Page 1
LG LSC27935 French Door Refrigerator manual — page 1

Model Name/Nombre de Modelo**=color number/número de color

Lsc27935**

P/No. MFL63719705

English

Español

www.lg.com

Owner’S Manual

Side By Side

Refrigerator

Please read this manual carefully before operating your set and retain it for future reference.

Manual De Usuario

Refrigerador

De Dos Puertas

Lea detenidamente este manual antes de empezar a utilizar el refrigerador y guárdelo como referencia para el futuro.

Page 2
LG LSC27935 French Door Refrigerator manual — page 2

1

Warranty

Visit our web site http://www.lg.com LG Electronics

Limited Warranty

United States of America LG Electronics will repair or at its option replace, without charge, your product which proves to be defective in material or workmanship under normal use during the warranty period listed below from the date of original purchase. This warranty is good only to the original purchaser of the product during the warranty period as long as it is in the U.S. including Alaska, Hawaii, and U.S. Territories. LG Refrigerator / Freezer Warranty Period Product Parts Labor Refrigerator / Freezer 1 year 1 year [In-Home Service (Except Model GR-051)] Sealed System (Compressor, Condenser, Evaporator) 7 years 1 year [In-Home Service (Except Model GR-051)] No other express warranty is applicable to this product. THE DURATION OF ANY IMPLIED WARRANTIES, INCLUDING THE IMPLIED WARRANTY OF MERCHANTABILITY, IS LIMITED TO THE DURATION OF THE EXPRESS WARRANTY HEREIN. LG ELECTRONICS SHALL NOT BE LIABLE FOR THE LOSS OF USE OF THE PRODUCT, INCONVENIENCE OR ANY OTHER DAMAGES, DIRECT OR CONSEQUENTIAL, ARISING OUT OF THE USE OF OR INABILITY TO USE THIS PRODUCT OR FOR ANY BREACH OF ANY EXPRESS OR IMPLIED WARRANTY, INCLUDING THE IMPLIED

Warranty Of Merchantability Applicable To This Product.

Some States do not allow the exclusion or limitation of incidental or consequential damages or limitations on how long an implied warranty lasts; so these limitations or exclusions may not apply to you. This warranty gives you specific legal rights and you may also have other rights which vary from state to state.

The Above Warranty Does Not Apply To:

  • Service trips to your home to deliver and pickup, install, instruct, or replace house fuses or correct house wiring or
    • plumbing, or correction of unauthorized repairs.
  • Damage to the product caused by accident, pests, fire, floods, or acts of God.
  • Repairs when your LG product is used in other than normal, single-family household use.
  • Damage resulting from accident, alteration, misuse, abuse, or improper installation.
  • Damages caused during and/or after delivery.
  • Display, discount, or refurbished units purchased with scratches, dents, or defects.
    • Proof of purchase is required and must be provided to LG in order to validate warranty. Therefore, these costs are paid by the consumer. If the product is installed outside the normal service area, any cost of transportation involved in the repair of the product, or the replacement of defective parts, shall be borne by the owner.

    Customer Assistance Numbers:

    To obtain Warranty Coverage: Retain your Bill of Sale to prove date of purchase. A Copy of your Sales Receipt must be submitted at the time warranty service is provided. To obtain Product or Customer: Call 1-800-243-0000 (24 hrs a day, 7 days per week, 365 days per year). Service Assistance: Press the appropriate menu option, and have your product type (Refrigerator), model number, serial number, and ZIP/Postal Code ready. To obtain the nearest Authorized Service Center: Call 1-800-243-0000 (24 hrs a day, 7 days per week, 365 days per year) Press the appropriate option, and have your product type (Refrigerator), model number, serial number, and ZIP/Postal Code ready.

    Page 3
    LG LSC27935 French Door Refrigerator manual — page 3

    2

    Garantía

    Visite nuestro sitio web http://www.lg.com LG Electronics

    Garantía Limitada

    Estados Unidos de América LG Electronics reparará o en su defecto reemplazará sin cargo, el producto defectuoso en material o mano de obra bajo uso normal durante el período de garantía que se menciona a continuación desde la fecha original de compra. Esta garantía es válida solo para el comprador original del producto durante el período de garantía mientras permanezca en los E.E. U.U. Incluyendo Alaska, Hawaii y otros territorios de E.E.U.U. Período de Garantía del Refrigerador/Congelador LG Producto Partes Mano de Obra Refrigerador / Congelador 1 año 1 año [Servicio a Domicilio (Except Model GR-051)] Sistema Sellado (Compresor,Condensador, Evaporador) 7 años 1 año [Servicio a Domicilio (Except Model GR-051)] No se aplicará otro tipo de garantía a este producto. LA DURACIÓN DE OTRAS GARANTÍAS, INCLUYENDO LA DE COMPRA, ESTÁN LIMITADAS A LA DURACIÓN DE ÉSTA GARANTÍA. LG ELECTRONICS NO SE HACE RESPONSABLE POR LA PÉRDIDA EN EL USO DEL PRODUCTO, POR INCONVENIENCIA O CUALQUIER OTRO DAÑO DIRECTO O CONSECUENTE QUE PROVENGA DEL USO Y/O NO USO DE ESTE PRODUCTO O POR ALGUNA VIOLACIÓN A LAS GARANTÍAS IMPLEMENTADAS INCLUYENDO LA GARANTÍA DE COMPRA APLICADA A ESTE PRODUCTO. Algunos estados no permiten la exclusión o limitación de daños incidentales o consecuenciales o limitaciones en cuanto al tiempo que dura una garantía implícita; por lo que algunas de estas limitaciones o exclusiones pueden no aplicarse a usted. Esta garantía le otorga derechos legales específicos y usted puede además tener otros derechos los cuales varían de Estado a Estado.

    La Garantia Anterior No Aplica A :

  • Servicio a su casa para entregar, recoger, instalar o reemplazar fusibles caseros, corregir cableado casero o plomería,
    • corrección de reparaciones no autorizadas.
  • Daño al producto causado por accidente, plagas, incendios, inundaciones o actos por naturaleza.
  • Reparaciones cuando su producto LG sea usado diferente a lo normal.
  • Daño resultante de accidente, alteración, mal uso o instalación inadecuada.
  • Daños causados durante y después de la entrega.
  • Reemplazo, descuento o restauración de unidades compradas con rayones, abolladuras o defectos.
    • La prueba de la compra se requiere y se debe proporcionar a LG para validar la garantía. Por lo tanto, estos costos serán pagados por el consumidor. Si el producto es instalado fuera del área normal de servicio, cualquier costo de transportación relacionado en la reparación del producto, o el reemplazo de partes defectuosas, serán cargados al propietario.

    Números De Asistencia Al Cliente:

    Para obtener cobertura de la Garantía: Conserve su factura para comprobar la fecha de compra. Una copia de su recibo de compra debe ser entregada cuando se le proporcione el servicio de garantía. Para obtener información: Llame al 1-800-243-0000 (24 hrs al día, 7 días por semana, 365 días al año) Servicio de Asistencia: Presione la opción de menú apropiado, y tenga su tipo de producto (Refrigerador), número de modelo, número de serie, y ZIP / Código Postal listos. Para obtener el Centro de Servicio Autorizado más cercano: Llame al 1-800-243-0000 (24 hrs al día, 7 días por semana, 365 días al año). Presione la opción adecuada, y tenga su tipo de producto (Refrigerador), número de modelo, número de serie, y ZIP /código Postal listos.

    Page 4
    LG LSC27935 French Door Refrigerator manual — page 4

    3 Warranty (USA) 1-2 English Version 3-26 Spanish Version 27-50 Important Safety Instructions 4-5 Requirements for Ground Connection 5 Refrigerator Installation 6-11 Unpacking your Refrigerator 6 Installation 6 Base Grille Installation 6 Handle Removal 7 Handle Installation 7 Removing and Replacing Refrigerator Doors 7-8 Door Alignment 8-9 Connecting the Water Line 9-11 Refrigerator Features 12 Using your Refrigerator 13-18 Ensuring Proper Air Circulation 13 Prior to Use 13 Control Panel Features 13-14 Refrigerator and Freezer Controls 13-14 Adjusting Control Settings 14-15

    Ice maker Operation 15 Food Storage Guide 15 Storing Frozen Food 16 Water and Ice Dispenser 16 Ice Storage Bin 16 Door and Rack Support 17 Snack Pan 17 Crisper and Crisper Cover 17 Humidity Controls 17 Refrigerator Shelves 17-18 Freezer Shelf 18

    Filter (Water Filter) 19-20 Care and Cleaning 21-22 General Cleaning Tips 21 Outside 21 Inside Walls 21 Door Liners & Gaskets 21 Plastic Parts (Covers and Panel) 21 Back Cover 21 Lamp Replacement 21 Power Interruptions 21-22 When you go on Vacation 22 When you Move 22 When you should set the Ice maker Power Switch to off 22 Normal Sounds you May Hear 22 Troubleshooting Guide 23-26

    Table Of Contents

    Page 5
    LG LSC27935 French Door Refrigerator manual — page 5

    4 This manual contains several important safety notices. Always read and obey all of the following safety messages. This is the safety alert symbol. This symbol is a warning to potential dangers that could cause death, injury or damage to you, others or the product. All safety messages will follow after this warning symbol and the word “DANGER”, “CAUTION” or “WARNING”. These words mean: You may be killed or suffer fatal damage if you do not follow instructions. You may be killed or seriously injured if you do not follow instructions. Indicates a potentially hazardous situation which, if not avoided, may result in minor injury or damage to the product. All safety messages inform you of potential danger, advise you on how to reduce the risk of injury and tell you what can occur if the instructions are not followed.

    To reduce the risk of fire, electrical shock or personal injury, the following precaution measures should be followed:

  • NEVER disconnect the refrigerator by pulling the power
    • cord, always grip the plug firmly and disconnect it directly from the outlet.
  • Immediately repair or replace all faulty or damaged
    • service cables. Do not use cords that have cracks or abrasion damage on the length of the cord or on the plug.
  • When moving your refrigerator, take care not to roll over
    • the electrical cord.
  • DO NOT store or use gasoline or other combustible
    • liquids or vapors in proximity with this or any other electrical appliance.
  • DO NOT permit children to climb, stand or swing from
    • the doors or shelves of the refrigerator. This can cause serious injury to them and damage to the product.
  • Keep your fingers away from areas in which they
    • can become caught, such as the doors, hinges and cabinets. Be careful closing the doors when children are near.
  • Unplug the refrigerator before cleaning or repairing.
    • NOTE: We strongly recommend that any repair services be performed by a qualified professional.
  • Before replacing a burned-out light bulb, unplug the
    • refrigerator or shut down the circuit breaker to avoid contact with a live wire (the bulb could break while being replaced). NOTE: Setting the control to the OFF position does not disconnect the power from the light bulb circuit.
  • Do not keep bottles in the freezer compartment, they
    • could explode after freezing and cause damage.
  • For your safety, this product should be properly
    • grounded. Have a qualified professional check the electrical circuit and outlet to ensure a proper ground connection.
  • Read all instructions before utilizing the product. Utilize
    • this product only as explicitly expressed in this guide.
  • Once the refrigerator is operating, avoid touching cold
    • surfaces of the freezer with damp or wet hands; the skin could become adhered to these surfaces.
  • In refrigerators with an automatic ice dispenser, avoid
    • contact with moving parts of the ejector mechanism or with the heating mechanism that discharges the cubes. DO NOT place your fingers or hands in the ice dispenser mechanism while the refrigerator is connected.
  • DO NOT refreeze foods which have already thawed. The
    • Department of Agriculture of the United States, in your Bulletin of Home and Gardens No. 69 establishes that: “...You can refreeze food that has thawed if they contain ice crystals or are cold and below 40 °F (4 °C)”. “...Ground beef, perishable food or seafood that is discolored or has an unpleasant odor should not be frozen or consumed. Consumption of melted ice cream should also be avoided. If the odor or color of food is questionable, discard it. The food may be dangerous to consume”. “Partial thawing or refreezing reduces the quality of the food, especially fruit, vegetables and prepared meals. The quality of red meat is less affected than other foods. Use refrozen products as soon as possible in order to maintain their quality”.

    Save These Instructions

    Important Safety Instructions

    Safety Messages

    Warning

    Danger

    Warning

    Caution

    Page 6
    LG LSC27935 French Door Refrigerator manual — page 6

    5 This appliance is not intended for use by children, persons with physical or mental disabilities, persons with reduced sensory or mental capacity, or persons with lack of experience or know-how, unless they have supervision or instruction in relation to the use of the appliance by the person responsible for their safety. Children should be supervised to assure that they do not play with the appliance. Children becoming trapped or suffocated is not a problem of the past. Discarded and abandoned refrigerators are a hazard, even if they remain there “for just a few days”. If you would like to dispose of your old refrigerator, please follow the instructions below to prevent any accidents.

    Before Disposing Your Refrigerator Or

    Freezer When No Longer In Use:

  • Remove the doors.
  • Leave the shelves in place so that children cannot
    • easily become stuck in them. Your old refrigerator may have a cooling system that uses CFC’s (chlorofluorocarbons). CFC affects the stratospheric layer of the ozone. If you decide to throw out your old refrigerator, ensure that CFC contaminants are properly disposed of by a qualified professional. If you intentionally remove the CFC refrigerant, you could be subject to fines or prison in accordance with environmental legislation in effect. IMPORTANT: Attentively read the following.

    To Connect Electricity

    Warning

    Electrical Shock Hazard

    FOR YOUR PERSONAL SAFETY, this appliance must be properly grounded. Have a qualified electrician check your wall outlet to ensure that the plug is grounded properly.

    3 prong grounding type wall receptacle

    3 prong Ensure proper grounding ground exists plug before use

    Recommended Grounding Method

    Your refrigerator must always be plugged to its own outlet which is adequately grounded. The energy current should only be 115 V, 60 Hz, A. C. and fused at 15 or 20 A. This provides the best performance and prevents an overload which could cause a fire from the overheating of the cables. It is recommended that a separate circuit be used for this appliance, as well as a receptacle that cannot be disconnected with a switch. Do not use an extension cable. It is your responsibility and obligation to replace two- prong outlets with that of an adequately grounded three- prong outlet. Do not, under any circumstance, cut or extract the third prong from the plug. NOTE: Before installation, cleaning or replacing light bulbs, you must disconnect the appliance from the power source. When finished, plug the appliance back in and adjust the thermostat to the desired position.

    Use Of Extension Cables

    We do not recommend the use of extension cables. However, if you still choose to utilize an extension cable, it is absolutely necessary that it is listed in the UL (in the United States) or CSA (in Canada), that it supports three- pronged plugs and that the electrical current support a minimum of 15 A and 120 V. The use of an extension cable will increase the amount of space needed behind the refrigerator.

    Warning

    Replacing Electrical Cable

    If the power cord is damaged, it must be replaced by our service center or qualified LG technician to avoid any risk.

    Caution

    Danger: Children May Become Trapped

    Cfc Disposal

    Requirements For Ground Connection

    Page 7
    LG LSC27935 French Door Refrigerator manual — page 7

    6

    Refrigerator Installation

    Warning

    Excessive Weight Hazard

    Use the assistance of two or more persons to move or install the refrigerator. Not following these instructions may cause injury to the back and other parts of the body.

    Unpacking Your Refrigerator

    Before installing your refrigerator, remove any tape or temporary stickers. Do not remove any stickers that feature warnings, the model serial number or the technical label of the product located on the back of the refrigerator. To remove adhesive tape residue, rub it well with your fingers and a little liquid detergent. Clean with warm water and let dry. Do not use sharp instruments, rubbing alcohol, flammable liquids or abrasive cleaning products to remove the adhesive tape or glue. These products can damage the surface of your refrigerator. For more information, see the section on “Important Safety Instructions”. The shelves come already installed in their factory position. Remove the shelves and replace them according to your spacing needs.

    Warning

    When Moving Your Refrigerator

    Your refrigerator is extremely heavy. Make sure you protect the floor when moving your refrigerator for cleaning or servicing. Always pull your refrigerator straight out when moving it. Do not shift from side to side or “walk” the refrigerator when attempting to move it as this can cause damage to the floor.

    Warning

    Explosion Hazard

    Keep all flammable materials and vapors (such as gasoline) away from the refrigerator. Not following these instructions may cause death, explosion or fire

    Installation

  • Avoid placing the unit near heat sources, direct sunlight
    • or humidity.
  • To minimize noise and vibration, the refrigerator MUST
    • be installed on a solidly constructed floor.
  • Carpeting and soft tile surfaces are not recommended.
  • NEVER install the refrigerator on a platform or a weakly
    • supported structure.
  • Install this appliance in an area where the temperature
    • is between 41 °F (5 °C) and 110 °F (43 °C). If the temperature around the appliance is too low or high, cooling ability may be adversely affected. NOTE: For proper air circulation, and best cooling and energy consumption results, maintain a minimum distance of 2 inches (5,08 cm) from adjacent items and surfaces.

    Warning

    Be careful when you work with the hinge, base grille, stopper, etc. You may be injured. Do not put hands or metal sticks into air vents, base grille or bottom of the refrigerator. You may be injured or receive an electrical shock.

    Base Grille Installation

    To install or replace base grille:
  • Remove the 2 screws from the bottom front part of
    • refrigerator.
  • Place base grille into position and insert and tighten
    • screws. To remove the base grille:
  • Open the doors (Refrigerator and Freezer).
  • Once doors are open, remove screws from base grille
    • and remove.
  • Reattach screws to the base of refrigerator.

    • 2"(5,08 cm)

    Page 8
    LG LSC27935 French Door Refrigerator manual — page 8

    7

    Handle Removal

    You may have to remove the door handles to move the refrigerator through a narrow opening. See instructions below. NOTE: To avoid damaging door surfaces when moving the refrigerator through narrow openings, it is ALWAYS recommended to remove the doors as instructed in the next two pages.
  • Loosen the set screws with a 3/32” (2,38 mm) Allen
    • wrench and remove the handle. NOTE: If the handle mounting fasteners need to be tightened or moved, use a 1/4” (6,35 mm) Allen wrench.

    Handle Installation

    Place the handle on the door by adjusting handle footprints to fit mounting fasteners and tighten the set screws with a 3/32” (2,38 mm) Allen wrench . NOTE: If the handle mounting fasteners need to be tightened or removed use a 1/4” (6,35 mm) Allen wrench.

    Warning

    Electric Shock Hazard

  • Disconnect electrical supply to the refrigerator before
    • installing. Failure to do so could result in death or serious injury.
  • Do not put hands, feet or other objects into the air
    • vents, base grille, or bottom of the refrigerator. You may be injured or receive an electrical shock.
  • Be careful when you work with the hinge, base grille
    • and stopper. You may be injured. Before removing the doors, remove the base grille.

    Removing And Replacing Refrigerator

    Doors

    Before removing the doors, remove the base grille. See “Base Grille Installation” for reference. To remove the right (refrigerator) door:
  • Open the door. Remove the top hinge cover screw (1).
  • Use a flat blade screwdriver to pry back the hooks
    • (not shown) of the hinge cover (2) from the top of the refrigerator cabinet. Lift up the cover.
  • Rotate the hinge lever (3) clockwise. Lift the top hinge
    • (4) free of the hinge lever latch (5). NOTE: Regardless of hinge lever type, removal process is the same.
  • Lift the door from the lower hinge pin.
  • Place the door, inside facing up, on a non scratching
    • surface.

    Caution

    When lifting the hinge free of the latch, be careful that the door does not fall forward. Removing the left (freezer) door with water line connection: Pull up the water feed tube while pressing the area (Figure 1) as shown in the figure below. NOTE: If a tube end is deformed or abraded, trim the part away. Disconnecting the tube under the door causes about 0,13 gallons (0,5 liters) water to flow out. Put a large container at end of tube to prevent water from draining onto the floor.
  • Open the door. Remove the top hinge cover screw (1).
  • Use a flat blade screwdriver to pry back the hooks
    • (not shown) of the hinge cover (2) from the top of the refrigerator cabinet (2). Lift up the cover.
  • Disconnect all the wire harnesses (3).
  • Remove the grounding screw (4).
  • Rotate hinge lever (5) counterclockwise. Lift the top
    • hinge (6) free of the hinge lever latch (7). NOTE: Regardless of hinge lever type, removal process is the same.

    Refrigerator Installation

    Mounting Fasteners Set Screw Allen Wrench (1 ) (2 ) (3 ) (4 ) (5 ) Type 2 Type 1 (3 ) (4 ) (5 ) Rivet

    Page 9
    LG LSC27935 French Door Refrigerator manual — page 9

    8

    Caution

    When lifting the hinge free of the latch, be careful that the door does not fall forward.
  • Lift the door from the lower hinge pin being careful to
    • pull the water lines through the lower hinge pin.
  • Place the door, inside facing up, on a non scratching
    • surface. Reinstalling the right (refrigerator) door:
  • Place the door onto the lower hinge pin.
  • Fit top hinge (4) over hinge lever latch (5) into place.
    • Rotate lever (3) counterclockwise to secure hinge. NOTE: Regardless of hinge lever type, reinstallation process is the same.
  • Hook tab on switch side of corner under edge of wire
    • opening in cabinet top. Position cover (2) into place. Insert and tighten cover screw (1). Reinstalling the left (freezer) door:
  • Feed the water tubes through the lower hinge pin and
    • place the door onto the lower hinge pin.
  • Fit top hinge (6) over hinge lever latch (7) and into
    • place. Rotate lever (5) clockwise to secure hinge. NOTE: Regardless of hinge lever type, reinstallation process is the same.
  • Install the grounding screw (4) and connect all the wire
    • harnesses (3).
  • Hook tab on door switch side of cover (2) under edge
    • of wire opening in cabinet top. Position cover into place. Insert and tighten cover screw (1).
  • Reconnect the water tubes by inserting the tubes into
    • the connectors.

    Door Alignment

    Remove the base grille before adjusting the doors. See “Base Grille Installation” for reference. Two methods of door alignment are available based on the amount of adjustment needed and installation requirements. Type 1 Adjusting tool: Flat blade screwdriver. If the freezer compartment door is lower than the refrigerator compartment door, level them by inserting a flat blade screwdriver into the groove of the left leveling leg and rotating it clockwise. If the freezer compartment door is higher than the refrigerator compartment door, level them by inserting a flat blade screwdriver into the groove of the right leveling leg and rotating it clockwise.

    Refrigerator Installation

    (1) (3) (4) (5) Type 2 Type 1 (3 ) (4 ) (5 ) Rivet (2 ) (1 ) (2 ) (3) (5) (6) (7) (4) Type 2 Type 1 (5) (6) (7) Rivet Collet Tube Insert Line Left leveling leg Height Height difference difference

    C

    F

    C

    F

    H

    C

    F

    Right Height difference

    C

    F

    C

    F

    H

    C

    F

    Height difference leveling leg Figure 1 (1 ) (2 ) (3) (5) (6) (7) (4) Type 2 Type 1 (6) (5) Rivet (7)

    Page 10
    LG LSC27935 French Door Refrigerator manual — page 10

    9

    Refrigerator Installation

    Type 2 Adjusting tools: 5/16” (8 mm) wrench and 3/4” (19 mm) wrench. Using a 3/4” (19 mm) wrench, turn the keeper nut clockwise to loosen the keeper nut. Using a 5/16” (8 mm) wrench, turn the adjustment hinge pin clockwise or counterclockwise to level the refrigerator and freezer door. After setting level door, turn the keeper nut counterclockwise to tighten.

    Caution

    Do not over tight the door adjustment screw. The hinge pin can be pulled out. (Adjustable range of height is a maximum of 1/2” (1,27 cm)).

    After Leveling The Door Height

    Confirm all legs are in contact with the floor.

    Connecting The Water Line

    NOTE: Water line installation is needed when the Automatic Ice maker and/or Water Dispenser features are available on your product.

    Before You Begin

    This water line installation is not warranted by the refrigerator or ice maker manufacturer or seller. Follow these instructions carefully to minimize the risk of expensive water damage. Water hammer (water banging in the pipes) in house plumbing can cause damage to refrigerator parts and lead to water leakage or flooding. Call a qualified plumber to correct water hammer before installing the water supply line to the refrigerator. To prevent burns and product damage, do not hook up the water line to the hot water line. If you use your refrigerator before connecting the water line, make sure the ice maker power switch is in the OFF (O) position. Do not install the ice maker tubing in areas where temperatures fall below freezing. When using any electrical device (such as a power drill) during installation, be sure the device is double insulated or grounded in a manner to prevent the hazard of electric shock, or is battery-powered. All installations MUST be in accordance with local plumbing code requirements. NOTE: Wear eye protection.
  • If a reverse osmosis water filtration system is
    • connected to your cold water supply, the water line installation is not warranted by the refrigerator or ice maker manufacturer or seller. Follow next instruction carefully to minimize the risk of expensive water damage.
  • If a reverse osmosis water filtration system is
    • connected to your cold water supply, the water pressure to the reverse osmosis system needs to be a minimum of 40 to 60 PSI (2,8 kg•f/cm² ~ 4,2 kg•f/ cm² , less than 2~3 sec to fill a cup of 7 oz. capacity). If the water pressure from the reverse osmosis system is less than 21 PSI (1,5 kg•f/cm², more than 4 sec to fill a cup of 7 oz. capacity):
  • Check to see whether the sediment filter in the reverse
    • osmosis system is blocked. Replace the filter if necessary.
  • Allow the storage tank on the reverse osmosis system to
    • refill after heavy usage.
  • If the issue about water pressure from reverse osmosis
    • remains, call a licensed, qualified plumber.

    What You Will Need

  • Copper Tubing, 1/4” (6,35 mm) outer diameter
    • to connect the refrigerator to the water supply. Be sure both ends of the tubing are cut square. To determine how much tubing you need, measure the distance from the water valve on the back of the refrigerator to the water supply pipe. Then add 8 feet (2,4 m). Be sure there is sufficient extra tubing (about 8 feet [2,4 m] coiled into 3 turns of about 10” [25 cm] diameter) to allow the refrigerator to move out from the wall after installation. Be sure that the kit you select allows at least 8 feet (2,4 m) as described above.
  • A cold water supply. The water pressure MUST be
    • between 20 and 120 PSI (1,4 bar and 8,2 bar) on models without a water filter and between 40 and 120 PSI (2,8 bar and 8,2 bar) on models with a water filter.
  • Power drill.
  • 1/2” (12,7 mm) or Adjustable Wrench.
  • Flat head and Phillips screwdrivers.
    • Height difference Keeper Nut Adjustment hinge pin Wrench Up Down

    C

    F

    C

    F

    H

    C

    F

    Height difference

    Page 11
    LG LSC27935 French Door Refrigerator manual — page 11

    10

  • Two 1/4” (6,35 mm) outer
    • diameter compression nuts and 2 ferrules (sleeves) to connect the copper tubing to the shutoff valve and the refrigerator water valve. If your existing copper water line has a flared fitting at the end, you will need an adapter (available at plumbing supply stores) to connect the water line to the refrigerator OR you can cut off the flared fitting with a tube cutter and then use a compression fitting.
  • Shutoff valve to connect
    • to the cold water line. The shutoff valve should have a water inlet with a minimum inside diameter of 5/32” (3,96 mm) at the point of connection to the COLD WATER LINE. Saddle-type shutoff valves are included in many water supply kits. Before purchasing, make sure a saddle-type valve complies with your local plumbing codes.

    Installation Instructions

    Warning

    Connect to potable water supply only.

    1. Shutoff The Main Water Supply

    Turn on the nearest faucet to relieve the pressure on the line.

    2. Choose The Valve Location

    Choose a location for the valve that is easily accessible. It is best to connect into the side of a vertical water pipe. When it is necessary to connect into a horizontal water pipe, make the connection to the top or side, rather than at the bottom, to avoid drawing off any sediment from the water pipe.

    3. Drill The Hole For The Valve

    Drill a 1/4” (6,35 mm) hole in the water pipe using a sharp bit. Remove any burrs resulting from drilling the hole in the pipe. Take care not to allow water to drain into the drill. Failure to drill a 1/4” (6,35 mm) hole may result in reduced ice production or smaller cubes. NOTE: Licensed plumbers MUST use only cooper tubing NDA tubing #49595 or 49499 or Cross Link Polyethylene (PEX) tubing.

    4. Fasten The Shutoff Valve

    Fasten the shutoff valve to the cold water pipe with the pipe clamp. NOTE: Commonwealth of Massachusetts Plumbing Codes 248CMR shall be adhered to. Saddle valves are illegal and use is not permitted in Massachusetts. Consult with your licensed plumber.

    5. Tighten The Pipe Clamp

    Tighten the clamp screws until the sealing washer begins to swell. NOTE: Do not overtighten or you may crush the tubing.

    6. Route The Tubing

    Route the tubing between the cold water line and the refrigerator. Route the tubing through a hole drilled in the wall or floor (behind the refrigerator or adjacent base cabinet) as close to the wall as possible. NOTE: Be sure there is sufficient extra tubing [about 8 feet (2,4 m) coiled into 3 turns of about 10” (25 cm) diameter] to allow the refrigerator to move out from the wall after installation.

    7. Connect The Tubing To The Valve

    Place the compression nut and ferrule (sleeve) for copper tubing onto the end of the tubing and connect it to the shutoff valve. Make sure the tubing is fully inserted into the valve. Tighten the compression nut securely.

    Refrigerator Installation

    Pipe Clamp Saddle-Type Shutoff Valve Vertical Cold Water Pipe Pipe Clamp Clamp Screw Washer Inlet End

    Page 12
    LG LSC27935 French Door Refrigerator manual — page 12

    11

    Refrigerator Installation

    NOTE: Commonwealth of Massachusetts Plumbing Codes 248CMR shall be adhered to. Saddle valves are illegal and use is not permitted in Massachusetts. Consult with your licensed plumber.

    8. Flush Out The Tubing

    Turn the main water supply on and flush out the tubing until the water is clear. Shut the water off at the water valve after about one quart (1 L) of water has been flushed through the tubing.

    9. Connect The Tubing To The Refrigerator

    Notes:

  • Before making the connection to the refrigerator, be
    • sure the refrigerator power cord is not plugged into the wall outlet.
  • If your refrigerator does not have a water filter, we
    • recommend installing one. If your water supply has sand or particles that could clog the screen of the refrigerator’s water valve, install the filter in the water line near the refrigerator.
  • Do not uses old hoses; only use new hoses provided by
    • the manufacturer.
  • Remove the plastic flexible cap from the refrigerator
    • connection.
  • Place the compression nut and ferrule (sleeve) onto the
    • end of the tubing. (See figure 1).
  • Insert the end of the tubing into the connection as
    • far as possible. While holding the tubing, tighten the fitting.

    Caution

    Check to make sure that leaks are not occurring in the water line. Fasten the tubing into the tubing clamp attached to the back of the refrigerator. First, loosen the screw fastening the clamp. Next, insert the tubing in the groove. Finally, re-fasten the screw.

    10. Plug In The Refrigerator

    Arrange the coil of tubing so that it does not vibrate against the back of the refrigerator or against the wall. Push the refrigerator back to the wall.

    11. Start The Ice Maker

    Set the ice maker power switch to the ON (I) position. The ice maker will not begin to operate until it reaches its operating temperature of 15 °F (-9 °C) or below. It will then begin operation automatically if the ice maker power switch is in the ON (I) position.

    Saddle-Type Shutoff Valve Packing Nut Outlet Valve Compression Nut Ferrule (sleeve)

    Figure 1 Ferrule (Sleeve) Tubing Clamp Refrigerator Connection 1/4” (6,35 mm) Tubing 1/4” (6,35 mm) Compression Nut Back of Refrigerator

    Page 13
    LG LSC27935 French Door Refrigerator manual — page 13

    12

    Refrigerator Features

    Use this page to become more familiar with the parts and features. NOTE: This guide covers several different models. The refrigerator you have purchased may have some or all of the items listed below. The locations of the features shown below may not match your model. Automatic Ice maker The ice is produced in the ice maker and sent to the dispenser. Freezer Shelf Freezer Light (LED) Freezer Door Rack Drawer Base Grille Refrigerator Light (LED) Dairy Corner For storage of dairy products such as butter and cheese. Water Filter Refrigerator Shelf Snack Pan For storage of meat or fresh food. Refrigerator Door Rack Vegetable Drawer

    A

    B

    C

    F

    G

    E

    D

    H

    I

    J

    K

    L

    M

    A

    B

    C

    B

    D

    D

    E

    F

    M

    G

    H

    I

    J

    L

    J

    G

    L

    K

    Page 14
    LG LSC27935 French Door Refrigerator manual — page 14

    13

    Using Your Refrigerator

    Ensuring Proper Air Circulation

    In order to ensure proper temperatures, air MUST flow between the refrigerator and freezer sections.
  • Cool air enters the freezer through the vents located
    • at the top of the compartment and exits through the vents located behind the freezer drawers.
  • Cool air from the freezer section enters the fresh
    • food section through vents located at the top of the compartment. The air moves down throughout the compartment and exits through the vents located behind the crisper drawers.
  • Do not block any of these vents with food packages.
    • If the vents are blocked, airflow will be interrupted and temperature and moisture problems may occur. IMPORTANT: Because air circulates between both sections, any odors formed in one section will transfer to the other. You MUST thoroughly clean both sections to eliminate odors. To prevent odor transfer and dried out food, wrap or cover foods tightly. (See the “Food Storage Guide” section for details).

    Note:

    If you close the refrigerator door, you may see the freezer door open and close again due to pressure from internal air flow.

    Prior To Use

  • Clean your refrigerator thoroughly and wipe off dust
    • accumulated during shipping.
  • Install accessories such as ice cube bin, drawers,
    • shelves, etc., in their proper places. They are packed together to prevent possible damage during shipment.
  • Let your refrigerator run for at least 2 or 3 hours before
    • putting food in it. Check the flow of cold air in the freezer compartment to ensure proper cooling. Your refrigerator is now ready for use.

    Control Panel Features

    Press the button for the desire function to review and select other settings.

    Led Display

    The LED display shows the temperature settings, dispenser options, and the water filter door alarm and status messages.

    Ice Type

    The ICE TYPE is used to select cube, ice or crushed ice. NOTE: Hold the glass or other container in place for a couple of seconds after dispensing ice or water to catch the last few cubes or drops. The dispenser is designed not operate while either refrigerator door is open.

    Freezer

    Press the FREEZER button to adjust the temperature in the freezer compartment.

    Refrigerator

    Press the REFRIGERATOR button to adjust the temperature in the refrigerator compartment. NOTE: The actual inner temperature varies depending on the food status, since the indicated temperature setting is the target temperature an not the actual temperature within the refrigerator. Initially set the REFRIGERATOR CONTROL at 37 °F (3°C). Leave it at these settings for 24 hours (one day) to stabilize. Then adjust the compartment temperature as illustrates above. NOTE: When press simultaneously the FREEZER button and the REFRIGERATOR button for more than 5 seconds, the temperature display will change from Fahrenheit to Celsius or vice versa.

    Ice Plus

    Press this button once to activate the increased ice making function. The ICE PLUS icon on the display panel will illuminate when activated. The Ice Plus function runs the freezer compartment at the coldest settings for a 24 hours period to increase ice making. Press the button again to cancel the Ice Plus function.

    Ice Type

    Crush

    Cube

    Ice Plus

    Hold

    3 Secs

    Month

    Ice Type

    Freezer

    Refrigerator

    Ice Plus

    Light/Filter

    Alarm/Lock 3 Sec

    Ice Type

    Freezer

    Refrigerator

    Ice Plus

    Page 15
    LG LSC27935 French Door Refrigerator manual — page 15

    14

    Using Your Refrigerator

    Light/Filter

    The LIGHT/FILTER button controls the lamp in the dispenser, resets the water filter replacement indicator when the filter has been replaced. The water filter needs replacement once every six months. Filter month indicator becomes “0” to let you know when replace filter. Press and hold the LIGHT/FILTER button for more than 3 seconds to reset the filter month indicator to six after the water filter has been replaced.

    Alarm/Lock

    Press this button to control the door-open alarm. Press and hold the ALARM/LOCK button for 3 seconds to lock the dispenser and all the other control panel functions. Press and hold again for 3 seconds to unlock. The ALARM/LOCK button also controls the door alarm that sounds three times in 30 seconds intervals when a compartment door is left open for more than 60 seconds. The alarm stop sounding when the door is closed. Press the ALARM/LOCK button once to activate or deactivate the door alarm function.

    Display Off Mode

    To activated Display Off Mode press and hold ICE PLUS and FREEZER key over 5 seconds until lights will turn on and after 20 seconds of inactivity the lights will turn off automatically. To exit Display Off Mode press and hold ICE PLUS and FREEZER key over 5 seconds until lights will tilt. Display Off Mode does not affect the temperature control settings of the unit. Ice Type Indicator Shows the type of ice, crushed or cube, or water that the dispenser will dispense. Freezer Temperature Shows the temperature in the freezer, Celsius or Fahrenheit. Refrigerator Temperature Shows the temperature in the refrigerator, Celsius or Fahrenheit.

    Ice Plus When this button is on the screen will show this has been activated. Dispenser Light When this button is in function on the light will show this has been activated. When the dispenser light is on the display will indicate this feature. Door Alarm Indicator This indicator shows that the door-open warning alarm is activated. Water Filter Status This light shows the filter’s status. See the filter’s configurations. Lock Status This light shows the actual status of the control panel, in which the lock function is on.

    Diagnosis Function (Failure Detection)

    Diagnosis function automatically detects failure during the normal use of refrigerator. If you refrigerator fails, do not turn off the power. Instead, contact a local Authorized service center or call our support line for assistance. Turning off the appliance will make it more difficult for the service technician to determine the problem.

    Adjusting Control Settings

    Give the refrigerator time to cool down completely before making final adjustments. It is best to wait 24 hours before doing this. The initial settings mentioned in “Control Panel Features” section should be correct for normal household refrigerator use. The refrigerator control functions as the thermostat for the entire appliance (refrigerator and freezer sections). The colder the setting, compressor will the longer the run to keep the temperature colder. The freezer control adjusts the cold air flow from the freezer to the refrigerator. Setting the freezer control to a lower temperature keeps more cold air in the freezer compartment to make it colder. If you need to adjust temperatures in the refrigerator or freezer, start by adjusting the refrigerator and allow 24 hours for the temperature to stabilize. If it is too warm or too cold, then adjust the freezer control. Use the settings listed in the chart below as a guide. Always remember to wait at least 24 hours between adjustments.

    Condition/Reason:

    Recommended

    Adjustment:

    REFRIGERATOR section is too cold
  • Controls not set
    • correctly for your conditions Adjust the REFRIGERATOR setting to the next lowest number and wait 24 hours, then check. FREEZER section is too cold
  • Controls not set
    • correctly for your conditions Adjust the FREEZER setting to the next lowest number and wait 24 hours, then check.

    Light/Filter

    Ice Type

    Crush

    Cube

    Ice Plus

    Hold

    3 Secs

    Month

    1 2 3 4 5 6 7 8 1 2 3 4 5 6 8 7

    Alarm/Lock

    3 Sec

    Page 16
    LG LSC27935 French Door Refrigerator manual — page 16

    15

    Using Your Refrigerator

    Condition/Reason:

    Recommended

    Adjustment:

    REFRIGERATOR section is too warm
  • Opening the door often
  • Adding a large amount
    • of food
  • Room temperature is
    • very warm Adjust the REFRIGERATOR setting to the next highest number and wait 24 hours, then check. FREEZER section is too warm/ ice is made too slowly
  • Opening the door often
  • Adding a large amount
    • of food
  • Room temperature is
    • very low (not cycling often enough)
  • Using ice frequently
  • Air vents blocked by
    • objects Adjust the FREEZER setting to the next highest number and wait 24 hours, then check. Remove any objects blocking air flow.

    Ice Maker Operation

    Warning

    Personal Injury Hazard

    Avoid contact with the moving parts of the ejector mechanism, or with the heating element that releases the cubes. DO NOT place fingers or hands on the automatic ice making mechanism while the refrigerator is plugged in. A newly-installed refrigerator may take 12 to 24 hours to begin making ice. The ice maker produces 5 cubes per cycle (in between 60 and 80 cubes in a 24 hour period), depending on the temperature of the freezer, the times in which the door opens, and other using conditions (amount of food in the freezer, etc). If the refrigerator is used before the water connection is made to the ice maker, set the power switch to OFF (O). Throw away the first few batches of ice to allow the water line to clear. Be sure nothing interferes with the sweep of the feeler arm. When the bin fills to the level of the feeler arm, the ice maker will stop producing ice. It is normal for several cubes to be stuck together. If ice is not used frequently, old ice cubes will become cloudy, taste stale and shrink.

    Food Storage Guide

    Wrap or store food in the refrigerator in airtight and moisture-proof material unless otherwise noted. This prevents food odor and taste transfer throughout the refrigerator. For dated products, check date code to ensure freshness.

    Items

    How To Store

    Storing Fresh Food Wrap or store food in the refrigerator in airtight and moisture-proof material unless otherwise noted. This prevents food odor and taste transfer throughout the refrigerator. For dated products, check date code to ensure freshness. Butter or margarine Store opened butter in a covered dish or in a closed compartment. When storing a larger quantity, wrap in freezer packing and freeze. Cheese Store in original packaging until you are ready to use it. Once opened, tightly rewrap with plastic wrap or aluminum foil. Vegetables with skins (carrots, peppers) Place in bags or plastic containers inside the crisper. Fruit Wash and let dry; store in plastic bags in the refrigerator. Do not wash or pit berries until you are ready to eat them. Berries should be selected and kept in their original packaging (if there is any) or in a paper bag closed halfway and set on a shelf. Leafy Vegetables Remove original packaging and trim any dirty or discolored parts. Wash in cold water and drain. Place in a plastic bag or plastic container and store in the crisper. Fish Consume fish or seafood the same day purchased. Chef Fresh Store any meat in original airtight, moisture-proof packaging. Rewrap if it is necessary. Leftovers Cover leftovers with plastic wrap or aluminum foil. Plastic containers with airtight lids can also be used. Cube Size Light Shutoff Arm Power Switch

    Page 17
    LG LSC27935 French Door Refrigerator manual — page 17

    16

    Using Your Refrigerator

    Ice

    Type

    Cube

    Crush

    Ice

    Plus

    Hold

    3

    Secs

    Month

    Ice Type

    Crush

    Cube

    Ice Plus

    Hold

    3 Secs

    Month

    Holes Ribs

    Ice

    Type

    Cube

    Crush

    Ice

    Type

    Cube

    Crush

    Ice

    Plus

    Hold

    3

    Secs

    Month

    Ice

    Plus

    Hold

    3

    Secs

    Month

    Ice

    Type

    Cube

    Crush

    Ice

    Plus

    Hold

    3

    Secs

    Month

    Ice Type

    Crush

    Cube

    Ice Plus

    Hold

    3 Secs

    Month

    Storing Frozen Food

    NOTE: For further information about preparing food for freezing or food storage times, check a freezer guide or a reliable cookbook. Packaging Successful freezing depends on correct packaging. When you close and seal the package, it must not allow air or moisture in or out. If it does, you could have food odor and taste transfer throughout the refrigerator and also dry out frozen food. Packaging Recommendations:
  • Rigid plastic containers with “tight-fitting lids”.
  • Straight-sided canning/freezing jars.
  • Heavy-duty aluminum foil.
  • Plastic-coated paper.
  • Non-permeable plastic wraps.
  • Specified freezer-grade self-sealing plastic bags.
    • Follow package or container instructions for proper freezing methods. Do not use:
  • Bread wrappers
  • Containers without tight lids
  • Wax paper or wax-coated freezer wrap
  • Thin, semi-permeable wrap

    • Caution

    Do not keep beverage cans or plastic food containers in the freezer compartment. They may burst if they freeze. Freezing Your freezer will not quick-freeze any large quantity of food. Do not put more unfrozen food into the freezer than will freeze within 24 hours [no more than 2 to 3 lbs of food per cubic foot (0,9 to 1,35 kg per cubic meter) of freezer space]. Leave enough space in the freezer for air to circulate around packages. Be careful to leave enough room at the front so the door can close tightly. Food storage times will vary according to the quality and type of food, the type of packaging or wrap used (airtight and moisture-proof) and the storage temperature. Ice crystals inside a sealed package are normal. This simply means that moisture in the food and air inside the package have condensed, creating ice crystals. NOTE: Allow hot foods to cool at room temperature for 30 minutes, then package and freeze. Cooling hot foods before freezing saves energy.

    Water And Ice Dispenser

    Your refrigerator has a mechanism that dispatch cool water and ice cubes without open the door.
  • Tray can be easily removed by
    • pressing and pulling it.
  • Tilt up the front of tray slightly and snap the ribs into
    • the holes to reinstall the tray.

    Warning

    Do not put your hands into the water & ice dispenser opening. Doing so may cause an injury to your hand.

    Caution

    When opening the container with the small opening, use it near the opening of the water or ice dispenser as close as possible. Water Switch Press the push water switch or activate water button with a plass or the water container and chilled water will be dispensed. When the water switch or water button is pressed, the light will be illuminated.

    Ice Storage Bin

    The ice bin stores the ice cubes made by the ice maker. If you need to remove the ice storage bin, do so as follows: NOTE: Use both hands to remove the ice bin to avoid dropping it.
  • Lift the ice storage bin slightly
    • and pull it out as shown in the figure.

    Page 18
    LG LSC27935 French Door Refrigerator manual — page 18

    17

    Door Rack And Support

    Your refrigerator and freezer features racks which can easily be arranged for packaged products.
  • Lift the door rack holding both sides and pull it out
    • in direction.

    Snack Pan

  • To remove the snack pan cover, pull out the snack pan
    • compartment a bit to the front , then lift the front part of the snack pan compartment later raises a little the snack pan compartment until it leaves the top of the shelf as shown in , and take it out.

    Crisper And Crisper Cover

    The crisper allows for better conservation of fruits and vegetables.
  • To remove the crisper compartment cover, pull out the
    • crisper compartment a bit to the front , lift the front part of the cover as shown in , and take it out .
  • To remove the crisper compartment, pull the crisper
    • compartment to the front until it stops. Then slightly lift the crisper compartment while pulling it out .

    Caution

    When removing the crisper compartment you will see the water tank. Do not remove it, or water leakage may result. The water tank is not a removable part.

    Humidity Controls

    You can control the amount of humidity in the moisture sealed crispers. Adjust the control to any setting between “HIGH” and “LOW”. “HIGH”: Keeps moist air in the crisper for best storage of fresh, leafy vegetables. “LOW”: Keeps moist air out of the crisper for best storage of fruits or vegetables with skins.

    Refrigerator Shelves

    Caution

    Make sure to keep shelf horizontal while removing; otherwise it may drop. The refrigerator compartment shelf is adjustable so that you can place it at a height according to space requirement of foods. Sliding out Shelf: Pull the shelf towards you , then lift both front and rear while taking it out .

    Using Your Refrigerator

    Tank

    Page 19
    LG LSC27935 French Door Refrigerator manual — page 19

    18

    Caution

    Be careful when pulling out the shelf. If you apply too much force, it may hit the refrigerator door and damage it or you could hurt yourself. Fixed Shelf:
  • Lightly lift up the front part of the shelf to pull it
    • towards you ,then take it out while lifting the rear part of shelf .

    Freezer Shelf

    To assemble or disassemble the freezer shelf, follow the next steps:
  • Lift the left part of the shelf a bit. Lift it to the direction
    • , push the right part to the direction and take it out. Door

    Using Your Refrigerator

    Page 20
    LG LSC27935 French Door Refrigerator manual — page 20

    19

    Filter

    Water Filter

    The water control panel shows in months the time to be left to change the filter; from the first turn on of the refrigerator or 6 months or the water dispenser has been used. If you have changed the filter after 6 months of use or you wish to reset the filter indicator screen, press the FILTER button more than 3 seconds until you hear a beep, this will let you know that the screen has been reseted. NOTE: The average life of the filter is 6 months. It’s highly recommended to change the filter when the indicator light is on or the water dispenser or the ice dispenser changes drastically. After changing the water filter cartridge, reset the water filter status display and indicator light by pressing and holding the BUTTON for 3 seconds. How to change the old cartridge.
  • Turn the shutoff valve off (house valve).
  • Dispense water from the system to
    • empty the tubing (approximately for 50 seconds).
  • Remove the old cartridge. Rotate the knob of the
    • cartridge counter clockwise. When the cartridge is removed, it will click out of place. Pull out the cartridge. NOTE: There will be water in the cartridge. Some spilling may occur through the hole at rear bottom side of cover. You may use a cup or something like that to prevent split water drop into food.
  • Replace with a new cartridge. Take the new cartridge
    • out of its packaging and remove protective cover from the o-rings. With cartridge knob in the vertical position, push the new filter cartridge into the cover until it stops. If you can´t turn the filter from side to side, it is not fully inserted. Push it in firmly and twist it into place. You will hear it click into place. Using its handle, twist the cartridge clockwise about 1/4 turn. You will hear when it clicks into place.
  • Turn the shut off valve on (house valve).
  • Flush water out from the system
    • until air gets eliminated and water start to dispense (approximately for 60 seconds). Flush 2,5 gallons (9,5 liters) of water through filter. NOTE: To purchase replacement water filter cartridges, visit your local appliance dealer or part distributor.

    Ice Type

    Crush

    Cube

    Ice Plus

    Hold

    3 Secs

    Month

    Ice Type

    Cube

    Crush

    Ice Plus

    Hold

    3 Secs

    Month

    Ice Type

    Cube

    Crush

    Ice Plus

    Hold

    3 Secs

    Month

    Page 21
    LG LSC27935 French Door Refrigerator manual — page 21

    20

    Filter

    Performance Data Sheet Models Number 5231JA2006E Use with replacement cartridge 5231JA2006E This system has been tested according to NSF/ANSI Standards 42 for the reduction of the substances listed below. The concentration of the indicated substances in water entering the system was reduced to a concentration less than or equal to the permissible limit for water leaving the system as specified in NSF/ANSI 42. System tested and certified by NSF International against NSF/ANSI Standard 42 for the reduction of Chlorine Taste and Odor and Nominal Particulate Class III.

    Contaminant Reduction Average Influent Influent Challenge Concentration. Units apply to each row Product Water Average % Reduction

    Nsf

    Reduction Requirements Max Effluent mg/L Min % Reduction NSF Test Nominal Particulate Class I Particle size: ›0.5 to ‹1 um 5600000 At least 10,000 particles/ml 915 96 ≥ 85% 470000 91.6% 511032-03 Chlorine taste and odor 1,9 mg/L 2,0 mg/L ± 10% 0,07 96,4 ≥ 50% 0.05 mg/L 97.4% 511032-03
  • To a capacity of 300 gallons (1.135 L).
  • Note that while the testing was performed under standard laboratory conditions, actual performance may vary.
    • Application Guidelines / Water Supply Parameters Water Pressure 20 - 120 psi (138 - 827 kPa) Water Temperature 33 ºF - 100 ºF (0,6 ºC - 38 ºC) Service Flow 0,5 gpm (1,9 lpm)

    Warning

    To reduce the risk associated with ingestion of contaminants due to use with water that is micro biologically unsafe or of unknown quality. Do not use with water that is micro biologically unsafe or of unknown quality without adequate disinfection before or after the system. Systems must be installed and operated in accordance with manufacturer’s recommended procedures and guidelines.

    Caution

    To reduce the risk of property damage due to water leakage:
  • Read and follow Use instructions before installation
    • and use of this system.
  • Install on COLD water lines only. Comply with all
    • state and local plumbing codes.
  • Company with all state and local plumbing codes.
    • Never install or operate where inlet water pressure may exceed 125 psi (862 kPa).
  • Protect filter from freezing. Remove filter in
    • temperatures below 34 °F (1 °C).
  • Replace cartridge at specified service interval.
    • Cartridge MUST be replaced at least every 6 months.
  • After replacing the water filter cartridge, dispense
    • 2,5 gallons (9,46 liters) of water to purge the system, depressing and releasing the dispenser pad in cycles of 30 seconds ON and 60 seconds OFF. Discard the purged water. To purchase or replace water filters call your Service Center. Refer to the Warranty Card to obtain the telephone number of the Service Center near you and ask for part no. 5231JA2006E. *

    Page 22
    LG LSC27935 French Door Refrigerator manual — page 22

    21

    Warning

    Explosion Hazard

    Use non-flammable cleaner. Failure to do so can result in death, explosion, or fire. Both the refrigerator and freezer sections defrost automatically. However, clean both sections about once a month to prevent odors. Wipe up spills immediately.

    General Cleaning Tips

  • Unplug refrigerator or disconnect power.
  • Remove all removable parts, such as shelves, crispers,
    • etc. Refer to sections in “Using Your Refrigerator” for removal instructions.
  • Use a clean sponge or soft cloth and a mild detergent
    • in warm water. Do not use abrasive or harsh cleaners.
  • Hand wash, rinse and dry all surfaces thoroughly.
  • Plug in refrigerator or reconnect power.

    • Outside

    Waxing external painted metal surfaces helps provide rust protection. Do not wax plastic parts. Wax painted metal surfaces at least twice a year using appliance wax (or auto paste wax). Apply wax with a clean, soft cloth. Do not use wax on stainless steel exteriors. Use a product specially designed for polishing stainless steel appliances, or clean with a soft cloth or clean sponge and a mild detergent dissolved in warm water. Dry thoroughly with a soft cloth. NOTE: Avoid door surface contact with chemical products that contain Phosphate or Chlorine, such as degraders, detergents (containing TSP) and bleaches.

    Inside Walls

    NOTE: Allow freezer to warm up so cloth will not stick. To help remove odors, you can wash the inside of the refrigerator with a mixture of baking soda and warm water. Mix 2 tablespoons baking soda to 1 quart of water (26 g soda to 1 liter water.) Be sure the baking soda is completely dissolved so it does not scratch the surfaces of the refrigerator.

    Door Liners And Gaskets

    Do not use cleaning waxes, concentrated detergent, bleaches, or cleaners containing petroleum on plastic refrigerator parts. Use a clean sponge or soft cloth and a mild detergent in warm water. Wash, rinse and dry all surfaces thoroughly. PLASTIC PARTS (covers and panels) Do not use window sprays, abrasive cleaners or flammable fluids. These can scratch or damage the material. Use a clean sponge or soft cloth and a mild detergent in warm water. Wash, rinse and dry all surfaces thoroughly.

    Back Cover

    Warning

    Electrical Shock Hazard

    Before you begin, either unplug the refrigerator or turn off power at the circuit breaker or fuse box. Failure to do so could result in death or serious injury. NOTE: Back Cover should only be removed by a qualified technician. Clean the vents on the back cover. Use a vacuum cleaner with the brush attachment, at least twice a year to keep your refrigerator working efficiently.

    Light (Led) Replacement

    NOTE: Do not remove the LED, it is only to be removed by a qualified technician.

    Power Interruptions

  • If the power will be out for 24 hours or less, keep all
    • refrigerator doors closed to help foods stay cold and frozen.
  • If the power will be out for more than 24 hours:
    • a) Remove all frozen food and store it in a frozen food locker.

    Or

    b) Place 2 lbs. (1 kg) of dry ice in the freezer for every cubic foot (28 L) of freezer space. This will keep the food frozen for two to four days. While handling dry ice, wear gloves to protect your hands from frostbite.

    Warning

    Suffocation Hazard

    When using dry ice, provide adequate ventilation, Dry ice is frozen carbon dioxide (CO2). When it vaporizes, it can displace oxygen, causing dizziness, light-headedness, unconsciousness and death by suffocation. Open a window and do not breathe the vapors.

    Or

    c) If neither a food locker nor dry ice is available, consume or dispose of food at once.

    Back

    Cover

    Care And Cleaning

    Page 23
    LG LSC27935 French Door Refrigerator manual — page 23

    22 REMEMBER: In a power failure, a full freezer stays cold longer than a partially filled one. If you see that food contains ice crystals, it may be affected. If the condition of the food is poor, or if you feel it is unsafe, dispose of it.

    Warning

    DO NOT refreeze frozen foods which have thawed completely. The United States Department of Agriculture in Home and Garden Bulletin No. 69 says: ...You may safely refreeze frozen foods that have thawed if they still contain ice crystals or if they are still cold- below 40 °F (4 °C). ...Thawed ground meats, poultry or fish that have any off-odor or off-color should not be frozen and should not be eaten. Thawed ice cream should be discarded. If the odor or color of any food is poor or questionable, dispose of it. The food may be dangerous to eat. Even partial thawing and refreezing reduces the eating quality of foods, particularly fruits, vegetables and prepared foods. The eating quality of red meats is affected less than that of many other foods. Use refrozen foods as soon as possible to save as much of their quality as you can.

    When You Go On Vacation

    If you choose to leave the refrigerator ON while you are away, follow these steps to prepare your refrigerator before you leave.
  • Use up any perishables and freeze other items.
  • Empty the ice bin.
  • Turn OFF the Ice maker. NOTE: If the ambient
    • temperature will drop below freezing, have a qualified service technician drain the water supply system (on some models) to prevent serious property damage due to possible flooding from ruptured water lines or connections. If you choose to turn the refrigerator OFF before you leave, follow these steps:
  • Remove all food from the refrigerator and empty ice
    • bin.
  • Unplug refrigerator.
  • Clean refrigerator, wipe and dry well.
  • Tape rubber or wood blocks to the tops of both doors
    • to prop them open far enough for air to get in. This stops odor and mold from building up.

    When You Move

    When you are moving your refrigerator to a new home, follow these steps to prepare it for the move.
  • Remove all food from the refrigerator and pack all
    • frozen food in dry ice.
  • Unplug refrigerator.
  • Clean refrigerator, wipe, and dry well.
  • Empty water from the defrost pan.
  • Clean, wipe and dry thoroughly.
  • Take out all removable parts, wrap them well and tape
    • together so they don’t shift and rattle during the move. Refer to sections in “Using your Refrigerator” for removal instructions.
  • Depending on the model, raise the front of the
    • refrigerator so it rolls more easily OR screw in the leveling legs all the way so they don’t scrape the floor. See the “Door Alignment” section.
  • Tape the doors shut and tape the power cord to the
    • refrigerator cabinet. When you get to your new home, put everything back and refer to the “Refrigerator Installation” section for setup instructions.

    When You Should Set The Ice Maker

    Power Switch To Off (O)

  • When the water supply will be shut off for several hours.
  • When the ice storage bin is removed for more than a
    • minute or two.
  • When the refrigerator will not be used for several days.

    • Normal Sounds You May Hear

  • The ice maker water valve will buzz as the ice maker fills
    • with water. If the power switch is in the ON position, it will buzz even if it has not yet been hooked up to water. To stop the buzzing, move the power switch to OFF position. NOTE: Keep the power switch in the ON position before the water line is connected can damage the ice maker.
  • You will hear the sound of cubes dropping into the bin
    • and water running in the pipes as the ice maker refills.

    Care And Cleaning

    Page 24
    LG LSC27935 French Door Refrigerator manual — page 24

    23

    Understanding Sounds You May Hear

    Your new refrigerator may make sounds that your old one did not make. Because the sounds are new to you, you might be concerned about them. Most of the new sounds are normal. Hard surfaces, like the floor, walls and cabinets, can make the sounds seem louder than they actually are. The following list describes the kinds of sounds and what may be making them.
  • The defrost timer will click when the automatic defrost
    • cycle begins and ends. The thermostat control (or refrigerator control, depending on the model) will also click when cycling on and off.
  • Rattling noises may come from the flow of refrigerant,
    • the water line, or items stored on top of the refrigerator.
  • Your refrigerator is designed to run more efficiently
    • to keep your food items at the desired temperature. The high efficiency compressor may cause your new refrigerator to run longer than your old one, and you may hear a pulsating or high-pitched sound.
  • You may hear the evaporator fan motor circulating the
    • air through the refrigerator and freezer compartments.
  • As each cycle ends, you may hear a gurgling sound
    • due to the refrigerant flowing in your refrigerator.
  • Contraction and expansion of the inside walls may
    • cause a popping noise.
  • Water dripping on the defrost heater during a defrost
    • cycle may cause a sizzling sound.
  • You may hear air being forced over the condenser by
    • the condenser fan.
  • You may hear water running into the drain pan during
    • the defrost cycle. Problem Possible Causes Solutions

    Refrigerator

    Does Not

    Operate

  • The power supply cord is unplugged.
  • A household fuse has blown or
    • circuit breaker tripped.
  • The refrigerator control is set to the
    • OFF position.
  • Refrigerator is in the defrost cycle.
  • Firmly plug the cord into a live outlet with proper
    • voltage.
  • Replace the fuse or reset the circuit breaker.
  • Refer to the “Control Panel Features” section.
  • Wait about 30 minutes for defrost cycle to end.

    • Vibration Or

    Rattling Noise

  • The refrigerator is not resting solidly
    • on the floor.
  • Floor is weak or uneven or leveling legs need
    • adjusting. See “Door Alignment” Section.

    Led

    (Lamp)

    Do

    Not Work

  • The power supply cord is unplugged.
  • LED Light has burned out.
  • Firmly plug the cord into a live outlet with proper
    • voltage.
  • See the “Light (LED) Replacement” section.

    • Compressor

    Motor Seems To

    Run Too Much

  • The refrigerator that was replaced
    • was an older model.
  • The room temperature is hotter than
    • normal.
  • The
    • refrigerator was recently plugged in and the refrigerator control was set correctly.
  • The door is opened often or a large
    • amount has just been added.
  • The refrigerator control was not
    • set correctly for the surrounding conditions.
  • Modern refrigerators with more storage space
    • require more operating time.
  • The motor will run longer under warm conditions.
    • At normal room temperatures, expect your motor to run about 40% to 80% of the time. Under warmer conditions, expect it to run even more often.
  • The refrigerator will take up to 24 hours to cool
    • completely.
  • Adding food and opening the door warms the
    • refrigerator. It is normal for the refrigerator to run longer in order to conserve energy, try to get everything you need out of the refrigerator at once, keep food organized so it is easy to find and close the door as soon as the food is removed. See the “Food Storage Guide” section.
  • See the “Adjusting Control Settings” Section.

    • Troubleshooting Guide

    Page 25
    LG LSC27935 French Door Refrigerator manual — page 25

    24 Problem Possible Causes Solutions

    Compressor

    Motor Seems To

    Run Too Much

  • The doors are not closed completely.
  • The condenser coils are dirty.
  • Push the doors firmly shut. If they will not shut all
    • the way, see Doors will not close completely below.
  • This prevents air transfer and makes the motor
    • work harder. Clean the condenser coils. Refer to the “Care and Cleaning” section.

    Doors Will Not

    Close

    Completely

  • The refrigerator is not level.
  • Food packages are blocking the
    • door open.
  • The ice bin, crisper cover, pans,
    • shelves, door bins or baskets are out of position.
  • The gaskets are sticking.
  • The refrigerator wobbles or seems
    • unstable.
  • The doors were removed during
    • product installation and not properly replaced.
  • See the “Refrigerator Installation” and “Door
    • Alignment” sections to level refrigerator.
  • Rearrange food containers to clear door and door
    • shelves.
  • Push bins all the way in and put crisper cover, pans,
    • shelves and baskets into their correct positions. See the “Using your Refrigerator” Section.
  • Clean gaskets and the surface that they touch.
    • Rub a thin coat of paraffin wax on the gaskets after cleaning.
  • Level the refrigerator. Refer to the “Door
    • Alignment” section.
  • Remove and replace the doors according to the
    • “Removing and Replacing Refrigerator Doors” section or call qualified service technician.

    The Doors Are

    Difficult To

    Open

  • The gaskets are dirty or sticky.
  • The door is reopened within a short
    • time after having been opened.
  • Clean gaskets and the surfaces that they touch.
    • Rub a thin coat of appliance polish or kitchen wax on the gaskets after cleaning.
  • When you open the door, warmer air enters the
    • refrigerator. As the warm air cools, it can create a vacuum. If the door is hard to open, wait 5 minutes to allow the air pressure to equalize, then see if it opens more easily.

    Temperature Is

    Too Warm Or

    There Is

    Interior

    Moisture

    Buildup

  • The doors are opened often.
  • The control is not set correctly for
    • the surrounding conditions.
  • A large amount of food has just
    • been added to the refrigerator or freezer.
  • The food is not packaged correctly.
  • The doors are not closing completely.
  • The weather is humid.
  • A self-defrost cycle was completed.
  • The air vents are blocked. Cold air
    • circulates from the freezer to the fresh food section and back again through air vents in the wall dividing the two sections.
  • When the door is opened, warm humid air is
    • allowed into the refrigerator. The more the door is opened, the faster the humidity builds up, and the more warm air the refrigerator must cool. In order to keep the refrigerator cool, try to get everything you need out of the refrigerator at once, keep food organized so it is easy to find and close the door as soon as the food is removed.
  • Refer to the “Control Panel Features”. Wait 24
    • hours for temperatures to stabilize or even out. If the temperature is too cold or too warm, adjust the setting one level at a time.
  • Adding food warms the refrigerator. It can take a
    • few hours for the refrigerator to return to normal temperature.
  • Wrap food tightly and wipe off damp containers
    • prior to storing in the refrigerator to avoid moisture accumulation. If necessary, repackage food according to the guidelines in the “Food Storage Guide” section.
  • See “Doors will not close completely”.
  • In humid weather, air carries moisture into
    • refrigerator when doors are opened.
  • It is normal for droplets to form on the back wall
    • after the refrigerator self-defrosts.
  • Locate air vents by using your hand to sense
    • airflow and move all packages that block vents and restrict airflow. Refer to “Ensuring Proper Air Circulation” section for the location of air vents.

    Troubleshooting Guide

    Page 26
    LG LSC27935 French Door Refrigerator manual — page 26

    25 Problem Possible Causes Solutions

    Cubes

    Produced By

    Ice Maker Are

    Too Small

  • Water shutoff valve connecting
    • refrigerator to water line may be clogged.
  • Call a plumber to clear the valve.

    • Ice Has Bad

    Taste Or Odor

  • The ice maker was recently installed.
  • The ice has been stored for too long.
  • The food has not been wrapped
    • tightly in either compartment.
  • The water supply contains minerals
    • such as sulfur.
  • The interior of refrigerator needs
    • cleaning.
  • Ice storage bin needs cleaning.
  • Discard first few batches of ice to avoid discolored
    • or off-flavored ice.
  • Throw away old ice and make new supply.
  • Rewrap foods since odors may migrate to the ice if
    • food is not wrapped properly.
  • A new filter may need to be installed to eliminate
    • taste and odor problems.
  • See “Care and Cleaning” section.
  • Empty and wash bin. Discard old cubes.

    • There Is Water

    In The Defrost

    Drain Pan

  • The refrigerator is defrosting.
  • It is more humid than normal.
  • The water will evaporate. It is normal for water to
    • drip into the defrost pan.
  • Expect that the water in the defrost pan will take
    • longer to evaporate. This is normal when it is hot or humid.

    The

    Refrigerator

    Seems To Make

    Too Much Noise

  • The sounds may be normal for your
    • refrigerator.
  • Refer to the “Understanding sounds you may
    • hear” section.

    Frost Or Ice

    Crystals On

    Frozen Food

  • The door is not closing properly.
  • The door is opened often.
  • See “Doors will not close completely” above.
  • When the door is opened, warm, humid air is
    • allowed in the freezer resulting in frost.

    The Ice Maker Is

    Not Producing

    Ice Or Ice Cubes

    Are Freezing

    Too Slowly

  • The freezer temperature is cold
    • enough to produce ice.
  • Door left open.
  • Wait 24 hours after hook-up for ice production.
    • See the “Control Panel Features” section.
  • Check to see if something is holding the door
    • open.

    Automatic Ice

    Maker Does

    Not Work

  • Ice maker power switch on OFF (O)
    • position.
  • Water supply turned off or not
    • connected.
  • Freezer compartment too warm.
  • Piled up the cubes in the storage
    • bin cause the ice maker to shut off.
  • Move the switch to the ON (I) position.
  • See the “Connecting the Water Line” section.

  • Wait 24 hours for the freezer to reach its ideal
    • temperature.
  • Level cubes by hand or shake the bin occasionally.

    • Not Dispensing

    Ice

  • All the doors are not closed
    • completely.
  • The dispenser display is locked.
  • Ice is not selected on the dispenser
  • The ice dispenser is not used often.
  • Ice bin is not installed correctly.
  • New installation.
  • Ice cubes are stuck in the delivery
    • chute.
  • Ice will not dispense if any of the refrigerator doors
    • are left open.
  • Press and hold the Lock button for 3 seconds to
    • unlock the control panel and dispenser.
  • The dispenser can be set for ice or water. Make
    • certain that the control panel is set for the proper operation. Press the dispenser button on the control panel to cycle through the ice and water options.
  • Check the ice bin for ice cubes clumping/ sticking
    • together. If they are, break up the ice cubes allow for proper operation.
  • Be sure to install the ice bin firmly into position.
  • Wait 24 hours after ice maker installation for ice
    • production to begin. Wait 72 hours for full ice production.
  • Use a plastic utensil to clear the delivery chute.

    • Troubleshooting Guide

    Page 27
    LG LSC27935 French Door Refrigerator manual — page 27

    26 Problem Possible Causes Solutions

    Not Dispensing

    Ice

  • The ice dispenser is stalling while
    • dispensing “crushed” ice.
  • Ice maker power switch in the OFF
    • (O) position.
  • Water supply turned off or not
    • connected.
  • Change the ice button from “crushed” to “cubed”. If
    • cubed ice dispenses correctly, depress the button for“crushed” ice and begin dispensing again.
  • Move the switch to the ON (I) position.
  • See the “Connecting the Water Line” section.

    • Not Dispensing

    Water

  • The dispenser display is locked.
  • New installation.
  • Refrigerator or freezer doors are not
    • closed properly.
  • Water supply turned off or not
    • connected.
  • The water pressure is less than 40

    • Psi.

  • Home filter or reverse osmosis
    • system is used.
  • The dispenser is not set for water
    • dispensing.
  • Press and hold the Lock button for 3 seconds to
    • unlock the control panel and dispenser.
  • Flush and fill the water system.
  • Water will not dispense if any of the refrigerator
    • doors are left open.
  • See the “Connecting the Water Line” section.
  • The water pressure to the home affects the flow
    • from the dispenser.
  • This
    • can decrease water pressure. It is recommended not to connect the supply line to a reverse osmosis system for optimal operation.
  • The dispenser can be set for ice or water. Make
    • certain that the control panel is set for the proper operation. Press the dispenser button on the control panel to cycle through the ice and water options.

    Troubleshooting Guide

    Page 28
    LG LSC27935 French Door Refrigerator manual — page 28

    1-800-243-0000 1-888-865-3026 1-888-542-2623 USA, Consumer User USA, Commercial User

    Canada

    LG Customer Information Center www.lg.com Register your Product Online!

    More from LG

    Washing Machines

    AI Inverter Direct Drive WM3988HWA Washing Machine

    27 Q&As

     Air Conditioners

    Air Conditioner FAQ Guide

    28 Q&As

     TVs

    AW-47LG30M 47-Inch LED TV

    19 Q&As

     Washing Machines

    CL Washer

    10 Q&As

    Similar Refrigerators

    Bosch

    800 Series B36IT900NP Built-In Refrigerator

    20 Q&As

     Dometic

    A C N Series Hipro Refrigerator

    0 Q&As

     Bosch

    B30/B36 Fridge-Freezer

    20 Q&As

     Bosch

    B30BB130SS Counter-Depth French Door Refrigerator

    20 Q&As
