warranty.
Printed in the United States Consumer Support. GE Appliances Website GEAppliances.com Have a question or need assistance with your appliance? Try the GE Appliances Website 24 hours a day, any day of the year! For greater convenience and faster service, you can now download Owner’s Manuals, order parts, catalogs, or even schedule service on-line. You can also “Ask Our Team of Experts™” your questions, and so much more... Schedule Service GEAppliances.com Expert GE repair service is only one step away from your door. Get on-line and schedule your service at your convenience 24 hours any day of the year! Or call 800.GE.CARES (800.432.2737) during normal business hours. Real Life Design Studio GEAppliances.com GE supports the Universal Design concept–products, services and environments that can be used by people of all ages, sizes and capabilities. We recognize the need to design for a wide range of physical and mental abilities and impairments. For details of GE’s Universal Design applications, including kitchen design ideas for people with disabilities, check out our Website today. For the hearing impaired, please call
