Common questions
Common Questions
17 totalWhy won't my dishwasher run at all?
A fuse in your home may be blown or the circuit breaker may have tripped — replace the fuse or reset the circuit breaker and remove any other appliances sharing the circuit. Check the Problem Solver section for additional causes of minor operating problems you can correct yourself.
How much detergent should I use depending on my water hardness?
For soft water (0–3 grains hardness), use a minimum of 1 tablespoon in the main cup for a Normal Wash cycle. For hard water (7–12 grains), fill both the main cup and open cup completely full. A filled main cup holds 3 tablespoons and a filled open cup holds 2 tablespoons. At 12 grains and above, a water softener is recommended.
What safety precautions should I follow when loading sharp items and knives?
Load sharp knives with the handles up to reduce the risk of cut-type injuries. Also locate sharp items so they are not likely to damage the door seal. Light plastic items should be secured so they cannot become dislodged and drop to the bottom where they could contact the heating unit.
Why is there suds in my dishwasher tub and how do I fix it?
Suds are caused by using a non-automatic-dishwasher detergent — only automatic dishwasher detergents should be used. To remove existing suds, open the dishwasher and let suds evaporate, then add 1 gallon of cold water to the tub, close and latch the door, and pump out the water by slowly turning the control dial until a drain period is reached. Spilling rinse agent can also cause foam and potential overflowing, so wipe up any accidental spills with a damp cloth.
How do I use and fill the rinse agent dispenser?
Unscrew the dispenser cap and add liquid rinse agent until it just reaches the bottom of the lip inside the dispenser opening, then replace the cap. The dispenser automatically releases the rinse agent into the final rinse water. Occasionally check to ensure the rinse agent container is at least half full, and if you accidentally spill rinse agent, wipe it up with a damp cloth immediately so it doesn't interfere with detergent performance.
How do I maintain and clean the air gap on my GSD570?
Check the air gap at least once a month by turning off the dishwasher, lifting off the chrome cover, unscrewing the plastic cap, and checking for any buildup of grit — a toothpick makes cleaning easy. Also check the air gap any time your dishwasher isn't draining well. Note that the air gap is not part of the dishwasher and is not covered under the warranty.
Show 11 more questions
How do I load plastic items safely in my dishwasher?
What detergent should I use in the GSD570?
Why are my dishes not drying properly?
How do I remove spots and film from glassware?
What does the GSD570 warranty cover and for how long?
What water temperature should I use with my GSD570 dishwasher?
How do I use rinse agent in my dishwasher?
What should I do if detergent is left in the dispenser cups?
Can I wash sterling silver and stainless steel together?
What should I do if my dishwasher won't run?
How do I clean the air gap in my dishwasher drain?
Full Manual
16 pages
Use & Care Guide Dishwasher Contenh Air Gap 14 Stiety Instructions 3 Apphance Re~strdtion 2 User Maintenance Instructions 14 Care and Cleaning 14 Warranty Back Cover China, Crystal, Sterling 10 Water Saver 4-6 Consumer Services 15 Water Temperature 6 Cycle Features 5 Winter Storage 14 Detergent, Detergent Guide 6,7 Dispenser Cups 7 Ener~ Saver Stitch 4 Ener~-Saving Tips 2 Front Panel Color Change 14 Loading 8,9 Model and Serial Numbers 2 Operathg Instructions 4,5 Cycle Selection 4,5 Drying Options 4,5 Problem Solver 11-13 GE Answer Center m Rinse Agent 6 800.626.2000 Built-h Model GSD570 fl- GE Appliances
Help us help you... If you need service Before using your dishwasher, read this book carefully. It is intended to help you operate and maintain your new dishwasher properly. Keep it handy for answers to your questions. If you don’t understand something or need more help, write (include your phone number): Consumer Affairs GE Appliances Appliance Park Louisville. KY 40225 Write down the model and serial numbers. You’ll find them on a label fastened to the tub wall just inside the dishwasher door. These numbers are also on the Consumer Product Ownership Registration Card that came with your dishwasher. Before sending in this card, please write these numbers here: Mfid Number Serial Number Use these numbers in any correspondence or service calls concerning your dishwasher. If you received a damaged dishwasher... Immediately contact the dealer (or builder) that sold you the dishwasher. Save time and money. Before you request service... Check the Problem Solver section. It lists causes of minor operating problems that you can correct yourself. To obtain a Spanish language version of this book, call GE Answer Center@ 800.626.2000 consumer information service. Para obtener la versi6n en Espafiol de este manual, name a GE Answer Center! servicio de inforrnaci6n para el consumidor, te16fono 800.626.2000. Energy-Saving tips G Operate dishwasher only when it’s full. Let the dishes accumulate in dishwasher. When you put in only a partial load, use the RINSE & HOLD cycle to rinse off heavy soils. Be sure to latch the door when waiting for a full load. This helps keep soils moist, easier to remove. G If you don’t need your dishes right away, use your energy saver NO HEAT DRYING that turns the drying heater off automatically. Dishes dry naturally over a longer period such as overnight. G Always select the cycle that uses least amount of water that will remove the soil from the load. (See the Operating section). To obtain service, see the Consumer Services page in the back of this book. We’re proud of our service and want you to be pleased. If for some reason you are not happy with the service you receive, here are three steps to follow for further help. FIRST, contact the people who serviced your appliance. Explain why you are not pleased. In most cases, this will solve the problem. NEXT, if you are still not pleased, write all the details—including your phone number—to: Manager, Consumer Relations GE Appliances Appliance Park Louisville, KY 40225 FINALLY, if your problem is still not resolved, write: Major Appliance Consumer Action Panel 20 North Wacker Drive Chicago, IL 60606 2
Important Safety Instructions
Read all instructions before using this applianceA
WARNING–When using this appliance, ~ways exercise basic safety precautions, including the following: . Use this appliance only for its intended purpose, as you will find described in this Use and Care Guide. G This dishwasher must be properly installed and located in accordance with the Installation Instructions before it is used. If you did not receive an Installation Instructions sheet with your dishwasher, you can obtain one by contacting the service location nearest you. —This appliance must be connected to a grounded metal, permanent wiring system; or an equipment- grounding conductor must be run with the circuit conductors and connected to the equipment-grounding terminal or lead of the appliance. —Connect to a properly rated, protected and sized power- supply circuit to avoid electrical overload. G Do not store or use combustible materials, gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance. G Use only powder or liquid detergents or wetting agents recommended for use in a dishwasher. G Do not wash plastic items unless marked “dishwasher safe” or the equivalent. For plastic items not so marked, check the manufacturer’s recommendations. G Load light plastic items so they will not become dislodged and drop to the bottom of the dishwasher—they might come into contact with the heating unit and be damaged. To minimize the possibility of injury. G When loading items to be washed: A. Locate sharp items so that they are not likely to damage the door seal, and B. Load sharp knives with the handles up to reduce the risk of cut-type injuries. G Do not touch the heating element during or immediately after use. G Do not operate your dishwasher unless all enclosure panels are properly in place. G Do not tamper with controls. G Do not abuse, sit on, or stand on the door or dish rack of the dishwasher. G Close supervision is necessary if this appliance is used by or near children. Do not allow children to play inside, on or with this appliance or any discarded appliance. Dispose of discarded appliances and shipping or packing material properly. Before discarding a dishwasher, remove the door of the washing compartment. G Keep all washing detergents and wetting agents out of the reach of children, preferably in a locked cabinet. Observe all warnings on container labels to avoid personal injury. G To minimize the possibility of electric shock, disconnect this appliance from the power supply before attempting any maintenance. Note: Turning the control dial to the OFF position does not disconnect the appliance from the power supply. We recommend having a qualified technician service your appliance. AwkGmmm GM is produced by the chemical action within your water heater. It can accumulate in the water heater andor water pipes if hot water has not been used for a period of two weeks or longer.Hydrogen Gas Is
EXPLOSIVE. To prevent the possibility of damage or injury, if you have not used hot water for two weeks or more, or moved into a residence in which the hot water system may not have been used for some time, turn on all hot water faucets and allow them to run for several minutes before using any electrical appliance which is connected to the hot water system. This will allow any hydrogen gas to escape. Also, since the gas is flammable, do not smoke or use an open flame or appliance during this process.Save These
Instructions
3
How to operate your dishwasher STEP 1. Load your dishwasher with dishes, silverware, pots, pans, bowls, etc. accordingto instructions in the Loading section. STEP 2. Add detergent to the detergent dispenser. Make sure the Cycle Indicator DiaI is at OFF position before adding detergent. (See Detergent Guide.) Use rinse aid agent to help prevent spotting. Occasionally check to insure that rinse agent container is at least half full. (See How To Use A Rinse Agent.) STEP 3. Select DRYING Option. ~ HEaTED
Drving
No Heat
Drying
HEATED DRYING. Turns the drying heater on for fast drying. NO HEAT DRYING (energy saving drying). Turns the drying heater off to save energy. Dishes will dry naturally over a longer period such as overnight. If you need your dishes sooner, open the dishwasher door after the cycle is complete to reduce the natural drying time. Use of this option reduces the electrical energy used by this model approximately 7~0 for the NORMAL WASH cycle. STEP 4. Select the Cycle and start dishwasher. If your dishwasher drains into a food waste disposer, operate the disposer until it is empty before starting the dishwasher. (See Cycle selection hints on next page. ) To obtain the benefits of a complete cycle, be careful that you do not turn the dial any further than necessary to start the dishwasher. “ For NORMAL WASH cycle: a. Latch the door.0; :N
WATER SAfiR @ t“Orving G
Washing
Rim E&Hou
G
d ,,,., ,~; op,,oti, 1L
,.”. b. Slowly turn Cycle Indicator Dial to ON position to start the cycle. You will hear the motor start. There is a time delay between start-up and water fill so you wiIl not hear any wash action right away. G For WATER SAVER cycle: a. Be sure door is unlatched.I
Water Saves
@ f14Drying G
Washing
slN~E howG
4(“%E,& ,0,,>0.,
b. Slowly turn Cycle Indicator Dial to WATER SAVER position. c. Latch door to start the cycle. G For RINSE & HOLD cycle: a. Be sure door is unlatched. b. Select NO HEAT DRYING drying option. c. Slowly turn Cycle Indicator Dial to RINSE & HOLD position. d. Latch door to start the cycle.
Cycle selection hinb It is important to follow the loading instructions. NORMAL WASH is for loads of everyday dishes, glasses and cookware with medium soils. WATER SAVER is for dishes with light soils that have not dried on, or that have extra preparation before loading. It saves water and energy. RINSE & HOLD is for rinsing partial loads which will be washed later. Do not use detergent. What happens in each cycle G You’11 hear occasional clicking sounds: —Soft food disposer shredding action. —Drain valve opening to pump water out. —Timer control as cycle progresses. —Detergent cup opening. G During the drying period: —The motor stops. —Water vapor comes through the vent by the door latch during drying and when water is being pumped out. Wash Water Use Cycle Time Gallons Minutes Wash Cycles (approx.) (approx.) Cycle Sequence
Water Saver
8.7 46K
mH@HRinse & Hold
4.9 14 mm Drying Options: HEATED DRYING. Available on all wash cycles except RINSE & HOLD. Add 29 minutes to wash cycle time. NO HEAT DRYING. Drying heater is turned off. Dishes dry naturally. 5
Good dishwashing starts with HOT water. To get dishes clean and dry, you need hot water. To help you get water of the proper temperature, your dishwasher automatically heats the water in the wash cycle. For good washing and drying, the entering water must be at least 120°F. To prevent dish damage, inlet water shodd not exceed 150°F. How to test water temperature: Higher water temperature is needed to dissolve grease and activate powder detergents. Check you water temperature with a candy or meat thermometer. Turn on the hot water faucet nearest the dishwasher. Put the thermometer in a glass and let the water run continuously into the glass until the temperature stops rising. If the water temperature is below 120°F., adjust your water heater. Helpful hints: If outside temperatures are unusually low, or if your water travels a long distance from water heater to dishwasher, you may need to set your water heater’s thermostat up. If you have not used hot water for some time, the water in the pipes will be cold. Turn on the hot water faucet at the sink and allow it to run until the water is hot. Then start the dishwasher. If you’ve recently done laundry or run hot water for showers, give your water heater time to recover before operating the dishwasher. To improve washability if the water is less than 120°F. and you cannot adjust your water heater: Select a longer cycle and fill both detergent cups at least half-full with detergent. How to use a rinse agent... A rinse agent makes water flow off dishes quicker than usual. This lessens water spotting and makes drying faster, too. For best dishwashing performance, use of a rinse agent such as JET- DRY brand is recommended. Rinse agents come in either liquid or solid form. Your dishwasher uses the liquid form. How to fill the rinse agent dispenser. Unscrew the cap. Add the liquid rinse agent until it just reaches the bottom of the lip inside the dispenser opening. Replace the cap. The dispenser automatically releases the rinse agent into the final rinse water. If you accidentally spill: Wipe up the rinse agent with a damp cloth. Don’t leave the spill in the dishwasher. It can keep your detergent from working. How to choose and use the right detergent. First, use only powder or liquid detergent specifically made for use in dishwashers. Other types will cause oversudsing. Second, check the phosphate content. Phosphate helps prevent hard-water materials from forming spots or film on your dishes. If your water is hard (7 grains or more), your detergent has to work harder. Detergents with a higher phosphate level will probably work better. If the phosphate content is low (8.7~o or less), you’ll have to use extra detergent with hard water. Your water department can tell you how hard your water is. So can your county extension agent or your area’s water softener company. Just call and ask them how many “grains” of hardness is in your water. If you can’t find any rinse agent, How much detergent should you write: use? That de~ends. Is vour water
Benckiser Consumer
Products, Inc.
(“Jet Dry”)
411 W. Putnam Ave. Greenwich, CT 06830 / /’ “hard” or “sift”? Wi~h hard water, you need extra detergent to get dishes clean. With soft water, you need less detergent. Too much detergent with soft water not only wastes money, it can be harmful. It can cause a permanent cloudiness of glassware, called “etching.” An outside layer of glass is etched away! But why take a chance when it’s easy to find out the hardness of your water. Keep your detergent fresh and dry. Under the sink isn’t a good place to store detergent. Too much moisture. Don’t put powder detergent into the dispenser until you’re ready to wash dishes, either. (It won’t be fresh OR dry.) If your powder detergent gets old or lumpy, throw it away. Old detergent often won’t dissolve. If you use a liquid dishwasher detergent, these precautions are not necessary because liquid detergents don’t “lump” as they age or come in contact with water. 6
You’ll find two detergent dispensers on the inside door of your dishwasher. There are two because some cycles use two washes. See “Deter~ent Usage Guide” below. (Be ;ure the ~ycle Indicator Dial is at OFF position before adding detergent. Otherwise, the detergent cup will not close and latch properly.)
Grasp
Handle,
,/ “Rotate And /
Close Tightly /
[“ How to prepare the dishes for washing If this is your first dishwasher, or if you’re replacing a much older model, you may wonder how much preparation your dishes need. Actually very little. Pre-rinsing of norrnd food soils is not necessary. With common sense and a little practice you’ll soon know what foods to remove. Here are some guidelines:So~ Water
Medium Water
Hard Water
(O-3 grains hardness) (3-7 grains) (7-12 grains*)I
Cycles
Main Cup Open Cup Main Cup$ Open Cup* Main Cup$ Open Cup*L
Normal Wash
1 Tablespoon + 1 Tablespoon Half Full + Half Full Completely + Completely minimum minimum Full FullWater Saver
1 Tablespoon None Half Full None Completely None minimum Full r b kcE
Rinse& Hold
Use no detergent Use no detergent Use no detergentI*~
t *12 grains and up is extremely hard water. A water softener is recommended. Without it, lime can build up in the water valve. The water valve may stick while open and cause flooding.I~
$Filled Main Cup holds 3 tablespoons; Filled Open Cup holds 2 tablespoons. I h m 71
How to load your dishwasher How to load the TOP MCK This is a random mixed load, the most common type The top rack is best for glasses, cups and saucers. Cups you will have. and glasses fit best along the sides. This is the place for Make sure dishes are properly loaded to insure that dishwasher-safe plastics, too. Make sure small plastic water can reach the soiled surfaces. The wash arm in items are lodged in tightly so they can’t fall onto the the bottom sprays water up. The tower that rises in the CalrodOheating unit. Arrange stemware so that it cannot center sends water out over the dishes to wash the move easily. Don’t let the glasses touch each other. items in the upper rack. A spray arm in the top washes down. Make sure to place tall items to the outside so the upper wash arm is not blocked.
Watch Out For This.
This rack is ideal for dishwasher-safe plastics. When The wash tower rises through the center of the bottom loading, place plastic items along the back and be sure rack during the wash and rinse portions of the cycle. that each plastic tumbler is secured over two fingers. Don’t block it or load tall things next to it. Also, be This will prevent dislodging; tumbler will not fall careful not to let a ~ortion of an item such as a pot or through rack onto heating unit. dish handle extend’through the bottom rack. This could block the wash arm and cause poor washing results.
Sauce pans, mixing bowls and other small items may be placed—face down—in the top rack. The top rack is handy for all kinds of odd shapes. Load platters, pots, pans and bowls along the sides, in corners or in the back. All large items, such as pitchers salad bowls and mixing bowl;, should be washed in tht lower rack. How to load the BOTTOM WCK *. Fit plates and saucers between the pins. Place items so that water and detergent from wash arm can reach soiled surfaces. pans and racks along the edge. Put flatware in the removable basket with handles up to protect your hands. Mix knives, forks and spoons so they don’t nest together. Distribute evenly. Small plastic items, such as measuring spoons and lids from small containers are not recommended for automatic dishwashing. If placed in the dishwasher, they should go in the bottom of silverware basket with silverware on top. Precaution! Take out anything that may fall or extend through the bottom of the basket. Heavily soiled pots, puns and casseroles MUST be loaded in the bottom rack, facing down. Prop broiler
I
)m. (,
What you can usually wash safely in your dishwasher. And what you can’t. Usually Safe
Yes
Material Exceptions (not safe) Special Instructions Some colored anodized aluminum can Some darkening or spotting possible. Remove by fade. scouring with soap-filled steel wool pads. Aluminum Antique, metal-trimmed, hand-painted or over-the-glaze patterns fade. Gold leaf will discolor. If in doubt, check with the manufacturer. Or test wash one piece daily for at least a month. Compare with the rest of the set. ChintiStonewareYes
Yes
Antique, metal-trimmed or hand- painted patterns fade. Gold leaf will discolor. Crystal Load securely to prevent movement. Check manufacturer’s instructions for your crystal. Do not wash in dishwasher. Damage to dishwasher and discoloration or staining of dishwasher may result. Non-dishwasher items-such as electronic air cleaner filters, furnace filters, paint brushes, etc.No
Glass IronYes
No
Milk glass may yellow. Iron will rust. Pewter tarnishes. Pewter PlasticsNo
Yes
If it doesn’t say DISHWASHER SAFE, test one piece in the top rack before dishwashing an entire set. Wash in top rack only. Stainless steelYes
Rinse if not washing immediately. Salty or acid foods can stain if left on. Sterling Silver and Silver plate Don’t put in same silverware basket with stainless steel. Contact between metals can damage silver. Don’t wash copper utensils in the same load. Silver may get a brown film. Adhesive used to attach some hollow-handle knives can loosen. Rinse if not washing immediately. Salty or acid foods can stain if left on. Dry detergent can cause difficult-to- remove black spots. Place in back section of silverware basket to avoid exposure to detergent from the detergent cup.Yes
Yes
Non-stick coatingsI
After washing, wipe the non-stick coating area with vegetable oil to keep it from losing its non-stick quality. TinNo
I
Tin can rust. WoodNo
I
Wood can warp, crack or lose its finish with any type of washing. Forget a dish? Here’s when you can add it. Add dishes any time during the RINSE & HOLD cycle. With other wash cycles, you can add dishes at any time BEFORE the WASHING signal light goes off. However, opening the door during
= Questions? m Use Ttis Problem Solver
Problem
Dishwasher
Won’T Run
Unusual Noise
Dishes Don’T Dry
Unclean Dishes
And Flatware
Detergent Le~
In Dispenser Cups
Detergent Cup
Lid Won’T Latch
A~Er Adding
Detergent
Yellow Or
Brown Film
Possible Cause
A fuse in your home maybe blown, or the circuit breaker tripped. Replace fuse or reset circuit breaker. Remove any other appliances from the circuit. Utensils may not be secure on rack pins, or something small may have dropped from the rack. Water is causing utensils to rattle. Make sure everything is securely placed in dishwasher. Make sure inlet water temperature is correct. (See How To Test Water Temperature section.) Unload the bottom rack first. Water from dishes in the top rack maybe spilling into the bottom rack. Check for improper loading. Dishes shouldn’t nest together. Avoid overloading. Check the rinse agent dispenser to see that it’s not empty. Check inlet water temperature. It should be at least 120°F. (To test, see How To Test Water Temperature section,) Water pressure may be temporarily low. Turn on a faucet. Is water coming out slower than usual? If so, wait until pressure is normal before using your dishwasher. Plugged air gap. (See Care and Cleaning section.) Improper rack loading. (See Loading section.) Water may not be reaching the detergent cups. Move dishes that maybe blocking detergent cup. The dispenser cover may not be opening or may be blocked by improperly loaded items. If you used a powder detergent, open the cup and remove any caked-on detergent. If the cup still doesn’t open automatically, call for service. Detergent may be old. If the powder detergent is hard or caked in the box, throw it away. The detergent may not be working well. Try another brand. Cycle Indicator Did must be in OFF position for cup lid to close and latch proprly. If you unlatch the door and open it to dry your dishes, the Cycle Indicator Did does not advance to OFF by itself. Tea or coffee can stain cups. Remove the stain by hand, using a solution of 1/2 cup bleach and 3 cups warm water. An overall yellow or brown film on dishes or glassware can be caused by iron deposits in water. A special filter in the water supply line is the only way to correct this problem. Your water softener company can tell you about the filter. Yellow film on sterling silver results when you wash copper utensils in the same load. Silver polish will usually remove this stain. (~<~ntinued next page) 11
The Problem Solver (continued)
Problem
Spots And Filminc
On Glasses ~D
Flatware
Cloudiness On
Glassware
Chipping Of China
Possible Cause
Spotting can be caused by all these things: G Extremely hard water. (See How To Choose and Use Detergent section.) G Low inlet water temperature. (See How To Test Water Temperature section.) G Overloading the dishwasher. G Improper loading. (See Loading section.) G Old or damp powder detergent. G Phosphate level in detergent too low. (See How to Choose and Use Detergent section.) G Rinse agent dispenser empty. (See How To Use Rinse Agent section.) “ Too little detergent. (See How to Choose and Use Detergent section,) Local water conditions and personal preferences vary. Try several brands of detergents to find one that gives the best results for you. A liquid dishwasher detergent may help reduce filming. To remove stubborn spots and film from glassware:
Problem
Black Or Gray
Marks On Dishes
Small Amount Of
Water Standing
In The Bottom
Of The Tub
Water Won’T Pump
Out Of The Tub
Suds In The Tub
Dishwasher
Leaks
Motor Hums
Possible Cause
Aluminum utensils often leave marks when they rub against dishes. Remove marks with a mild abrasive cleanser. Water around the outlet on the tub bottom at the back of the tub is normal. [t is clean water. It’s there to keep the water seal lubricated. If the entire bottom of the tub has water, you may have a drain problem. Clean the air gap, if you have one. (See Care and Cleaning section.) Check the kitchen sink. Is it draining well? You may need a plumber. If dishwasher drains into disposer, run disposer to clear. Be sure disposer is not clogged. Sudsing detergents are not meant for dishwashers. USE ONLY AUTOMATICDishwasher Detergents To Avoid Sudsing.
To remove suds from the tub: Open the dishwasher. Let suds evaporate. Add 1 gallon of cold water to the tub. Close and latch the dishwasher. Pump out water by slowly turning the control dial until a drain period is reached. Repeat if necessary. Suds can cause unit to oveflow. That’s why it’s so important to use a detergent that’s designed for automatic dishwashers. Spilling the rinse agent can cause foam during washing. This can lead to overflowing. Wipe up accidental spill of rinse agent with a damp cloth. Dishwasher has not been used on a regular basis. If you do not use your dishwasher often, set it to fill and pump out once every week. This will help keep the seal moist, and the garbage disposer clear. If you need more help... call, toll free: GE Answer Center@ 800.626.2000 consumer information service 13
Care and Cleaning
User Maintenance
Instructions
Clean the control panel with a lightly dampened cloth. Dry thoroughly. Do not use abrasives or sharp objects on the panel. They can damage it. Clean the outside with a good appliance polish wax. The outside cabinet finish is durable, but it can scratch. So use no scouring pads, or harsh or gritty cleaners. Appliance Polish Wax & Cleaner (Cat. No. WR97X0216) is available from GE Appliance Parts Mart. The inside usually takes care of itself. If it should ever need cleaning, use a mild cleansing powder. Scouring pads and harsh cleaners can mar the finish. Built-in dishwashers often use an air gap. Keep it clean. An air gap is a plumbing device. It protects your dishwasher against water backing up into it if a drain clogs. The air gap is not a part of the dishwasher. And you may not even have one. Not all plumbing codes require air gaps. If you have an air gap, check it at least once a month. IT IS NOTPart Of Your Dishwasher.
It Is Not Covered In Your
Warranty.
The air gap is easy to clean. With most types, first turn off the dishwasher, then lift off the chrome cover. Then unscrew the plastic cap and check for any buildup of grit. A toothpick makes cleaning easy. Check the air gap any time your dishwasher isn’t draining well. Not using your dishwasher in winter? Protect against freezing. If your dishwasher is left in an unheated place during the winter, ask a service technician to: G Cut off electric power to the dishwasher. Remove fuses or trip circuit breaker. G Turn off the water supply. G Disconnect the water inlet line from the water valve. G Drain water from the inlet line and water valve. (Use a pan to catch the water.) G Reconnect the water inlet line to the water valve. G Remove the plastic pump cover in the tub bottom and use a sponge to soak up water in the rubber boot. How to change color panels If you are redecorating, you can How to change the door panel: A wood panel trim kit contains . -. . change your dishwasher’s door
Wdll Be There With the purchase of your new GE appliance, receive the assurance that if you ever need information or assistance from GE, we’ll be there. Ml you have to do is cdl—toll-free! GEAnswer Center@
F
800.626.2000 sMOs Whatever your question about any GE ~ major appliance, C~E Answer Cente@ In-Home Repak Service Contracts Service 8m-GE-cAREs (800--273fl AGE Consumer Service professional will provide expert repair service, scheduled at a time that’s convenient for you. Many GE Consumer Service company-operated locations offer you service today or tomorrow, or at your convenience (7:00 a.m. to 7:00 p.m. weekda~ 9:00 a.m. to 2:00 pm. Satur- days). Our factory-trained technicians know your appliance inside and out— so most repairs can be handed in just one visit. 800-626-=4 You can have the secure feeling that GE Consumer Service will still be there after your warranty expires. Pur- chase a GE contract while your war- ranty is still in effect and you’ll receive a substantial discount. With a multiple- year contract, you’re assured of future service at today’s prices. Patis andAccessories 800-626-2002 hdividuti qutied to service their o- appliances can have needed parts or accessories sent directty to their home, free of shipping charge! The GE parts system provides access to over 47,000 parts. ..and dl GE Genuine Renewal Parts are fully warranted. WSA, Maste~ard and Discover cards are accepted. User maintenance instictions contained in this boo~et cover proce- dures intended to he performed by any user. Other servicing genedy should be referred to qutiled ser- vice personnel. Caution must be exercised, since improper servicing may cause unsafe operation. inform~tion service is available to help. Your cat—and your question- will be answered promptiy and courteously And you can cdl any time. GE Answer Cente@ service is open 24 hours a day 7 days a week. “4 Telecommunication Device for the Deaf -— -. . . . ,., ----- -- .,.. . . . ..= - ..-—..s .., . For Customers Wfih SpecialNeeds... $ 800.626.2000 3 Upon request, GE will provide Braille controls for a variety of GE appliances, and a brochure to assist in planning a barrier-free kitchen for persons with limited mobility To obtain these items, free of charge, catl 800.626.2000. Consumers with impaired hearing or speech who have access to a TDD or a conventional teletypewriter may Cdl 800-TDD-GFAC (800-833-4322) to request information or service.
